Support for trees and nodes

1
Support for trees and nodes
2
Assessing phylogenetic hypothesis

• We should not be content with constructing
  phylogenetic hypothesis but should also assess
  what confidence we can place in our hypothesis

3
Assigning confidence intervals to phylogenies

• Resampling methods
• bootstrap (non parametric)
• jackknife
• Other methods
• decay analyses (only MP)
• posterior probability (ML bayesian)

4
Assigning confidence intervals to phylogenies

• The sampling error
• we use samples in our studies
• the values stimated from a sample of a population
  will be more or less close to the real value but
  rarely they will coincide
• A way of calculating the sampling error is taking
  multiple samples from the population and
  comparing the estimations obtained for each of
  them.

5
(No Transcript)
6
(No Transcript)
7
Bootstrapping

• The frecuency with which a certain group appears
  is a measure of the goodness of that group
• These values are shown in a consensus tree and
  some additional information is given on a table

8
Bootstrapping
Pseudorreplicate-1
Original matrix

Characters Taxa 1 2 2 2 5 5 8 8 A
R R R R Y Y Y Y B R R R R Y Y Y Y C
Y Y Y Y Y Y R R D Y Y Y Y R R R R Outgroup
R R R R R R R R
Characters Taxa 1 2 3 4 5 6 7 8 A
R R Y Y Y Y Y Y B R R Y Y Y Y Y Y C
Y Y Y Y Y R R R D Y Y R R R R R R Outgroup
R R R R R R R R
Pseudorreplicate-2
The pseudoreplicates are obtained from the
original matrix with replacement to built a new
matrix of the same size than the original one.
Characters Taxa 3 3 4 4 5 7 7 8 A
Y Y Y Y Y Y Y Y B Y Y Y Y Y Y Y Y C
Y Y Y Y Y R R R D R R R R R R R R Outgroup
R R R R R R R R
Pseudorreplicate-n
9
Bootstrapping
Real phylogeny stimate
Trees obtained from the 100 pseudo-replicates
Case-1
30
60
10
Case-2
31
20
49
Consensus Bootstrap case-2
Consensus Bootstrap case-1
AB 90 ABC 60 CD 40 BCD 10
80 49 51 20
80
51
90
60
10
Bootstrapping
Partition table
SSUrDNA Ciliates - parsimony
123456789 Freq ----------------- .......
100.00 ....... 100.00 .......
100.00 ..... 100.00 ...
95.50 ....... 84.33 ....
11.83 .... 3.83 ..
2.50 ...... 1.00 ...... 1.00
Ochromonas (1)
Symbiodinium (2)
100
Prorocentrum (3)
Euplotes (8)
84
Tetrahymena (9)
96
Loxodes (4)
100
Tracheloraphis (5)
100
Spirostomum (6)
100
Gruberia (7)
Majority-rule consensus
11
Interpretation of Bootstraps (BPs)

• Felsenstein (1985) is a measure of repeatibility
• Probability that the internal branch appears when
  a new analysis is done with an independent sample

• Felsenstein y Kishino (1993) is a measure of
  exactitud
• probability that the internal branch is in the
  real tree

12
Interpretation of Bootstraps (BPs)

• BPs provide an index of the relative support for
  groups provided by a set of data under a certain
  method of analysis.
• High BPs are indicative of strong signal in the
  data
• Provided we have no evidence of strong misleading
  signal (e.g. base composition bias, great
  differences in branch lengths) high BPs are
  likely to reflect strong phylogenetic signal

13
Interpretation of Bootstraps (BPs)

• Low BPs need not mean the relationship is false,
  only that is poorly supported (by this data)

14
Interpretation of Bootstraps (BPs)

• Bootstrapping was introduced as a way of
  establishing confidence intervals for phylogenies

• This interpretation of bootstrap proportions
  (BPs) depends on the assumption that the original
  data is a random sample from a much larger set of
  independent and identically distributed data

15
Interpretation of Bootstraps (BPs)

• However, several things complicate this
  interpretation
• Perhhaps the assumptions are unreasonable -
  making any statistical interpretation of BPs
  invalid
• Some theoretical work indicates that BPs are very
  conservative, and may underestimate confidence
  intervals - problem increases with numbers of
  taxa

16
Interpretation of Bootstraps (BPs)

• BPs can be high for incongruent relationships in
  separate analyses - and can therefore be
  misleading (misleading data -gt misleading BPs)
• with parsimony it may be highly affected by
  inclusion or exclusion of only a few characters

17
Jackknifing

• Jackknifing is similar to bootstrapping, the only
  difference being in the way the data are
  resampled
• A certain proportion of data are eliminated at
  random (por ej. 50)
• The pseudoreplicates are analysed and the results
  are summarised in a majority-rule consensus
  tree
• Jackknifing and bootstrapping use to give similar
  results and are interpreted in a similar way

18
Assigning confidence intervals to phylogenies

• Resampling methods
• bootstrap (non parametric)
• jackknife
• Other methods
• decay analyses (only MP)
• posterior probability (ML bayesian)

19
Posterior Probability

• In the Bayesian method of inference for every
  node its posterior probability is calculated
  (BPP).
• This value has a direct interpretation from the
  statistical point of view
• The probability that the given group is true,
  given a model, the premises and the data
  (Huelsenbeck, 2002)
• However, the BPP values, with the same data, use
  to be a lot higher than bootstrap values.

20
Posterior Probability vs. bootstrap

• Douady et al., 2003 proposed to treat bootstrap
  and posterior probability as the lower and upper
  limits respectively.
• Alfaro et al., 2003 find that BPP can give high
  values for branches that are very short (being
  true)
• What is clear the two values are not equivalent
  and consequently it is not possible to compare
  them.
