Chapter 4: Threads

1
Chapter 4 Threads
2
Chapter 4 Threads

• Overview
• Multithreading Models
• Threading Issues
• Pthreads
• Windows XP Threads
• Linux Threads
• Java Threads

3
Thread Definition

• A Thread is a basic unit of CPU utilization.
• A thread of execution.
• A placeholder information associated with a
  single use of a program that can handle multiple
  concurrent users
• Thread
• Lightweight process (LWP)
• Threads of instructions or thread of control
• Shares address space and other global information
  with its process
• Registers, stack, signal masks and other
  thread-specific data are local to each thread

4
Thread Composition

• A Thread is comprised of
• A thread ID.
• A program counter.
• A register set.
• A stack.

5
Process vs Threads

• A traditional or heavyweight process has a single
  thread of control.
• If a process has multiple threads of control, it
  can perform more than one task at a time, thus a
  thread is a lightweight process.

6
Single and Multithreaded Processes
7
Benefits

• Responsiveness
• A program may continue even if parts of it are
  blocked.
• Ex web browser loading some images while others
  take more time.
• Resource Sharing
• By default, threads share memory and the
  resources of the process to which they belong.
• Economy
• Easier to create and context switch between
  threads since they share resources.
• Utilization of MP Architectures
• Run multiple threads in parallel, taking
  advantage of multiple processors.

8
Benefits

• Takes less time to create a new thread than a
  process.
• Less time to terminate a thread than a process.
• Less time to switch between two threads within
  the same process.
• Since threads within the same process share
  memory and files, they can communicate with each
  other without invoking the kernel

9
Multithreading Modes

• Provided in different levels
• User Threads.
• Supported above the kernel and managed without
  kernel support.
• Kernel Threads.
• Supported and managed directly by the operating
  system.

10
User Threads

• Thread management done by user-level threads
  library.
• The kernel is not aware of the existence of
  threads.
• Three primary thread libraries
• POSIX Pthreads
• Win32 threads
• Java threads

11
Kernel Threads

• Supported by the Kernel
• Kernel maintains context information for the
  process and the threads
• Examples
• Windows XP/2000
• Solaris
• Linux
• Tru64 UNIX
• Mac OS X

12
Multithreading Models

• Many-to-One
• Maps many user-level threads to a single kernel
  thread.
• One-to-One
• Maps each user-level thread to a kernel thread.
• Many-to-Many
• Multiplexes many user-level threads to a smaller
  or equal number of kernel threads.

13
Many-to-One

• Many user-level threads mapped to single kernel
  thread.
• Thread management is done by the thread library
  in user space.
• Will block if thread makes a blocking system
  call.
• Multiple threads are unable to run in parallel on
  multiprocessors.
• Examples
• Solaris Green Threads
• GNU Portable Threads

14
Many-to-One Model
15
One-to-One

• Each user-level thread maps to kernel thread.
• Provides more concurrency allowing another thread
  to run when one makes a blocking system call.
• Allows multiple threads to run in parallel in
  multiprocessors.
• Developer must be careful not to make too many
  threads per application.
• Examples
• Windows NT/XP/2000
• Linux
• Solaris 9 and later

16
One-to-one Model
17
Many-to-Many Model

• Allows many user level threads to be mapped to
  many kernel threads.
• Allows the operating system to create a
  sufficient number of kernel threads.
• Developers can create as many threads as
  necessary.
• Solaris prior to version 9.
• Windows NT/2000 with the ThreadFiber package.

18
Many-to-Many Model
19
Two-level Model

• Similar to MM, except that it allows a user
  thread to be bound to kernel thread
• Examples
• IRIX
• HP-UX
• Tru64 UNIX
• Solaris 8 and earlier

20
Two-level Model
21
Thread State Life Cycle of a Thread

• Thread states
• Born state
• Ready state (runnable state)
• Running state
• Dead state
• Blocked state
• Waiting state
• Sleeping state
• Sleep interval specifies for how long a thread
  will sleep

22
Thread State Life Cycle of a Thread

• Thread Life Cycle

23
Thread Libraries

• A thread library provides the programmer an API
  for creating and mapping threads.
• Two ways of implementing a thread library
• Library entirely in user space with no kernel
  support.
• Invoking a function in the library results in a
  local call function not a system call.
• Kernel-level library supported directly by the
  operating system.
• Code and structures reside in kernel space.
• Invoking a function in the API typically results
  in a system call to the kernel.

24
Thread Libraries

• Three main libraries are used today
• POSIX Pthreads.
• User or kernel level.
• Win32.
• Kernel level only on windows systems.
• Java.
• Java programs.

25
Pthreads

• A POSIX standard (IEEE 1003.1c) API for thread
  creation and synchronization
• API specifies behavior of the thread library,
  implementation is up to development of the
  library
• Common in UNIX operating systems (Solaris, Linux,
  Mac OS X)
• Third party support for Windows Systems.
