German Military Aircraft of WWII

1
German Military Aircraft of WWII
By Teach 1
2
Part One Fighters
Messerschmitt Me-109 Fighter
3
(No Transcript)
4
(No Transcript)
5
General Specifications Aircraft Type
Fighter Manufacturer Messerschmitt AG Crew Size
1 Weaponry 2 machine guns (7.9mm)2 cannons
(20mm) Maximum Weight 7,500 lbs
Dimensions Length 28 ft. 3.75 in. Height 8
ft. 6 in. Wingspan 32 ft. 6.5 in.
Propulsion Number of Engines 1 Powerplant
Liquid-cooled Daimler-Benz DB 605A-1
twelve-cylinder inverted-vee engine Horsepower
1,475 hp Performance Range 425 miles
loaded Maximum Speed 387 mph Maximum Altitude
38,500 ft
6
Messerschmitt Me-110 Fighter
7
(No Transcript)
8
Me-110s over southern England
9
General Specifications Aircraft Type Night
fighter Manufacturer Messerschmitt AG Crew Size
2 Weaponry 2 machine guns (7.9mm)4 cannons (2
20mm and  2   30mm)1,540 pounds of bombs Gross
Weight 20,730 lbs (9,391 kg) Dimensions
Length 41 ft. 7 in. Height 13 ft. 1 in.
Wingspan 53 ft. 5 in. Propulsion Number of
Engines 2 Powerplant Liquid-cooled Daimler-Benz
DB 605B twelve-cylinder engines Horsepower 1,475
hp each Performance Range 1,310 miles Maximum
Speed 341 mph Maximum Altitude 26,070 ft
10
Focke-Wulf FW-190 Fighter
11
(No Transcript)
12
(No Transcript)
13
General Specifications Aircraft Type
Fighter Manufacturer Focke-Wulf Flugzeugbau
GmbH Crew Size 1 Weaponry 2 machine guns
(7.9mm)4 cannons (20mm) Gross Weight 8,770
pounds Dimensions Length 28 ft. 11.64 in.
Wingspan 34 ft. 5 in. Propulsion Number of
Engines 1 Powerplant BMW 801D-2 air-cooled
fourteen-cylinder radial engine Horsepower 1,700
hp Performance Range 525 miles loaded Maximum
Speed 382 mph Maximum Altitude 34,780 ft.
14
Junkers Ju-87 "Stuka" Fighter
15
(No Transcript)
16
(No Transcript)
17
General Specifications Aircraft Type Fighter,
dive-bomber and tank buster Manufacturer Junkers
Flugzeug und Motorwerke AG Crew Size 1 Weaponry
4 machine guns (7.9mm)2 optional 37-mm underwing
cannon2,205 pounds of bombs Gross Weight 12,600
pounds Dimensions Length 37 ft. 8.75 in.
Height 12 ft. 9.125 in. Wingspan 45 ft. 3.3
in. Propulsion Number of Engines 1 Powerplant
Junkers Jumo 211J-1 twelve-cylinder inverted-vee
liquid-cooled engine Horsepower 1,400
hp Performance Range 620 miles loaded Maximum
Speed 255 mph Maximum Altitude 23,950 ft
18
Messerschmitt Me-262 Fighter
19
(No Transcript)
20
(No Transcript)
21
General Specifications Aircraft Type
Fighter Manufacturer Messerschmitt AG Crew Size
1 Weaponry Four 30-mm MK 108 cannon in
nose Maximum Weight Empty 8,378 lbs., Max
Takeoff 14,110 lbs. Dimensions Length 34ft.
9.5in. Height 12ft. 7in. Wingspan 40ft. 11.5in.
Propulsion Number of Engines 2 Powerplant
1,984-pound thrust Junkers Jumo 004B-1/-2/-3
turbojets Performance Range 652 miles
loaded Maximum Speed 540 mph Maximum Altitude
37,565 ft.Number Built 1,433
22
Part Two Bombers
Heinkel He 111
23
(No Transcript)
24
(No Transcript)
25
General Specifications Aircraft Type Medium
(torpedo) bomber Manufacturer Ernst Heinkel
AG Crew Size 4 Weaponry 6 machine guns
(7.9mm)1 cannon (20mm)5,510 pounds of bombs or
2 LT 950 torpedoes Gross Weight 25,000 pounds
Dimensions Length 54 ft. 5.5 in. Height 13
ft. 9 in. Wingspan 74 ft. 1.5 in.
Propulsion Number of Engines 2 Powerplant
Junkers Jumo 211F-2 twelve-cylinder
liquid-cooled engines Horsepower 1,340 hp
each Performance Range 760 miles
loaded Maximum Speed 258 mph Maximum Altitude
25,500 ft
26
Dornier Do-17 Bomber
27
(No Transcript)
28
(No Transcript)
29
General Specifications Aircraft Type Medium
bomber Manufacturer Dornier Werke GmbH Crew
Size 4 Weaponry 6 machine guns (7.9mm)2,200
pounds of bombs Gross Weight 18,832 pounds
Dimensions Length 53 ft. 3.75 in. Height 15
ft. 1 in. Wingspan 59 ft. Propulsion Number
of Engines 2 Powerplant Bramo 323P super-
charged radial engines Horsepower
1,000 hp each Performance Range 745 miles
loaded Maximum Speed 263 mph Maximum Altitude
26,740 ft.
30
Junkers Ju-88 Bomber
31
(No Transcript)
32
(No Transcript)
33
General Specifications Aircraft Type Medium
bomber Manufacturer Junkers Flugzeug und
Motorwerke AG Crew Size 4 Weaponry 2 machine
guns (13mm)4 machine guns (7.9mm)6,614 pounds
of bombs Gross Weight 26,700 lbs
Dimensions Length 47 ft. 1.5 in. Height 15
ft. 11 in. Wingspan 65 ft. 10.5 in.
Propulsion Number of Engines 2 Powerplant
Junkers Jumo 211J-1
twelve-cylinder inverted-vee liquid-cooled
engines Horsepower 1,400 hp each Performance Ra
nge 650 miles loaded Maximum Speed 273
mph Maximum Altitude 27,880 ft
34
Arado Ar-234 BLITZ
35
(No Transcript)
36
(No Transcript)
37
General Specifications Aircraft Type
Single-seat reconnaissance jet
bomber Manufacturer Arado Crew Size 4 Weaponry
2x fixed MG151 cannon firing aft One 2,205 lb
(1000 kg) bomb under fuselage One 1,102 lb (500
kg) bomb next to each jet nacelle Gross Weight
Ramp weight 11,464 pounds, Max takeoff
wt with RATO packs 21,715 pounds
Dimensions Length 41 ft. 6 in. Height 14 ft,
1¼ in. Wingspan 46 ft. 4 in.
Propulsion Number of Engines 2 Powerplant
Junkers Jumo 004B turbojet Horsepower 1,340 hp
each Performance Range 1012 miles with 1-500
kg bomb Maximum Speed 465 mph Maximum
Altitude 32,810 feet
38
The End
