Learning the threshold in Hierarchical Agglomerative Clustering

1
Learning the threshold in Hierarchical
Agglomerative Clustering

• Kristine Daniels
• Christophe Giraud-Carrier

Speaker Ngai Wang Kay
2
Hierarchical clustering
Threshold
Dendrogram
d3
d2
d1
d2
d1
d3
3
Distance metric

• Single-link distance metric the minimum of the
  simple distances (e.g. Euclidean distances)
  between the objects in the two clusters.

4
Distance metric

• Complete-link distance metric the maximum of
  the simple distances between the objects in the
  two clusters.

5
Threshold determination

• Some applications may just want a set of clusters
  for a particular threshold instead of a
  dendrogram.
• A more efficient clustering algorithm may be
  developed for such case.
• There are many possible thresholds.
• So, it is hard to determine the threshold that
  gives an accurate clustering result (based on a
  measure against the correct clusters).

6
Threshold determination

• Suppose C1, , Cn are the correct clusters and
  H1, , Hm are the computed clusters.
• A F-measure is used to determine the accuracy of
  the computed clusters as follows

7
Threshold determination
where N is the dataset size
8
Semi-supervised algorithm

• Select a random subset S of the dataset.
• Label the correct clusters of the data in S.
• Cluster S using the previous algorithm.
• Compute the F-measure value for each threshold in
  the dendrogram.
• Find the threshold with the highest F-measure
  value.
• Cluster the dataset using this threshold.

9
Sample set

• Preliminary experiments show that a sample set of
  size 50 gives reasonable clustering results.
• The time complexity of the hierarchical
  clustering is usually O(N2) or higher in simple
  distance computations and numerical comparisons.
• So, learning the threshold may be a very small
  cost in comparison to that of clustering the
  dataset.

10
Experimental results

• Experiments are conducted by complete-link
  clustering on various real datasets in the UCI
  repository (http//www.ics.uci.edu/mlearn/mlrepos
  itory.html).
• They are originally collected for the
  classification problem.
• The class labels of the data are used as the
  cluster labels in these experiments.

11
Experimental results
12
Experimental results
13
Experimental results

• Because of the nature of the data, there may be
  many good threshold values.
• So, large differences between the target and
  learned thresholds do not have to yield large
  differences between the corresponding F-measure
  values.

14
Experimental results
15
Experimental results

• The Vehicle dataset shows a huge difference in
  the number of clusters but a moderate difference
  in the F-measure.
• The Car dataset suffers from a serious loss of
  the F-measure, but the difference in the number
  of clusters is small.
• These anomalies may be explained, in part, by the
  sparseness of the data, the skewness of the
  underlying class distributions, and the cluster
  labels are based on the classification labels.

16
Experimental results

• The Diabetes dataset achieves a F-measure value
  close to optimal with fewer clusters when using
  the learned threshold.
• In summary, the learned threshold achieves
  clustering results close to the optimal ones at a
  fraction of the computational cost of clustering
  the whole dataset.

17
Conclusion

• Hierarchical clustering does not produce a single
  clustering result but a dendrogram, a series of
  nested clusters based on distance thresholds.
• This leads to the open problem of choosing the
  preferred threshold.
• An efficient semi-supervised algorithm is
  proposed to obtain such threshold.
• Experimental results show the clustering results
  obtained using the learned threshold are close to
  optimal.
