Heat Energy Transfer Lesson 4

1
(No Transcript)
2
Heat (Energy) TransferLesson 4

• Dan Hartung
• 2/22/08

3
The Nature of Heat

• Definition Heat is the internal kinetic energy
  of the atoms and molecules that make up a
  substance
• Since it is a form of energy, it is measured in
  the standard unit of a Joule
• 1 Joule 1Nm 1 kg m2/s2
• More commonly, it is measured in the following
  units
• calorie heat energy needed to raise 1 gram of
  water by 1 degree Celsius. 1 calorie 4.186
  Joules
• Calorie commonly used to measure energy content
  of food. 1 Calorie 1000 calories
• British Thermal Unit (BTU) heat energy needed
  to raise one pound of water by 1 degree
  Fahrenheit. 1 BTU 252 calories 1,054 Joules

4
Temperature

• Definition Temperature is the average speed or
  kinetic energy of the atoms and molecules in a
  substance
• Heat will not flow between two substances of the
  same temperature
• Heat is really energy in the process of being
  transferred from one object to another because of
  the temperature difference between them
• Temperature is measured
• by three different scales
• Celsius
• Fahrenheit
• Kelvin

5
Brad Pitt
Heidi Klum
HOT
HOT

Contrary to rumor NO HEAT TRANSFER !!!!!
6
Temperature

• Absolute Zero The lowest temperature possible
• Also signified as the temperature at which empty
  space is completely devoid of all motion and/or
  energy
• The coldest place in nature is the depths of
  outer space where temperatures are approximately
  3 degrees above absolute zero

7
Heat Capacity

• Definition Heat capacity is the amount of heat
  required per unit increase in temperature
• It is a measure of how well the substance stores
  heat
• H. C. (heat added) / (change in temperature)
• Materials with large heat capacities hold heat
  well.
• Their temperatures will not rise much for a given
  amount of heat
• Example water, air
• Materials with small heat capacities do not hold
  heat well
• Their temperatures will rise quickly for a given
  amount of heat
• Example copper, soil

8
Specific Heat Capacity

• Definition Specific heat capacity is the amount
  of energy required to raise the temperature of
  one kilogram (kg) of a substance by one degree
  Kelvin (K)
• It is a measure of heat capacity per unit mass
• Specific heat is measured in Joules per kilogram
  Kelvin
• J/(kgK)
• Substances with different specific heats require
  different amounts of energy
• Low specific heat Less input energy
• High specific heat High input energy

9
Specific Heat

• Q Amount of heat added to the substance (in
  calories)
• c specific heat
• for water c 4.18 J/g K, for air c 1.0 J/g K
• m mass of the substance (in grams)
• ?T change in temperature by the substance

10

• Example You add 12 calories of heat to 1 gram of
  air what is the temperature change?
• Q c x m x ?T
• ? ?T Q / (c x m)
• ?T 12 cal / (0.24 cal/g oC x 1 g)
• ?T 48oC
• So if the initial temperature of the air is 10oC,
  the final temperature is 58oC.

11
Heat Transfer

• There are three ways that heat may be transferred
  between substances at different temperatures
• Conduction
• Convection
• Radiation

12
Heat Transfer

• Conduction The flow of heat via collisions
  between atoms and molecules in a substance
• Collisions lead to faster molecules losing speed,
  and slower molecules gaining speed
• This results in the faster molecules transferring
  some of their kinetic energy to the slower
  molecules
• Thus, heat is always transferred from warmer to
  colder regions during conduction
• Solids, such as metals, are good conductors of
  heat
• Gases, such as air, are poor conductors of heat

13
Heat Transfer by Conduction
Fast (hot) atoms
Slow (cold) atoms
Common Temperature
http//theory.uwinnipeg.ca/mod_tech/img115.gif
14
Heat Transfer

• Convection The transfer of heat by the mass
  movement of a fluid (such as water and air)
• Takes place in fluids and gases
• Buoyant (warmer, less dense) blobs of air are
  called thermals
• Heat transported upward by rising thermals
• Cooler, heavier air flows to surface to replace
  rising air
• Horizontal heat transfer by fluid motions is
  called Advection

15
Heat Transfer by Convection
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Heat Transfer

• Radiation Energy transfer by electromagnetic
  (EM) waves
• Every object emits EM waves
• Wavelength depend on temperature of object
• Stefan-Boltzmann Law E (const) T4
• Hotter objects radiate a lot more energy (heat)
  per unit surface area
• Objects with a temperature of 500 degrees C or
  greater radiate at wavelengths we can seecooler
  objects radiate at wavelengths that are too long
  to stimulate vision
• Example hot red coals and a room-temperature
  book

22
Heat Transfer

• Radiation Shortwave vs. Longwave Radiation
• Hot objects emit radiation concentrated at
  shorter wavelengths
• Radiation from the sun is concentrated at much
  shorter wavelengths than radiation from the earth
• Sun vs. Earth
• Sun Shortwave radiation
• Earth Longwave radiation

23
Heat Transfer

• Radiation What happens to incoming solar
  radiation?
• Scattering Incoming radiation is deflected in
  all directions
• Reflection Incoming radiation is deflected
  like scattering, although more is sent backward
  (towards space)
• Albedo Amount of reflected radiation compared
  to the amount of incoming radiation

24
(No Transcript)
25
Typical Albedo of Various Surfaces
26
Summary
