ADS-B Safety Analysis (ASA

1
ADS-B Safety Analysis (ASA GSA)
ASAS Thematic Network Second Workshop 6-8 October
2003

• Bob Darby
• EUROCONTROL ADS Programme

2
OUTLINE

• Background
• Current work
• analysis processes
• comments on the methods, not the results
• Wider context Conclusions
• Safety is only part of SPR / IA
• Requirements Focus Group
• Longer term
• Points of Contact

3
BACKGROUND
4
Safety Work History

• 1999-2000 Stage 0
• Initial Safety Study - brief look high level
  workshops
• 2000-2001 Stage 1
• Operational Hazard Analysis (OHA) based on Case
  Studies
• Difficulty - not detailed enough definition of
  the applications

5
Safety Work History

• 2002
• Package I proposed at Rome
• CARE-ASAS / EUROCONTROL development of Package I
• EUROCAE WG51 RTCA SC-186
• Common applications review proposal
• Common methodology proposal - ED78A / DO-264
• Guidelines for Approval of the Provision and Use
  of Air Traffic Services supported by Data
  Communications
• In parallel
• Stage 2A Safety Contract launched
• At the time (Jan 2002) the aim was to
• Use EUROCONTROL Safety Assessment Methods (SAM)
• Use ED78A as a means of compliance with the SAM
• Aim has changed as ESARR4 developed and use of
  ED78A has proceeded, to establish an effective
  methodology. Differences/complementarity handled
  as an outcome.

6
CURRENT WORK
7
Stage 2A Safety Contract

• Coordinated with CBA and Architecture work
• Assessment of some ADS-enabled ASA and GSA
  applications defined in the Package I OSED -
  including ADS-B in a mixed surveillance
  environment
• For each Package I application
• OHA building on the results of the ADS Programme
  Stage 1 OHA
• ASOR allocation to elements / domains within the
  architecture
• from ASOR options safety requirements for the
  ADS-B element based on the specific enabling
  infrastructure.
• PSSA for one application, using a specific
  architecture
• Issues
• Methodology and Software tools equally important
  as the results

8
Logical Flow
9
Applications assessed

• Ground Surveillance Applications (GSA)
• ATC surveillance in en-route airspace
• ATC surveillance in terminal areas
• ATC Surveillance in non-radar area
• Airport Surface Surveillance
• Surface Traffic Awareness application
• Runway Incursion application
• Airborne Surveillance Applications (ASA)
• Enhanced traffic situational awareness on the
  airport surface
• Surface Traffic Awareness application
• Runway Incursion application
• Enhanced successive visual approaches
• Sequencing and merging applications

10
OHA process
11
OHA output (example)
From Enhanced Successive Visual Approach

• OHA is summarised in a diagram.
• Details in several tables
• OH summary table, that refers to
• Candidate safety requirements lists
• environmental
• procedural
• technical
• Recommendations list
• Causes list
• Supported by detailed OH tables

12
OHA - comments on process

• Exhaustive detailed ...
• time-consuming to develop and to review
• Mature process, used (with slight variations) by
  many European projects, NUP, MFF,
• Needs tool support to ensure
• consistency between diagrams and tables
• traceability and accurate cross-referencing
  between all tables
• database is being developed
• Derived from application model in OSED
• Changes to OSED may mean complete rework of OHA

13
ASOR process

• Follows on from OHA
• traceability essential
• Objective identify
• responsible domains/elements (ATC, aircraft,
  crew,)
• system failure relationships
• mitigation means strategy
• Key processes
• Building the fault tree
• stop when the safety requirement can be
  exclusively met in a domain
• Allocation of safety requirements
• several options

14
ASOR - comments on process

• Relatively new process - learning as we proceed
• More complex for surveillance than for
  communications
• No single correct answer - tradeoffs will occur
• Trees give the understanding - tables give the
  detail
• Tools for traceability and consistency essential

15
PSSA

• Specific to a particular implementation
• Assess if the proposed architecture is safe for
  its intended purpose
• ASOR has already mapped safety requirements to
  the domain
• Now look at the architecture within the domain
  i.e. main functional (and physical) components
• EUROCONTROL study example Toulouse airport
• Package I applications
• Airport Surface Surveillance
• Enhanced traffic situational awareness on the
  airport surface
• Surface Traffic Awareness application
• Runway Incursion application
• Just starting this phase of the study

16
Overall Comments

• Learning about the processes as we use themgoing
  from the generic to the specific
• Status
• OHA mature but effort intensive
• ASOR developing well
• PSSA just started but relatively straightforward
• Overall large effort
• Tool support essential, especially when iterating
  and reworking
• Complementary approach to identify critical areas
  would pay dividends
• OSED is critical - clarity and accuracy of
  application modelling is vital

17
WIDER CONTEXT CONCLUSIONS
18
Safety is only part of the process
OSED Operational Service Environment Definition
OSA Operational Safety Assessment OHA ASOR
OPA Operational Performance Assessment Identify
allocate performance requirements
IA Interoperability Assessment
SPR Safety Performance Requirements
Interop Document
19
Preparation for RFG/3

• Joint EUROCONTROL, FAA, EUROCAE, RTCA
  Requirements Focus Group
• 1st-4th December 2003, Washington DC
• OSEDs OSED Harmonisation Group
• First complete PI OSED due out soon
• Safety EUROCONTROL, NUP, MFF,
• Convergence on the methods
• More coordination and consensus needed - EC can
  help?
• SPR IA as a whole
• ad-hoc SPR/IA group working since July
• aiming at common approach for Europe and USA
  extend world-wide?

20
Longer term considerations

• Operational expertise to validate the analysis
  conclusions
• Complementary methods could be of value
• for greater efficiency overall
• for confirming results
• Coordination with Safety Unit, SRC and EASA

21
POINTS OF CONTACT

• EUROCONTROL ADS Programme
• visit the ADS Programme website
• http//www.eurocontrol.int/ads
• STNA Sofréavia
• who have carried out the detailed work and
  developed in a practical form the processes
  described today
• RFG colleagues
• discussions in preparation of material for RFG/3
