Use of the spectrophotometer

1
Use of the spectrophotometer
2
Transmittance

• As bacterial number increases, the culture
  becomes more dense and turbid
• Less light can pass through
• The transmittance decreases

3
We will measure transmittance with a
spectrophotometer
4
Turn the machine on and let it warm up for 15
minutes

• The on-off switch is in the back of the machine
• Press it to 1 to turn the machine on

5
The machine should flash BLA (blank) when it is
turned on
6
Then, it should read 0 T
7
Press the mode button to make sure you are
measuring T (transmittance) and not A
(absorbance)
8
This machine is NOT set correctly it is reading
A

• Press the mode button to change it to T

9
This is now correct the machine is reading T
10
Set the wavelength to 686
11
You will put your media or culture into the
cuvettes and then into the appropriate slot in
the machine
12
Close the compartment after you put your cuvette
in
13
Place control media (with no bacteria) into the
machine

• Set the machine to 100 transmittance
• Notice that the media is clear

14
Place your sample into the machine and read the
transmittance

• It should read less than 100T
• Notice that it is cloudier than the control media
  and there will be less transmittance

15
Readings

• As the culture becomes less dense (with increased
  dilutions), the readings should increase
