Use of the spectrophotometer

1
Use of the spectrophotometer
2
Picture of the spectrophotometer
3
How to turn on the spectrophotomoter
Turn the button to 1 in the back of the machine
When warming up the spectrophotometer, there
should be no cuvettes in the machine
4
Place about 500 mL of sample into the cuvette
use enough sample so the light can pass through
Wipe cuvette with a kimwipe to remove fingerprints
5
Place cuvettes into the spectrophotometer

• There are 6 places put your blank in the space
  closest to you.
• Put the other samples in the next spaces.

6
Go to first screen and select photometricand
then enter
7
Then, enter your wavelengths

• Enter the number of wavelengths that you will use
  and the numbers of those wavelengths

8
Press sample control (F4)

• Enter the number of samples you have
• Make sure the blank says yes
• Then return to this screen by pressing previous
  screen

9
Go to the next screen by pressing F5
10
The screen with the different wavelengths should
come up
11
You should get readings close to zero for the
first sample which is the blank
12
Press read to get absorbance values for your
sample
If the cuvettes do not shift automatically,
adjust the cell number to read the different
samples
13
Record your values or press print to get a
printout

• If you have more than 5 samples, you will need to
  repeat the process
• Turn off the machine
