An SQL API for Object Oriented Perl

1
An SQL API for Object Oriented Perl

• Tim Adye
• BaBar Collaboration
• Particle Physics Department
• eScience Centre informal seminar
• 12th November 2004

2
Talk Plan

• Summary of BaBar and its bookkeeping system
• large-scale distributed metadata catalogue in
  Gridspeak
• The problem
• Why not just write SQL?
• The BaBar SQL API
• User view Perl classes and command-line tool
• Behind the scenes
• Table schema configuration classes
• Summary of features
• Could this be generalised to other applications?
• Possible improvements
• Comparison with other DBIx packages
• Summary and references

3
Feedback and Discussion

• Would this be useful outside BaBar?
• Would it be worth making a public release?
• eg. on CPAN
• Does it need any improvements?
• New features
• Make it compatible with some other standards
• eg. sit on top of another abstraction like
  DBIxTable
• A better name!
• or have I just reinvented the wheel?
• If so, maybe I should import some classic wheel
  technology into BaBar, rather than try to export
  my own square wheel idea to the rest of the
  world

4
The BaBar Collaboration
10 Countries 77 Institutions 593
Physicists
5
The BaBar Detector at SLAC
Linear Accelerator
26th May 1999 first events recorded by BaBar
2.2 km PEP-II ring
BaBar
6
The BaBar Bookkeeping

• New bookkeeping system created in parallel with
  new data model
• Switch from OO database (Objectivity) to flat
  files (ROOT)
• Much simpler to manage, but no longer have the
  top-level Objectivity catalogue
• Actually the catalogue didnt really help us, so
  random set of bookkeeping tools had been build up
• The main aim of the project was to create a
  coherent bookkeeping system to replace these ad
  hoc tools
• Successfully deployed Feb 2004. In use ever
  since.
• Started development in Jan 2003
• beta test in Autumn

7
Bookkeeping Concepts

• Currently BaBar analysis data consists of
• 43G events (event results from one ee-
  collision)
• in 335k files
• total size of 186 TB
• 156M rows in largest table
• Expect all to grow geometrically over the next
  few years
• Data grouped in an overlapping hierarchy
• many-to-many relations between tables, eg.
• 1.7M runs unit of datataking
• 219k collections unit of access to event store
• 335k files each collection stored in a few
  physical files
• 18k datasets groups of data that analysis users
  want
• Need to select runs, collections, etc based on
  attributes from any of these tables

8
(No Transcript)
9
Features of the BaBar Bookkeeping

• Decoupled from event store
• Job configuration written to site-independent tcl
  file
• Worker nodes dont need access to database server
• Mirrored to other sites
• From SLAC to 4 Tier A, 15 Tier C, user
  laptops
• Supports Oracle and MySQL (mirror Oracle?MySQL)
• Remote access
• Used for mirroring and for sites who dont want
  local db
• Connection parameter/key distribution system
• Eg. BookkeepingCommand -siteslac or -siteral
  transparently connects to correct Oracle server
  at SLAC or MySQL at RAL.
• Allows fallback servers if there are problems

10
Other Features of the Bookkeeping

• Import of data to each site managed by local
  bookkeeping system
• Each site knows what it has and what it wants
• New data imported automatically in cron job
• Task management system
• Controls job submission, checking, resubmission
• Currently just for production jobs, but soon
  for user analysis jobs too
• Looking at interfacing this to LCG job submission
• Already use LCG for UK Monte Carlo production

11
User Access

• Users need to query database to find out what
  data to process
• May also need other information
• eg. luminosity, run numbers, file sizes
• Mostly select by dataset, but may need to limit
  further
• eg. only data available locally, taken at peak
  energy, excluding some problem datataking period
• Cannot expect users to know which tables to use,
  how to join them, or even the SQL syntax
• Even worse if the schema change
• Cannot expect developers to code for all
  combinations of queries with all possible
  selections
• Previous ad hoc tools (some mine!) tried to do
  this and it was a nightmare, even for a simpler
  table structure

12
BaBar SQL API user view

• Each column that users might want to query or
  select on is given a unique logical name
  regardless of which table it lives in
• These names are used to specify query values
• query-gtaddValues('collection', 'gbytes')
• and selections
• query-gtaddSelector('dataset', 'Dilepton-')
• query-gtaddSelector('run', '10000-19999')
• Different types of data allow for different
  selection syntax, eg. wildcards for names, or
  ranges for run numbers.
• Can also use SQL expressions (in terms of logical
  names)
• query-gtaddValues('SUM(lumi)/1000')
• and sorting, row limits, etc

Each of these happens to be in a different table
13
SQL API returning results

• Thats enough to generate a valid SQL SELECT
  query. To return the results-
• my sta query-gtexecute()
• while (my row sta-gtfetch())
• print row-gtgbytes(), row-gtcollection(), "\n"
• The query object collects the user requests
• query-gtexecute() returns a statement accessor
  (like a DBI statement handle).
• sta iterates over row objects, each of which has
  accessors for each query value, gbytes and
  collection.
• Thats all there is to it!
• After the usual DBI connect, and query object
  instantiation (see later), these statements form
  a working program

14
Command-Line Tools

• Standard BaBar tools use this API to create job
  configuration, create datasets, calculate
  luminosities, etc.
• Standard tasks, but optionally allowing
  additional selections
• Also provide an expert tool that allows access
  to full API functionality from the command line
• This has proved very popular, with many
  non-experts making their own unique queries

15
Examples

• BbkUser --datasetA0-Run4-OnPeak-R14 \
  --is_local1 --file_status0 \ dse_lumi
  events gbytes file
• DSE_LUMI EVENTS GBYTES FILE

•

• 1250.3 526115 1.6 /store/PRskims/R14/14.4.0d/
  A0/02/A0_0239.01.root
• 1250.3 526115 0.8 /store/PRskims/R14/14.4.0d/
  A0/02/A0_0239.02HBCA.root
• 1348.4 576239 1.6 /store/PRskims/R14/14.4.0d/
  A0/02/A0_0240.01.root
• 1348.4 576239 1.0 /store/PRskims/R14/14.4.0d/
  A0/02/A0_0240.02HBCA.root
• ...
• 156 rows returned
• BbkUser -collection-filecoll.lis \
• tot_gbytes collection

16
What happens behind your back

• The SQL API
• translates the logical names to table columns
• selects the required tables and joins
• including otherwise unused tables required for
  the joins
• generates and executes a valid SQL SELECT
  statement
• creates a statement accessor object
• dynamically generates a class for the row objects
  with accessors for each query value

17
Our Example
BbkUser --datasetA0-Run4-OnPeak-R14
--is_local1 --file_status0 dse_lumi
events gbytes file

• That first BbkUser command involved 5 tables
• including one that provides the join between
  dataset and collection tables
• SELECT dse.lumi_sum AS "dse_lumi",
  dse.output_nev AS "events",
• file.bytes, dse.name AS
  "collection",
• file.suffix AS "file_suffix", ds.id AS
  "ds_id",
• dse.id AS "dse_id", dtd.id AS
  "dtd_id",
• dtd.link_status
• FROM bbk_dataset ds, bbk_dsentities dse,
  data_files dfile,
• bbk_files file, bbk_dstodse dtd
• WHERE ds.iddtd.ds_id
• AND dtd.dse_iddse.id
• AND dse.idfile.dse_id
• AND file.iddfile.file_id
• AND ds.name'A0-Run4-OnPeak-R14'
• AND dse.is_local'1'
• AND dfile.status'0'

The SQL API can even pretty-print it like this
for you ? (Whats shown here is somewhat
abbreviated actual command includes full
database and table names in case of ambiguities)
18
(No Transcript)
19
Table schema configuration classes

• Mapping between logical names and table columns
  is defined in the configuration classes.
• One class per table
• Can also define special properties of each column
  (eg. whether to allow ranges (100-199) for
  selection).
• Possible joins between tables defined here too
• Use logical column names for join conditions, so
  one table class does not need to know about
  column names in other classes.
• In most cases its just a matter of listing
  logical vs. column names
• with a little Perl syntactic sugar
• Inheritence of config classes expresses
  commonalities
• eg. common id and created, and modified columns

20
Example Table Configuration

• sub table return 'bbk_files'
• sub tableConfig
• return
• alias gt 'file',
• columns gt
• bytes gt 'bytes,
• uuid gt 'uuid',
• checksum gt 'checksum',
• file_suffix gt 'suffix',
• nfiles gt 'COUNT(DISTINCT file_id)',
• gbytes gt '(bytes/1073741824)',
• tot_gbytes gt 'SUM(bytes)/1073741824',
• file_dse_id gt column gt 'dse_id',
  selectorType gt 'range' ,
• file gt valueAction gt 'addLfnValue',
  selectorAction gt 'lfnSelector' ,
• ,
• joins gt
• dse_id gt 'file_dse_id',
• file_id gt 'dfile_file_id',

21
Putting it all together

• Configuration classes must be registered with
  query object
• my query new BbkSqlSelect
• query-gtaddModules(new MyTableClass(dbi))
• but of course it is usually simpler to provide a
  query object pre-registered with all the table
  configs as part of a specific API.

22
Overriding and Synthetic Columns

• A crutial advantage of this system is that it
  allows us to override the default behaviour
• Allows us to hide complexities from user
• Make even complex schema changes transparent to
  users
• A logical name can refer to
• ordinary database column name
• SQL expression (in terms of database columns, or
  other logical names)
• Perl method to pre- or post-process selection or
  query value
• synthetic query value or selection
• can return calculated value or alter behaviour
• Global post-processing
• Can be triggered by value, selection, or table
  inclusion
• Allows global filtering of returned rows

23
What happens behind your back 2

• We already used some of these features without
  noticing!
• Dataset names can be found in the bbk_dataset or
  the bbk_aliases table
• Requires a check and translation using the alias
  table
• Datasets can evolve with time, with collection
  being added or removed
• Need to query dataset for any time in the past,
  or use tagged dataset alias (like a CVS tag)
• Implemented by automatically including date
  selection in query, and post-processing returned
  results to remove deleted collections
• File names are made from a collection name a
  suffix
• query-gtaddSelector('file') splits the file name
  for the query and the row-gtfile() accessor
  rejoins them

24
Features

• Supports Oracle 8 and MySQL 3.23
• Most queries that can be expressed in both these
  dialects can be expressed by users via the API
  without breaking the paradigm of a flat namespace
• aggregatation and grouping
• sorting and distinct
• MySQLs LIMIT emulated in Oracle
• inner and outer joins (generates Oracle or MySQL
  syntax)
• Does not support UNION or subqueries
• Could be added, but not in MySQL 3.23
• Convenience features
• automatic Getopt specification
• query results display formatting and summary
  table generation
• Configuration class summary table generation

25
Limitations

• Assumes tables can be joined in a unique way
• ie. the joins form an acyclic graph
• can still select different joins with explicit
  switches
• Each column must have its own unique logical name
• This is usually a good thing
• but if the same data is held in different
  columns, it would be more efficient to
  automatically select from tables that are already
  included

26
A public version

• Current version has a few BaBar-specific pieces
• BaBar Connection manager can use DBI directly
• BaBar Options manager can use Getopt directly
• BaBar base objects borrow required methods
• BaBar table formatting class remove
  functionality or publish this too
• otherwise just uses standard Perl modules
• but with different table configs could be used
  elsewhere
• Already do this in BaBar used for QA and TM
  databases
• Maybe Im making some other assumptions that are
  true of our database and requirements, but not
  more generally so. I cant think of any.
• Needs a better name!
• This is really an SQL API creator

27
Possible improvements

• Tidy up code!
• User and config APIs are OK, but in between its
  pretty ugly
• Separate functionality that can be used on its
  own
• Already true of the DBI statement accessor class
• More SQL dialects PostgreSQL, MS SQL?
• New SQL syntax subqueries, UNIONs,
• INSERT, UPDATE, etc
• these dont need joins, so hand-coding not such a
  problem
• Automatic selection of different join
  possibilities
• Automatic generation of default table classes
  from SQL schema
• Could use The SQL Fairy
• though not much work to do it by hand

28
Why not use another package?

• More than 100 DBIx and other SQL access packages
  in CPAN
• Could not find any that do all (or even most) of
• hide table structure from user
• allow multi-table queries, taking care of joins
  automatically
• do not impose their own conventions on table
  schema
• allow query values and selections to be
  overridden
• allow transparent post-processing of query
  results
• provide accessor functions for query results
• I believe that taken together these features
  provide a clear and easy to use abstraction

29
References

• The BaBar Experiment
• http//hepunx.rl.ac.uk/BFROOT/
• BaBar Bookkeeping project
• http//hepunx.rl.ac.uk/BFROOT/www/Computing/Distri
  buted/Bookkeeping/Documentation/
• BaBar Bookkeeping presentation and paper
• http//indico.cern.ch/contributionDisplay.py?contr
  ibId338sessionId7confId0
• D.A. Smith et al.,BaBar Book Keeping project
  a distributed meta-data catalog of the BaBar
  event store,Proc. Computing in High Energy and
  Nuclear Physics 2004 (CHEP04).
• CPAN Database Interfaces (see particularly DBIx)
• http//cpan.uwinnipeg.ca/chapter/Database_Interfac
  es
