SKYNET

1
Vision-Guided RobotPosition Control

• SKYNET

Tony Baumgartner Computer Science Jeff Clements
Mechanical Engineer Norman Pond Electrical
Engineer Brock Shepard Mechanical
Engineer Nicholas Vidovich Computer Engineer
Advisors Dr. Juliet Hurtig Dr. J.D. Yoder
February 19, 2004
2
Problem Identification
3
Equipment Provided

• Desktop computer
• Two CCD (Charge-Coupled Device ) cameras
• ABB Robot
• Controller

4
Robot
ABB Articulated IRB 140
5
Controller
6
Design Deliverables

• Image Processing Completion Date
• Difference Algorithm 12/19/03
• Blob Detection 02/20/04
• Object Recognition 03/17/04
• User Interface 03/17/04
• Overall
• CPU/Robot Communication 03/17/04
• Gripper Implementation 03/17/04
• Testing 04/15/04

7
Vision Systems

• Eye-On-Hand Configuration
• Limited view of work area
• Partial view of object
• Continually changes coordinate system mapping

8
Vision Systems

• External Stereo Camera Configuration
• Distance fixed between cameras
• Coordinate system relation between camera space
  and real space fixed
• Full view of object

9
Software Block Diagram
10
Difference Algorithm Visuals
11
Object Recognition Algorithms

• Shape-Based Matching
• Thresholding
• Blob Detection
• Pattern Recognition
• Similarity Measure

12
Object Recognition VisualsNo Object in Scene
13
Object Recognition VisualsObject Enters Scene
14
Object Recognition VisualsBlob Show
15
Object Recognition VisualsBlob Find
16
Other Object Recognition Visuals
17
Other Object Recognition Visuals
18
Current Status

• Object recognition is currently being developed
• Serial communications with robot controller and
  computer are being established to send and
  receive coordinate values

19
Future Implementation

• After Completion of Object Recognition
• Develop a coordinate system that can be converted
  from pixels to millimeters
• Develop calculations of where the object actually
  is in the camera view compared with the actual
  space

20
Future Implementation

• After Completion of Controller/Computer
  Connection
• Develop algorithm that loops receiving values and
  transmitting values to move the robot

21
QUESTIONS
?
22
References

• lt1gt ABB Product Specification Sheet (2003)
• lt2gt Lin, C.T., Tsai D.M. (2002) Fast normalized
  cross correlation for defect detection. Machine
  Vision. Yuan-Ze University,1-5.
• lt3gt Phil Baratti Robot Precision (personal
  communication, November 4
• 2003)
• lt4gt Stegar, C.., 2001. Similarity measures for
  occlusion, clutter, and
• illumination invariant object recognition. In
  B. Radig and S. Florczyk(eds), Mustererkennung
  2001, Springer Munchen, pp. 145-154.
• lt5gt Stegar, C., Ulrich, M. 2002 Performance
  Evaluation of 2D Object
• Recognition Techniques. Technical Report
  Technische Universitat Munchen, 1-15.
• lt6gt Robots and Manufacturing Automation, pg.
  220-222.
• lt7gt http//www.prip.tuwien.ac.at/Research/RobotVis
  ion/vs.html
