Title: Physics 106P: Lecture 1 Notes


1
Acoustic Impedance Measurements
Presented by Brendan Sullivan June 23, 2008
2
Agenda for Today
  • What acoustic impedance is and why we are
    interested in it
  • Physical interpretations of acoustic impedance
  • Notes on an instrument
  • Electrical circuits
  • How to measure acoustic impedance
  • First, in General
  • Mainly, in a trumpet
  • Phase Sensitive
  • Results
  • No general theory, but some interesting data
  • Future Plans

3
What is Acoustic Impedance?
Air Pressure
P(x) U(x)
Z(x)
Specific Acoustic Impedance
Longitudinal Particle Velocity
Units are Acoustical Ohms (Pa-s/m), or ? for
short.
4
What Really is Acoustic Impedance?
Take a look at this typical impedance spectrum
  • Blue lines (maxima) are accessible frequencies
  • Red lines (minima) are inaccessible frequencies
  • The first peak is the fundamental
  • Subsequent peaks are harmonics
  • Harmonics decrease in amplitude just as in the
    overtones of an instrument

Image modified from J. Backus, J. Acoust. Soc.
Am. 54, 470 (54)?
5
Ohms? Impedance? This sounds like a circuit...
  • ...because it is!
  • Any acoustical system creates an acoustical
    circuit
  • Parts of the acoustical system behave exactly
    like the components of a circuit

The Circuit Components
Zi Mouthpiece input impedance Z Mouthpiece
output Impedance L The inductance, or the area
between the cup and tube R, C Values determined
by geometry of mouthpiece
Image modified from J. Backus, J. Acoust. Soc.
Am. 54, 470 (54)?
6
How Do We Measure Impedance?
Pressure Microphone
P(x) U(x)
Z(x)
Time-Integrated Differential Pressure Microphone
  • Two quantities to measure pressure (P) and
    particle velocity (U)?
  • For pressure, we use a pressure microphone
  • For particle velocity, we use a (time-integrated)
    differential pressure microphone

7
How the Microphones Work Electret Condenser
Microphone (P-mic)?
d
Condenser microphone schematic
V E d
  • Pressure (sound) waves press against front plate,
    changing d, thereby inducing a voltage
  • Assuming elastic particle-plate collisions,
    conservation of momentum ensures induced voltage
    is linear in pressure

8
How the Microphones Work Fix this Differential
Pressure Microphone (DPM)?
Differential pressure microphone schematic
  • Measures the pressure immediately to the right
    and left of a particular location
  • Numerically integrates to find the pressure at
    that location

9
Placing the Microphones in a Trumpet
  • The openness of the trumpet bell makes mounting
    the exit microphones easy
  • Microphones can be secured outside the trumpet
    and simply placed in
  • Wiring can also be done externally

A trumpet bell - notice the large, accessible
geometry
Schematic of the bell the mics easily fit in
the bell and can be wired/secured externally
10
Placing the Microphones in a Trumpet
  • Mouthpiece is much narrower than the bell
  • Harder to use microphones
  • Drill tiny holes in mouthpiece to run
    wires/brackets through
  • As tiny as possible so as not to change the
    instrument
  • Can't just run directly out of the mouthpiece
    because the path is blocked by a transducer...

Schematic of the mouthpiece notice that the
wires run through small holes in the mouthpiece
11
Exciting the Trumpet
  • A player's lips resonate at a specific frequency
  • Excites the instrument with nearly monochromatic
    sound wave
  • Using a function generator, drive the transducer
    at a specific frequency
  • Much like a piston
  • Closely recreates an actual player
  • Some aspects still not reproducible yet, i.e.,
    humidity

Schematic of the mouthpiece The transducer has a
position that goes as x(t) A sin(? t)?
12
Adding Complexion to the Measurement Lock-in
Amplifiers
  • We want this to be a phase-sensitive measurement
  • We can do this using a lock-in amplifier
  • How lock-in amplifiers work
  • Pick out any components of the desired
    frequency in this case, the function generator's
    frequency
  • Resolve vector into real (in phase) and
    imaginary (perfectly out of phase) parts
  • Record the real and imaginary values separately

A phasor diagram The lock-in amplifier will pick
out the blue vector and resolve it into its real
(red) and imaginary (green)? components.
13
An overview of the setup each microphone is
connected to a lock-in amplifier which is
recorded on a computer. The spectrum is obtained
by sweeping a frequency range.
14
Above A picture of the trumpet with
measurements being taken. The four closed
boxes are the microphones and the open box is
the piezo driver Left A picture of the
measurement setup.
15
Results An Overview
  • First time a phase-sensitive measurement of this
    sort has been made
  • No general theory can explain all the data
  • Even for non-phase sensitive, theory is
    inaccurate
  • Imaginary component very small compared to real
    component
  • Like a correction factor

16
Pressure vs. Frequency
  • Magnitude of output is much less than real
    (output is even amplified 10x)?
  • Output component switches sign each harmonic
  • Output part generally increasing, real part
    increases then decreases
  • Higher notes seem louder

A plot of input (blue) and output (pink)
pressure versus frequency
17
Pressure Phase vs. Frequency
  • Output is mostly noise below 250 Hz
  • Distinct Patterns
  • Output like tan(f)?
  • Input has defined peaks and troughs
  • Period increases with frequency
  • Indicative that something cyclical is happening
    with phase difference

A plot of output (blue) and input (pink) phase
difference versus frequency
18
Pressure in the Complex Plane
  • Different way to look at the last plot the
    elliptical nature of the plots indicates the
    repeating phase shift
  • Bigger loops correspond to higher frequencies
  • No 'deeper' interpretation of this data
  • No general theory, yet

A parametric plot of output (blue) and input
(pink) pressure in the complex plane
19
Complex Acoustic Impedance
  • Distinct peaks and troughs on input we noted
    earlier
  • Output is nearly linear (three separate lines,
    perhaps)?
  • Relates to structure of musical notes, but we
    won't go into that
  • Can only access the output frequencies at input
    peaks

A plot of output (blue) and input (pink)
impedance versus frequency
20
How the Notes Line Up
  • Each data point is the frequency of output at an
    input impedance peak (e.g., C4 Middle C
    261.626 Hz)?
  • Very small deviations from accepted notes
  • Since measurement errors on experiment were 5,
    these notes clearly coincide with accepted notes

21
Looking Ahead
  • This summer, same experiment for an Oboe and
    Clarinet
  • Much smaller instruments make it harder
  • These instruments use reeds, not metal
    mouthpieces
  • Data may help with a more general theory

Above Clarinet mouthpiece Left Oboe reed and
top of mouthpiece
22
Recap
  • Acoustic Impedance is defined as pressure over
    particle velocity
  • Relates to the accessible sounds an object can
    make
  • Measured using a DPM and U-mic
  • No general theory yet, though some interesting
    data

23
Special Thanks to David Pignotti, Professor
Errede, and all of you!
Questions?
