Title: Snowboarding Poles


1
Snowboarding Poles
  • Tim Choate
  • Jeff Jones
  • Matt Kaloupek
  • Vicki Krapohl
  • Brian Schaaf

2
Project Definition
  • Collapsible Snow Boarding Pole
  • A product that alleviates the need for
    snowboarders to unlock their bindings while
    boarding.
  • The product must collapse down to fit
    comfortably.
  • It must be accessible and unobtrusive.
  • It must be comparable in performance and cost to
    other poles on the market.

3
Information Gathered
  • Many major corporations outsource their pole
    manufacturing to foreign countries
  • Mr. Charley French Ski Pole Engineer at Scott
    USA
  • Mr. Brian Jordan Head Engineer at Black Diamond
  • Adjustable poles for hiking already exist but not
    for the same purpose
  • Experience has shown that in these poles,
    twist-lock mechanism does not hold
  • The flick lock and oval shaft types are better
    and costlier.
  • Order placed for flick lock poles to reverse
    engineer and analyze

4
Information from Mr. French at Scott
  • For all of our pole designs we look at strength
    vs. weight vs. cost.
  • We do not use any computer simulation in the ski
    pole design or production.
  • They also have a minimum strength requirement,
    which is measured by athree-point bend test.

5
More Information from Scott
6
Black Diamond FlickLock Mechansim
  • Two- or Three-Piece adjustable pole
  • Patterned after a bicycles quick-release nut on
    wheel hubs and seat poles, the flick-lock works
    by clamping the larger, upper shaft around the
    smaller-diameter lower shaft of the pole with the
    security of a vice.
  • Adjusts by flipping open the plastic tab and
    tightening the screw.

7
Black Diamond Test Results
  • Three point load test
  • For the experiment we tested deflection vs. load.
  • Pole slipped at 120lbsf

8
Concept 1
  • Features
  • Telescoping pole with expandable pins to lock it
    in place. Twisting the handle retracts the pins
    allowing the pole to collapse.
  • Pros
  • Strong
  • Easy to extend and retract
  • Takes up little space
  • Cons
  • Complicated to build
  • Has many parts, so might break more easily
  • More expensive than other designs

9
Concept 2
  • Features
  • Under tension from an internal elastic, the pole
    is locked or unlocked by twisting.
  • Pros
  • Simple and Durable
  • Easy to Maintenance
  • Cons
  • Not Aesthetically Pleasing
  • Questionable Strength

10
Concept 3
  • Features
  • Medium strength magnetic lock for links
  • Only strong enough to support weight if
    compressed in appropriate direction
  • Pros
  • Easy to deploy and collapse
  • Simple and cheap to design
  • Cons
  • Will collapse if not used properly
  • Not as secure as other designs

11
QFD
12
Work Breakdown Structure
13
Gantt Chart
14
Product Architecture
15
Pole Measurements
16
More Views
17
Design Analysis
  • Buckling Analysis
  • Given length (l)135cm, diameter (d)14mm, and
    thickness (t)2mm

18
Design Analysis
  • Shear Stress
  • Given the pins are cylinders with 6.36mm
    diameter, and shear strength493MPA

19
Joint Stiffness
20
Material Evaluation
21
Material Evaluation
  • Aluminum
  • Pros-low cost and light weight
  • Cons-not as strong as other metals
  • Stainless Steel
  • Pros-low cost
  • Cons-heavier than other options and not as strong
  • Carbon Fiber
  • Pros-light weight and very strong
  • Cons-costly and very hard to manufacture
  • Titanium
  • Pros-light weight and strong
  • Cons-very costly and hard to find

22
Placement Evaluation
  • Store on lower leg
  • Scored the highest on the QFD
  • Biggest place on the body to store the test
  • Average female lower leg-18 inches
  • Average male lower leg- 20 inches
  • Can use the board to help lock the pole in place
  • Safest location

23
References
Alpinism Ice Climbing www.bdel.comBlack
Diamond Equipment, Ltd. - Rock Climbing,
Backcountry Skiing, Leki www.leki.com Life-Link
www.life-link.comMaclean Quality Composites
www.macac.com Metal Express www.metalexpress.net S
cott USA www.scottusa.com
