Edoardo Apr

1
Edoardo Aprà

• Materials Chemistry Applications on the ORNL XT3

2
Acknowledgments

• Part of this work is funded by the U.S.
  Department of Energy, Office of Advanced
  Scientific Computing Research and by the division
  of Basic Energy Science, Office of Science, under
  contract DE-AC05-00OR22725 with Oak Ridge
  National Laboratory.
• This research used resources of the National
  Center for Computational Sciences at Oak Ridge
  National Laboratory under contract
  DE-AC05-00OR22725.

3
Motivation

• CHM022 Incite Allocation
• The Chemical Endstation brings together
  researchers from 12 academic and government
  laboratories representing research projects
  funded by DOE, NSF and other agencies, with the
  common interest in the rational design of
  catalysts

4
Scalable and Accurate First Principles Method
Atomistic Methods
5
Application Software

• Plane-wave basis
• CPMD, VASP, Dacapo, Espresso, Parsec
• Gaussian basis
• NWChem

6
The Quantum-ESPRESSO Software Distribution

• Quantum-ESPRESSO stands for Quantum opEn-Source
  Package for Research in Electronic Structure,
  Simulation, and Optimization
• An initiative by DEMOCRITOS (Trieste), in
  collaboration with
• CINECA Bologna,
• Princeton University, EPFL,
• MIT Boston, and many other individuals, aimed at
  the development of
• high-quality scientic software
• Released under a free license (GNU GPL)
• Written in Fortran 90, with a modern approach
• Efficient, Parallelized (MPI), Portable
• Integrated suite of computer codes for
  electronic-structure calculations and materials
  modeling at the nanoscale

7
The Quantum ESPRESSO suite of ab-initio codes

• PWscf (Trieste, Lausanne, Pisa) self-consistent
  electronic structure, structural relaxation, BO
  molecular dynamics, linear-response (phonons,
  dielectric properties)
• CP (Lausanne, Princeton) (variable-cell)
  Car-Parrinello molecular dynamics
• FPMD (Trieste, Bologna) also (variable-cell)
  Car-Parrinello molecular dynamics
• Plus a number of utilities for graphical input
  (GUI), molecular graphics (XCrysDen), output
  postprocessing, including
• Wannier-function generation, pseudopotential
  generation, etc.

8
QE - Technical characteristics (algorithms)

• use of iterative techniques the Hamiltonian is
  stored as operator, not as matrix. All standard
  PW technicalities FFT, dual-space, etc., are
  used.
• Iterative diagonalization used whenever it is
  useful.
• fast double-grid" implementation for ultrasoft
  PP's the cutoff for the augmentation part can be
  larger (the corresponding FFT grid denser in real
  space) than the cutoff for the smooth part of the
  charge density. CP only very fast box grid"
  implementation.
• Parallelization is performed on both PW's and
  FFT grids, using a parallel 3D FFT algorithm
  having good scaling with the number of processors
  (memory use also scales)
• Parallelization on k-points is also available by
  dividing the processors into pools" and dividing
  k-points across pools of processors

9
QE - Technical features (implementation)

• Written mostly in fortran 90, with some degree of
  sophistication (advanced f90 features).
• Portable optimization achieved by extensive use
  of standard (and free!) mathematical libraries
  (FFTW, BLAS, LAPACK)
• c-style pre-processing options allow to maintain
  various
• architecture-dependent features on a same tree
• Parallelization via MPI calls hidden in very few
  routines allow for an easy maintenance of a
  unified serial/parallel code
• Easy (or not-so-difficult) installation via the
  GNU configure utility

10
QE - CP code

• Car-Parrinello variable-cell molecular dynamics
  with Ultrasoft PPs.
• Developed by Alfredo Pasquarello (IRRMA,
  Lausanne), Kari Laasonen (Oulu), Andrea Trave
  (LLNL), Roberto Car (Princeton), Nicola Marzari
  (MIT), Paolo Giannozzi, and Carlo Cavazzoni,
  Gerardo Ballabio (CINECA), Sandro Scandolo
  (ICTP), Guido Chiarotti (SISSA), Paolo Focher.
• Verlet dynamics with mass preconditioning
• Temperature control Nosé thermostat for both
  electrons and ions, velocity rescaling
• variable-cell (Parrinello-Rahman) dynamics
• Damped dynamics minimization for electronic and
  ionic minimization
• Modified kinetic functional for constant-pressure
  calculations
• Grid Box for fast treatment of augmentation
  terms in Ultrasoft PPs
• Metallic systems variable-occupancy dynamics
• Nudged Elastic Band (NEB) for energy barriers and
  reaction paths
• Dynamics with Wannier functions
• Limitations
• no k-points

11
PWSCF code

• Developed by S. Baroni, S. de Gironcoli, A. Dal
  Corso (SISSA), PG, and others.
• Self-consistent ground-state energy and Kohn-Sham
  orbitals, forces, structural optimization
• Spin-orbit and non-collinear magnetization
• Molecular dynamics on the ground-state
  Born-Oppenheimer surface
• Variable-cell molecular dynamics with modified
  kinetic functional
• Phonon frequencies and eigenvectors at a generic
  wave vector. interatomic force
• constants in real space, effective charges and
  dielectric tensors, electron-phonon
• interaction coefficients for metals
• Macroscopic polarization via Berry Phase
• Nudged Elastic Band, Fourier Strings Method
  schemes for transition paths,
• energy barriers
• Third-order anharmonic phonon lifetimes,
  nonresonant Raman cross sections
• Limitations
• no Car-Parrinello dynamics
• very limited constrained minimization and dynamics

12
Flow chart
13
Basics of Plane Wave Method
Core electrons are removed through the
pseudopotential generation, thus only treat the
valence electrons

• Important advantages
• Planewave basis can be performed on a discrete
  numerical grid
• Can use preconditioned conjugate gradient
  iterative techniques

14
Computational Techniques and Libraries

• Fast Fourier Transforms
• Machine library or FFTW
• Diagonalization
• Direct methods
• Preconditioned iterative methods (CG)
• Dense Linear Algebra
• LAPACK and BLAS

15
FFT Decomposition

• Data Structure
• Global array N x N x N
• Local array N x N x (N/p)
• Algorithm
• Perform local FFT along X
• Perform local FFT along Y
• Transpose array to get Z values on local memory
• Perform local FFT along Z
• Complexity
• No. of FFTs per cpu N2/p
• FFT FLOPS 5 x N x log2(N)

16
Cray XT3 Scaling

• Vienna Ab-initio Simulation Package (VASP)
• Based on BCC Cu
• Single k-point (0.0,0.0,0.0)
• 400 eV Plane wave cutoff
• Small system sizes
• Forward and backward FFT transform
• Large system sizes
• Davidson diagonalization
• Forward and backward FFT transform

17
Cray XT3 Scaling (fixed system size)

• Fixed number of plane waves
• Changing the number of plane waves per processor
• Optimal density of atoms/node
• For the Buckyball 1.9 atoms/node
• Thus, to run a 1000 atom system optimally would
  require 500 processors

18
Quantum Espresso Performance
Cray-XT3 located in the NCCS at ORNL
2-16 N 16-54 N-N2 54-128 N2
19
Quantum Espresso Performance
Roberto Ansaloni, Cray Workshop on
High-Performance Computing ETH-Zurich-September
4-5, 2006
20
Porphyrin Functionalized Nanotube

• New materials for solar energy applications
• Relatively simple, synthetically feasible (at
  ORNL-UT) mimics of light-harvesting antenna units
• Porphyrin molecules are the light absorbing
  antenna and the nanotube may provide a conducting
  channel (or at least an electron acceptor)
• Key questions
• Do the covalently attached porphyrins undergo
  facile absorption of visible light and transfer
  electrons onto the tube
• What types of efficiencies does one obtain

21
Porphyrin Functionalized Nanotube

• Problem size ranges from 1532 atoms ( 60 Å) to
  6128 atoms ( 202 Å by 60 Å)
• Key research question to address are
• How does porphyrin attach to the nanotube
• How does the electronic structure change as
  porphyrin molecules are added to the nanotube (
  up to 22 by weight has been observed
  experimentally
• How is the conductance affected by surface
  orientation and composition

22
Problem Requirements

• Lattice constant approximately z-381.72 a.u.,
  x,y-113.38 a.u.
• Approximately 6128 atoms (C,N,O, H)
• Energy cut-off 25 Ryd.
• Produces a mesh (608x180x180)19,699,200
• Number of states 10,464
• RAM for Hamiltonian Matrix (10,464)2161.6
  Gbytes ( or .16 Mbytes per processor on 10,000
  processors)
• Store the double precision real
  wavefunction/k-point 19,699,2001046418
  1.6 Tbytes
• On 10,000 processors this would require .16
  Gbytes/processor
• This would require a bandwidth of 30
  Gbytes/sec to read in or write out data in 1
  minute
• Store the double precision real charge density
  would require .16 Gbytes
• For a 1532 atom system divide all numbers by 4

23
Espresso - XT4 Benchmark
24
PARSEC

• computer code that solves the Kohn-Sham equations
  by expressing electron wave-functions directly in
  real space, without the use of explicit basis
  sets.
• uses norm-conserving pseudopotentials (e.g.
  Troullier-Martins).
• designed for ab initio quantum-mechanical
  calculations of the electronic structure of
  matter, within Density-Functional Theory (DFT).

25
http//www.ices.utexas.edu/parsec
Features

• High order finite difference expansion of
  differential operators (Hamiltonian matrix is
  sparse).
• Scalability in parallel environment.
• Confined and periodic boundary conditions.
• Molecular dynamics.
• Open Source

26
Algorithm

• Wave-functions ?i(r) are calculated on a grid.
• Regular grid (cartesian for simplicity).
• Laplacian evaluated using finite differences.
• Code parallelized w.r.t. to number of grid
  points.
• Source code fortran 95.

27
Chebyshev subspace filtering
Given a set of basis vectors ?i, filter
according to ?i Pm(H) ?i Pm Chebyshev
polynomial of degree m. Vectors ?i will have
their projection onto the desired subspace
enhanced.
Window for Filtering
28
Traditional Approach
Most of the time is spent on the diagonalization
part. One can use ARPACK, variant of the Lanczos
algorithm, or other exact eigensolvers.
29
Kohn-Sham SCF with filtering
Exact diagonalization.
Chebyshev filtering, much faster than exact
diagonalization.
30
PARSEC model input

• Si2713PH828
• Silicon nanocrystal, prototypical semiconductor
  nanocrystal
• surface passivated with hydrogen atoms
• P atom adds three degenerate levels very close to
  the LUMO, making the nanocrystal itself virtually
  gap-less. Study the properties of p-doped silicon
  nanocrystals

31
Parsec XT4 Benchmark
32
Performance - Summary

• TFlops Cores Sust Scalab
• RMG 7.78 4,096 36.5 50
• Espresso 7.68 4,096 36 50
• PARSEC 7.45 4,096 35 50

33
Why Was NWChem Developed?

• Developed as part of the construction of the
  Environmental Molecular Sciences Laboratory
  (EMSL) at Pacific Northwest National Lab
• Designed and developed to be a highly efficient
  and portable Massively Parallel computational
  chemistry package
• Provides computational chemistry solutions that
  are scalable with respect to chemical system size
  as well as MPP hardware size

34
What is NWChem used for?

• Provides major modeling and simulation capability
  for molecular science
• Broad range of molecules, including biomolecules,
  nanoparticles and heavy elements
• Electronic structure of molecules
  (non-relativistic, relativistic, structural
  optimizations and vibrational analysis)
• Increasingly extensive solid state capability
  (DFT plane-wave, CPMD)
• Molecular dynamics, molecular mechanics

35
Molecular Science Software Group
36
GA Tools Overview

• Shared memory model in context of distributed
  dense arrays
• Complete environment for parallel code
  development
• Compatible with MPI
• Data locality control similar to distributed
  memory/message passing model
• Extensible and scalable
• Compatible with other libraries ScaLapack,
  Peigs,
• Parallel and local I/O library (Pario)

37
Structure of GA
F90
Java
Application programming language interface
Fortran 77
C
C
Babel
Python
distributed arrays layer memory management, index
translation
Global Arrays and MPI are completely
interoperable. Code can contain calls to both
libraries.
Message Passing Global operations
ARMCI portable 1-sided communication put,get,
locks, etc
system specific interfaces LAPI, GM, threads,
QSnet, IB, SHMEM, Portlals
38
NWChem Architecture

• Object-oriented design
• abstraction, data hiding, APIs
• Parallel programming model
• non-uniform memory access, Global Arrays, MPI
• Infrastructure
• GA, Parallel I/O, RTDB, MA, Peigs, ...
• Program modules
• communication only through the database
• persistence for easy restart

39
Gaussian DFT computational kernelEvaluation of
XC potential matrix element
my_next_task SharedCounter() do i1,max_i
if(i.eq.my_next_task) then call ga_get()
(do work) call ga_acc()
my_next_task SharedCounter() endif
enddo barrier()
r(xq) ?mn Dmn ?k(xq) ?n(xq) Fls ?q wq
?l(xq) Vxcr(xq) ?s(xq)
Both GA operations are greatly dependent on the
communication latency
40
NWChem Porting issues on the XT3

• Re-use of existing serial port for x86_64
  (compilers)
• Communication library GA/ARMCI
• Two ARMCI ports CRAY-SHMEM Portals
• Made Pario library compatible with Catamount
  (using glibc calls)

41
NWChem Porting - II

• Stability issue with SHMEM port
• Uncovered portal problem Cray SHMEM group
  provided workaround
• NWChem crashes the whole XT running large jobs
• Performance of SHMEM port
• Latency 10 ?sec
• BW
• Contiguous put/get 2GB/sec
• Strided put/get 0.3GB/sec
• ARMCI using Portal in progress

42

H2O7 287 Basis functions aug-cc-pvdz MP2 Energy
Gradient
43

Replicated Data vs. Distributed Data on XT3

Si28O67H30 1687 Basis f. LDA wavefunction
44

Parallel scaling of the DFT code of NWChem

Si28O67H30 1687 Basis f. LDA wavefunction
45

Si28O148H66 3554 Basis functions LDA
wavefunction
46

Si159O264H110 7108 Basis functions LDA
wavefunction
47

Si159O264H110 7108 Basis functions GGA
wavefunction
48
Thanks

• NWChem group and GA Group - PNNL
• Bill Shelton Bobby Sumpter - ORNL
• Roberto Ansaloni Cray
• Murilo Tiago and Jim Chelikowsky University of
  Texas
• Carlo Cavazzoni Cineca and the rest of the
  Quantum Espresso developers

49
Backup
50
Non-Blocking Communication

• Allows overlapping of communications and
  computations
• resulting in latency hiding
• Non-blocking operations initiate a communication
  call and then return control to the application
  immediately
• operation completed locally by making a call to
  the wait routine

51

Si159O264H110 7108 Basis functions LDA
wavefunction 2 SCF cycles Benchmark run
on Itanium2/Elan4
52
Recent improvements in algorithm

• Use symmetry operations and reduce the real-space
  domain to an irreducible wedge.
• Tiago Chelikowsky, in preparation
• Replace numerical diagonalization with Chebyshev
  subspace filtering
• Zhou et al., J. Comp. Phys. in press(2006)

In 1997, a SCF calculation of Si525H276 took 20
hours of CPU time on the Cray T3E (300 MHz) using
48 processors. Today, it takes 2 hours on one SGI
Madison processor (1.3 GHz).
Impact in real calculations
53
(No Transcript)
