Title: State Variable Models
1State Variable Models
- Modern Control Systems
- Lecture 7
- Lecture 8
2Outline
- Linking state space representation and transfer
function - Phase variable canonical form
- Input feedforward canonical form
- Physical state variable model
- Diagonal canonical form
- Jordan canonical form
3Consider the following RLC circuit
- We can choose state variables to be
- Alternatively, we may choose
- This will yield two different sets of state space
equations, but both of them have the identical
input-output relationship, expressed by - Can you derive this TF?
4Linking state space representation and transfer
function
- Given a transfer function, there exist infinitely
many input-output equivalent state space models. - We are interested in special formats of state
space representation, known as canonical forms. - It is useful to develop a graphical model that
relates the state space representation to the
corresponding transfer function. The graphical
model can be constructed in the form of
signal-flow graph or block diagram.
5We recall Masons gain formula when all feedback
loops are touching and also touch all forward
paths,
- Consider a 4th-order TF
- We notice the similarity between this TF and
Masons gain formula above. To represent the
system, we use 4 state variables
Why?
6Signal-flow graph model
- This 4th-order system
- can be represented by
- How do you verify this signal-flow graph by
Masons gain formula?
7Block diagram model
- Again, this 4th-order TF
- can be represented by the block diagram as shown
8With either the signal-flow graph or block
diagram of the previous 4th-order system,
- we define state variables as
- then the state space representation is
9Writing in matrix form
10Let us consider a more general 4th-order system
- How do we construct the signal-flow graph and
block diagram using Masons gain formula? - forward paths (they have to touch all the loops)
- feedback loops (all of them are touching)
- integrators
11For the 4th-order TF
- One form of the signal-flow graph and block
diagram is
Phase variable canonical form
12Phase variable canonical form
- The state space equation developed from the above
graph is - with
x1, x2, x3, x4 are called phase variables.
13There is an alternative state space
representation by feeding forward input signal.
Input feedforward canonical form
14Input feedforward canonical form
- The state space equation representing the above
graph is - with
15When studying an actual control system block
diagram, we wish to select the physical variables
as state variables. For example, the block
diagram of an open loop DC motor is
We draw the signal-flow diagraph of each block
separately and then connect them. We select
x1y(t), x2i(t) and x3(1/4)r(t)-(1/20)u(t) to
form the state space representation.
16Physical state variable model
- The corresponding state space equation is
17We revisit the block diagram model of the open
loop DC motor.
The overall TF is
Distinct poles
- where k1-20, k2-10, k330. If we choose state
variables associated with distinct poles, we can
build a decoupled form of state space model.
18Diagonal canonical form
Distinct poles
- The state space equation for the above model is
19Jordan canonical form
- If a system has multiple poles, the state space
representation can be written in a block diagonal
form, known as Jordan canonical form. For
example,
Three poles are equal
