Title:


1
Probabilistic SurfacesPoint Based Primitives
to Show Surface Uncertainty
Authors Gevorg Grigoryan and Penny
Rheingans Presented by Allan Spale, Spring 2004
2
Uncertainty Is Inevitable
  • Technical fields have measurements with an amount
    of uncertainty
  • Example 25 mm /- 2 mm
  • Visualizations require a merging of the main data
    being displayed in addition to the uncertainty
    values
  • Especially crucial when decision-making must be
    done by users of the visualization

3
Traditional Uncertainty Visualization
  • Examples
  • Vertical bars on bar graphs
  • Probability density curves and surfaces
  • Adjacent displays of data and its uncertainty
  • Problem
  • Does not scale well to multidimensional data

4
Uncertainty VisualizationDiscrete Points
  • Examples
  • Glyphs 12,16 sonification (sound used to
    convey data) 7, 9, 11 discrete point
    distribution 14 procedural annotation 2
  • Advantage
  • Useful sampling
  • Disadvantage
  • Using discrete points limits its application to
    continuous domains

5
Uncertainty VisualizationPseudo-coloring
  • Example
  • Coloring a mountain range to show the likelihood
    of an avalanche or mud slide
  • Advantage
  • Uncertainty displayed continuously
  • Disadvantages
  • Uncertainty relates to a variable, not to a
    single point or group of points
  • Disconnect between uncertainty and geometry
  • Further reading in 17

6
Uncertainty VisualizationGeometry Modification
  • Examples
  • Fat surfaces (surfaces with thickness) 1, 12
  • Displaced/perturbed geometry 10, 12
  • Animation 4,
  • IFS (iterated function system) fractal
    interpolation 18
  • Advantages
  • Fat surfaces illustrate potential range of data
    point locations
  • Animation easy to detect uncertainty
  • Fractals good for introducing geometric
    variability
  • Disadvantages
  • Animation not printable to paper, motion
    distracts from other variables

7
Uncertainty VisualizationProbabilistic Surfaces
  • Application
  • MRI of brain showing probabilities of cancerous
    tumor boundaries
  • Requirements to be successful
  • Information about both surface geometry and
    regional uncertainty
  • Intuitive and not distracting
  • Display of other variables in addition to
    uncertainty

8
Tumor Growth ModelGeneral Information
  • Gompertz model 15
  • V(t) V(0) exp( A/B ( 1 exp( -Bt ) ) )
  • Parameters
  • V(0) initial volume of tumor at time t 0
  • A, B tumor growth parameters
  • Trends
  • t ? (as t approaches infinity)
  • A/B final tumor size
  • B rate of initial growth
  • Used to build a large tumor from small tumors
    dispersed in a region

9
Tumor Growth ModelUncertainty
  • Uncertainty equation
  • d (V(t))/d t V(0) exp( A/B ( 1 exp( -Bt ) )
    ) A exp( -Bt )
  • V(t) A exp( -Bt )
  • Equation information
  • Growth rate proportional to current tumor volume
    and an exponentially decaying term
  • Inverse proportionality between cell density and
    uncertainty
  • High cell density ? low uncertainty

10
Tumor Growth ModelUncertainty
  • Uncertainty equation
  • d (V(t))/d t V(0) exp( A/B ( 1 exp( -Bt ) )
    ) A exp( -Bt )
  • V(t) A exp( -Bt )
  • Equation information
  • t ? (as t approaches infinity)
  • Uncertainty ? 0
  • Growth rate ? 0
  • Tumor reaches a constant volume

11
Tumor Growth ModelMetastasis
  • Description
  • As cancer develops, cells separate from tumor
  • Cells travel in blood vessels and settle in a new
    place
  • Parameter in the growth model
  • At an increasing time interval d t, tumor size
    increases
  • At some size threshold, metastasis occurs
  • New tumor center created at a random distance
    from the origin in the direction of the blood
    vessel flow
  • Output as age along with an uncertainty value

12
Geometry Alone vs.Geometry with Uncertainty
13
Approach toUncertainty Points
  • For each surface point, displace it along the
    surface normal of the point
  • Point displacement is proportional to the points
    uncertainty value
  • Reasons to use points instead of polygons
  • Levoy Whitted (1985) pioneered the use of
    points as display primitives (paper reference
    8)
  • Increasing scene complexity reduces algorithm
    design complexity
  • Do not have to consider surfaces at polygons

14
Improved Approach toUncertainty Points
  • Transparency is appropriate for displaying
    uncertainty
  • High uncertainty ? high transparency
  • Result
  • Highly uncertain regions will contain points with
    blurriness and large displacements

15
ImplementationInitialization
  • Read in surface and uncertainty information
    (polygon mesh with uncertainty data at vertices
    uncertainty values between 0 and 1)
  • Note The text for all implementation steps are
    directly quoted from the paper.

16
ImplementationCreating Random Points
  1. Create N random points inside each triangle (user
    is able to control the density of points)
  2. Interpolate uncertainty values and normals from
    the vertices of the triangle onto each point in
    each triangle

17
ImplementationCalculating Displacement
  • For each point P do
  • Calculate the displacement
  • disp rand( )
  • ( uncertainty at P )a
  • ( scale factor )
  • rand() returns a random number between the values
    of 0 and 1
  • a and scale factor are controlled by the user

18
Implementation Point Displacement Transparency
  • For each point P do
  • Displace P in the direction of the normal at P
  • Calculate the transparency, alpha
  • alpha 1
  • ( uncertainty at P )b
  • b is controlled by the user

19
ImplementationOptional Pseudo-coloring
  • For each point P do
  • Pseudo-coloring
  • If pseudo-coloring is enabled, assign the color
    of P by mapping the uncertainty at P through the
    current color map
  • Otherwise, assign the default color
  • End loop

20
ImplementationDisplaying the Primitives
  • Display all points
  • Polygons
  • If polygonal model usage is enabled, display
    all the polygons

21
Implementation Results
  • Simplest version
  • Certain and uncertain areas are clearly displayed
  • The uncertainty area of the tumor boundary is
    clearly defined
  • Size of region proportional to level of
    uncertainty
  • Best suited for interactive display
  • Disadvantage
  • Artifacts difficulty making dense areas smooth

Certain Region
Uncertain Region
22
EnhancementAdding Polygonal Rendering
  • Improving computational efficiency
  • Use point rendering for uncertain areas
  • Use polygonal rendering for certain areas
    regardless of its point density
  • Advantages
  • Well-defined low uncertainty areas
  • More pleasing to view and more informative

Certain Region
Uncertain Region
23
EnhancementAdjusting Transparency
  • Adjust transparency according to uncertainty
    level using the equation
  • a 1.0 err c
  • err uncertainty value scaled from 0 to 1
  • c rate that transparency increases with
    uncertainty constant value

24
Reviewing Uncertainty Visualization Requirements
  • Informative
  • Polygonal (certainty) and point (uncertainty)
    rendering
  • Intuitive/not distracting
  • Transparency value uncertainty value
  • Additional information
  • Inclusion of tumor age
  • Correlation between tumor age and uncertainty
  • Seemingly contradictory items (blue, green
    arrows) remain valid for Equation 2

25
Application to Diagnostic Data
  • Datasets of CAT scan of human kidney tumors
  • Creation of the visualization
  • Input
  • Each point is in 3-D with a density value
  • Output
  • Geometry used isovalue of tumor density to
    create the isosurface volume
  • Certainty at the tumor surface, used inverse
    density gradient
  • Results
  • High density gradient ? sharp border
  • Low density gradient ? fuzzy border
  • Certainty data coexists with geometry data
  • Scalable to larger datasets

26
Images of Diagnostic Data
  • Red arrows ? high uncertainty blue arrows ? low
    uncertainty

27
Performance Tests
  • System
  • Red Hat Linux 6.1, Intel 1 GHz, 256 MB RAM,
    NVIDIA GeForce3 graphics card
  • Metrics
  • Polygons Polygon count in the model
  • Density Points per single polygon in point-based
    model
  • Points Point count in the model
  • Display Time for displaying model after finished
    calculations
  • Build Time for generating all primitives,
    calculating, etc.
  • Miscellaneous information
  • Figure 3 Basic point-based model
  • Figure 4 Hybrid polygonal-point model
  • Use of transparency does not affect running time

28
Performance Data (from Table 1)
FFigure, POLYPolygons, DENDensity, PTPoints,
DISPDisplay, BBuild
F1 POLY18,532 DN/A PTN/A DISP0.034
B0.034
F5 POLY18,532 D20 PT370,640 DISP0.16
B1.33
F2 POLY18,532 DN/A PTN/A DISP0.034,
B0.033
F6 POLY28,088 D20 PT561,176 DISP0.25
B2.02
F3 POLY18,532 D100 PT1,853,200 DISP0.61
B5.9
F7 POLY26,486 D20 PT529,720 DISP0.32
B2.78
F4 POLY18,532 D20 PT370,640 DISP0.16
B1.33
F8 POLY75,248 D30 PT2,257,440 DISP0.89
B7.2
29
Summary Future Work
  • Point-based model for uncertainty visualization
    is successful
  • Geometry and uncertainty data can coexist
  • Adding polygonal mesh increases run-time
    efficiency
  • Use of transparency creates an intuitive model
  • Future improvements
  • More parameters to display uncertainty
  • Specular coefficient
  • Refractive index

30
Thanks for listening
31
Paper References
  • 1 R.E. Barnhill, K. Opitz, and H. Pottmann. Fat
    surfaces A trivariate approach to triangle-based
    interpolation on surfaces. Computer Aided
    Geometric Design, 9(5)365378, 1992.
  • 2 Andrej Cedilnik and Penny Rheingans.
    Procedural annotation of uncertain information.
    In Proceedings of IEEE Visualization 00, pages
    7784. IEEE, 2000.
  • 3 Baoquan Chen and Minh Xuan Nguyen. POP A
    hybrid point and polygon rendering system for
    large data. In Proceedings of Visualization 2001,
    pages 4552. IEEE, 2001.
  • 4 C.R. Ehlschlaeger, A.M. Shortridge, and M.F.
    Goodchild. Visualizing spatial data uncertainty
    using animation. Computers in GeoSciences,
    23(4)387395, 1997.
  • 5 Markus Gross. Are points the better graphics
    primitives? Computer Graphics Forum, 20(3),
    2001.
  • 6 A.R. Kansal, S. Torquato, G.R.IV Harsh, E.A.
    Chiocca, and T.S. Deisboeck. Simulated brain
    tumor growth dynamics using a three-dimensional
    cellular automaton. Journal of Theoretical
    Biology, 203367382, 2000.
  • 7 Gregory Kramer. Auditory Display,
    Sonification, Audification, and Auditory
    Interfaces, pages 178. Addison-Wesley, 1994.
  • 8 Marc Levoy and Turner Whitted. The use of
    points as a display primitive. Technical Report
    85-022, University of North Carolina at Chapel
    Hill, January 1985.
  • 9 S. K. Lodha, C. M. Wilson, and R. E. Sheehan.
    LISTEN sounding uncertainty visualization. In
    Proceedings of Visualization 96, pages 189195.
    IEEE, 1996.

32
Paper References
  • 10 Suresh Lodha, Robert Sheehan, Alex Pang, and
    Craig Wittenbrink. Visualizing geometric
    uncertainty of surface interpolants. In
    Proceedings of Graphics Interface, pages 238
    245, May 1996.
  • 11 R. Minghim and A.R. Forrest. An illustrated
    analysis of sonification for scientific
    visualization. In Proceedings of Visualization
    95, pages 110117. IEEE, 1995.
  • 12 A. T. Pang, C. M. Wittenbrink, and S. K.
    Lodha. Approaches to uncertainty visualization.
    The Visual Computer, 13(8)370 390, 1997.
  • 13 Hanspeter Pfister and Jeroen van Baar.
    Surfels Surface elements as rendering
    primitives. In Kurt Akele, editor, Proceedings of
    SIGGRAPH 2000, pages 335342. ACM SIGGRAPH,
    Addison Wesley Longman, July 2000.
  • 14 P. Rheingans and S. Joshi. Visualization of
    molecules with positional uncertainty. In E.
    Groller, H. Loffelmann, and W. Ribarsky,
    editors, Data Visualization 99, pages 299306.
    Springer-Verlag Wien, 1999.
  • 15 G.G. Steel. Growth Kinetics of Tumors.
    Oxford Clarendon Press, 1977.
  • 16 C. M. Wittenbrink, A. T. Pang, and S.K.
    Lodha. Glyphs for visualizing uncertainty in
    vector fields. IEEE Transactions on Visualization
    and Computer Graphics, 2(3)226279, 1996.
  • 17 C.M. Wittenbrink, A.T. Pang, and S. Lodha.
    Verity visualization Visual mappings. Technical
    Report UCSC-CRL-95-48, University of California
    Santa Cruz, 1995.
  • 18 Craig M. Wittenbrink. IFS fractal
    interpolation for 2D and 3D visualization. In
    Proceedings to Visualization 95, pages 7784.
    IEEE, October November 1995.

33
Credits and References
  • Non-paper sources
  • Microsoft Excel 2000, Help Error bars in
    charts
  • Microsoft Excel 2000, Help Examples of Chart
    Types XY Scatter
  • Paper sources
  • All images labeled figure
  • Internet
  • IFS http//www.cse.ucsc.edu/research/slvg/ifs.htm
    l
  • Fat Surfaces http//www.ticam.utexas.edu/reports/
    1999/9908.pdf

34
Questions and Comments
Write a Comment
User Comments (0)
About PowerShow.com
