Title: Fourier Transform


1
Fourier Transform as Used by Chemists Literatur
e Seminar by Michael Curry
2
Applications of Fourier Transform in Spectroscopy
  • Infrared Spectroscopy (FT-IR)
  • Raman Spectroscopy (FT-Raman)
  • Nuclear Magnetic Resonance Spectroscopy (FT-NMR)
  • Mass Spectrometry (FT-MS)

3
Fourier Transform Spectrometers
  • First commercial FT spectrometer 1962
    (Grubb-Parson infrared spectrometer)
  • Suffered from drawbacks (slow, sensitive to
    vibrations, limited sample analysis)
  • Advancements in computers
  • Development of the Cooley-Tukey algorithm (Fast
    Fourier Transform, 1965)

4
Fourier Series
  • In 1805, Joseph Fourier introduced Fourier series
  • Mathematical process that can be used to
    decompose any waveform into a sum of sine waves,
    or harmonics.
  • The sum of the harmonics makes up the original
    waveform.

Reproduced from Johnston, S. F. Fourier Transform
Infrared 1991
5
Fourier Transform (FT)
  • is the signal (t-domain)
  • is the spectrum (f-domain)

6
Development of Optical Spectroscopy
  • In early 1800s, quest for monochromatic light
  • In 1752, spectroscope invented by Thomas Melvill
  • In 1814, telescope added to view light by Joseph
    Fraunhofer
  • In 1850, the introduction of chemical analysis by
    Bunsen and Kirchoff (professors of chemistry and
    physics, respectively)

7
Interference Patterns of Waves
  • In 1802, Thomas Youngs light interference
    discovery observed bright and dark fringes
  • Hippolyte Fizeau (ca. 1840) studied interference
    patterns (large optical path differences)
  • In 1862, fringe counting revealed the ratio
    between slightly different wavelengths

8
Wavelength Comparison
  • Fringe counting (principle used by Fizeau)
  • Wavelengths in phase (bright) and out of phase
    (dark)
  • The first variable path interferometer

Reproduced from Johnston, S. F. Fourier Transform
Infrared 1991
9
Interferential Spectroscopy
  • In 1880, Albert A. Michelson (University of
    Berlin) developed the Michelson interferometer
  • Study of luminiferous aether (medium allowing
    propagation of light through space)
  • Essential elements Beam splitter, fixed and
    moveable mirror, and a hand-turned screw

Reproduced from Johnston, S. F. Fourier Transform
Infrared 1991
10
The Interferogram
  • Lack of sensitive detectors (Michelson used his
    eye as the detector)
  • Mechanical harmonic analyzer invented by
    Michelson and Stratton
  • Investigation of the infrared region (Heinrich
    Rubens)
  • Exploration of the region between light waves to
    radio waves
  • Employment of an energy detector and broad band
    measurements (observed a wide band of wavelength
    simultaneously)
  • In 1911, first recorded interferogram (Rubens and
    R. W. Wood)

11
Visible Spectrum
  • Interferogram (top) and visible curve (bottom)
  • Dotted line relates visibility curve to
    interferogram
  • Recorded overall characteristics of the
    interferogram

Reproduced from Kauppinen, J. et al Fourier
Transform Spectroscopy 2001
12
Harmonic Analyzer
  • Consist of rods, levers, springs, drums, and a
    pen
  • Constructed using 20 mechanical elements (later
    80 elements)
  • Simulated light waves of particular frequency

Reproduced from Kauppinen, J. et al Fourier
Transform Spectroscopy 2001
13
First Published Interferogram
  • Heinrich Rubens and S. W. Wood (1911)
  • Output intensity from interferometer versus the
    optical path difference of two beams

Reproduced from Kauppinen, J. et al Fourier
Transform Spectroscopy 2001
14
The Spectrum
  • Difficulties in Fourier transforms computation
    prevented calculation of spectrum
  • Spectrum shapes were guessed and compared to the
    interferogram
  • In 1949, first spectrum computed by Peter
    Fellgett
  • Scanned interference pattern formed by two wedge
    plates
  • Performed the Fourier transform by hand

15
Fourier Transform Infrared Spectroscopy
  • Source generates radiation
  • Collimated and impinged upon a beam splitter
  • Half reflected to the fixed and half to moveable
    mirror
  • Both halves reflected by to beam splitter
  • Recombined and detected

Reproduced from Skoog, D. A. Principles of
Instrumental Analysis 1992
16
Interferograms and Optical Spectra
  • A beat frequency is observed as waves go in and
    out of phase

Reproduced from Skoog, D. A. Principles of
Instrumental Analysis 1992
17
Discrete Fourier Transform (DFT)
  • Digital processing of the data
  • Finite limits (-T to T-1)
  • ?t is the sample interval

18
Cooley-Tukey Algorithm
  • Advancements in computers (vacuum tube to
    transistors)
  • Algorithm published in 1965 by James Cooley and
    John Tukey
  • Reduced the number of operations needed to
    compute an n-point spectrum
  • FFT requires 2n data points

19
Truncation of the Signal
  • Truncation function ?2T(t) times the original
    signal h(t)
  • The Boxcar function

Reproduced from Kauppinen, J. et al Fourier
Transform Spectroscopy 2001
20
Distortion of the Spectrum
  • Truncating the signal in the time domain give
    rise to distortion of the spectrum in the
    frequency domain.
  • The signal is convolved by a sinc function
    (Ringing pattern).
  • The sinc function is defined as H (?) 2T
    sinc(2p? T) H(?).

h(t)
Reproduced from Kauppinen, J. et al Fourier
Transform Spectroscopy 2001
21
Apodization
  • Multiplying the time domain signal by a
    triangular function to minimize ringing pattern
    (foot removal)
  • Smooth the interferogram to zero intensity

Reproduced from Faires, M. L. Analytical
Chemistry 1986, 58, 1023A-1033A
22
Apodization Functions
  • Apodization function (left hand side) and
    corresponding line shape (right hand side)

Reproduced from Davis, S. P. et al Fourier
Transform Spectrometry 2001
23
Sampling of the Frequency
  • In order to represent the signal correctly it
    must be sampled at the Nyquist Frequency
  • A 1600 Hz cosine wave (dash line) sampled at 2000
    data per second

Reproduced from Skoog, D. A. Principles of
Instrumental Analysis 1992
24
Zero-Filling
  • Zeros added to the interferogram before
    transformation

Reproduced from Cassady, C. J. Personal
Communication
25
Advantages of FT-IR Compared to Dispersive
Instruments
  • Multiplex or Fellgett advantage
  • More information obtained about each frequency
  • Rapid scanning
  • S/N increase with increased signal averaging
  • Throughput or Jacquinot advantage
  • Power of radiation reaching the detector is
    greater
  • Increased S/N and sensitivity
  • High wavelength accuracy and precision
  • Signal averaging possible
  • Improved S/N

26
Summary I
  • Advancements in mathematics
  • Joseph Fourier (Fourier series)
  • Discovery of interference patterns
  • Developments in optical spectroscopy
  • Michelson Interferometer
  • Advancements in computers
  • smaller, cheaper, faster
  • Cooley-Tukey algorithm
  • Fast Fourier Transform

27
Ion Cyclotron Resonance
  • Origin of ion cyclotron resonance mass
    spectrometry begins with E. O. Lawrences
    Cyclotron
  • In 1950, Thomas and Hipple introduced first ion
    cyclotron spectrometer (Omegatron)
  • Beginning in 1974, Marshall and Comisarow applied
    Fourier transform methods
  • In 1981, first commercial FT-ICR

28
Analyzer Cell
  • Trapping plates left and right
  • Excitation plates front and back
  • Detection plates top and bottom

Reproduced from Asamoto, B. FT-ICR/MS 1991.
29
Ionization Methods
  • Ions formed internally or externally
  • Some methods include
  • Electrospray Ionization (ESI)
  • Matrix Assisted Laser Desorption Ionization
    (MALDI)
  • Chemical Ionization (CI)
  • Electron Ionization (EI)

30
Ion Excitation
  • Figure a and b impulse excitation and chirp
    excitation, respectively

Reproduced from Asamoto, B. FT-ICR/MS 1991.
31
Signal Generation
  • Ionization of the sample
  • Ions trapped in magnetic field are accelerated
  • Image current detected by detector plates

Reproduced from Asamoto, B. FT-ICR/MS 1991.
32
Signal Acquisition
  • Signal acquired in full spectrum mode (broadband)
    or heterodyne mode (narrowband)

Reproduced from Asamoto, B. FT-ICR/MS 1991.
33
Data Processing
  • Discrete Fourier Transform is used
  • Fast Fourier Transform
  • Truncation
  • Distortion
  • Apodization of the time domain signal
  • Minimizes artifacts
  • Zero-Filling
  • S/N increased

34
Advantages of FT-ICR compared to Conventional
Instruments
  • Multiplex or Fellgett advantage
  • More information obtained about each frequency
  • Rapid scanning
  • S/N increase with increased signal averaging
  • Superconducting Magnets in FT-ICR/MS
  • Higher magnetic field strengths
  • Less expensive to operate

35
Summary II
  • FT revolutionized data processing
  • Optical spectroscopy
  • Non optical spectroscopy
  • Advancements in technology
  • Bench top instrument
  • Rapid scanning

36
Acknowledgments
Dr. John Doe Dr. Jane Doe The University of
