Benign Lesions of Bone

1
Benign Lesions of Bone
2
Osteoma

• Benign osseous tumor, usually affecting
  membranous bone
• Painless, slowly enlarging
• Paranasal sinus involvement is common
• Jaw lesions are usually associated with the
  condylar area

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Gardner Syndrome

• Autosomal dominant trait uncommon
• One of the multiple intestinal polyposis
  syndromes
• Characterized by osteomas of the facial bones
• Epidermoid cysts and desmoid tumors

8
Gardner Syndrome

• Radiographically, the osteomas of Gardner
  syndrome could resemble florid cemento-osseous
  dysplasia or osteitis deformans
• May see impacted supernumerary teeth or, less
  commonly, odontomas

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Gardner Syndrome

• The most significant aspect of the syndrome is
  the development of precancerous polyps of the
  colon
• 50 of patients develop adenocarcinoma of the
  colon by 30 years of age

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Gardner Syndrome

• Management includes
• Prophylactic colectomy
• Removal of cosmetically problematic cysts and
  osteomas
• Genetic counseling

24
Central Giant Cell Granuloma

• Benign, somewhat controversial, lesion of the
  jaws
• Some pathologists feel this is the same lesion as
  the giant cell tumor of bone, which typically
  arises in long bones, particularly in the knee
  area

25
Central Giant Cell Granuloma

• 2nd to 4th decade of life
• 21 female predilection
• Usually affects the mandible, often crossing the
  midline
• Unilocular when small larger lesions often
  multilocular and expansile

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Central Giant Cell Granuloma

• Histopathologically, granulation tissue with
  numerous benign multinucleated giant cells

32
(No Transcript)
33
Central Giant Cell Granuloma

• Treatment generally consists of aggressive
  curettage
• Recurrence rate of 15-20
• Prognosis is generally considered to be good

34
Langerhans Cell Histiocytosis

• Considered to be a group of related disorders
  caused by proliferation of Langerhans cells
• Langerhans cells are related to monocytes and
  serve as antigen-presenting cells
• Evidence that these are monoclonal
  proliferations, consistent with neoplasia

35
(No Transcript)
36
Langerhans Cell Histiocytosis

• At least three clinical presentations
• Acute disseminated histiocytosis
• Chronic disseminated histiocytosis
• Eosinophilic granuloma, which may be monostotic
  or polyostotic

37
Langerhans Cell Histiocytosis

• Acute disseminated histiocytosis (also known as
  Letterer-Siwe disease) is seen in infants
• Skin rash, splenic and hepatic involvement
• Usually a very aggressive, malignant course

38
(No Transcript)
39
(No Transcript)
40
Langerhans Cell Histiocytosis

• Chronic disseminated histiocytosis (also known as
  Hand-Schuller-Christian disease) is seen in older
  children
• Classic triad of exophthalmos, diabetes
  insipidus, and bone lesions (well-defined
  radiolucencies) is actually rather uncommon

41
(No Transcript)
42
(No Transcript)
43
Langerhans Cell Histiocytosis

• Eosinophilic granuloma of bone affects teenagers
  and adults
• May be polyostotic (teenagers) or monostotic
  (older adults)
• Well-defined, but non-corticated radiolucency

44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
Histopathologic Features

• Sheets of large, histiocytic-appearing cells
  (neoplastic Langerhans cells)
• Variable numbers of eosinophils (eosinophilic
  granuloma)

49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
Management and Prognosis

• Acute chemotherapy poor prognosis
• Chronic radiation and/or chemotherapy guarded
  prognosis
• Eosinophilic granuloma curettage or radiation
  good prognosis

54
Central Ossifying Fibroma

• Uncommon benign neoplasm that probably arises
  from periodontal ligament fibroblasts
• Probably confused with focal cemento-osseous
  dysplasia in the past
• Mandibular premolar/molar region adult female,
  3rd to 4th decade

55
Central Ossifying Fibroma

• Swelling may be present if the lesion is large
• Well-circumscribed radiolucency with variable
  amount of central opacity
• Range from almost purely radiolucency to very
  radiodense with a defined lucent border

56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
Central Ossifying Fibroma

• Cellular fibrous connective tissue containing
  mineralized trabeculae and spherules of material
  that may resemble cellular cementum or woven bone
• Microscopically similar to fibrous dysplasia, so
  radiographs are often necessary

61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
Central Ossifying Fibroma

• Treatment consists of enucleation lesion tends
  to shell out as one mass
• Prognosis is considered to be excellent, and
  recurrence is very uncommon

67
Malignancies Affecting Bone
68
Chondrosarcoma

• Rare malignancy of cartilaginous differentiation
• Most are seen in adult males (4th to 6th decade)
  and affect femur, pelvis or ribs
• 10 occur in the head and neck region
• May present with pain, swelling or loose teeth

69
Chondrosarcoma

• Poorly defined radiolucency with variable amounts
  of radiopacity
• Larger lesions may appear multilocular
• May see widened PDL of the teeth in the area of
  the tumor, similar to osteosarcoma

70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
Chondrosarcoma

• Histopathologically, this tumor is characterized
  by invasive lobules of atypical cells showing
  cartilaginous differentiation

80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
Chondrosarcoma

• Treatment is radical surgery
• Prognosis depends on the location and
  histopathologic grade of the tumor, but generally
  is considered poor
• Death is usually due to direct extension of
  tumor, involving vital structures

84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
Osteosarcoma

• Malignancy showing production of osteoid by tumor
  cells
• Most common primary bone malignancy twice as
  common as chondrosarcoma
• Only 900 new cases in the US annually only 7 of
  these affect the jaws

89
Osteosarcoma

• Osteosarcoma of the jaws has a different
  presentation epidemiologically compared to
  osteosarcoma of long bones
• Osteosarcoma of long bones develops around the
  knee area mean age 18 years
• Patients with osteosarcoma of the jaws have a
  mean age of 28 years

90
Osteosarcoma

• Initial complaint is often pain, followed by
  swelling, loose teeth or paresthesia
• Mixed radiopaque/radiolucent lesion with
  ill-defined borders
• Symmetrically widened PDL of teeth in the area
  may be seen
• Sun-burst pattern is uncommon in jaws

91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
(No Transcript)
107
(No Transcript)
108
Osteosarcoma

• Infiltrating sheets of malignant spindle-shaped
  or angular lesional cells
• Direct production of osteoid or bone
• Mitotic activity can vary from field to field
• Osteoblastic, chondroblastic and fibroblastic
  differentiation may be seen

109
(No Transcript)
110
Osteosarcoma

• Treatment is radical surgery
• Historically, 5-year survival has been in the
  30-50 range
• One study, using radical surgery, had an 80
  5-year survival
• Death is usually due to uncontrolled local disease

111
Plasmacytoma/Multiple Myeloma

• Neoplastic proliferation of plasma cells
• Solitary plasmacytoma
• Multiple myeloma
• Extramedullary plasmacytoma

112
Plasmacytoma/Multiple Myeloma

• Comprises 47 of malignancies involving bone,
  excluding metastases
• Over 14,000 cases annually in the US
• Mean age of 70 years rare lt 40 years
• 21 male predilection

113
Plasmacytoma/Multiple Myeloma

• Initially present with bone pain
• Myelophthisic anemia may cause fatigue,
  susceptibility to infection, fever, petechial
  hemorrhage
• Renal failure due to circulating monoclonal
  immunoglobulin

114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
118
(No Transcript)
119
Plasmacytoma/Multiple Myeloma

• Circulating monoclonal immunoglobulin may spill
  over into the urine (Bence Jones protein)
• May be deposited in tissues as eosinophilic
  acellular material amyloid

120
(No Transcript)
121
(No Transcript)
122
(No Transcript)
123
(No Transcript)
124
Plasmacytoma/Multiple Myeloma

• Monotonous sheets of atypical plasma cells
• Varying stages of differentiation
• Immunohistochemical studies show a monoclonal
  light chain restriction (kappa or lambda) of the
  lesional cell population
• Similar finding of monoclonal gammopathy on serum
  protein immunoelectrophoresis

125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
Plasmacytoma/Multiple Myeloma

• Treatment chemotherapy (prednisone plus an
  alkylating agent) thalidomide bone marrow
  transplant
• Prognosis poor
• Median survival of 30-36 months after onset of
  symptoms

130
Metastatic Disease

• Most common malignant process to involve bone
• Jaws are occasionally affected
• Metastatic deposits from malignancies below the
  neck may affect the jaws through Batsons
  paravertebral plexus of veins no valves

131
(No Transcript)
132
(No Transcript)
133
Metastatic Disease

• Over half of affected patients are over 50 years
  of age
• Mandible 61 of cases
• Maxilla 24 of cases
• Soft tissue 15 of cases

134
Metastatic Disease

• Paresthesia, tooth mobility, swelling,
  hemorrhage, pathologic fracture, trismus
• With lack of healing of a tooth socket,
  clinically consider granulation tissue,
  lymphoma, metastatic disease
• Poorly defined radiolucency less commonly,
  radiopacity

135
(No Transcript)
136
(No Transcript)
137
(No Transcript)
138
(No Transcript)
139
(No Transcript)
140
(No Transcript)
141
(No Transcript)
142
(No Transcript)
143
(No Transcript)
144
(No Transcript)
145
(No Transcript)
146
Metastatic Disease

• Histopathologically, these lesions have the
  pattern of the primary malignancy from which they
  arose
• Scattered clusters of lesional cells give a
  seeded effect
• Breast, lung, colon, thyroid, prostate, kidney,
  melanoma are among the more common primary sites

147
(No Transcript)
148
(No Transcript)
149
(No Transcript)
150
(No Transcript)
151
(No Transcript)
152
Metastatic Disease

• Treatment palliation, usually with radiation
  therapy
• Prognosis very poor most patients die within
  one year of the diagnosis
• 22 of jaw metastases represent the initial
  manifestation of the malignant process
