Title: Motor Systems


1
COGNITIVE SCIENCE 107A Motor
Systems Basal Ganglia Jaime A. Pineda, Ph.D.
2
Two major descending pathwaysPyramidal vs.
extrapyramidal
Motor cortex
Brain stem centers
Pyramidal system
Extrapyramidal system
  • Pathway for voluntary movement
  • Most fibers originate in motor cortex (BA 46)
  • Most fibers cross to contralateral side at the
    medulla
  • Pathways for postural control/certain reflex
    movement
  • Originates in brainstem
  • Fibers do not cross
  • Cortex can influence this system via inputs to
    brain stem

Lower motor neurons (brain stem and spinal cord)
Striated muscles
3
  • In order to generate voluntary movement many
    components are necessary
  • A representation of the actual position of the
    body segments (current program).. somatosensory
    systems
  • 2) A representation of the desired position of
    the body segments in time (model
    program).....cortex
  • 3) A spatial and temporal motor plan for
    achieving 2) starting from 1).cerebellum
  • 4) Monitoring and maintaining the
    movement..basal ganglia

4
Feedforward and feedback Processing are needed
5
Optimal action requires a proper representation
of the external world A mistaken evaluation of
the weight of an object to be lifted generates a
different, more complex motor plan
6
Voluntary Movement Conscious
Figure 13-11 Control of voluntary movements
7
Cortical Motor System
  • Primary motor cortex
  • Execution of movement
  • Somatotopically organized
  • Massive descending projections to spinal cord
  • Damage gt pronounced weakness in affected body
    parts
  • Stimulation gt simple movt in small muscle
    groups

8
  • Somatotopy in M1

9
Cortical Motor System
Area 8 frontal eye fields
  • Pre-motor cortex
  • Movement planning/sequencing
  • Many projections to M1
  • But also many projections directly into pyramidal
    tract
  • Damage gt more complex motor coordination
    deficits
  • Stimulation gt more complex movt
  • Two distinct somatotopically organized subregions
  • SMA (dorso-medial)
  • May be more involved in internally generated
    movement
  • (anti-mirror neurons)
  • Lateral pre-motor
  • May be more involved in externally guided
    movement
  • (mirror neurons)


10
These various motor areas execute different tasks
relative to motor learning Supplementary motor
area initiates learning Premotor area starts a
learnt motor program Primary motor cortex
coordinates the details of the movement
11
Cortical Motor System
  • Posterior parietal cortex (PPC)
  • Sensory guidance of movement
  • Many projections to pre-motor cortex
  • But also many projections directly into pyramidal
    tract
  • Damage can cause deficits in visually guided
    reaching (Balints syndrome) and/or apraxia
  • Likely part of the dorsal visual stream

Areas 5, 7 visuo-motor integration
12
Subcortical Motor SystemBasal Ganglia
Cortex
input
or neostriatum
output
(internal/external)
input
(STN)
(pars compacta, pars reticulata
output
13
Subcortical Motor SystemBasal Ganglia
14
(No Transcript)
15
BG is a basic release circuit that works through
disinhibition to translate perception and
cognition into action
VA BG input VL cerebellum input
16
Motor Cortex-Basal Ganglia-Cerebellum Circuit
Cortex
M1, PM SMA
Striatum
Direct pathway
Indirect pathway
Somatosensory systems

GPe
Thalamus
STN
Cerebellum
excitatory
GPi/SNr
inhibitory
17
Basal Ganglia Functions
  • Motor planning, sequencing, learning, maintenance
  • Rule-based and habit (reinforcement) learning
  • Predictive control
  • Working memory
  • Attention
  • Switches in behavioral set

18
(No Transcript)
19
  • Striatum caudate - putamen
  • 80-95 medium spiny neurons
  • GABAergic 0.1 - 1 Hz rate
  • Receives vast majority of BG input
  • cortical
  • excitatory (glutamatergic)
  • 2 types of medium spiny cells
  • Those expressing D1 receptors
  • Excited by DA
  • contain dynorphin/Subst P
  • send to GPi SNpr (direct)
  • Those expressing D2 receptors
  • Inhibited by DA
  • contain enkephalin
  • send to Gpe (indirect)
  • Patchy
  • ACh striosomes
  • gets limbic input
  • sends to SNpc

CORTEX

Striatum
_
D1
D2
Direct
Indirect
20
(No Transcript)
21
Patches or striosomes (AChE-poor)
Matrix or matrisomes (AChE-richGABA)
22
Sensorimotor association areas
Limbic areas
matrisomes
striasomes
23
-
Thalamus
  • GPi (Globus Pallidus internal)
  • Major BG output for limb movement
  • DIRECT pathway from striatum
  • (striatopallidal pathway)
  • Also receives STN input
  • excitatory
  • contacts many neurons
  • 10-15ms faster than striatum
  • GABA output to thalamus brain stem
  • SNpr (Substantia Nigra pars reticulata)
  • Major BG output for eye movement
  • Also gets striatum STN input
  • SNpr projects to SC to control eye movements

Direct
-

SC

24
CORTEX
Thalamus
SC
25
  • GPe (Globus Pallidus external)
  • Much like internal segment
  • Gets striatum STN input
  • Sends output to STN
  • Striatum ? GPe ? STN ? GPi ? Thalamus
  • INDIRECT striatopallidal pathway
  • May act to oppose, limit, or focus the effect of
    striatal and STN projections to GPi and SNpr.

-
Striatum
Indirect

-
STN
26
CORTEX
Thalamus
SC
27
-
  • SNpc (Substantia Nigra pars compacta)
  • Most studied structure in the basal ganglia
  • Large DAergic cells
  • Receives inhibitory input from striasomes in
    striatum
  • Sends DAergic output to same/adjacent striatal
    areas
  • DA action (inhibitory/excitatory) depends on
    striatal receptors.
  • D1 receptors excite
  • D2 receptors inhibit

28
CORTEX
Thalamus

-

-

Direct
-

-

Indirect

SC
29
CORTEX
Thalamus

-

-
Hyperdirect
Direct
-

-

Indirect

SC
30
Basal Ganglia Circuit
  • Striatum receives input from cortical areas
  • inputs are roughly topographical (multiple
    parallel circuits)
  • GPi/SNr are the major output nuclei
  • Output is inhibitory
  • Gpi/SNr neurons have high baseline firing rates
    (baseline inhibition)
  • Gpi/SNr input from the striatum is focal and
    inhibitory, whereas input from the STN is diffuse
    and excitatory
  • Direct vs. indirect striatal pathways have
    opposing effects (inhib. vs. excit.)
  • Output of thalamus is primary to motor areas

Cortex
M1, PM SMA
Striatum
Direct pathway
Indirect pathway
SNc
Hyperdirect pathway
GPe
Thalamus
STN
excitatory
GPi/SNr
inhibitory
31
Malfunctioning of basal ganglia induces dramatic
abnormalities in voluntary movement. Basal
ganglia coordinates movement indirectly, by
receiving information from motor cortex and
re-sending back to the motor cortex processed
information through the thalamus.
32
Basal Ganglia Circuit
Cortex
M1, PM SMA
Striatum
Direct pathway
Indirect pathway
SNc
Hyperdirect pathway
D2
D1 ()
(-)
GPe
Thalamus
Indirect
Direct
STN
(bias is to maintain thalamic channels opened and
info flowing to cortex)
excitatory
GPi/SNr
inhibitory
33
Parkinsons Disease
  • Etiology
  • Adult onset, thought to be genetic without 100
    penetrance.
  • One hypothesis is that it results from a genetic
    susceptibility to an environmental factor.
  • Loss of DA input to striatum from SNpc
  • Loss must involve over 90 of cells before
    symptoms appear.

34
Parkinsons Disease Clinical Symptoms
  • Motor
  • Tremor
  • Cogwheel rigidity
  • Shuffling steps
  • Akinesia
  • Bradykinesia
  • Dystonia
  • Non-motor
  • Cognitive slowing
  • Difficulty with tasks requiring high level
    processing
  • Depression

Akinesia Difficulty beginning or
maintaining a body motion Bradykinesia Slowness
of movement paucity or incompleteness of
movement Dystonia Sustained involuntary
muscle contractions and spasms
35
Parkinsons Disease (Hypokinetic Movement)
  • Decreased output of SNc dopaminergic projections
  • Decrease excitation in direct pathway
  • Increase inhibition in indirect pathway
  • Net effect more inhibition of thalamus and
    therefore less excitatory input to motor cortex

Cortex
M1, PM SMA
Striatum
Direct pathway
Indirect pathway
SNc
GPe
Thalamus
STN
D2
D1 ()
(-)
excitatory
GPi/SNr
inhibitory
Indirect
Direct
36
Parkinsons Disease Treatment
  • L-DOPA (taken up by DA terminals in the
    striatum) converted to DA and then released.
  • Not effective for long-term treatment
  • Patients develop a tolerance to it
  • Has many side effects (honeymoon period 3-5
    years)
  • Transplantation of fetal tissue
  • Pallidotomy (cells in the posteroventral GPi are
    surgically ablated either unilaterally or
    bilaterally
  • Deep Brain Stimulation (DBS) a surgical
    treatment involving the implantation of a brain
    pacemaker, which sends electrical impulses to
    brain.

37
DBS
  • DBS leads are placed in the brain according to
    the type of symptoms to be addressed.
  • For essential tremor and Parkinsonian tremors,
    the lead is placed in the thalamus.
  • For symptoms associated with Parkinson's disease
    (rigidity, bradykinesia/akinesia and tremor), the
    lead may be placed in either the globus pallidus
    or subthalamic nucleus.

38
Huntingtons Disease (Hyperkinetic Movement)
Cortex
M1, PM SMA
  • Cell loss in the striatum that seems to affect
    the indirect pathway disproportionately
  • Net effect less inhibition of the thalamus and
    therefore excessive excitation of motor cortex

Striatum
Direct pathway
Indirect pathway
SNc
GPe
Thalamus
STN
excitatory
GPi/SNr
inhibitory
39
Subcortical Motor SystemBasal Ganglia
  • Behavioral effects when damaged can include
  • Resting tremor
  • Akinesia (paucity of movt)
  • Muscular rigidity
  • Unstable posture
  • Bradykinesia (slowness of voluntary movt)
  • Tic-like involuntary movements
  • Hemiballism (sudden involuntary large scale
    movt)
  • Possibly obsessive compulsive disorder,
    Tourettes, stuttering
  • Assorted cognitive deficits (e.g., aphasia)

Parkinsons disease
Huntingtons disease
40
Because of its cellular inhibitory nature, the
core of the basal ganglia is a system with
multiple loops of inhibition in which cortical
activation has the effect of disinhibiting the
part of motor thalamus in the initiated movement
thalamus
41
Subcortical Motor SystemBasal Ganglia
  • So what is the basal ganglia circuit doing?
  • The Brake hypothesis
  • B.G. essentially acts like a brake to prevent
    unwanted movement.
  • Excitation of STN via motor input leads to
    diffuse increase in inhibition.
  • Excitation of the striatum in one motor circuit
    decreasing this inhibition focally thus
    releasing the brake for the selected movement.

42
Real situation Clinically there are two types
of signs of malfunctioning of motor
control Negative signs loss of function of a
particular motor area Positive signs initiation
of stereotyped movements or exaggerate
strength This facts indicate that the motor
system not only uses a constructive approach to
movement, but it also uses an organized
inhibition that controls a menu of stereotyped,
learnt, motor sequences. Basal ganglia and
cerebellum are involved in this kind of
processing.
43
Example running Although the initiation of the
action is typically voluntary, the complex motor
sequence underlying it is organized in an
automatic, stereotyped manner. The animal is
able only to control Initiation Stop Modulation
(increase, decrease, go right, go left and a
number of other variables) Without being able to
control the contraction or relaxation of a single
muscle This is the reason for the creation and
storage of automatic motor patterns
44
The simplest motor pattern, the reciprocal
inhibition of couple of agonist and antagonist
muscles is organized at the spinal level
45
CORTEX
Thalamus
SC
46
CORTEX
Thalamus
SC
47
CORTEX
Thalamus
SC
48
CORTEX
Thalamus
SC
49
CORTEX
Thalamus
SC
50
CORTEX
Thalamus
SC
51
CORTEX
Thalamus
SC
52
CORTEX
Thalamus
SC
53
CORTEX
Thalamus
SC
54
CORTEX
Thalamus
SC
55
Subcortical Motor SystemCerebellum
Three main systems
Damage causes
Decreased muscle tone (hypotonia), difficulty
coordinating multiple joint movt (ataxia),
tremor/ oscillation at the end of a movement.
Slowed movement initiation time, movements become
fractionated and performed sequentially rather
than as one smooth movt
1.
2.
3.
Impairs ability to use vestibular information to
control eye movements during head rotations or
limb movements during walking or
standing. Difficulty maintaining balance, fall
often
56
The cerebellum receives and processes information
coming from muscles, joints and vestibulum,
creating a temporal template for the fine
adjustments of movement. In cerebellotomized
animals, cerebellum motor function may be
recovered by the rest of the motor system.
57
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
