Title: Programming


1
Programming
  • Sorting
  • Arrays

2
Sorting
  • To arrange a set of items in sequence.
  • It is estimated that 2550 of all computing
    power is used for sorting activities.
  • Possible reasons
  • Many applications require sorting
  • Many applications perform sorting when they don't
    have to
  • Many applications use inefficient sorting
    algorithms.

3
Sorting Applications
  • To prepare a list of student ID, names, and
    scores in a table (sorted by ID or name) for easy
    checking.
  • To prepare a list of scores before letter grade
    assignment.
  • To produce a list of horses after a race (sorted
    by the finishing times) for payoff calculation.
  • To prepare an originally unsorted array for
    ordered binary searching.

4
Some Sorting Methods
  • Selection sort
  • Bubble sort
  • Shell sort (a simple but faster sorting method
    than above see p.331 of Numerical Recipes in C,
    2nd ed., by William H. Press et al, Cambridge
    University Press, 1992)
  • Quick sort (a very efficient sorting method for
    most applications p.332-336, ibid.)

5
Ex. 1A Selection Sort
  • Selection sort performs sorting by repeatedly
    putting the largest element in the unsorted
    portion of the array to the end of this unsorted
    portion until the whole array is sorted.
  • It is similar to the way that many people do
    their sorting.

6
Ex. 1A Selection Sort
  • Algorithm
  • 1. Define the entire array as the unsorted
    portion of the array
  • 2. While the unsorted portion of the array has
    more than one element ? Find its largest
    element.
  • ? Swap with last element (assuming their
    values are different).
  • ? Reduce the size of the unsorted portion
    of the array by 1.

7
Before sorting 14 2 10 5 1 3 17 7

After pass 1 14 2 10 5 1 3 7 17

After pass 2 7 2 10 5 1 3 14 17

After pass 3 7 2 3 5 1 10 14 17

After pass 4 1 2 3 5 7 10 14 17
8
  • // Sort array of integers in ascending order
  • void select(int data, // in/output array
  • int size) // input array size
  • int temp // for swap
  • int max_index // index of max value
  • for (int rightmostsize-1 rightmostgt0
    rightmost--)
  • //find the largest item in the unsorted portion
  • //rightmost is the end point of the unsorted
    part of array
  • max_index 0 //points the largest element
  • for ( int current1 currentltrightmost
    current)
  • if (datacurrent gt datamax_index)
  • max_index current
  • //swap the largest item with last item if
    necessary
  • if (datamax_index gt datarightmost)
  • temp datamax_index // swap
  • datamax_index datarightmost
  • datarightmost temp

9
  • const int array_size 8
  • int main()
  • int listarray_size 14, 2, 10, 5, 1,
  • 3, 17, 7
  • int index, ans
  • cout ltlt "Before sorting "
  • for (index 0 indexltarray_size index)
  • cout ltlt listindex ltlt" "
  • cout ltlt endl
  • cout ltlt "Enter sorting method 1(select),
    2(bubble)"
  • cin gtgt ans
  • if (ans 1) select(list, array_size)
  • else bubble(list, array_size)
  • cout ltlt endl ltlt "After sorting "
  • for (index 0 indexltarray_size index)
  • cout ltlt listindex ltlt" "
  • cout ltlt endl
  • return 0

10
Ex. 1B Bubble Sort
  • Bubble sort examines the array from start
  • to finish, comparing elements as it goes.
  • Any time it finds a larger element before a
    smaller element, it swaps the two.
  • In this way, the larger elements are passed
    towards the end.
  • The largest element of the array therefore
    "bubbles" to the end of the array.
  • Then it repeats the process for the unsorted
    portion of the array until the whole array is
    sorted.

11
Ex. 1A Bubble Sort
  • Bubble sort works on the same general principle
    as shaking a soft drink bottle.
  • Right after shaking, the contents are a mixture
    of bubbles and soft drink, distributed randomly.
  • Because bubbles are lighter than the soft drink,
    they rise to the surface, displacing the soft
    drink downwards.
  • This is how bubble sort got its name, because the
    smaller elements "float" to the top, while
  • the larger elements "sink" to the bottom.

12
Ex. 1B Bubble Sort
  • Algorithm
  • Define the entire array as the unsorted portion
    of the array.
  • While the unsorted portion of the array has more
    than one element
  • 1. For every element in the unsorted portion,
    swap with the next neighbor if it is larger than
    the neighbor.
  • 2. Reduce the size of the unsorted portion of
    the array by 1.

13
Before sorting 14 2 10 5 1 3 17 7
outer7, inner0 2 14 10 5 1 3 17 7
outer7, inner1 2 10 14 5 1 3 17 7
outer7, inner2 2 10 5 14 1 3 17 7
outer7, inner3 2 10 5 1 14 3 17 7
outer7, inner4 2 10 5 1 3 14 17 7
outer7, inner6 2 10 5 1 3 14 7 17
outer6, inner1 2 5 10 1 3 14 7 17
outer6, inner2 2 5 1 10 3 14 7 17
outer6, inner3 2 5 1 3 10 14 7 17
outer6, inner5 2 5 1 3 10 7 14 17
outer5, inner1 2 1 5 3 10 7 14 17
outer5, inner2 2 1 3 5 10 7 14 17
outer5, inner4 2 1 3 5 7 10 14 17
outer4, inner0 1 2 3 5 7 10 14 17
---
outer1, inner0 1 2 3 5 7 10 14 17
14
  • //Example1b Bobble sort
  • // Sort an array of integers in ascending order
  • void bubble(int data, // in/output array
  • int size) // input array size
  • int temp // for swap
  • for(int outersize-1 outer gt 0 outer--)
  • for (int inner0 inner lt outer inner)
  • // traverse the nested loops
  • if ( datainner gt datainner1 )
  • // swap current element with next
  • // if the current element is greater
  • temp datainner
  • datainner datainner1
  • datainner1 temp
  • // inner for loop
  • // outer for loop

15
  • const int array_size 12, string_size 11
  • int main()
  • char montharray_sizestring_size
    "January",
  • "February","March","April","May","June","July","A
    ugust",
  • "September", "October", "November", "December"
  • int index, ans
  • cout ltlt "Enter sorting method 1(select),
    2(bubble) "
  • cin gtgt ans
  • if (ans 1) select(month, array_size)
  • else bubble(month, array_size)
  • cout ltlt endl ltlt "After sorting "
  • for (index 0 indexltarray_size index)
  • cout ltlt monthindex ltlt" "
  • cout ltlt endl
  • return 0

16
0 1 2 3 4 5 6 7 8 9 10
month0 J a n u a r y \0
month1 F e b r u a r y \0
month2 M a r c h \0
month3 A p r i l \0
month4 M a y \0
month5 J u n e \0
month6 J u l y \0
month7 A u g u s t \0
month8 S e p t e m b e r \0
month9 O c t c b e r \0
month10 N o v e m b e r \0
month11 D e c e m b e r \0
17
  • // Sort array of strings in ascending order
  • void select(char datastring_size, //
    in/output array
  • int size) // input array size
  • char tempstring_size // for swap
  • int max_index // index of max value
  • for (int rightmostsize-1 rightmostgt0
    rightmost--)
  • // find the largest item
  • max_index 0
  • for(int current1 currentltrightmost
    current)
  • if (strcmp(datacurrent,
    datamax_index) gt0)
  • max_index current
  • // swap with last item if necessary
  • if(strcmp(datamax_index, datarightmost)gt0)
  • strcpy(temp,datamax_index) // swap
  • strcpy(datamax_index,datarightmost)
  • strcpy(datarightmost, temp)
  • for (int index0 indexlt size index)
  • cout ltlt dataindex ltlt " "
  • coutltltendl

18
  • // Sort an array of strings in ascending order
  • void bubble(char datastring_size, //
    in/outputarray
  • int size) // input array
    size
  • char tempstring_size // for swap
  • for(int outersize-1 outergt0 outer--)
  • for (int inner0 inner lt outer inner)
  • // traverse the nested loops
  • if ( strcmp(datainner, datainner1)gt0 )
  • // swap current element with next
  • // if the current element is
    greater
  • strcpy(temp, datainner)
  • strcpy(datainner,
    datainner1)
  • strcpy(datainner1, temp)
  • for (int index0 indexlt size
    index)
  • cout ltlt dataindex ltlt " "
  • coutltltendl
  • // inner for loop
