Absolute Observations Training

1
Absolute Observations Training

• Bill Worthington
• June 10 12, 2008

2
Absolute measurements are not that hard to do,
but it takes work to do them well.
3
Outline

• Introduction, Background and Principles
• Absolute measurements, what are they and why do
  we need them?
• Introduction to DI-Flux
• Measurement Procedures
• Computation of Results

4
Description of Earths Magnetic Field

• D Declination Angle
• I Inclination Angle
• F Total Field
• H Horizontal
• Z Vertical

5
Geomagnetic Observations

• Measure the total field, F, which has both
  magnitude and direction and is time dependent.
• Horizontal reference plane, for Inclination
• True North meridian plane, for Declination
• F is measured with a nuclear resonance technique
  using the proton gyromagnetic ratio ?p2.6751525
  40 108 T-1 s-1

6
Declination Measurements
7
Inclination Measurement
8
Observatory Instrumentation

• 3-Axis fluxgate magnetometer
• Scalar magnetometer, proton or overhauser
• DI-Flux magnetometer
• Data collection computer

9
Absolute vs. Variation Instruments

• Absolute Instruments directly measure the
  strength of or the orientation of the magnetic
  vector.
• Variation or relative instruments, measures the
  deviation from an undetermined field. To
  determine the value of the undetermined field, it
  is necessary to make an absolute measurement.

10
Magnetometer Baselines

• Absolute measurements of I and F are used to
  compute absolute values of H and Z.
• The difference between the absolute values of H,
  D, Z and the H, D, Z output from the variations
  instrument is known as the baseline for each
  component.
• The baseline values are compiled and used to
  adopt a continuous baseline to correct the
  variations data to absolute values.

11
Example Baselines, CMO
12
Magnetometer Drift

• Variations instruments such as a fluxgate
  magnetometer can drift due to
• Temperature changes in the electronics and/or
  sensor
• Aging of components
• Pier drift magnetometer piers can slowly move
  with time introducing change in baselines
• Hence, baselines are not just used to correct the
  variation data but also to remove magnetometer
  drift.

13
DI-Flux Instrument

• Is used to measure the D and I angles
• Non-magnetic Theodolite
• Fluxgate Sensor
• Fluxgate Electronics

14
Non-magnetic Theodolite, Zeiss 020

• Telescope microscope
• Circles
• Sensor
• Circle clamps
• Slow motion controls
• Feet
• Mirror
• Pendulum

15
Reading the Microscope 020

• Vertical Scale
• Yellow background
• 256 52.2
• Horizontal Scale
• Blue background
• 235 05.0

16
Reading the Microscope (010)

• This instrument reads to 1 second and has a much
  different scale.
• The knob with the clamps allows one to switch
  between the horizontal and vertical circles.

17
DI-Flux Fluxgate

• Single axis sensor
• The fluxgate sensor orientation is very sensitive
  with respect to magnetic field direction. The
  highest sensitivity is when sensor magnetic axis
  and magnetic field are almost perpendicular
• Null reading when output is 0.0 Volts the
  magnetic vector is perpendicular to the sensor.
• The Sensor axis and the optical axis of telescope
  are aligned so they are parallel.

18
DI-Flux Electronics

• Digital display of output in Volts or nT. Few
  units use an analog meter anymore.
• The output in nT may need to be calibrated to use
  with the offset method.
• Usually battery operated
• May be slightly magnetic.

19
Measurement Procedure

• Preparation
• Leveling the Instrument
• Reading the Azimuth mark
• Leveling the telescope
• Four Declination readings
• Computation of the meridian
• Alignment to the meridian
• Four Inclination readings

20
Observation form

• Hand out

21
Absolutes Preparation

• Check magnetic field for disturbance level, at
  high latitudes this can be important.
• Remove all magnetic items from your person. This
  includes keys, coins, watches, knives, pens, and
  cell phones.
• Turn on the clock or set it as necessary.
• Check battery voltage of the DI-Flux electronics.
• Make sure instrument is properly placed and/or
  clamped on the pier.

22
Leveling the Theodolite

• 3 adjustable feet
• 2 axes of alignment
• Left hand rule
• Precision of level
• Need for clamps

23
Terminology and Cautions

• Descriptions of instrument positions refer to the
  direction the telescope is pointing (N, S, E, W)
  and whether the magnetometer sensor is up or
  down.
• Never handle the instrument by grabbing the
  magnetometer sensor.
• Leave your hands off the instrument when you are
  moving to a new position.
• Do not touch the optics.

24
Reading the Azimuth Mark

• The bearing to the Azimuth mark from the
  absolutes pier is a known bearing with respect to
  true north.
• The Azimuth measurements provide the reference
  for the angular measurements of Declination.
• The Azimuth mark is read in the Up and Down
  positions, before and after each set of
  Declination measurements.
• Make sure the telescope is properly focused on
  the mark or target.
• The alignment on the mark should be as precise as
  possible. Double check the alignment.

25
Reading the azimuth mark
26
Leveling the telescope

• Leveling the telescope to 90 or 270 is
  critically important to obtaining precise
  Declination measurements. If your instrument
  reads in grads, this would be 100 and 300.
• The alignment of the scales in the microscope
  should be done Exactly. Poor leveling is the
  most common problem when the D baselines are not
  repeatable.

27
Declination observations

• Declination is measured with four orientations.
  This is to average out any mis-alignment of the
  sensor and telescope.
• USGS uses the following orientations
• West Down
• East Down
• West Up
• East Up

28
Nulling and Timing for D

• Once the orientation is set, the magnetometer
  should be nulled or zeroed using the Horizontal
  Slow motion control.
• The null can be within 0.2 nT of zero.
• Once the magnetometer is nulled, the time and
  reading should be recorded.
• Typically the null is performed at the top of the
  minute, 10 seconds.
• It is important that the timing of the null is
  recorded correctly to compute the baselines.

29
Computing the magnetic meridian

• This is necessary to align the telescope in the
  H-Z plane for the Inclination measurements.
• The meridian is the average of the four angular
  measurements for D.
• One must be careful because the measurements are
  in degrees, minutes, and sometimes seconds.
• Most scientific calculators have buttons or
  functions to convert from degrees, minutes, and
  seconds to decimal degrees.

30
Computing the meridian (cont)

• First convert to Decimal degrees
• Add up Decimal Degrees
• Divide by 4
• Convert back to D, M, S
• Result is 184 50 33 and its reverse bearing 4
  50 33

31
Aligning the meridian

• To perform the inclination readings the
  Horizontal Circle must be aligned with the
  computed meridian.
• Using the example in the previous slide, rotate
  the instrument until the Horizontal Circle reads
  184 50 33.

32
Inclination observations

• Inclination is measured with four orientations.
  They are often referred to as plungings.
• USGS uses the following orientations
• South Down (SD)
• North Up (NU)
• Realign the horizontal circle to the reverse
  bearing of the meridian.
• South Up (SU)
• North Down (ND)

33
Nulling and Timing for I

• Once the orientation is set, the magnetometer
  should be nulled or zeroed using the Vertical
  Slow motion control.
• The null can be within 0.2 nT of zero.
• Once the magnetometer is nulled, the time and
  reading should be recorded.
• Typically the null is performed at the top of the
  minute, 10 seconds.
• It is important that the timing of the null is
  recorded correctly to compute the baselines.

34
Repeat the readings

• The measurement of D and I just described should
  be repeated 2-3 more times. The goal its to have
  at least three repeatable readings from one
  absolute session.

35
F measurements

• For the Declination and Inclination readings to
  be useful the total field or F needs to be
  measured at the same time as the observations.
• At some observatories, including the USGS, F is
  recorded along with variation recordings of H, D,
  Z. In this case the values of F are easily
  obtained.
• F must be corrected back to the Absolute pier.

36
Computation of Results

• Basic Formulas
• Absolute Values
• Baseline Values
• USGS Baseline Program

37
Computation of D

• Compute Meridian
• Compute the mean value of the Mark Readings.
• Mean Az (((MU1MD1)/2 (MU2MD2)/2)180)/2
• Subtract the Meridian from the Mark readings to
  get the Magnetic Azimuth
• Mag. Az Mean Az Meridian
• D True Az Mag. Az 180

38
Computation of I and H and Z

• I (((SD NU) (SU ND)) 360) / 4
• H F cos(I)
• Z F sin(I)
• F should be the average of F measured when the
  four inclination angles were measured. In
  addition the average F needs to be corrected to
  the Absolutes Pier.

39
Computation of Baseline Values

• The values of H, D, and Z, also called ordinates,
  recorded by the variometer are needed.
• The ordinate values used for each component
  should correspond to the same time that the
  measurements of D and I were performed.
• For example, the D ordinates should be for the
  same time D was observed and the H and Z
  ordinates should be at the same time I was
  observed.

40
Computation of H and Z Baseline Values

• The baseline value is the absolute value minus
  the ordinate value.
• For example
• Hbl HAbs HOrd .
• Zbl ZAbs ZOrd .

41
Computation of D Baseline Values

• The D baseline computation requires more care
  because the Absolute value of D is measured in
  Degrees and the D ordinate is usually recorded in
  nT.
• Need to convert D in nT to D in degrees or
  minutes
• Commonly the D scale value (Dsv) converts nT to
  minutes and is defined as
• (36060) / 2p / HAbs or 3437.747 / HAbs.
• Then Dbl DAbs ( DOrd Dsv)

42
Baseline Computations

• While it is possible to compute the absolute and
  baseline values by hand, it is much easier to
  make use of a spreadsheet or write a computer
  program to do the computations.
• During this course we will use a program that we
  developed to work with our data acquisition
  program. One feature of this program is that it
  has the capability to obtain the values of F and
  the H, D, and Z ordinates from the data
  collection computer.

43
Baseline Program
44
Baseline Program
45
Baseline Program

• The program works somewhat like a spreadsheet.
  There are open blocks where the measurements can
  be entered. With this program all that is needed
  to do is to enter the DI-Flux readings and the
  time of each reading. Once entered and double
  checked for accuracy, the Calculate button is
  clicked on. The sequence is repeated for each
  set.

46
Baseline Results

• On the far right of the program there is a tab
  labeled DCP Summary that displays the absolute
  values and baseline results for all observed
  sets.
• With this screen it is possible review and
  evaluate your results.

47
Baseline Summary
