Stochastic Processes

1
Stochastic Processes Markov Chain

• From DeGroot Schervish

2
Example

• Occupied Telephone Lines
• Suppose that a certain business office has five
  telephone lines and that any number of these
  lines may be in use at any given time.
• The telephone lines are observed at regular
  intervals of 2 minutes and the number of lines
  that are being used at each time is noted.
• Let X1 denote the number of lines that are being
  used when the lines are first observed at the
  beginning of the period let X2 denote the number
  of lines that are being used when they are
  observed the second time, 2 minutes later
• and in general, for n 1, 2, . . . , let Xn
  denote the number of lines that are being used
  when they are observed for the nth time.

3
Stochastic Process

• sequence of random variables X1, X2, . . . is
  called a stochastic process or random process
  with discrete time parameter.
• The first random variable X1 is called the
  initial state of the process
• and for n 2, 3, . . . , the random variable Xn
  is called the state of the process at time n.

4
Stochastic Process (cont.)

• In the example, the state of the process at any
  time is the number of lines being used at that
  time.
• Therefore, each state must be an integer between
  0 and 5.

5
Stochastic Process (cont.)

• In a stochastic process with a discrete time
  parameter, the state of the process varies in a
  random manner from time to time.
• To describe a complete probability model for a
  particular process, it is necessary to specify
  the distribution for the initial state X1 and
  also to specify for each n 1, 2, . . . the
  conditional distribution of the subsequent state
  Xn1 given X1, . . . , Xn.
• Pr(Xn1 xn1X1 x1, X2 x2, . . . , Xn xn).

6
Markov Chain

• A stochastic process with discrete time parameter
  is a Markov chain if,
• for each time n, the probabilities of all Xj for
  j gtn given X1, . . . , Xn depend only on Xn and
  not on the earlier states X1, . . . , Xn-1.
• Pr(Xn1 xn1X1 x1, X2 x2, . . . , Xn xn)
• Pr(Xn1 xn1Xn xn).
• A Markov chain is called finite if there are only
  finitely many possible states.

7
Example Shopping for Toothpaste

• Consider a shopper who chooses between two brands
  of toothpaste on several occasions. Let Xi 1 if
  the shopper chooses brand A on the ith purchase,
  and let Xi 2 if the shopper chooses brand B on
  the ith purchase.
• Then the sequence of states X1, X2, . . . is a
  stochastic process with two possible states at
  each time.
• the shopper will choose the same brand as on the
  previous purchase with probability 1/3 and
• will switch with probability 2/3.

8
Example Shopping for Toothpaste

• Since this happens regardless of purchases that
  are older than the previous one, we see that this
  stochastic process is a Markov chain with
• Pr(Xn1 1Xn 1) 1/3
• Pr(Xn1 2Xn 1) 2/3
• Pr(Xn1 1Xn 2) 2/3
• Pr(Xn1 2Xn 2) 1/3

9
Transition Distributions/Stationary Transition
Distributions

• Consider a finite Markov chain with k possible
  states. The conditional distributions of the
  state at time n 1 given the state at time n,
  that is, Pr(Xn1 j Xn i) for i, j 1, . . .
  , k and n 1, 2, . . ., are called the
  transition distributions of the Markov chain.
• If the transition distribution is the same for
  every time n (n 1, 2, . . .), then the Markov
  chain has stationary transition distributions.

10
Stationary Transition Distributions

• The notation for stationary transition
  distributions, pij
• suggests that they could be arranged in a matrix.

• The transition probabilities for Shopping for
  Toothpaste example can be arranged into the
  following matrix

11
Transition Matrix

• Consider a finite Markov chain with stationary
  transition distributions given by
• pij Pr(Xn1 j Xn i) for all n, i, j.
• The transition matrix of the Markov chain is
  defined to be the k k matrix P with elements
  pij . That is,

12
Transition Matrix (cont.)

• A transition matrix has several properties that
  are apparent from its definition.
• For example, each element is nonnegative because
  all elements are probabilities.
• Since each row of a transition matrix is a
  conditional p.f. for the next state given some
  value of the current state, we have

13
Stochastic Matrix

• Square matrix for which all elements are
  nonnegative and the sum of the elements in each
  row is 1 is called a stochastic matrix.
• It is clear that the transition matrix P for
  every finite Markov chain with stationary
  transition probabilities must be a stochastic
  matrix.
• Conversely, every k k stochastic matrix can
  serve as the transition matrix of a finite Markov
  chain with k possible states and stationary
  transition distributions.

14
Example

• Suppose that in the example involving the office
  with five telephone lines, the numbers of lines
  being
• used at times 1, 2, . . . form a Markov chain
  with stationary transition distributions.
• This chain has six possible states 0, 1, . . . ,
  5, where i is the state in which exactly i lines
  are being used at a given time (i 0, 1, . . . ,
  5).
• Suppose that the transition matrix P is as
  follows

15
Example

• (a) Assuming that all five lines are in use at a
  certain observation time, we shall determine the
  probability that exactly four lines will be in
  use at the next observation time.
• (b) Assuming that no lines are in use at a
  certain time, we shall determine the probability
  that at least one line will be in use at the next
  observation time.

16
Example

• A manager usually checks the server at her store
  every 5 minutes to see whether the server is busy
  or not. She models the state of the server (1
  busy or 2 not busy) as a Markov chain with two
  possible states and stationary transition
  distributions given by the following matrix

17
Example (cont.)

• Pr(Xn2 1Xn 1) Pr(Xn1 1, Xn2 1Xn
  1) Pr(Xn1 2, Xn2
  1Xn 1).
• Pr(Xn1 1, Xn2 1Xn 1) Pr(Xn1 1Xn
  1) Pr(Xn2 1Xn1 1) 0.9 0.9 0.81.
• Similarly,
• Pr(Xn1 2, Xn2 1Xn 1) Pr(Xn1 2Xn
  1) Pr(Xn2 1Xn1 2) 0.1 0.6 0.06.
• It follows that Pr(Xn2 1Xn 1)0.81 0.06
  0.87, and hence Pr(Xn2 2Xn1) 1- 0.87
  0.13.
• By similar reasoning, if Xn 2, Pr(Xn2 1Xn
  2) 0.6 0.9
  0.4 0.6 0.78,
• and Pr(Xn2 2Xn 2) 1- 0.78 0.22.

18
The Transition Matrix for Several Steps

• Consider a general Markov chain with k possible
  states 1, . . . , k and the transition matrix P.
• Assuming that the chain is in state i at a given
  time n, we shall now determine the probability
  that the chain will be in state j at time n 2.
• In other words, we shall determine the
  conditional probability of Xn2 j given Xn
  i. The notation for this probability is p(2)ij .

19
The Transition Matrix for Several Steps (cont.)

• Let r denote the value of Xn1

20
The Transition Matrix for Several Steps (cont.)

• The value of p(2) ij can be determined in the
  following manner If the transition matrix P is
  squared, that is, if the matrix P2 PP is
  constructed, then the element in
• the ith row and the jth column of the matrix
  P2 will be
• Therefore, p(2)ij will be the element in the ith
  row and the jth column of P2.

21
Multiple Step Transitions

• Let P be the transition matrix of a finite Markov
  chain with stationary transition distributions.
• For each m 2, 3, . . ., the mth power Pm of the
  matrix P has in row i and column j the
  probability p(m) ij that the chain will move from
  state i to state j in m steps.

22
Example

• Consider again the transition matrix P given by
  the example for the Markov chain based on five
  telephone lines.
• We shall assume first that i lines are in use at
  a certain time, and we shall determine the
  probability that exactly j lines will be in use
  two time periods later.
• If we multiply the matrix P by itself, we obtain
  the following two-step transition matrix

23
Example

• i. If two lines are in use at a certain time,
  then the probability that four lines will be in
  use two time periods later is ..
• ii. If three lines are in use at a certain time,
  then the probability that three lines will again
  be in use two time periods later is ..

24
The Initial Distribution

• The manager in Example enters the store thinking
  that the probability is 0.3 that the server will
  be busy the first time that she checks.
• Hence, the probability is 0.7 that the server
  will be not busy.
• We can represent this distribution by the vector
• v (0.3, 0.7)
• that gives the probabilities of the two states
  at time 1 in the same order that they appear in
  the transition matrix.

25
Probability Vector/Initial Distribution

• A vector consisting of nonnegative numbers that
  add to 1 is called a probability vector.
• A probability vector whose coordinates specify
  the probabilities that a Markov chain will be in
  each of its states at time 1 is called the
  initial distribution of the chain or the intial
  probability vector.

26
Example

• Consider again the office with five telephone
  lines and the Markov chain for which the
  transition matrix P
• Suppose that at the beginning of the observation
  process at time n 1, the probability that no
  lines will be in use is 0.5, the probability that
  one line will be in use is 0.3, and the
  probability that two lines will be in use is 0.2.

• The initial probability vector is v (0.5, 0.3,
  0.2, 0, 0, 0).
• Distribution of the number of lines in use at
  time 2, one period later.

27
Example

• By an elementary computation it will be found
  that
• vP (0.13, 0.33, 0.22, 0.12, 0.10, 0.10).
• Since the first component of this probability
  vector is 0.13, the probability that no lines
  will be in use at time 2 is 0.13 since the
  second component is 0.33, the probability that
  exactly one line will be in use at time 2 is
  0.33 and so on.
