Title: IEEE 802.16


1
IEEE 802.16
2
Topics
  • Introduction
  • Physical Layer
  • MAC Layer
  • QoS

3
  • Introduction
  • Physical Layer
  • MAC Layer
  • QoS

4
  • Goal Provide high-speed Internet access to home
    and business subscribers, without wires.
  • Base stations (BS) can handle thousands of
    subscriber stations (SS)
  • Access control prevents collisions.
  • Supports
  • Legacy voice systems
  • Voice over IP
  • TCP/IP-Applications with different QoS
    requirements.

5
  • 802.16 standards
  • 802.16.1 (10-66 GHz, line-of-sight, up to
    134Mbit/s)
  • 802.16.2 (minimizing interference
    between coexisting WMANs.)
  • 802.16a (2-11 Ghz, Mesh, non-line-of-
    sigth)
  • 802.16b (5-6 Ghz)
  • 802.16c (detailed system profiles)
  • P802.16e (Mobile Wireless MAN)

6
(No Transcript)
7
  • Introduction
  • Physical Layer
  • MAC Layer
  • QoS

8
  • Adaptive Data Burst Profiles
  • Transmission parameters (e.g. modulation and FEC
    settings) can be modified on a frame-by-frame
    basis for each SS.
  • Profiles are identified by Interval Usage Code
    (Downlink Interval Usage Code (DIUC) and Uplink
    Interval Usage Code (UIUC).)

9
  • Using both
  • TDM (Time Division Multiplexing) and
  • TDMA (Time Division Multiple Access)
  • What is the difference, you ask..
  • TDM Time-Division Multiplexing (TDM) is a type
    of digital or (rarely) analog multiplexing in
    which two or more signals or bit streams are
    transferred apparently simultaneously as
    sub-channels in one communication channel, but
    physically are taking turns on the channel. The
    time domain is divided into several recurrent
    timeslots of fixed length, one for each
    sub-channel.
  • TDMA Time division multiple access (TDMA) is a
    channel access method for shared medium (usually
    radio) networks. It allows several users to share
    the same frequency channel by dividing the signal
    into different timeslots. The users transmit in
    rapid succession, one after the other, each using
    his own timeslot. This allows multiple stations
    to share the same transmission medium (e.g. radio
    frequency channel) while using only the part of
    its bandwidth they require. TDMA is used in the
    digital 2G cellular systems such as Global System
    for Mobile Communications (GSM), IS-136, Personal
    Digital Cellular (PDC) and iDEN, and in the
    Digital Enhanced Cordless Telecommunications
    (DECT) standard for portable phones.

10
  • The main difference between tdm and tdma (also
    fdm/fdma, etc) is that with tdm (also fdm, etc.)
    the signals multiplexed (i.e. sharing a resource)
    come from the same node, whereas for tdma (also
    fdm, etc.) the signals multiplexed come from
    different sources/transmitters.

11
Time Division Multiplexing (TDM) imply
partitioning the bandwidth of the channel
connecting two nodes into finite set of time
slots.
12
Time Division multiple Access (TDMA) imply
partitioning the bandwidth of a channel shared by
many nodes, typically an infrastructure node and
several mobile nodes, where each node gets to
access its dedicated time slot.
13
  • Introduction
  • Physical Layer
  • MAC Layer
  • QoS

14
  • Connection orienteded
  • Connection ID (CID), Service Flows(FS)
  • Channel access
  • UL-MAP
  • Defines uplink channel access
  • Defines uplink data burst profiles
  • DL-MAP
  • Defines downlink data burst profiles
  • UL-MAP and DL-MAP are both transmitted in the
    beginning of each downlink subframe (FDD and
    TDD).

15
TDD Downlink subframe
16
FDD Downlink subframe
17
FDD burst framing
18
Uplink subframe
19
Upplink periods
  • Initial Maintenance opportunities
  • Ranging
  • To determine network delay and to request power
    or profile changes.
  • Collisions may occur in this interval
  • Request opportunities
  • SSs request bandwith in response to polling from
    BS.
  • Collisions may occur in this interval aswell.
  • Data grants period
  • SSs transmit data bursts in the intervals granted
    by the BS.
  • Transition gaps between data intervals for
    synchronization purposes.

20
Bandwidth request and allocation
  • SubscribersStations may request bw in 3 ways
  • Use the contention request opportunities
    interval upon being polled by the BS (multicast
    or broadcast poll).
  • Send a standalone MAC message called BW request
    in an allready granted slot.
  • Piggyback a BW request message on a data packet.

21
  • BS grants/allocates bandwidth in one of two
    modes
  • Grant Per Subscriber Station (GPSS)
  • Grant Per Connection (GPC)
  • Decision based on requested bw and QoS
    requirements vs available resources.
  • Grants are realized through the UL-MAP.

22
Unicast Polling
  • BS allocates space for the SS in the uplink
    subframe.
  • SS uses the allocated space to send a bw request.
  • BS allocates the requested space for the SS (if
    available).
  • SS uses allocated space to send data.

23
4 types of Scheduling Service
  • Unsolicited Grant Service (UGS)
  • Real-time, periodic fixed size packets (e.g. T1
    or VoIP)
  • Restrictions on bw requests (Poll-Me bit)
  • Slip Indicator (SI)
  • Real-Time Polling Service (rtPS)
  • Real-time, periodic variable sizes packets (e.g
    MPEG)
  • BS issues periodic unicast polls.
  • Cannot use contention requests, but piggybacking
    is ok.
  • Non-Real-Time Polling Service (nrtPS)
  • Variable sized packets with loose delay
    requirements (e.g. FTP)
  • BS issues unicast polls regularly (not
    necessarily periodic).
  • Can also use contention requests and
    piggybacking.
  • Best Effort Service
  • Never polled individually
  • Can use contention requests and piggybacking

24
Scheduling types
25
  • Introduction
  • Physical Layer
  • MAC Layer
  • QoS

26
  • The 802.16 standard specifies two modes for
    sharing the wireless medium
  • point-to-multipoint (PMP) and
  • mesh(optional).

27
  • PMP With PMP, the BS serves a set of SSs within
    the same antenna sector in a broadcast manner,
    with all SSs receiving the same transmission from
    the BS. Transmissions from SSs are directed to
    and centrally coordinated by the BS.
  • Mesh Traffic can be routed through other SSs and
    can occur directly among SSs. Access coordination
    is distributed among the SSs.

28
PMP MODE
  • uplink (from SS to BS) and downlink (fromBS to
    SS) data transmissions occur in separate time
    frames.
  • In the downlink sub-frame, the BS transmits a
    burst of MAC protocol data units (PDUs).
  • In the uplink sub-frame, on the other hand, any
    SS transmits a burst of MAC PDUs to the BS in a
    time-division multiple access (TDMA) manner.

29
(No Transcript)
30
  • Downlink and uplink sub-frames are duplexed using
    one of the following techniques, as shown in
    above figure
  • Frequency-division duplex(FDD) is where downlink
    and uplink sub-frames occur simultaneously on
    separate frequencies, and time-division duplex
    (TDD) is where downlink and uplink sub-frames
    occur at different times and usually share the
    same frequency. SSs can be either full duplex
    (i.e., they can transmit and receive
    simultaneously)or half-duplex (i.e., they can
    transmit and receive at nonoverlapping time
    intervals).

31
(No Transcript)
32
  • The MAC protocol is connection-oriented all data
    communications, for both transport and control,
    are in the context of a unidirectional
    connection.
  • At the start of each frame, the BS schedules the
    uplink and downlink grants in order to meet the
    negotiated QoS requirements.
  • Each SS learns the boundaries of its allocation
    within the current uplink sub-frame by decoding
    the UL-MAP message.
  • The DL-MAP message contains the timetable of the
    downlink grants in the forthcoming downlink
    sub-frame. More specifically, downlink grants
    directed to SSs with the same DIUC are advertised
    by the DL-MAP as a single burst. Both maps are
    transmitted by the BS at the beginning of each
    downlink sub-frame.
  • Above Figure 2 shows the blueprint of the
    functional entities for QoS support, which
    logically reside within the MAC layer of the BS
    and SSs.
  • Each downlink connection has a packet queue (or
    queue, for short) at the BS (represented with
    solid lines).
  • In accordance with the set of QoS parameters and
    the status of the queues, the BS downlink
    scheduler selects from the downlink queues,on a
    frame basis, the next service data units (SDUs)
    to be transmitted to SSs.
