Markov chains Notations and Definitions

1
Markov chains Notations and Definitions

• Stochastic Processes
• By
• TMJA Cooray

2
Notations and Definitions

• Consider a sequence of trials numbered n0,1,..
  The outcome of the nth trial is represented by
  the random variable Xn, which is assumed to be
  discrete and to take one of the values j1,2,.
• The actual set of outcomes at any trial is a
  system of events, Ei , i1,2,. That are mutually
  exclusive and exhaustive.They are the states of
  the system and they may be finite or infinite in
  number.

3

• Write the absolute probability of outcome Ej at
  the nth trial as
• PrXnj pj(n) ----------(1)
• Where the initial distribution is given by
• If Xn-1i and Xnj ,
• then we say that the system has made
• a transition of type
• Ei ? Ej at the nth trial or step.
• We are interested in knowing the probability of
  occurrences of these transitions .

PrX0j pj(0)
4

• If the trials are not independent , we have to
  specify the conditional probability.
• PrXnj Xn-1i,Xn-2k, X0l ---------(2)
• With independent trials (1) and (2) may be
  identical.
• According to the Markovian property,the behavior
  of the sequence of events is uniquely decided by
  the previous state .
• Thus the transition probability depends only on
  Xn-1 and not on previous r.v.s.

5

• Therefore we can define a Markov chain as a
  sequence of consecutive trials such that
• PrXnj Xn-1i,Xn-2k, X0l PrXnj Xn-1i


•
  --------(3)
• We now have an important class of chains defined
  by the property in (3),for which the transition
  probabilities are independent of n.(time
  homogeneous)

6

• We can then write a homogeneous Markov chain ,
• PrXnj Xn-1i pij
  --------(4)
• Order of the subscript ij corresponds to the
  direction of the transition i?j.
• We also have
•
  -----(5)
• For any fixed i, the pij will form a probability
  distribution .

7

• In real situation ,
• we will be given the initial distribution and
  the transition probabilities (one step),and we
  want to determine the probability distribution
  for each random variable Xn.
• We may also be interested in the limiting
  distribution of the r.v.
• Xn as n? ? ,if it exists.

8
Transition matrix

• Suppose there are k states of the system.
  Transition probabilities can be easily
  represented in matrix form .
• Ppij or PPijT, can be finite or infinite
  in order depending on the number of states
  involved.
• As P

To state n1
From state n
9

• In the transition matrix
• if all pij ?0 and
• row sum (or column sum ) is unity
• then it is called a stochastic matrix.
• In order to determine the absolute
  probabilities at any stage ,the n step transition
  probabilities should be calculated, where ngt1.
• PrXnmj Xmi pij (n)
  ----------------(7)
• With pij (1) pij
• n step transition probability pij (n) is
  independent of m.

10

• Let p(0) be the initial pr.distribution.
• The distribution at the first stage is given by
• In matrix terms we can express (8) as
• p(1) P p(0) ------------(9)
• Similarly p(2) P p(1) P P p(0) P2 p(0) ---(10)
• In general p(n) Pn p(0) ------------(11)

11

• We also have p(nm) Pnm p(0)
• Pn Pm p(0)
• Pn p(m)
  ------------(12)
• For all states i and j and all integers mgt0 and
  n0
• This is the Chapman -Kolmogorov equation

12

• Absolute probabilities at any stage can be
  obtained by the initial distribution and the
  relevant step transition matrix

13
Classification of states

• Lemma suppose a Markov chain has N states.Let i
  and j be pair of states .Then (j can be reached
  from i) i?j iff theres an integer 0nltN such
  that the i,j entry of Pn is positive. That is pij
  n is gt0
• Definition states i and j communicate if i?j
  and j?i.
• We write i??j
• Thus theres at least one path in the transition
  diagram from i to j and vice versa.

14

• Definition A Markov chain is irreducible if
  every state communicates with every other state.
• For each state i, let class of the state i is

• C(i)all states j such that i ??j
• Properties of classes or closed sets
• (1) i C(i) for every state i.
• (2)If j C(i) then i C(j) .
• (3) for any two states i and j either C(i)C(j)
  or C(i) is disjoint from C(j).

15

• Definition State i is called absorbing if pii1.

16

• If the state is persistent and the mean
  recurrence time is infinity then the state is a
  null state.
• If the state is persistent and the mean
  recurrence time is finite then the state is a
  positive recurrent.

17

• A state is periodic with period d gt1, if every
  path that starts and ends at this state has
  length nd, where n can be any integer.0,1,2,

18

• Lemma
• Suppose i is periodic and i??j then j is periodic
  and has the same period .
• A state is aperiodic if it is not periodic and
  d1.
• A finite Markov chain is called regular if it
  is irreducible and aperiodic.

19

• If a state is persistent, aperiodic and not null
• then it is said to be ergodic.

20

• Definition A class C is called ergodic if
  every path that starts in C remains in C.
• In matrix terms, a class C is ergodic if the
  partial row sum
• The individual states in an ergodic class are
  also called ergodic.
• A single absorbing state is an ergodic class. An
  irreducible chain consists of a single ergodic
  class.

21
Transient classes

• Definition A class C is called transient if
  there is a path out of C.
• In matrix terms, a class C is transient if state
  i in C and state k not in C so that i?k (pikgt0)
  then the partial row sum is

22
Stationary distribution

• Definition ? is a stationary distribution for
  the Markov chain with transition matrix P, if
  ?P ? and in general if
• ?Pn ? for all integers ngt0
• Theorem Suppose that P is the transition matrix
  for a regular chain ,and that ? is the limiting
  vector for P,
• Then ? is the unique stationary distribution for
  the chain a Pn converges to ? as n?? where a
  is the initial pr.distribution .

23
Example

• Gamblers ruin problem ?

24

• Consider two gamblers, A having Rs.2/ and B
  having Rs.3/. Probability of A winning (Rs.1)
  the game at any trial be p and losing (Rs.1) the
  game be q.what are the possible states?
• A state can be defined as (x,y), where x,y are
  the amounts possessed by each player.

A state can be defined as (x,y), where x,y are
the amounts possessed by each player. Or by the
amount possessed by player A
Initially , at t0 ,state is (2,3) or state is
2.
25
(No Transcript)
26

• Initial distribution is

27
Standard form for transition matrix

• When a Markov chain is not irreducible( includes
  more than one class of states),the powers of the
  transition matrix are easier to analyze if we
  group the states in to classes.
• list the ergodic classes before the transient
  classes.

28
(No Transcript)
29
(No Transcript)
30
Powers of P can be easily found.
