Title: Architecture, Networks and System


1
Architecture, Networks and System
  • Soumitra Sengupta, PhD
  • Asst Clinical Professor, Dept of Biomedical
    Informatics Information Security Officer,
    NewYork-Presbyterian Hospital Information
    Security Officer, Columbia University Medical
    Center

2
Overview
  • Architectural Concepts
  • Networking Concepts
  • Systems

3
Architectural Concepts
Organizational Goals
Requirements
influence
lead to
suggest new
Architecture
Systems
yield
4
Architectural Concepts
Organizational Goals Become a Reference
laboratory service
Requirements Acquire Specimens Reduce
Errors Speed up result time Be Cost Effective
influence
lead to
suggest new
Architecture Distribution of Work Acquisition Tran
sportation Instrumentation Reporting
Systems Nursing Data collection, Containers Data
Entry, Pneumatic Tubes Instruments, maintenance,
staff Laboratory Information System Review of
data
yield
5
Architects Job
  • Understand Goals and Requirements
  • Needs and Expectations, Business case
  • Understand Prototyping, prioritization,
    functional substitution
  • Create/Select architecture based on quality and
    design considerations
  • Represent and CommunicateBudget and timeline,
    functional view, data flow, etc.
  • Analyze and evaluate Use case, maintainability
  • Implement and test Modules, performance,
    interoperability
  • Independent of Computing !!

6
Stakeholder Communication
  • Different views about the problem and the
    solution
  • Architect needs input from all stakeholders
  • Developer/Integrator
  • Development organization/Seller
  • Buyer
  • Customer/end user
  • Implementer
  • Operations
  • Maintenance staff

7
Information systems architectural structures
  • How and what to communicate?
  • Modules - Work assignment, phasing
  • Conceptual - Functions, correct behavior
  • Process - Programs, performance, human
  • Physical - Hardware, delivery framework
  • Uses - Program and system dependency
  • Calls - modules/subroutines, distributed
    messaging, client-server
  • Data flow - Functional flow of information
  • Control flow - System states, flowcharts
  • Classes - Object-oriented design

8
IAIMS Architecture (Modular View)
9
Success Criteria for an Architecture
  • Quality Attributes
  • System
  • Business
  • Criteria
  • Observable at the development site
  • Observable via execution at the customer site
  • Quantitative/Qualitative

10
Success Criteria for an Architecture
  • System Quality Attributes Observable at
    development end
  • Development expenses and time
  • Ease of development
  • Testability
  • Modifiability
  • Portability
  • Reusability

11
Success Criteria for an Architecture
  • System Quality Attributes Observable at customer
    end
  • Performance (Sluggish Slows down at 2 PM)
  • Functionality (Does it do X?)
  • Correctness (Sometimes!)
  • Completeness (Partially!)
  • Reliability (Why is it not working?)
  • Availability (Your cable is disconnected!)
  • Security (Please use a password longer than 3
    letters!)

12
Success Criteria for an Architecture
  • System Quality Attributes Observable at customer
    end
  • Usability (More on this in Cognitive/HCI
    sections)
  • Learnability
  • Efficiency
  • Memorability
  • Error Avoidance
  • Error Handling
  • Modifiability (What does it cost to add X?)
  • Ability to Integrate (How well does it fit
    institutional standards?)
  • Flexibility (How well does it adapt with
    changes?)

13
Success Criteria for an Architecture
  • Business Quality Attributes
  • Time to market
  • Target market
  • Projected lifetime of the system
  • Rollout schedule/Project plan execution
  • ROI
  • Maintenance/Operational Costs

14
Architecture Homilies
  • Gain high level but complete picture about
    business processes and technology solutions
  • Know the past, Master the present, Peer ahead to
    the future
  • Present facts demand facts, Practice
    evidence-based computing
  • Think institutional, but remember to sweat the
    details
  • Adapt, because technology moves fast
  • Communicate, because people remain the same
  • There is no perfection, so consider all pros and
    cons

15
Overview
  • Architectural Concepts
  • Networking Concepts
  • Systems

16
Networks
  • Communication infrastructure
  • Enabling technology (with Personal Computing)
  • Speed
  • Internet
  • Wireless
  • Convergence
  • Voice
  • Devices
  • Security

17
Layered Networks
  • OSI Structure

Useful pieces of code (message)
7. Application
ASCII ? EBCDIC data conversion
6. Presentation
None (IP) Logical Units (IBM)
5. Session
UDP, TCP (IP) (segment)
4. Transport
Internet Protocol (IP), SNA (IBM), AppleTalk,
Novell IPX (x) (datagram, packet)
3. Network
Ethernet, 802.11, PPTP, T1, Frame Relay LAN/WAN
(frames, packet)
2. Link
18
Layers, Services, Protocols
19
(No Transcript)
20
Physical Layer (EIA 569-A)
21
Physical Layer
  • Issues
  • COST (Labor)
  • Cabling standard and types
  • Category 3, 4, 5 Copper (16MHz, 20MHz, 100MHz)
  • Multi-Mode, Single-Mode Fiber (GHz, distance)
  • Competency (kinks, terminations, workmanship)
  • Reliability (HVAC, mess-up factor)
  • Flexibility (Topology reconfiguration - Star)

22
Data Link Layer
  • IEEE Standard
  • Two sub-layers
  • Logical Link Layer (802.2) and
  • Media Access Layer (802.3, 802.11)
  • Each Link Interface gets a Media Access Control
    (MAC) aka Ethernet Address
  • 6 Bytes long
  • Globally Unique 00096b (IBM), 00007d (Sun)

23
Data Link Layer
  • Topology
  • Bus (Ethernet Carrier Sense Multiple Access
    /Collision Detect),
  • Ring (Token Passing),
  • Hierarchy

24
Data Link Layer
W/S
  • Switches are multi-port link layer devices
    connecting workstations and switches
  • No collisions better speed
  • Organized hierarchically
  • Uplink Gigabit downstream 100/10 Mbps
  • Fits Star topology

Flr Sw
W/S
W/S
W/S
Flr Sw
Flr Sw
Bldg Sw
Bldg Sw
Core Sw
25
Network Layer
  • Problem in connecting multiple workstations
  • LAN / Link technology
  • Speed variation
  • Frame size variation
  • Network layer addresses global communication
  • Logical Addressing Layer 3 address (IP
    156.111.60.150)
  • World-wide Routing Optimal paths (using
    Routers)
  • Fragmentation and reassembly, Error Handling
  • Internet Protocol (IP) is Connection-less Best
    delivery

26
Transport Layer
  • Transport layer offers different levels of
    reliability
  • Program Level Addressing
  • (Ports 21, 23, 25, 80, 443, 1214, 3389, etc.)
  • Universal Datagram Protocol (UDP) Best-effort
    delivery, no guarantees
  • Domain Name Service (DNS)
  • Simple Network Management Protocol (SNMP)
  • Transmission Control Protocol (TCP) Guaranteed
    delivery, ordered segments, no duplicates
  • Hypertext Transport Protocol
  • Telnet

27
TCP/IP Routers
  • Routers connect disparate Link layer technologies
    to route IP packets
  • Construct Enterprise backbone as well as the
    Internet
  • Issues Performance, Redundancy, Security, Cost
  • Merged with switches (Switch Routers)
  • Improved efficiencies, speed
  • Better control and manageability (Virtual LAN
    technology)

28
Network Design
Dual-homed FloorSwitch-Routers
Server Farm
Server
Server
Dual-Homed BuildingSwitch-Routers
Redundant Backbone Core Switch-Routers
WAN Locations
Internet
29
Application Layer
  • Naming Services
  • Domain Name Service (DNS)
  • Lightweight Directory Access Protocol (LDAP)
  • Yellow Pages - Network Information Services
    (NIS)
  • File and Print Services
  • Network File Services (NFS), Server Message
    Blocks (SMB) / WinFS, Apple File Share
  • Internet Printing Protocol (IPP)
  • Terminal / GUI / file transfer services
  • Telnet, FTP, SSH, SCP
  • Email SMTP, IMAP, POP
  • Web HTTP
  • Domain specific Applications

30
NYSERnet Manhattan Dark Fiber Project NYP,
Columbia
31
NYSERNet Lower Manhattan
32
NYSERNet Upper Manhattan
33
Overview
  • Architectural Concepts
  • Networking Concepts
  • Systems

34
World Wide Web
  • Derived from gopher, WAIS, SGML, Apple
    Hyperlink, MIME, Public and Private Key
    cryptography, NeXTStep, etc.
  • Features
  • Links (URL, Ability to leverage independent
    publishers, functionality)
  • Multimedia (text, graphics, audio, video, forms,
    etc. - functionality)
  • Platform independent rendition (flexibility,
    simplicity)
  • Mark Up Language (HTML, XML, ASCII/Unicode,
    simplicity)
  • Dynamic computing (Common Gateway Interface,
    Javascript, Applets, Servlets, Extensibility)
  • Security (Authentication, SSL Encryption)
  • MIME-type Plug-in (extensibility)
  • And it continues to grow (Web Services)
  • http//www.boutell.com/newfaq/definitions/

35
World Wide Web - HTTP
  • telnet io.dbmi.columbia.edu 80
  • Trying...
  • Connected to io.dmi.columbia.edu.
  • Escape character is ''.
  • GET / HTTP/1.0 (ltenter twicegt)
  • HTTP/1.1 200 OK
  • Date Tue, 29 Mar 2005 162402 GMT
  • Server Apache/2.0.46 (Unix) mod_ssl/2.0.46
    OpenSSL/0.9.7b mod_jk/1.2.1 PHP/4.3.3
  • Last-Modified Tue, 22 Mar 2005 155049 GMT
  • ETag "f77-21e0-cefaa840"
  • Accept-Ranges bytes
  • Content-Length 8672
  • Connection close
  • Content-Type text/html charsetISO-8859-1
  • ltHTMLgt
  • ..
  • lt/HTMLgt
  • Connection closed.

36
World Wide Web - Naming
  • Uniform Resource Locator (URL)/ Web Address
  • Protocol http, https, ftp, file, mailto
  • Name www.dbmi.columbia.edu (or IP address)
  • Optional port number www.dbmi.columbia.edu80
  • Path /educ/curriculum/curriculum.html
  • Other possible protocols with different meanings
    of path

37
World Wide Web - CGI
38
Computing Models
  • Not Client-Server
  • Hardwired, unshared cable
  • Dumb terminals, limited or no graphics
  • Client-Server
  • Simple Clients
  • Efficient, very useful, no graphics
  • Terminal Emulation (Telnet, ssh), FTP
  • SMTP (Email)
  • Apple Print

39
Computing Models
  • Graphics based Client-Server
  • Graphics in Client to exploit client power
  • Heavy in networking load
  • X Windows
  • Citrix, Windows RDP
  • Fat Client
  • Adding significant logic to Clients
  • Version problem
  • Client power problem
  • Many applications
  • Windows Version 3

40
Computing Models
  • Thin Client Model
  • Graphics in Client with little logic
  • Markup Language
  • Web, Citrix
  • Uniformity across clients
  • 3-Tier Client-Server
  • Thin Client access from the workstation
  • Fat Client access from the intermediate
    application server
  • Database in the back server
  • Web-Services model
  • Using standard markup language (XML)
  • Using standard protocols (Web Services, derived
    from HTTP)

41
Data Processing
  • Online Transaction Processing (OLTP)
  • Lightweight processing
  • High volume during work hours
  • Network intensive
  • Enterprise class systems
  • Batch reporting
  • Heavy database access
  • Month-End, Year-End Processing
  • Web-based distribution

42
Data Processing
  • Online Analytic Processing (OLAP)/ Decision
    Support Systems (DSS)
  • Intermediate-term (hourly, daily) views
  • Dynamic, multi-dimensional views (Slice and Dice)
  • Replicated data into OLAP tools (Business
    Intelligence Systems)
  • Needs data from multiple sources
  • Time requirement is Semi-Real Time
  • Alerting

43
Data Processing
ProductionDatabases
Replicate
Enterprise Repository/ Data Warehouse
Query
Distribute
WorkgroupDatamarts
Query
Replicate
Query
PersonalMobileDatamarts
44
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
45
Patient Data Exchange
  • Message Handling
  • What are the messages, and how are they
    structured? How are they communicated?
  • ANSI Health Level 7 standard
  • Non-standard, institutional data unit structure
    local client-server comm.
  • Choice of underlying communication
  • Program based Sockets, RPC
  • Files over FTP, SFTP, file sharing drives
  • Message Aggregation Format
  • Multiple HL7 messages in a file (batch billing)
    or single HL7 Message in a file (EKG images)

46
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
47
Patient Data Exchange
  • Translation
  • Semantic Conversion of codes
  • Use of Translation tables
  • Maintenance problem
  • Medical Entities Dictionary
  • Holder of medical entities and their semantic
    relationships
  • Auto-generation of Translation tables from the
    MED
  • Also, many other benefits

48
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
49
Patient Data Exchange
  • Message Routing
  • Many applications need the same data (ADT)
  • The logic for appropriate data items to be
    replicated and routed to the correct destinations
  • A store-and-forward queuing mechanism
  • Handle failures gracefully
  • Maintain order of messages
  • Performance statistics

50
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
51
Patient Data Exchange
  • Event Monitoring
  • Messages represent Events
  • Events may be monitored for clinical alerting
  • Hard-coded rules, Medical Logic Modules (MLM)
  • Delivery and storage of alerts are interesting
    problems

52
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
53
Patient Data Exchange
  • Access Layer
  • Software modules for specific functions
  • Clinical repository functions
  • Alert rules database function
  • Data Access Modules
  • A layer that permits database independence
  • All DB related structures reside in this layer

54
Patient Data
ADT
Handling
Warehouse
Translation
Lab
Routing
Monitoring
Rad
Access
Workstation
ICU
Repository
DAMs
InterfaceEngine
Pharm
MLMs, Rules
Destinations
MED, Tables
Billing
HL7, formats
55
Health Care Middleware
  • Medical Entities Dictionary
  • Interface Engines
  • And other health communication engines
  • DICOM Brokers
  • Fax Brokers
  • Master Patient Index
  • Credentialing system
  • Health event monitoring and alerting system

56
Health Care Applications
  • Enterprise systems
  • Registration, Billing
  • HR, Materials, Gen Ledger, Payroll, etc.
  • Repositories (Inpatient, Outpatient)
  • PACS
  • Ancillary systems
  • Lab, Rad, Path, etc.
  • Devices and Modalities
  • Point Of Service
  • Diagnostic and Interventional devices
  • Drug or material dispensing devices
  • Monitoring devices, (cameras, HVAC sensors)

57
  • NYP CU WC Relationship picture

58
CUMC Health Care Systems
Web Browser Javascript
SunOne Web Server
IBM Mainframe CICS TPS DB2 database
CGI Programs (C)
2
HTTPS
SunOne Directory Server (LDAP)
Sockets Proprietary
MED Replica (Shmed)
1
2
59
CUMC Health Care Systems
Web Browser Javascript
SunOne Web Server
IBM Mainframe CICS TPS DB2 database
CGI Programs (C)
HTTPS
EKG Tracing Image Database
Sockets Proprietary
Reports
Images
Interface Engine
GE EKG System (MUSE)
60
CUMC Health Care Systems
Web Browser Javascript
SunOne Web Server
IBM Mainframe CICS TPS DB2 database
CGI Programs (C)
HTTPS
Sockets Proprietary
HL7
DB Replication
Interface Engine
Vigilence Alerting System (Monitoring)
HL7
61
CUMC Health Care Systems
Web Browser Javascript
SunOne Web Server
IBM Mainframe CICS TPS DB2 database
CGI Programs (C)
HTTPS
MED Replica (Shmed)
Sockets Proprietary
SFTP
Interface Engine
Jim Ciminos PC MED
MED Distribution Server
62
CUMC Health Care Systems
SunOne Web Server
IBM Mainframe CICS TPS DB2 database
CGI Programs (C)
Web Browser Javascript
SunOne Directory Server (LDAP)
HTTPS
Sockets Proprietary
Lab, Rad, Many others
Citrix Client
Authentication
Orders
Citrix ICA
Interface Engine
Eclipsys XA Order Entry (.com/.net)
Citrix Server
Lab, Rad, Pharmacy Results
63
Health Care Systems
IBM Mainframe CICS TPS DB2 database
Eclipsys SCC East campus
Interface Engine
DB2 Replication
Unix Warehouse Sybase database Research queries
Business Intelligence Systems
TIBCO
64
Electronic Master Patient Index
Eagle Registration System (East)
Eagle Registration System (West)
Interface Engine
ADT
ADT
EMPI Database
ADT
IDX Registration System (Univ)
Registration System M Hosp
Registration System Q Hosp
Query
Registration Workstation
Etc..
65
Overview
  • Architectural Concepts
  • Networking Concepts
  • Systems (Security)

66
Concepts of Info Security
  • Protect Electronic Protected Health Information
    (EPHI)
  • Confidentiality
  • Prevent unauthorized access or release of EPHI
  • Prevent abuse of access
  • Integrity
  • Prevent unauthorized changes to EPHI
  • Availability
  • Prevent service disruption due to malicious or
    accidental actions, or natural disasters.

67
Concepts of Info Security
  • There are NO perfectly secure information systems
  • We have to identify RISKS specific to an ASSET
    based upon possible THREATS, and then
  • Implement and modify SECURITY CONTROLS to reduce
    risks, so that
  • Residual risks are at an ACCEPTABLE level.
  • Threats may become security INCIDENTS, which lead
    to SANCTIONS and modified security controls
  • Acknowledge SECURITY CONTROLS and EASE OF ACCESS
    often work against each other

68
Risk Management Objects Relationships
Assets
value
have
Controls
costs
if imperfect, yield
Threats
Vulnerabilities
when realized,instantiate
potentiallyadd
potentiallyreduce
Risks
Incidents
quantify
resolve
criteria
Resolution
Measurement
re-evaluation(retroactively improve)
not acceptable(proactively improve)
may lead to
acceptable
Sanctions
69
Security Controls
  • Network/Host controls
  • Firewalls, Intrusion Detection/Prevention Systems
  • Secure Remote Access
  • Virtual Private Networks
  • VPN over SSL
  • Bandwidth monitoring
  • Anti-virus, Anti-spyware, Integrity checks
  • Etc.

70
Security Controls
  • Procedural Controls
  • Termination Control
  • Change Control
  • Disaster Recovery
  • Quarantine
  • Network
  • Application
  • Audits and Security Metrics
  • Single Authentication/Single Sign On
  • Etc.

71
Summary
  • There are measures of good health care systems
    in health care institutions
  • Understanding attributes of computing
    infrastructure is necessary to create good
    architectures and good systems
  • Healthcare computing is work in progress, its
    challenges are unique
Write a Comment
User Comments (0)
About PowerShow.com
