Clockless Computing

1
Clockless Computing

• Montek Singh
• Thu, Sep 13, 2007

2
Dynamic Logic Pipelines (contd.)

• Drawbacks of Williams PS0 Pipelines
• Lookahead Pipelines Singh/Nowick 2000
• High-Capacity Pipelines Singh/Nowick 2000

3
Drawbacks of PSO Pipelining

• Poor throughput
• long cycle time 6 events per cycle
• data tokens are forced far apart in time
• Limited storage capacity
• max only 50 of stages can hold distinct tokens
• data tokens must be separated by at least one
  spacer
• My Research Goals have been address both issues
• still maintain very low latency

4
Recent Approaches

• 3 novel styles for high-speed async pipelining
• MOUSETRAP Pipelines Singh/Nowick, TAU-00,
  ICCD-01
• Lookahead Pipelines (LP) Singh/Nowick,
  Async-00
• High-Capacity Pipelines (HC) Singh/Nowick,
  WVLSI-00
• Goal significantly improve throughput of PS0
• Two Distinct Strategies
• LP introduce protocol optimizations
• shave off components from critical cycle
• HC fundamentally new protocol
• greater concurrency loosely-coupled stages

?
?
5
Outline

• New Asynchronous Pipelines
• MOUSETRAP Pipelines
• Lookahead Pipelines (LP)
• High-Capacity Pipelines (HC)

6
Lookahead Pipeline Styles

• Singh and Nowick
• Async-2000
• Best Paper Award

7
Lookahead Pipelines Strategy 1

• Use non-neighbor communication
• stage receives information from multiple later
  stages
• allows early evaluation

Benefit stage gets head-start on next cycle
8
Lookahead Pipelines Strategy 2

• Use early completion detection
• completion detector moved before stage (not
  after)
• stage indicates early done in parallel with
  computation

early completion detector
Benefit again, stage gets head-start on next
cycle
9
Lookahead Pipelines Overview

• 5 New Designs
• Dual-Rail Data Signaling
• LP3/1 early evaluation
• LP2/2 early done
• LP2/1 early evaluation early done
• Single-Rail Bundled-Data Signaling
• LPSR2/2 early done
• LPSR2/1 early evaluation early done

10
Dual-Rail Design 1 LP3/1
PC
Eval
Data in
Data out
N
N1
N2
ProcessingBlock
Completion Detector
From N2

• Optimization early evaluation
• each stage has two control inputs from stages
  N1 and N2
• Idea shorten precharge phase
• terminate precharge early when N2 is done
  evaluating

11
LP3/1 Protocol

• PRECHARGE N when N1 completes evaluation
• EVALUATE N when N2 completes evaluation

N2 indicates done
N
N1
N2
N2 evaluates
N evaluates
N1 evaluates
12
LP3/1 Comparison with PS0
N
N1
N2
LP3/1
Only 4 events in cycle!
N
N1
N2
PS0
6 events in cycle
13
LP3/1 Performance
saved path
Savings over PS0 1 Precharge 1 Completion
Detection
14
LP3/1 Inside a Stage

• Merging 2 Control Inputs

old Eval
early Eval

• Timing Issues
• must satisfy several simple constraints
• Ex. PC must arrive before Eval de-asserted
• 1-sided timing requirement
• easily satisfied in practice

15
Dual-Rail Design 2 LP2/2

• Optimization early done
• Idea move completion detector before processing
  block
• stage indicates when about to precharge/evaluate

early Completion Detector
early done
Data in
Data out
Processing Block
16
LP2/2 Completion Detector

• Modified completion detectors needed
• Done1 when stage starts evaluating, and inputs
  valid
• Done0 when stage starts precharging
• asymmetric C-element

17
LP2/2 Protocol

• Completion Detection
• performed in parallel with evaluation/precharge
  of stage

N
N1
N2
N evaluates
N1 evaluates
18
LP2/2 Performance
4
1
2
LP2/2 savings over PS0 1 Evaluation 1
Precharge
19
Dual-Rail Design 3 LP2/1

• Hybrid of LP3/1 and LP2/2. Combines
• early evaluation of LP3/1
• early done of LP2/2

20
Lookahead Pipelines Overview

• 5 New Designs
• Dual-Rail Data Signaling
• LP3/1 early evaluation
• LP2/2 early done
• LP2/1 early evaluation early done
• Single-Rail Bundled-Data Signaling
• LPSR2/2 early done
• LPSR2/1 early evaluation early done

21
Single-Rail Design LPSR2/1

• Derivative of LP2/1, adapted to single-rail
• bundled-data matched delays instead of
  completion detectors

22
Inside an LPSR2/1 Stage
23
LPSR2/1 Protocol
N
N1
N2
N evaluates
24
FIFO Results (simulations)
0.19? CMOS 3.3 V, 300K
dual-rail
single-rail

• LP dual-rail over 80 faster than Williams PS0
• comparable latency
• LP single-rail even faster

25
Practicality of Gate-Level Pipelining
When datapath is wide

• Can often split into narrow streams

• Use localized completion detector
• for each stream

• need to examine only a few bits
• ? small fan-in

• send done to only a few gates
• ? small fan-out

• comp. det. fairly low cost!

26
High-Capacity Pipelines

• Singh/Nowick WVLSI-00, ISSCC-02, Async-02

27
HC Pipeline Style

• High-Capacity Pipelines (HC)
• bundled datapaths dynamic logic function blocks
• latch-free no explicit latches needed
• dynamic logic provides implicit latching
• novel highly-concurrent protocol maximizes
  storage capacity
• traditional latch-free approaches spacers
  limit capacity to 50
• Key Idea Obtain greater control of stages
  operation
• separate control of pull-up/pull-down
• result new isolate phase
• stage holds outputs/impervious to input changes
• Advantage Each stage can hold a distinct data
  item
• 100 storage capacity
• Extra Benefit Obtain greater concurrency
• ? High throughput

28
HC Basic Structure

• Key Idea
• 2 independent control signals
• pc controls precharge
• eval controls evaluation

• Allows novel 3-phase cycle
• Evaluate
• Isolate (hold)
• Precharge

pc
eval
ack
delay
delay
delay
N
N1
N2
29
HC Inside a Stage

• Independent Controls of pull-up and pull-down
• allows new 3rd phase isolate

• pc asserted precharge
• eval asserted evaluate
• pc and eval de-asserted enter isolate (hold)
  phase

30
HC Protocol
Stage N
Stage N1
Eval
X
Isolate
Precharge

• Our protocol only 2 synchronization arcs
• only 1 backward arc
• once stage N1 evaluates, N can complete entire
  next cycle!

• Most Existing Protocols 3 synchronization arcs
• 1 forward arc data dependency
• 2 backward arcs control synchronization

31
Formal Specification of Controller

• Problem Specification too concurrent for direct
  synthesis
• desired precharge condition N and N1 have
  evaluated same data
• problem this condition not uniquely captured by
  given signals!
• N may evaluate next data item, while N1 stuck on
  current item!

32
Modified Specification of Controller

• Solution Add a state variable ok2pc

• ok2pc records whether N1 has absorbed Ns data
  item
• ok2pc resets immediately when N deletes item (N
  precharges)
• ok2pc is set when N1 deletes item (N1
  precharges)

33
Controller implementation

• Controller implementation is very simple
• each signal implemented using a single gate
• ok2pc typically off the critical path

34
HC Stage Implementation
NAND
INV
eval
pc
ack
req
done
delay
35
HC Operation
N enables itself for next evaluation
N
N1
N evaluates
N precharges
N1 starts to evaluate
Cycle Time 8 CMOS gate delays
36
Performance
N
N1
N2
N enables itself for next evaluation
N precharges
N evaluates
N1 evaluates
37
FIFO Results (simulations)
0.19? CMOS 3.3 V, 300K
dual-rail
single-rail

• LP dual-rail over 80 faster than Williams PS0
• comparable latency
• LP single-rail even faster

38
Fabricated Chip HC FIFO

• 2.5 GHz in 0.18u
