Check to Checkmate !

1
Check to Checkmate !

• Group 1
• Ashutosh
• Pushkar
• Ameya
• Sudhir
• From

2
Motivation

• Game playing was one of the first tasks
  undertaken in AI
• Study of games brings us closer to
• Machines capable of logical deduction
• Machines for making strategic decisions
• Analyze the limitations of machines to human
  thought process
• Games are an idealization of worlds
• World state is fully accessible
• Actions outcomes are well-defined

3
Outline of the presentation

• Evaluation Functions
• Algorithms
• Deep Blue
• Conclusions from Deep Blue
• Conclusion
• References

4
Chess

• Neither too simple
• Nor too difficult for satisfactory solution
• Requires thinking for a skilled player
• Designing a chess playing program
• Perfect chess playing INTRACTABLE
• Legal Chess TRIVIAL
• Play tolerably good game SKILLFULLY

5
Evaluation Function
6
Evaluation Function

• Utility function
• Whole game tree is explored
• computationally expensive task !!
• Estimates the expected utility of a state
• Evaluation functions
• cut off the exploration depth by estimating
  whether a state will lead to a win or loss

7
Evaluation Function (cont.)

• A good evaluation function should
• not take too long
• Preserve ordering of the terminal states
  otherwise it will lead to bad decision making
• Consider strategic moves that lead to long term
  advantages

8
Evaluation Function (cont.)

• Typically includes
• Material Advantage (difference in total material
  of both sides)
• f (P) 200(k k) 9(q q) 5(r r)
• 3(b b) (p p) g(P) h(P)
• Positions of pieces
• Rook on open file
• double rooks
• rook on seventh rank etc. and their relative
  positions.
• Pawn Formation
• Mobility
• Evaluation function is an attempt to write a
  mathematical formula for intelligence ?

9
(No Transcript)
10
Algorithms
11
Games as Search Problems

• Initial states
• Where game starts
• Initial position in chess
• Successor function
• List of all legal moves from current position
• Terminal State
• Where the game is concluded
• Utility function
• Numeric value for all terminal states

12
Minimax Strategy
13
Minimax Strategy

• Optimal strategy
• Assumption opponent plays his best possible
  move.
• An option is picked which
• Minimizes damage done by opponent
• Does most damage to the opponent
• Idea
• For each node find minimum minimax value
• Choose the node with maximum of such values
• This will ensure best value against most damage
  done by opponent

14
Strategy of Minimax

• Opponent tries to reduce utility functions value
• For any move made by opponent in reply of
  computers move, choose minimum reduced value by
  opponent
• Find the move with maximum such value

15
(No Transcript)
16
Analysis

• Algorithm is complete for complete tree only
• Not best strategy against irrational opponent
• According to definition
• Time complexity O(bm)
• b max. no. of possible moves
• m max. depth of tree
• In chess even in average case, b 35 and
• m 100 gt time exceeds practical limits
• of states grows exponentially as per number of
  moves played

17
a-ß Pruning
18
a-ß Pruning

• The problem of minimax search
• of state to examine exponential in number of
  moves
• Returns same moves as minimax does
• Prunes away branches that cant influence final
  decision.
• a the value of the best (highest) choice so far
  in search of MAX
• ß the value of the best (lowest) choice so far
  in search of MIN
• Order of considering successor

19
Algorithm for a-ß Pruning

• Current highest ß is found and assigned as a
• ß is current lowest for as from that move
• For next possible node, while finding ß, if some
  a is found lower than current highest ß
• It will only give lesser value of final ß
• S0, other as are not found for that node
• After calculating ß for this node, a is replaced
  by max(a,ß for this node)
• In this way after all possible set of moves final
  value of a is found

20
(No Transcript)
21
a-ß Pruning (2)

• If m is better than n for Player, we will never
  get to n in play
• and just prune it.

22
Analysis of a-ß Pruning
Improvement over minimax algorithm

• Does not affect final results
• Worthwhile to examine that successor first which
  is likely to be best
• Time complexity O(b(m/2))
• Effective branching factor vb
• i.e. 6 rather than 35
• In case of random ordering
• Total number of nodes examined is of the order
  O(b(3m/4))

23
Transposition table

• Dynamic programming
• Multiple paths to the same position
• Savings through memorization
• Use a hash table of evaluated positions

24
Iterative Deepening

• Sometime chess is played under a strict time
• Depth of search depend on time
• Use of Breadth first Search
• Advantage program know which move was
• best at previous level

25
Horizon Effect

• Problem with fixed depth search
• Positive Horizon Effect
• Negative horizon effect

26
Quiescence Search

• Search till quiet position
• Quiet Position
• Doesnt affect the current position so much
• Example no capture of any piece, no check, no
  pawn promotions/threats

27
State of the art DEEP BLUE
28
Defeats Gary Kasparov

• Won a match in 1997
• Brute force computing power
• Massive, parallel architecture
• Special purpose hardware for chess
• Parameters of the evaluation function
• Learnt by studying many master games
• Different evaluation function for different
  positions
• Utilized heavily loaded endgame databases

29
Humans vs. Computers
Humans Computers
Lower Computational Speed Higher
Errors Possible Error Free
Tend to be instinctive No instincts
Imaginative None
High Learning Capabilities Limited
Inductive Not Inductive
30
Some intricacies of a chess playing system

• Should not play the same sequence of moves again
• A player wins a match against the computer
• Starts playing the same sequence of moves
• Hence, a statistical element is required
• Opponent can learn the algorithm used by computer
• Hence, again the need for a statistical element
• Different game play during different phases
• Start Game
• Mid Game
• End Game

31
Conclusion

• Computer chess as a search problem
• Good enough decisions
• Simulation of skill by knowledge
• Limitations of computers to humans
• Future work
• Better evaluation functions through learning
• Need for different AI techniques to play chess

32
References

• Claude E. Shannon Programming a Computer for
  Playing Chess, Philosophical Magazine, Ser.7,
  Vol. 41, No. 314, March 1950.
• S.Russel P. Norvig Artificial Intelligence A
  Modern Approach 2/E, Prentice Hall, ISBN-10
  0137903952
• Wikipedia

33
Thank You
