The Fermentation of Monosaccharides to make Ethanol

1
The Fermentation of Monosaccharides to make
Ethanol
Sandra Reynolds University Senior College
Dr Paul Grbin Wine Horticulture, University of
Adelaide
2
The Fermentation of Monosaccharides to make
Ethanol

• This material has been developed as a part of
  the Australian School Innovation in Science,
  Technology and Mathematics Project funded by the
  Australian Government Department of Education,
  Science and Training as a part of the Boosting
  Innovation in Science, Technology and Mathematics
  Teaching (BISTMT) Programme.

3
Fermentation of Monosaccharides

• To make Ethanol Subtopic 5.3
• ETHANOL IS DERIVED BY FERMENTATION OF GLUCOSE
  WHICH CAN BE DERIVED BY HYDROLYSIS OF COMPLEX
  CARBOHYDRATES.

4
(No Transcript)
5
The origins of wine-making are lost in
history. The earliest known beers were
brewed 6000 years ago in a country called
Sumer on the plains between the Tigris and the
Euphrates which is now part of Southern Iraq.
6
To pick grapes at the right pH is
important Too much makes the wine undrinkable To
o little gives a flat taste
7
Crushing Seeds stems are removed Grape juice
is called must.
8

• Sulphur dioxide has been used in winemaking for
  100s of years to control the growth of unwanted
  microorganisms.
• Sodium sulphite, sodium hydrogen sulphite and
  sodium metabisulphite are used.
• A wrong yeast strain can produce an aroma
  described as wet horse blankets, cow manure and
  plastic bandages!

9
Skins are removed from the must for white
wine. The skins give the red colour to red
wine!
10

• C6H12O6(aq) ? 2CH3CH2OH 2CO2FERMENTATION
  of monosaccharides using enzymes in yeast
• Conditions
• Anaerobic
• Yeast to provide enzymes
• Warmth, 20 to 30 deg. C
• pH less than 7
• Dilute aqueous

11
Saccharomyces cerevisiae the yeast that
provides our bread, wine and beer.Magnification
X 13,800
12
Skilled volumetric analysis determines the acid
content of wine.
13
Fractional Distillation of Wine to Produce
Spirits

• Maturation gives rise to new flavour components
  by many chemical changes and by extraction from
  oak casks.

14
Wine is Mostly Water Has Poor Keeping Qualities

• Fractional distillation of wine produces up to
  96 ethanol
• Spirits contain 52 95 ethanol and these are
  not attacked by microbes.
• 100 ethanol is called absolute alcohol an
  excellent preservative!

15
(No Transcript)
16
Australian brandy is double distilled
17
Cognac is triple distilled
18

Brandy whisky are matured in oak casks. Colour
and flavour components are extracted
19
Some 400 flavour components have been
identified in whisky.
20
Copper rum pump and rum measures to dispense
the daily tot on the Royal Yacht Britannia until
1970 when the rum issue was discontinued.
21
Her Majestys proof spirit
22
Australian wine ready for drinking
23
Beer Making

• Subtopic 5.3
• ETHANOL IS PRODUCED BY FERMENTATION OF GLUCOSE
  WHICH CAN BE DERIVED BY HYDROLYSIS OF COMPLEX
  CARBOHYDRATES.

24
To Make Ethanol in Beer

• THE WORLDS OLDEST RECIPE!
• WATER, MALT, HOPS, YEAST
• Beer is made by SOAKING malted barley with water,
  boiling it with hops cooling it and then letting
  the whole lot ferment and mature.
• This process was used at least 6000 years ago in
  Iraq to make ale bread.

25
Wine is usually made from fruits. These contain
simple sugars.Beer is made from grain barley
is best. Grains contain starch.

• Simple sugars are called MONOSACCHARIDES e.g.
• - Glucose (blood sugar, grape sugar)
• - Fructose, (fruit sugar)
• C6H12O6
• Double sugars are called DISACCHARIDES E.g.
• - Maltose
• - Sucrose
• - Lactose
• C12H22O11

26
Complex sugars are called POLYSACCHARIDES e.g. -
Starch (C6H10O5)n
27
Barley Contains Enzymes to Convert Starch into
Fermentable Sugars

• These are released when the grain is soaked in
  water allowed to germinate for several days at
  18oC.
• This is called BARLEY MALT
• The Sumerians baked this into barley bread.

28
Ground barley malt is soaked in water.This
revives the barley enzymes which break
polysaccharides into disaccharide.

• This reaction is called hydrolysis
• (C6H10O5)n ? C12H22O11

H2O
29
Boiling the Filtered Mixture Kill Germs
Deactivates Enzymes

• Boiling extracts bitter resin from the hops
  makes them soluble.
• Hops also act as a preservative

30
Fermentation
Yeasts are added to the cooled wort

• HYDROLYSIS
• C12H22O11 H2O ? 2C6H12O6
• OVERALL HYDROLYSIS
• (C6H10O5)n nH2O ? nC6H12O6
• FERMENTATION
• C6H12O6 ? 2C2H5OH 2CO2

Note Fermentation is an anaerobic process.
31
After maturing for several weeks at low several
for several weeks at low temperatures, the amber
liquid is filtered, ready for bottling or
kegging.
32
Making distilled spiritsThe word comes from
the latin destillaremeaning to drip
33
(No Transcript)
34
(No Transcript)
35
The Fate of Alcohol is Vinegar Acidic Wine
Vin Aigre F

• Acetobacter bacteria that can use O2 to
  metabolise alcohol extract energy from it.
• CH3CH2OH O2 ? CH3COOH H2O
• The ethanoic acid formed is a far more potent
  antimicrobial than ethanol .
• Vinegar came to be one of the most effective food
  preservatives of ancient and modern times.

36
Word List

• CARBOHYDRATES
• SIMPLE SUGAR
• DOUBLE SUGAR
• COMPLEX SUGAR
• GLUCOSE
• FRUCTOSE
• SUCROSE
• MALTOSE
• STARCH

• POLYSACCHARIDE
• HYDROLYSIS
• DISACCHARIDE
• HYDROLYSIS
• MONOSACCHARIDE
• FERMENTATION
• ANAEROBIC
• ETHANOL
• AEROBIC
• ENZYMES
• ETHANOIC ACID
