SPICE Simulation Cont'

1
SPICE Simulation(Cont.)
2
Optimization

• HSPICE can automatically adjust parameters
• Seek value that optimizes some measurement
• Example Best P/N ratio
• Weve assumed 21 gives equal rise/fall delays
• But we see rise is actually slower than fall
• What P/N ratio gives equal delays?
• Strategies
• (1) run a bunch of sims with different P size
• (2) let HSPICE optimizer do it for us

3
P/N Optimization
fo4opt.sp   Parameters and models -----------
--------------------------------------------------
--------- .param SUPPLY1.8 .option
scale90n .include '../models/tsmc180/models.sp' .
temp 70 .option post   Subcircuits ------------
--------------------------------------------------
-------- .global vdd gnd .include
'../lib/inv.sp' Simulation netlist -----------
--------------------------------------------------
--------- Vdd vdd gnd 'SUPPLY' Vin a gnd PULSE 0
'SUPPLY' 0ps 100ps 100ps 500ps 1000ps X1 a b inv P
'P1' Override PMOS width with P
P1 X2 b c inv P'P1' M4 X3 c d inv P'P1' M16
device under test
4
P/N Optimization
X4 d e inv P'P1' M64 load X5 e f inv P'P1' M
256 load on load   Optimization
setup -------------------------------------------
--------------------------- .param
P1optrange(8,4,16) search from 4 to 16, guess
8 .model optmod opt itropt30 maximum of 30
iterations .measure bestratio param'P1/4'
compute best P/N ratio   Stimulus -------------
--------------------------------------------------
------- .tran 1ps 1000ps SWEEP OPTIMIZEoptrange
RESULTSdiff MODELoptmod .measure tpdr
rising propagation delay TRIG
v(c) VAL'SUPPLY/2' FALL1 TARG v(d)
VAL'SUPPLY/2' RISE1 .measure tpdf falling
propagation delay TRIG v(c)
VAL'SUPPLY/2' RISE1 TARG v(d)
VAL'SUPPLY/2' FALL1 .measure tpd
param'(tpdrtpdf)/2' goal0 average prop
delay .measure diff param'tpdr-tpdf' goal 0
minimize diff between delays .end
5
P/N Results

• P/N ratio for equal delay is 3.61
• tpd tpdr tpdf 84 ps (slower than 21 ratio
  with tpd 75 ps)
• Big pMOS transistors waste power too
• Seldom design for exactly equal delays
• Compromise between using small PMOS to save area
  and large PMOS to eqaulize delays
• What ratio gives lowest average delay?
• .tran 1ps 1000ps SWEEP OPTIMIZEoptrange
  RESULTStpd MODELoptmod
• P/N ratio of 1.41
• tpdr 87 ps, tpdf 59 ps, tpd 73 ps

6
Power Measurement

• HSPICE can measure power
• Instantaneous P(t)
• Or average P over some interval
• .print P(vdd) measure inst. Power delivered
  by Vdd
• .measure pwr AVG P(vdd) FROM0ns TO10ns
• Power in single gate
• Connect to separate VDD supply

7
Logical Effort

• Logical effort can be measured from simulation
• As with FO4 inverter, shape input, load output
• Use the Sweep command to vary H
• .tran 1ps 1000ps SWEEP H 1 8 1

8
Logical Effort Plots

• Plot tpd vs. h
• Normalize by t
• y-intercept is parasitic delay
• Slope is logical effort
• Delay fits straight line
• very well in any process
• as long as input slope is
• consistent
• d 1.93 1.1h from plot
• d 2 1.3h from RC delay analysis

t 15 ps
9
SPICE Device Models

• Level 1
• Closely related to the Shockley model discussed
• Enhanced with channel length modulation and drain
  induced barrier lowering
• Enhanced with the body effect
• Level 2 and 3
• Enhanced with velocity saturation, mobility
  degradation, and subthreshold conduction.
• Level 3 allows faster simulations and better
  convergence
• BSIM models
• Are derived from device physics, are very
  complex, and use large number of parameters (
  100) to fit the behavior of modern transistors
• Are needed for accurate simulation of sub-micron
  technologies

10
Design Corner SPICE Deck
corner.sp   Spec response of unloaded
inverter across process corners -----------------
------------------------------- .option scale90n
Specifies l 90 nm .param SUPPLY1.8 Must
be set before calling .lib .lib
'../models/tsmc180/opconditions.lib TT invoke
the library card read in TT .option post
Simulation netlist ------------------------------
------------------ Vdd vdd gnd 'SUPPLY' Vin a gnd
PULSE 0 'SUPPLY' 50ps 0ps 0ps 100ps
200ps M1 y a gnd gnd NMOS W4 L2 AS20 PS18
AD20 PD18 M2 y a vdd vdd PMOS W8 L2 AS40
PS26 AD40 PD26   Stimulus ------------------
------------------------------ .tran 1ps
200ps .alter repeat simulations for a
different corner
11
Design Corner SPICE Deck cont.
.lib '../models/tsmc180/opconditions.lib FF
invoke the library card read in FF .alter .lib
'../models/tsmc180/opconditions.lib SS invoke
the library card read in FF   .end
12
OPCONDITIONS Library
opconditions .lib for TSMC 180 nm process TT
typical NMOS, PMOS, Voltage, Temperature .lib
TT .temp 70 .param SUPPLY 'SUPPLY .include
modelsTT.sp .end TT SS Slow NMOS, PMOS, Low
Voltage, High Temperature .lib SS .temp
125 .param SUPPLY 0.9 SUPPLY .include
modelsSS.sp .end SS FF Fast NMOS, PMOS,
High Voltage, Low Temperature .lib FF .temp
0 .param SUPPLY 1.1 SUPPLY .include
modelsFF.sp .end FF
13
Combinational Circuits
14
Circuit Families

• Static with NMOS, PMOS pull-down, pull-up
• Most widely used and available in most standard
  libraries
• Pass transistor
• Dynamic circuits

15
Bubble Pushing

• Y AB CD
• Start with network of AND / OR gates
• Convert to NAND / NOR inverters
• Push bubbles around to simplify logic
• Remember DeMorgans Law

16
Example

• Sketch a design using one compound gate and one
  NOT gate.
• Y AB CD

17
Compound Gates

• Logical Effort of compound gates

18
Example

• The multiplexer has a maximum input capacitance
  of 16 units on each input (twice the unit size).
  It must drive a load of 160 units. Estimate the
  delay of the NAND and compound gate designs.

H 160 / 16 10 B 1 (branching) N 2 (number
of stages)
19
NAND Solution

Work backwards to find sizes f gh gt 4.2
(4/3) (160/y) gt y 50 input cap of 2nd
NAND2 Can do the same for the first set of
NAND2s or we already know Y 16 for them
20
Compound Solution
Work backwards to find sizes f gh gt 4.5 (1)
(160/y) gt y 36 input cap of 2nd NAND2 Can do
the same for the first set compound stage or we
already Know Y 16
21
Example

• Annotate your designs with transistor sizes that
  achieve this delay.

22
Input Order

• Our parasitic delay model was too simple
• Calculate parasitic delay for Y falling
• If A arrives latest?
• If B arrives latest?

23
Input Order

• Our parasitic delay model was too simple
• Calculate parasitic delay for Y falling
• If A arrives latest? 2t
• If B arrives latest? 2.33t
• Logical effort and parasitic delay is different
  for different inputs
• Some gates like AOI21 are inherently asymmetric
• Other gates have slightly different logical
  efforts and parasitic delays for different inputs

24
Inner Outer Inputs

• Outer input is closest to rail (B)
• Inner input is closest to output (A)
• If input arrival time is known
• Connect latest input to inner terminal for
  smallest delay

25
Asymmetric Gates

• Asymmetric gates favor one input over another
• Ex suppose input A of a NAND gate is most
  critical
• Use smaller transistor on A (less capacitance)
• Boost size of noncritical input
• So total resistance is same
• gA 10/9 lt 4/3 for symmetric NAND
• gB 5/3 gt 4/3 for symmetric NAND
• Improvement on logical effort on input A comes at
  the cost of higher effort on the reset input

26
Symmetric Gates

• Inputs can be made perfectly symmetric
• If A comes earlier, then x is charged to 1 if B
  comes earlier, then x is charged to 1. In either
  case, the falling delay is the same

27
Skewed Gates

• Skewed gates favor one edge over another
• Ex suppose rising output of inverter is most
  critical
• Downsize noncritical nMOS transistor
• Calculate logical effort by comparing to unskewed
  inverter with same effective resistance on that
  edge.
• gu 2.5 / 3 5/6
• gd 2.5 / 1.5 5/3

28
HI- and LO-Skew

• Def Logical effort of a skewed gate for a
  particular transition is the ratio of the input
  capacitance of that gate to the input capacitance
  of an unskewed inverter delivering the same
  output current for the same transition.
• Skewed gates reduce size of noncritical
  transistors
• HI-skew gates favor rising output (small nMOS)
• LO-skew gates favor falling output (small pMOS)
• Logical effort is smaller for favored direction
• But larger for the other direction

29
Catalog of Skewed Gates
30
Asymmetric Skew

• Combine asymmetric and skewed gates
• Downsize noncritical transistor on unimportant
  input
• Reduces parasitic delay for critical input

31
Best P/N Ratio

• We have selected P/N ratio for unit rise and fall
  resistance (P/N ratio 2 assuming mr mn/mp
  2).
• Alternative choose ratio for least average delay
• Ex inverter
• Delay driving identical inverter
• tpdf 2 (P1) (RC)
• tpdr 2 (P1)(mr/P) (RC)
• tpd (P 1 mr mr/P) (RC)
• Differentiate tpd w.r.t. P
• Least delay for P

r
32
P/N Ratios

• In general, best P/N ratio giving the lowest
  average delay is sqrt of that giving equal rise
  and fall delays.
• Only improves average delay slightly for
  inverters
• But significantly decreases area and power

33
Observations

• Best P/N ratio should be chosen on the basis on
  area, power, and reliability (not only average
  delay)
• Smaller P/N ratio reduces area and power
  consumption however, unequal rise/fall times
  cause cycle duty distortion, longer path delays
  (if the worst edge is triggered , and reduces
  noise margin by lowering the switching point

34
Other Circuit Families

• What makes a circuit fast?
• I C dV/dt -gt tpd ? (C/I) DV
• low capacitance
• high current
• small swing
• Logical effort is proportional to C/I
• pMOS are the enemy!
• High capacitance for a given current
• Can we take the pMOS capacitance off the input?
• Various circuit families try to do this

35
Pseudo-nMOS

• Uses a pMOS that is always ON
• Benefits
• Input Cap is smaller than a 2/1 ratioed inverter
• Drawbacks
• Has slow rising transitions
• Dissipates power when output is low
• Lower noise margin since output low is non-zero
• Rarely used

36
Pass Transistor Circuits

• Pass transistors are essential to the efficient
  design of specific circuits such as the
  6-transistor static RAM (will discuss later)
• Inputs drive diffusion terminals as well as gates
• Other gates such as XORs can also be implemented
  efficiently using pass transistors (6 transistors
  using pass transistors v.s. 8 using static CMOS)
• However, because of diffusion inputs the delay
  depends on input driver
• Therefore, in most general purpose logic, static
  CMOS is superior in speed, power, and area.

37
Different 2-input Mux Implementations

• 2-input multiplexer (Y SA SB)
• CMOS Transmission Gates
• Compound gates
• Using tri-states

_
_
