SpeechtoSpeech MT in the JANUS System

1
Speech-to-Speech MT in the JANUS System

• Lori Levin and Alon Lavie
• Language Technologies Institute
• Carnegie Mellon University

2
Outline

• Design and Engineering of the JANUS/C-STAR
  speech-to-speech MT system
• Fundamentals of our approach
• System overview
• Engineering a multi-domain system
• The C-STAR Travel Domain Interlingua (IF)
• Evaluation and User Studies
• Conclusions, Current and Future Research

3
JANUS Speech Translation

• Translation via an interlingua representation
• Main translation engine is rule-based
• Semantic grammars
• Modular grammar design
• System engineered for multiple domains
• Incorporate alternative translation engines

4
Multilingual Interlingual Machine Translation

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

5
Advantages of Interlingua

• Avoid the n-sqared problem for all-ways
  translation.
• Mono-lingual grammar development teams.
• Add a new language easily and automatically get
  all-ways translation to all previous languages.

6
The C-STAR Travel Planning Domain

• General Scenario
• Dialogue between one traveler and one or more
  travel agents
• Focus on making travel arrangements for a
  personal leisure trip (not business)
• Free spontaneous speech

7
The C-STAR Travel Planning Domain

• Natural breakdown into several sub-domains
• Hotel Information and Reservation
• Transportation Information and Reservation
• Information about Sights and Events
• General Travel Information
• Cross Domain

8
A Travel DialogueTranslated from Italian

• A Albergo Gabbia DOro. Good evening.
• B My name is Anna Maria DeGasperi. Im calling
  from Rome. I wish to book two single rooms.
• A Yes.
• B From Monday to Friday the 18th, Im sorry, to
  Monday the 21st.
• A Friday the 18th of June.
• B The 18th of July. Im sorry.
• A Friday the 18th of July to, you were saying,
  Sunday.
• B No. Through Monday the 21st.

9
A Travel Dialogue(Continued)

• B So with departure on Tuesday the 22nd.
• A Then leaving on the 22nd. Yes. We have two
  singles certainly.
• B Yes.
• A Would you like breakfast?
• B Is it possible to have all meals?
• A No. We serve meals only in the evening.
• B Ok. If you can do breakfast and dinner.
• A Ok.
• B Do you need a deposit?

10
A Travel Dialogue(Continued)

• A You can give me your credit card number.
• B Ok. Just a moment. Ok. My name is Anna
  Maria DeGaperi. The card is 005792005792.
• A Good.
• B Expiration 2002.
• A 2002. Good. Thank you. We need a
  confirmation on the 18th of July before 6pm.
• B Goodbye.
• A Thanks. Goodbye.
• B Thanks. Goodbye.

11
A Non-Task-Oriented Dialogue(We cant translate
this.)

• A Are you cooking?
• B My father is cooking. Im cleaning. I just
  finished cleaning the bathroom.
• A Look. What do you know about Monica?
• B I dont know anything. Look. I dont know
  anything.
• A You dont know anything? I wrote her three
  weeks ago, but if she hasnt received the letter,
  they would have returned it. I hope she received
  it.
• B Because Celia told me that the address that
  Monica had given us was wrong. She said that if
  I was going to write to her, well, .

12
Semantic Grammars

• Describe structure of semantic concepts instead
  of syntactic constituency of phrases
• Well suited for task-oriented dialogue containing
  many fixed expressions
• Appropriate for spoken language - often disfluent
  and syntactically ill-formed
• Faster to develop reasonable coverage for limited
  domains

13
Semantic Grammars

• Hotel Reservation Example
• Input we have two hotels available
• Parse Tree
• give-informationavailabilityhotel
• (we have hotel-type
• (quantity (two)
• hotel (hotels)
• available)

14
The JANUS-III Translation System
15
The JANUS-III Translation System
16
The SOUP Parser

• Specifically designed to parse spoken language
  using domain-specific semantic grammars
• Robust - can skip over disfluencies in input
• Stochastic - probabilistic CFG encoded as a
  collection of RTNs with arc probabilities
• Top-Down - parses from top-level concepts of the
  grammar down to matching of terminals
• Chart-based - dynamic matrix of parse DAGs
  indexed by start and end positions and head cat

17
The SOUP Parser

• Supports parsing with large multiple domain
  grammars
• Produces a lattice of parse analyses headed by
  top-level concepts
• Disambiguation heuristics rank the analyses in
  the parse lattice and select a single best path
  through the lattice
• Graphical grammar editor

18
SOUP Disambiguation Heuristics

• Maximize coverage (of input)
• Minimize number of parse trees (fragmentation)
• Minimize number of parse tree nodes
• Minimize the number of wild-card matches
• Maximize the probability of parse trees
• Find sequence of domain tags with maximal
  probability given the input words P(TW), where
  T t1,t2,,tn is a sequence of domain tags

19
Modular Grammar Design

• Grammar development separated into modules
  corresponding to sub-domains (Hotel,
  Transportation, Sights, General Travel, Cross
  Domain)
• Shared core grammar for lower-level concepts that
  are common to the various sub-domains (e.g.
  times, prices)
• Grammars can be developed independently (using
  shared core grammar)
• Shared and Cross-Domain grammars significantly
  reduce effort in expanding to new domains
• Separate grammar modules facilitate associating
  parses with domain tags - useful for multi-domain
  integration within the parser

20
Translation with Multiple Domain Grammars
21
Analysis with Multiple Domain Grammars

• Parser is loaded with all domain grammars
• Domain tag attached to grammar rules of each
  domain
• Previously developed grammars for other domains
  can also be incorporated
• Parser creates a parse lattice consisting of
  multiple analyses of the input into sequences of
  top-level domain concepts
• Parser disambiguation heuristics rank the
  analyses in the parse lattice and select a single
  best sequence of concepts

22
A SOUP Parse Lattice
23
Alternative Analysis Approach SALT

• SALT - Statistical Analyzer for Lang. Translation
• Combines ML trainable and rule-based analysis
  methods for robustness and portability
• Rule-based parsing restricted to well-defined set
  of argument-level phrases and fragments
• Trainable classifiers (NN, Decision Trees, etc.)
  used to derive the DA (speech-act and concepts)
  from the sequence of argument concepts.
• Phrase-level grammars are more robust and
  portable to new domains

24
SALT Approach

• Example
• Input we have two hotels available
• Arg-SOUP exist hotel-type
  available
• SA-Predictor give-information
• Concept-Predictor availabilityhotel
• Predictors using SOUP argument concepts and input
  words
• Preliminary results are encouraging

25
Design Criteria of the Interchange Format

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• Suitable for task oriented dialogue
• Based on speakers intent, not literal meaning
• Domain independent framework with domain-specific
  parts
• Simple and reliable enough to use
• at multiple research sites.

• with widely varying type of parsers and
  generators

26
Domain Actions Extended, Domain-Specific Speech
Acts

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• Examples
• crequest-informationavailabilityroom
• agive-informationpersonal-data
• cgive-informationtemporalarrival

27
Task Oriented Sentences

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• Perform an action in the domain.
• Are not descriptive.
• Contain fixed expressions that cannot be
  translated literally.

28
Components of the Interchange Format

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• speaker a (agent)
• speech act give-information
• concept availabilityroom
• argument (room-type(single double),

• timemd12)

29
Examples

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• no thats not necessary
• cnegate
• yes I am
• caffirm
• and I was wondering what you have in the way of
  rooms available during that time
• crequest-informationavailabilityroom
• my name is alex waibel
• cgive-informationpersonal-data
  (person-name(given-namealex, family-namewaibel)
  )
• and how will you be paying for this
• arequest-informationpayment (methodquestion)
• I have a mastercard
• cgive-informationpayment (methodmastercard)

30
Speaker Tag
Client says Do you take credit cards?
crequest-informationpayment (methodcredit-card)
Agent says Will you be paying with a credit
card? arequest-informationpayment
(methodcredit-card)
31
Size of IF

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

• May 1999
• Speech acts 54
• Concepts 84
• Arguments 118

32
Speech Acts

• accept
• acknowledge
• acknowledge-action
• affirm
• affirm-action
• apologize
• closing
• delay-action
• end-action
• give-certainty
• give-information

• Ill take that, Sounds good
• Okay, Sure, Yeah
• Here you go, This is it
• Yes, That is correct
• Yes, please do, Go ahead
• Sorry, Im sorry
• Bye, See you next week
• Ill get back to you on that
• Thats all for now
• Im sure
• I have 2 singles available

33
Speech Acts

• greeting
• greeting-nice-meet
• greeting-request
• greeting-response-bad
• greeting-response-good
• greeting-welcome
• introduce-self
• introduce-topic
• negate
• negate-action
• not-understand

• Hello, Good morning
• Nice to meet you
• How are you
• Im not good
• Im fine
• Welcome to Pittsburgh
• This is Brian, Best Western
• About that flight
• No
• No, dont
• I dont understand

34
Speech Acts

• offer
• offer-information
• offer-repeat
• please-wait
• reject (e.g., offer)
• request-action
• request-affirmation
• request-certainty
• request-delay-action
• request-information
• request-introduce-self

• How about it?
• Let me get you the information
• Let me repeat that
• Just a minute, Let me see
• No, I dont want that
• Can you reserve that for me?
• Is that correct?
• Are you sure?
• Can I get back to you later?
• Do you accept visa?
• Who am I speaking with?

35
Speech Acts

• request-knowledge
• request-neg-affirmation
• request-repeat
• request-suggestion
• request-verification
• return-from-delay
• suggest
• thank
• verify
• welcome
• x-exclamation

• Do you know?
• Is that bad?
• Could you repeat that?
• Which hotel should I get?
• Right?, That was 40 dollars?
• Im back
• How about a single?
• Thank you very much
• Yes, that is 40 dollars.
• Youre welcome
• That is beautiful! (ETRI only)

36
Meta-Demo Speech acts

• testing
• testing-problem
• testing-start
• testing-stop
• testing-proceed
• testing-request-proceed
• testing-ready
• testing-present
• testing-request-present

• Testing 1 2 3, This is a test
• We have a problem
• Lets start
• Lets stop
• Go ahead!
• Would you go first
• Ready here
• We are here, CMU is on line
• Are you there?

37
Some Concepts

• Actions change, reservation, confirmation,
  cancellation, help, purchase, view, display,
  preference
• Attributes availability, price, temporal, price,
  location, size, features etc.
• Objects room, hotel, flight, tour, event,
  attraction, web-page etc.
• Other arrival, departure, numeral,
  expiration-date, payment

38
Using Concepts to Represent Information Focus
Is there a hotel in Pittsburgh? crequest-informat
ionavailabilityhotel (locationpittsburgh)
Is the hotel in Pittsburgh? crequest-information
locationhotel (locationpittsburgh)
39
Topic vs Focus
The Hilton Hotel is in Verona. agive-information
locationhotel (hotel-namehilton,
locationverona)
The hotel in Verona is the Hilton Hotel.
agive-informationlocationhotel
(hotel-namehilton, locationverona)
40
The Interchange Format Database
d.u.sdu olang X lang Y Prv Z
sdu-in-language-Y on one line d.u.sdu olang X
lang E Prv Z sdu-in-English on one
line d.u.sdu IF Prv Z
dialogue-act-on-one-line d.u.asdu comments
your comments d.u.asdu comments go here
61.2.3 olang I lang I Prv IRST telefono per
prenotare delle stanze per quattro
colleghi 61.2.3 olang I lang E Prv IRST Im
calling to book some rooms for four
colleagues 61.2.3 IF Prv
IRST crequest-actionreservationfeaturesroom
(for-whom (associate,
quantity4)) 61.2.3 comments dial-oo5-spkB-roca0
-02-3
41
The Interchange Format Database
English Dialogues English Sentences Korean
Dialogues Korean Sentences Italian
Dialogues Italian Sentences Japanese
Dialogues Japanese Utterances Distinct Dialogue
Acts
36 2466 70 1142 5 233 124 5887 554 (310 agent,
244 client)
42
Phenomena Not Covered

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

Anaphora
Comparative Constructions
Scope (negation and modifiers)
Relative Clauses
Plurality
Descriptive Sentences
43
Expressivity vs Simplicity

• If it is not expressive enough, components of
  meaning will be lost.
• If it is not simple enough, it cant be used
  reliably across sites.

44
Coverage

• The database includes about 550 distinct dialogue
  acts.
• About 60 dialogue acts cover about 70 of the
  data.
• About 5 of unseen data wasnt covered (as
  judged by human experts)

45
Consistency of Use Across Sites

• Successful international demo.
• After testing English-Italian and English-Korean,
  Italian-Korean worked without extra effort.
• Inter-coder agreement for each component of IF
  individually (speech acts, concepts, arguments)
  around 85
• Cross-site evaluation same as intra-site
  evaluation 60 spoken 75 transcribed.

46
User Studies

• We conducted three sets of user tests
• Travel agent played by experienced system user
• Traveler is played by a novice and given five
  minutes of instruction
• Traveler is given a general scenario - e.g., plan
  a trip to Heidelberg
• Communication only via ST system, multi-modal
  interface and muted video connection
• Data collected used for system evaluation, error
  analysis and then grammar development

47
Evaluations

• Accuracy Based Evaluation
• Translation preserves original meaning
• Task Based Evaluation
• goal success or failure
• user effort how many attempts before succeeding
  or giving up

48
Accuracy Based Evaluation

• End-to-end evaluations conducted at the SDU
  (sentence) level
• Multiple bilingual graders compare the input with
  translated output and assign a grade of Perfect,
  OK or Bad
• OK meaning of SDU comes across
• Perfect OK fluent output
• Bad translation incomplete or incorrect

49
Task Based Evaluation

• I would like to reserve 1s a single room 2f
• request-actionreservationhotel
  (room-typesingle)
• Translation
• I would like to reserve a seating room.

50
Task Based Evaluation

• Scoring Scheme
• For goals that succeed 1/n
• For goals that fail -(1-1/n)
• where n is the number of attempts
• Overall score average for all goals

51
August-99 Evaluation

• Data from latest user study - traveler planning a
  trip to Japan
• 132 utterances containing one or more SDUs, from
  six different users
• SR word error rate 14.7
• 40.2 of utterances contain recognition error(s)

52
Accuracy and Task Based Evaluations
53
Accuracy Based Evaluation
54
Evaluation - Progress Over Time
55
Current and Future Work

• Expanding the travel domain covering descriptive
  as well as task-oriented sentences
• Development of the SALT statistical approach and
  expanding it to other domains
• Full integration of multiple MT approaches SOUP,
  SALT, Pangloss
• Disambiguation improved sentence-level
  disambiguation applying discourse contextual
  information for disambiguation

56
Conclusions

• We started skeptically with tools that we thought
  were too simple context-free parser, semantic
  grammar, interlingua based on domain actions.
• We were surprised that they worked adequately for
  some types of task oriented dialogue.
• We improved portability.
• We are now working on embedding the simple
  task-oriented system into a more complete
  system.

57
The JANUS/C-STAR Team

• Project Leaders
• Lori Levin, Alon Lavie, Monika Woszczyna, Alex
  Waibel
• Grammar and Component Developers
• Donna Gates, Dorcas Wallace, Taro Watanabe,
• Boris Bartlog, Ariadna Font-Llitjos, Marsal
  Gavalda,
• Chad Langley, Marcus Munk, Klaus Ries, Klaus
  Zechner,
• Detlef Koll, Michael Finke, Eric Carraux, Celine
  Morel,
• Alexandra Slavkovic, Susie Burger, Laura
  Tomokiyo,
• Takashi Tomokiyo, Kavita Thomas, Mirella Lapata,
• Matthew Broadhead, Cortis Clark, Christie Watson,
• Daniella Mueller, Sondra Ahlen
