PWB511 Creating Section 508 Compliant
Applications with PowerBuilder
Elke Sacher Senior Software Engineer Elke.Sacher_at_s
ybase.com August 15-19, 2004
2
The Enterprise. Unwired.
3
The Enterprise. Unwired.
Industry and Cross Platform Solutions
Unwire People
Unwire Information
Manage Information

• Adaptive Server Enterprise
• Adaptive Server Anywhere
• Sybase IQ
• Dynamic Archive
• Dynamic ODS
• Replication Server
• OpenSwitch
• Mirror Activator
• PowerDesigner
• Connectivity Options
• EAServer
• Industry Warehouse Studio

• Unwired Accelerator
• Unwired Orchestrator
• Unwired Toolkit
• Enterprise Portal
• Real Time Data Services

• SQL Anywhere Studio
• M-Business Anywhere
• Pylon Family (Mobile Email)
• Mobile Sales
• XcelleNet Frontline Solutions
• PocketBuilder
• PowerBuilder Family
• AvantGo

Sybase Workspace
4
Accessibility

• Accessibility Standards
• Section 508 of the Rehabilitation Act of 1973
• Software Applications Requirements (1194.21)
• Microsoft Active Accessibility Version 2.0
• PowerBuilder Accessibility
• PowerBuilder Accessibility Enhancements
• PowerBuilder and the Section 508 Provisions
• Demo of PowerBuilder Accessibility with Microsoft
  AccExplorer

5
Software Accessibility

• AccessibilityIs accomplished by designing
  software that accommodates the widest range of
  users.
• Other Standards
• ISO/TS 16071, ISO Accessibility Guide for
  Software Design
• W3C, Web Content Accessibility Guidelines

6
Assistive Technology

• Accessibility aidsHardware and software which
  adapts the user interface so the computer can be
  used by people with disabilities. Examples
• Screen Magnifier enlarges the screen like a
  magnifying glass.
• Screen Readers make on-screen information
  available as synthesized speech or a refreshable
  Braille display.
• Keyboard Enhancement Utilities allow the user to
  perform key sequences serially (e.g. Control-C).
• Speech Recognition enable people to control
  computers with their voice instead of a mouse or
  keyboard.

7
U.S. Accessibility Legislation

• Rehabilitation Act of 1973Protects employment
  rights of disabled individuals applying to and
  working for
• Federal agencies
• Businesses or institutions under federal contract

• Businesses or institutions receiving federal
  funds
• Section 508
• Amendment to the Rehabilitation Act
• Requirements for electronic and information
  technology
• http//www.section508.gov/
• 1194.21
• Specifies the requirements for software
  applications and operating systems.
• http//www.access-board.gov/sec508/guide/

8
Terms

• Access BoardIndependent U.S. Federal agency
  devoted to accessibility.
• AgencyAny Federal department or agency,
  including the United States Postal Service.
• Electronic and Information TechnologyInformation
  technology, as well as any equipment or
  interconnected system or subsystem of equipment,
  that is used in the creation, conversion, or
  duplication of data or information.
• Undue burdenUndue burden means significant
  difficulty or expense.

9
Section 508

• Amendment to the Rehabilitation Act
• Signed August 7, 1998
• Enforcement provisions of section 508 are
  effective as of June 21, 2001
• Federal departments and agencies
• Required to provide Federal employees with
  disabilities access to office systems and
  information equal to their non-disabled
  colleagues.
• Have to assure that people in the general public
  who have disabilities, have equal access to
  Government information.
• Unless an undue burden would be imposed on the
  agency.
• Accessibility has to be ensured for
• Development
• Procurement
• Maintanance
• Use of electronic and information technology.

10
Section 508 Technical Standards

• The Technical standards provide criteria specific
  to various types of technologies
• 1194.21 software applications and operating
  systems
• 1194.22 web-based information or applications
• 1194.23 telecommunication products
• 1194.24 video and multimedia products
• 1194.25 self contained, closed products (e.g.
  calculators, fax machines)
• 1194.26 desktop and portable computers

11
Section 508 Software Provisions

• Section 508 1194.21
• Requirements for Software applications and
  operating systems.
• Program features that must be contained in
  software for the product to meet the 508
  standard.
• (a) Keyboard Access
• (b) Accessibility Features
• (c) Input Focus
• (d) Object Information
• (e) Bitmap Images
• (f) Textual Information
• (g) User Selected Attributes
• (h) Animation
• (i) Color Coding
• (j) Color and Contrast Settings
• (k) Flashing or Blinking Text
• (l) Electronic Forms

12
Software Provisions a, b, c

• (a) Keyboard AccessAll actions that can be
  identified or labelled with text are required to
  be executable from a keyboard.
• (b) Accessibility FeaturesApplications shall not
  disrupt or disable activated features of
  operating systems or other products that are
  identified as accessibility features.
• (c) Input FocusA well-defined on-screen
  indication of the current focus shall be
  provided. The focus shall be programmatically
  exposed so that assistive technology can track
  focus and focus changes.

13
Software Provisions d, e, f

• (d) Object InformationSufficient information
  about a user interface element including the
  identity, operation and state of the element
  shall be available to assistive technology.When
  an image represents a program element, the
  information conveyed by the image must also be
  available in text.
• (e) Bitmap ImagesWhen bitmap images are used to
  identify controls, status indicators, or other
  programmatic elements, the meaning assigned to
  those images shall be consistent.
• (f) Textual InformationTextual information shall
  be provided through operating system functions
  for displaying text.

14
Software Provisions g, h, i

• (g) User Selected AttributesApplications shall
  not override user selected contrast and color
  selections and other individual display
  attributes.
• (h) AnimationWhen animation is displayed, the
  information shall be displayable in at least one
  non-animated presentation mode at the option of
  the user.
• (i) Color CodingColor coding shall not be used
  as the only means of conveying information.

15
Software Provisions j, k, l

• (j) Color and Contrast SettingsWhen a product
  permits a user to adjust color and contrast
  settings, a variety of color selections capable
  of producing a range of contrast levels shall be
  provided.
• (k) Flashing or Blinking TextSoftware shall not
  use flashing or blinking text, objects, or other
  elements having a flash or blink frequency
  greater than 2 Hz and lower than 55 Hz.Intended
  to prevent applications from inducing seizures
  by users prone to having them.
• (l) Electronic FormsWhen electronic forms are
  used, the form shall allow people using
  assistive technology to access the information,
  field elements, and functionality required for
  completion and submission of the form, including
  all directions and cues.

16
Windows Accessibility Parameters

• SystemParametersInfoApplications can check the
  state of an accessibility parameter to determine
  whether the user wants special behaviour.
• High contrastIndicates whether the user wants a
  high contrast between the colors used for
  foreground and background visuals.
• Keyboard PreferenceIndicates whether the user
  relies on the keyboard instead of the mouse.
• Screen ReaderWhen this flag is set, an
  application should provide textual information in
  situations where it would otherwise present the
  information graphically.
• ShowSoundsIndicates whether the user wants
  applications to present all important information
  in visual form.

17
Windows Accessibility Features

• AccessTimeout timeout interval after which
  system-wide accessibility features are
  automatically disabled.
• FilterKeys keyboard properties, such as
• Amount of time before a keystroke is accepted
• Amount of time before a keystroke repeats
• Sound feedback when a key is pressed
• Sound feedback when a key is accepted as input
• MouseKeys controls the mouse via numeric keypad.

• SerialKeys enables input using an input device
  attached to the computer's serial port.

18
Windows Accessibility Features Continued

• SoundSentryDisplays a visual signal when a sound
  is generated by a Win32-based application or an
  MS-DOS application running in a window.
• StickyKeysEnables the user to type key
  combinations, such as CTRLALTDEL, in sequence
  rather than at the same time.
• ToggleKeysProvides sound feedback when the user
  turns on or off the CAPS LOCK, NUM LOCK, or
  SCROLL LOCK keys.

19
Microsoft Active Accessibility

• MSAA Microsoft Windows Standard
• Current version MSAA 2.0.
• Based on the Component Object Model (COM).
• Assistive technology (accessibility aids, like
  screen readers) obtain information about user
  interface (UI) elements.
• Software programs (like PowerBuilder
  applications) expose information to assistive
  technology .
• OLEACC.DLL
• Provides the Active Accessibility runtime and
  manages requests from Active Accessibility
  clients.
• Ships as a standard system component of Microsoft
  Windows XP.
• MSAA 2.0 Redistributable can be installed or
  upgraded on earlier Windows platforms.

20
Microsoft Active Accessibility Requirements

• Adhere to Windows Guidelines for Accessible
  Software Design
• Expose relevant Accessibility properties
• Support Active Accessibitliy Navigation
• Support Active Accessibitliy Hit Testing
• Generate WinEvents

21
Accessible Software Design Guidelines

• Microsoft Windows "Optimized for Accessibility
• Support standard system size, color, font, and
  input settings
• Ensure compatibility with the High Contrast
  option
• Enable programmatic access to user interface
  elements and text
• Provide keyboard access to all features
• Expose the location of the keyboard focus
• Provide user-selectable equivalents for non-text
  elements
• Do not rely exclusively on sound to convey any
  information
• Avoid flashing elements
• Create accessible documentation about
  accessibility features

22
Accessibility Properties

• Microsoft Active Accessibility Object Properties
• Name
• Description
• Role
• KeyboardShortcut
• Parent
• Value
• State
• ChildCount
• Child
• DefaultAction

23
Microsoft Active Accessibility Requirements

• Support NavigationProvides accessibility clients
  with the ability to move through the Active
  Accessibility object hierarchy and dynamically
  discover what user interface (UI) elements and
  objects are available.
• Support Hit TestingFor accessibility clients to
  retrieve object information for a UI element at a
  given point on the screen.
• Generate WinEventsFor accessibility clients to
  react on, e.g. focus change of a control within a
  window.

24
PowerBuilder Accessibility

• As an MSAA server PowerBuilder exposes UI
  information in order to provide accessibility
  aids (MSAA clients) with standard programmatic
  access to its controls.
• Standard PowerBuilder controls, as inherited from
  Microsoft standard controls, did already expose
  default MSAA information. Certain properties can
  now be overridden.
• PowerBuilder DataWindow, as a custom control has
  been enhanced to support MSAA.

25
Accessibility Properties

• New Accessibility Properties of PowerBuilder
  Controls
• AccessibleName
• AccessibleDescription
• AccessibleRole
• Examplesle_1.AccessibleName ShopName
• Enumerated type AccessibleRole

26
PowerBuilder and Provision (a)

• Keyboard AccessAll actions that can be
  identified or labelled with text are required to
  be executable from a keyboard.
• PowerBuilder Navigation and Shortcut Settings
• Specifying the Tabordersle_1.Taborder 10
• Setting the Accelerator (shortcut)sle_1.Accelerat
  or ASC(F")
• Shortcuts for unlabelled controlscb_1.Text
  Save

27
PowerBuilder and Provision (b)

• Accessibility FeaturesApplications shall not
  disrupt or disable activated features of
  operating systems or other products that are
  identified as accessibility features.
• For example, using the color scheme set by the
  user cannot be changed and/or turned off without
  allowing the user the ability to reset to their
  defaults.
• In summary, if your application can change an
  operating system accessibility feature, you must
  provide an interface for the user to reset that
  feature.
• External Function SystemParametersInfoW
  PowerBuilder can retrieve the current Windows
  Accessibility settings by calling the external
  function, e.g. getting the sticky keys
  optionFUNCTION boolean SystemParametersInfoW(UI
  NT uiAction, UINT uiParam, ref stickykeys sk,
  UINT fWinIni) LIBRARY "USER32.dllret
  SystemParametersInfoW(GETSTICKYKEYS, ul_size, sk,
  0)

28
PowerBuilder and Provision (c)

• Input FocusA well-defined on-screen indication
  of the current focus shall be provided. The focus
  shall be programmatically exposed so that
  assistive technology can track focus and focus
  changes.
• Focus is set and programmatically exposed through
  Windows events when the user tabs, on mouse
  clicks, and/or accelerator keys, there is no
  explicit function required.
• PowerBuilder Focus Settings
• p_1.FocusRectangle TRUE
• p_1.SetFocus( )
• If the program specifically uses the SetFocus(
  )function, then the focus is automatically
  programmatically exposed and available
  toassistive technologies.

29
PowerBuilder and Provision (d)

• Object InformationSufficient information about a
  user interface element including the identity,
  operation and state of the element shall be
  available to assistive technology.When an image
  represents a program element, the information
  conveyed by the image must also be available in
  text.
• PowerBuilder PropertiesMost PowerBuilder
  controls areinherited from standard
  Windowscontrols, which supply default Active
  Accessibility support.
• AccessibleName
• AccessibleDescription
• AccessibleRole
• can be set explicitly.
• Examplep_1.AccessibleName Fish

30
PowerBuilder and Provision (d) Continued

• PowerBuilder Object Information
• Viewed with Microsoft AccExplorer

31
PowerBuilder and Provision (e)

• Bitmap ImagesWhen bitmap images are used to
  identify controls, status indicators, or other
  programmatic elements, the meaning assigned to
  those images shall be consistent.It is the
  developers responsibility to ensure that any
  image utilized in an application has a consistent
  meaning.
• PowerBuilder Image ControlsPicture,
  PictureButton, PictureHyperlink, PictureListBox
  etc. controls and supplies a customizable range
  of images that simplify consistent usage.
• Code Examplepb_1.PictureName
  "c\pictures\mypic.bmp"

32
PowerBuilder and Provision (f)

• Textual InformationTextual information shall be
  provided through operating system functions for
  displaying text.The minimum information that
  shall be made available is text content, text
  input caret location and text attributes.
• PowerBuilder Text provides a variety of controls
  that allow the display of text on the screen.
  Internally these controls use the standard
  Windows functions to display the text on the
  screen.
• mle_1.text Textual information shall be
  provided through operating system functions.
• mle_1.SetFocus()
• Sets system focus to a specific control
• Sets system caret

33
PowerBuilder and Provision (g)

• User Selected AttributesApplications shall not
  override user selected contrast and color
  selections and other individual display
  attributes.
• PowerBuilder User SettingsExampleApplication
  should be using the Windows system colors
  settings.Viewed in High Contrast Black

34
PowerBuilder and Provision (h)

• AnimationWhen animation is displayed, the
  information shall be displayable in at least one
  non-animated presentation mode at the option of
  the user.
• PowerBuilder Animation Control
• E.g. when using the animation control, the
  content of the displayed animations could also
  be described as plain text.

35
PowerBuilder and Provision (i)

• Color CodingShall not be used as the only means
  of conveying information, indicating an action,
  prompting a response, or distinguishing a visual
  element.
• PowerBuilder Color PropertiesCode Example, e.g.
  use several properties to highlight data items
  in a DataWindow
• dw_1.Object.quantity.Color "0tif ( quantity
  lt 5, rgb(255,0,0), rgb(0,0,0))
• dw_1.Object.quantity.Font.Weight "0tif (
  quantity lt 5, 700, 400)"
• dw_1.Object.quantity.Font.Underline "0tif (
  quantity lt 5, 1, 0)"
• dw_1.Object.quantity.Font.Height "0tif (
  quantity lt 5, -12, -10)"

36
PowerBuilder and Provision (j)

• Color and Contrast SettingsWhen a product
  permits a user to adjust color and contrast
  settings, a variety of color selections capable
  of producing a range of contrast levels shall be
  provided.
• PowerBuilderColor Selection DialogCode
  Examplelong ll_color// initialize to
  blackll_color 0// display color dialog
  ChooseColor(ll_color)

37
PowerBuilder and Provision (k)

• Flashing or Blinking TextSoftware shall not use
  flashing or blinking text, objects, or other
  elements having a flash or blink frequency
  greater than 2 Hz and lower than 55 Hz.Intended
  to prevent applications from inducing seizures by
  users prone to having them.
• PowerBuilder does not provide standard
  functionality for flashing and blinking.

38
PowerBuilder and Provision (l)

• Electronic FormsWhen electronic forms are used,
  the form shall allow people using assistive
  technology to access the information, field
  elements, and functionality required for
  completion and submission of the form, including
  all directions and cues.
• PowerBuilder ApplicationIf an application
  conforms to all other provisions discussed, then
  it will also conform to this.

39
PowerBuilder 508 Compliance

• Provide keyboard access for all actions.
• Make sure an application provides a visual focus
  indicator.
• Set AccessibleName property.
• Provide text through standard static text
  controls.
• Use Windows system colors.
• Use color as an enhancement, not as the only way
  to convey information or indicate an action.

40
Documentation and URLs

• http//www.access-board.gov/sec508/guide/
• http//www.section508.gov/IRSCourse/
• http//msdn.microsoft.com/library/default.asp?url
  /library/en-us/msaa/msaapndx_2a05.asp
• Appendix A Supported User Interface Elements
  Reference
• PowerBuilder Application TechniquesChapter 36
  Building Accessible Applications
• Accessible PowerBuilder Documentation is in the
  works
• Downloads (MSAA Redistributable and
  Tools)http//msdn.microsoft.com/library/default.a
  sp?URL/downloads/list/accessibility.asp

41
Questions
