Soft PBX

1
Soft PBXsThe Time Has Come
2
The Technology Hysteria Curve
RealityCheck
Marketing
DisappointmentSlide (PHPD)
Hype Hyper-Drive
MarketReality
Creation
Time
Despair
3
Top rating in Gartners network convergence
report (North America)
More than 100 Lines
Less than 100 Lines
The only vendor to reach the magic quadrant In
both categories
4
Market DynamicsEnterprise IP Telephony
000 Lines, Europe
60
Total Lines (MZA)
IP Lines (Cahners In-Stats)
45
Traditional lines (Cahners In-Stats)
20
10
3
There is a growing consensus that end users
next communication system purchase will either be
an IP-PBX or a circuit-switched system with
substantial IP telephony capabilities

• - Phillips InfoTech 12/30/00

5
Customer requirements
6
What is the Requirement?
7
What is Driving Force?

• For connecting sites via IP
• Toll bypass to reduce costs
• Extend central applications to remote office and
  home workers
• Remote management

• For LAN telephony
• Reduce costs of management and installation (plug
  and play and on-line help)
• Provide architecture to support new integrated
  applications
• Simplified roll out of new applications

• For integrated business applications
• Enhanced conferencing
• Unified messaging
• Web enabled contact centres and self service
  solutions
• One number follow-me services
• Click-to-talk

8
The Many Faces of deployment
Voice over IP
Web Telephony Integration
9
Building Blocks for a Soft PBX
10
For Any Enterprise Phone System

• You will need

• Phones
• Telephony software
• Applications
• Management
• Underlying Network

11
The Building Blocks of Telephony

• Phones
• Telephony software
• Applications
• Management
• Underlying Network

Now, lets take a closer look
12
Todays Digital Phones Provide

• One touch line and feature keys
• Single line, multi-line, ACD for call centre
• Call forward, transfer, ring again,
  boss-secretary filtering
• Hands-free/Headset support
• Support for business applications
• Message waiting indication
• ACD queues for contact centres
• 6 party conference keys or 64 party conference
  bridge application
• Powered delivered through the cable

13
IP PhonesDo Consider

• Critical business features
• Boss secretary filtering
• Auto ring again when free
• Camp on when busy
• Conferencing
• Support for downloadable upgrades
• New feature and functionality
• Management and applications
• Easy to configure, easy to use?
• Power
• Power over LAN or mains?

14
The Building Blocks of Telephony

• Phones
• Telephony software
• Applications
• Management
• Underlying Network

15
Todays PBX Software Can Provide

• Tried and tested software
• First digital telephony system was introduced 25
  years ago
• Over 400 features and services developed over
  years of customer feedback
• Includes both visible and invisible features
• Least cost routing, network hop-off, etc
• Open CTI interfaces for controlling digital
  telephone sets
• Microsoft TAPI
• Carrier grade reliability

16
IP Telephony Software Do Consider

• All the functionality you need to run your
  business
• Operator features
• End user features
• Applications
• Management and billing
• Integration with your existing voice network
• ISDN, voicemail, operators, management system
• Reliability

17
The Building Blocks of Telephony

• Phones
• Telephony software
• Applications
• Management
• Underlying Network

18
Todays PBX Applications Can Provide
PBX

• Convergence of voice and data at the users
  desktop
• Voicemail in e-mail box
• Click to talk on web pages
• Multimedia contact centres
• Personal productivity apps
• Software running on commercially available
  platforms
• Open interfaces
• Choice of circuit switching or packet switching
  to the phone

Applications
TDM Network
User desktop
19
IP Telephony ApplicationsDo Consider

• What business applications you need to run your
  business
• Conferencing? Messaging? Call Centre? CTI? Web
  collaboration?
• Integration with your existing infrastructure
• New applications to existing users
• New users with existing applications
• Compare applications before choosing your
  communications system

20
The Building Blocks of Telephony

• Phones
• Telephony software
• Applications
• Management (I think you get the picture)
• Underlying Network

21
Customer Need IP PBX Pure IP centric solution

• Succession CSE 1000
• Business values of Nortel voice
• Leverages M1 feature set and client-server
  applications
• Proven, reliable technology foundation
• Transparent user interface to Meridian 1 users
• Supports all IP Enabled capability
• Full Feature networking with Meridian 1
  immediately
• Interworking with other vendors PBXs

Applications
Communication Server
Gateways
Management
End User Access
22
Enterprise Succession Building Blocks
Analogue Desktops
Infrastructure
CSE1000
Succession Media Gateway
HPA
23
Evolution without Discontinuity
Trunk Gateway
Meridian 1
PSTN
WirelessGateway
Lines Gateway
100 network feature transparency
LAN
Fax
WAN
i2004
CSE 1000
i2050
Data-oriented architecture
Voice-oriented architecture
Same telephony capability and unified applications
24
Carrier IP VPN Strategy

• Nortel migration story for installed voice base
  to a IP data infrastructure
• Ongoing
• Equip existing Meridian PBXs with IP Telephony
  Gateway (ITG) cards
• Main site migration of main telephony leased
  lines onto IP data network
• Current/Short term
• Smaller sites integration equipment unification
• Enterprise network simplification using Meridian
  Call Server 1000 (CSE1000)
• Medium term
• Carrier network integration
• New services within/between enterprises

25
Telephony evolution Ongoing

• Equip existing Meridian PBXs with IP Telephony
  Gateway (ITG) cards
• Main site migration of main telephony leased
  lines onto data network

Meridian 1
Leased Lines
Meridian 1
Norstar
Meridian 1
Norstar
Meridian 1
Leased Lines
Leased Lines
26
Telephony evolution Current/Short Term

• Smaller sites integration equipment unification
• Enterprise network simplification using Meridian
  Call Server 1000 (CSE1K)

Data network/VPN
Meridian 1
BCM
BCM
ITG
Meridian 1
27
Telephony evolution Medium term

• Carrier network integration
• New services within/between enterprises

i2050/i2004
CSE 1000
Data network/VPN
Meridian 1
BCM
BCM
Firewall NAT

• Telephony services
• Line and
• Trunk

Telephony services on a standard platform
Multimedia Services
28
Does It Have to Be an All or Nothing Solution?

• Absolutely not!

• The best approach is an evolutionary or a Mix
  and Match solution
• Mix digital (TDM) phones with IP applications
• Keep digital sets in campus but do VoIP between
  sites
• Add IP phones and re-use existing applications eg
  Voicemail
• The solution must satisfy your individual
  business requirements, not the vendors products

29
Many ThanksTime for questions?
