Title: Harbours and Marinas


1
Harbours and Marinas
2
Siting
  • Good land transportation
  • Sheltered water
  • Natural harbour preferred
  • Breakwaters possible
  • Waves
  • Littoral drift sedimentation
  • Tides currents
  • Navigation
  • Cost

3
Waves
  • Small entrance
  • Big wave reduction
  • Difficult approach (esp. in heavy sea)
  • Align entrance at small angle to heaviest sea to
    improve ease of entry.
  • Wave height reduces with
  • Distance from entrance
  • Width parallel to shore
  • Wave absorbing devices parallel to waves

4
Predicting wave height
  • Use a model
  • Computer simulation
  • Physical model (allow for size effects)
  • Empirical method (Stevenson formula)
  • is the height of the reduced wave at the
    point being considered. H is height at entrance

b
D
B
5
Sedimentation occurs as a result of
  • Littoral drift direction can change with
    season.
  • Heavier particles accumulate on drift side of
    obstacles may extend to inside.
  • Fine particles deposited in marina where water
    velocities are lower.
  • Tidal movements
  • Material enters harbour as tide rises and is
    deposited at turn when water is slack (i.e.
    moving at low speeds).
  • Water in marina moves more slowly than out at sea
    carries less sediment.
  • Where marina or harbour is at mouth of river
  • material carried in river is deposited when
    river water slows down on meeting sea.
  • Complicated by differences in density between
    fresh water and salt.

6
Navigation
  • Channel size depth required depends on
  • Boat dimensions
  • Water flow parameters
  • Waves, velocity etc.
  • Boat speeds
  • Hydrodynamic effects
  • a) bows move apart
  • b) bow moves to other ship, stern moves away
  • c) stern moves to other ship, bow moves away

Hydrodynamic effects of two ships passing,
travelling in opposite directions
7
Oscillatory Waves
  • L wavelength
  • m.w.l. mean water level
  • Pa apparent path of water particle - trochoid
  • Pt true path of water particle - circle
  • T period of wave or time for particle to
    apparently travel distance L (or to truly travel
    circumference Pt)
  • V wave velocity (L/T)
  • H wave height

8
Translatory Waves
  • A wave will always break on a sloping shore when
    the water is shallow enough

9
Forces from wave impact -difficult to estimate.
  • The pressure, p, that a breaking wave applies to
    a vertical plane is
  • Difficult to predict wave velocity.
  • No simple relationship between wave velocity and
    wave height.
  • Waves break at vertical planes only when water is
    shallow.
  • Most waves at vertical planes are usually
    oscillatory, at least at high tide.
  • The height of an oscillatory wave at a vertical
    plane will double compared to deep sea.

? is density of water V is velocity of breaking
wave g is acceleration due to gravity
10
A Look at Floating Structures
  • http//www.shoresidemarinas.com/index.asp
  • http//www.shoresidemarinas.com/images/MoreProject
  • http//www.shoresidemarinas.com/images/MoreProject
  • http//www.shoresidemarinas.com/images/USCG_Monter
  • http//www.abcpm.co.uk/marina/
  • http//www.marinasolutions.com/build.htm
  • Video of floating breakwater
  • http//www.atlantic-meeco.com/Table_Rock.html

11
Motion of Floating Structures
  • Six degrees of freedom
  • Side to side ( or x)
  • Up and down ( or y)
  • Forwards and backwards ( or z)
  • Rotate about any of 3 axes.

y
x
z
12
Significance of pontoon size
  • Small compared to Wave

Large compared to Wave
13
Bending of Floating Structures Critical Loading
Arrangements
(a) Simply Supported Beam unit supported at
ends only
(b) Double Cantilever unit supported at centre
of gravity only
14
Anchorages of floating structures
  • Vertical loads carried by the water.
  • Horizontal loads transmitted to anchorages.
  • Should be designed to permit free vertical
    movement of pontoon.
  • Should allow for vertical movement of one end
    relative to the other in response to wave action.
  • Must avoid/cater for crabbing.
  • Must be inspected and maintained.
  • Consider consequences of each failure mode and
    try to ensure that structure is fail safe.

15
System must tolerate relative movement (e.g. from
(a) to (b))
(a)
(b)
16
Stresses in Floating Structures designed to
permit free vertical movement
  • Pressure from wave or vessel impact.
  • From units flexing
  • (a) Tensile stresses in bottom, compression in
    top of unit maximum at centre of span.
  • (b) Tensile stresses in top, compression in
    bottom of unit maximum over crest of wave.
  • Unit flexing across width of unit (into page)
  • Twisting of unit about vertical axis.
  • Combinations of the above
  • In anchorages resisting horizontal translation.

17
Piles
  • A pile is a column that is sunk into the ground.
  • It carries vertical load by a combination of
  • End bearing
  • Friction between the pile sides and the ground
  • It carries horizontal loads
  • By using raking piles
  • Single vertical pile
  • By bending and shear within the pile and by
    transmitting the torque and the sliding force
    into the ground the ground must be able to
    resist.
  • Remember - ground is weak near the surface.

18
Raking Piles most robust solution for piles
carrying horizontal loads
Ship moored at fixed wharf applies horizontal
force that is taken by raking piles.
19
Single piles under horizontal loads short rigid
pile ground failure
F
F
Centre of rotation
(a) Free head
(b) Fixed head
20
Single piles under horizontal loads long pile
pile failure
F
F
(a) Free head
(b) Fixed head
21
Effect of Large Deformation on Bending Moment
Secondary Effects
V
h
H
Deformed Bending Moment Hl Vh
L
l
Undeformed Bending Moment HL
column
Note structural analysis commonly assumes small
deformation.
Fixed Base
22
Material Selection
  • High Strength/Weight ratio.
  • High Strength/Cost ratio.
  • High Stiffness/Weight ratio.
  • High Stiffness/Cost ratio.
  • Durable under working conditions.
  • Water
  • Salt
  • Exposure
  • Attractive appearance.
  • Surface properties may be significant
  • Wear resistance
  • Frictional resistance

23
Rot or Decay of Timber
  • Fungus grows on timber feeding off the cell walls
    and destroying the structure of the timber.
  • Damage caused by mycelium, not by fruiting body
    wood looses strength stiffness.
  • Rot can be cubical spongy stringy etc.
  • Needs moisture to grow (above 20), can remain
    dormant for many months when dry.
  • Needs oxygen only grows above low water line.
  • Some timber naturally resistant.
  • Growth vigorous when warm (above 20oC).

24
Weathering of Timber
  • Weathering
  • Slow disintegration of timber as a result of
    exposure to elements.
  • Surface softens under effect of water.
  • Rapid drying causes surface splitting.
  • Surface forms small cubes sometimes. mistaken
    for dry rot.
  • One surface has disintegrated rot often set in.

25
Marine Borers and Timber
  • Technically not insects.
  • Teredo, or ship, worm best known.
  • Much more severe in tropical climes than in
    temperate zones.
  • Greenheart billian have natural resistance
    (greenheart is poisonous so watch out for
    splinters).
  • Preservatives available consider environmental
    effects but casing in Muntz metal (a brass
    copper zinc) or studding with nails probably
    more cost effective.

26
Metal choose one developed for a marine
environment
  • Mostly alloys of copper, nickel and austenitic
    steel.
  • Copper-nickel alloys commonly have 10, (ship
    hulls) 30 (for pipes) 70 nickel (fasteners,
    propeller pump shafts) with traces of other
    metals.
  • Austenitic stainless steel contains nickel and
    (especially when used with trace alloys) performs
    well in marine environments
  • http//www.stainless-steel-world.net/pdf/10011.pdf
  • Aluminium is good, and getting cheaper.
    http//www.eaa.net/home.jsp?content/transportatio
    n/marine.htm
  • Titanium is good but very expensive.
  • Often metals are protected by painting
    (specialist paints available), galvanising, epoxy
    coating etc.

27
Concrete
  • Need dense, high quality concrete.
  • Good curing (control of setting) important.
  • Correct moisture content during setting
  • Correct temperature
  • Control of cracking
  • Small diameter, closely spaced reinforcement
  • Often pre-cast, pre-stressed concrete provides
    the best solution
  • Presence of chlorides and sulphates in sea water
    means you need a special mix.

28
Harsh Environment
  • The marine environment is very harsh
  • Storm dependant loads
  • Corrosive atmosphere
  • Dangerous working conditions
  • Fragile ecosystem
  • Many valuable resources yielding high rewards

29
Any Questions?
