Module 5: Creating and Configuring Group Policies

1

• Module 5 Creating and Configuring Group
  Policies

2
Module Overview

• Overview of Group Policies
• Configuring the Scope of Group Policy Objects
• Evaluating the Application of Group Policy
  Objects
• Managing Group Policy Objects
• Delegating Administrative Control of Group
  Policies

3
Lesson 1 Overview of Group Policies

• What Are Group Policies?
• Group Policy Settings
• How Group Policies Are Applied
• Exceptions to Normal Group Policy Processing
• Group Policy Components
• What Are ADM and ADMX files?
• What Is the Central Store?
• Demonstration Configuring Group Policy Objects

4
What Are Group Policies?
Group Policies enable IT administrators to
automate one-to-many management of users and
computers
Use Group Policies to

• Apply standard configurations

• Deploy software

• Enforce security settings

• Enforce a consistent desktop environment

Local group policies are always in effect for
local and domain users and local computer settings
5
Group Policy Settings

• Software
• Windows
• Security
• Desktop

Group Policy settings for users control these
settings

• Software
• Windows
• Security
• Operating systems

Group Policy settings for computers control
thesesettings
6
How Group Policies are Applied
Computer starts
Refresh Interval
Every 90 minutes

• Computer settings applied
• Startup scripts run

User logs on
Refresh Interval
Every 90 minutes

• User settings applied
• Logon scripts run

7
Exceptions to Group Policy Processing
Additional exceptions

• 500 KPS by default
• Certain client side extensions are not processed
• Prior to Vista, ICMP is used to detect a slow
  link
• Vista uses Network Location Awareness

Slow links
Cached credentials

• Windows XP and Vista use cached credential for
  faster logons
• Many GPO settings take two logons to take effect

• Remote access connections
• Moving a user or computer object in Active
  Directory

8
Group Policy Components
Group Policy Container

• Stored in Active Directory
• Provides version information

Group Policy Object
Group Policy Template

• Stored in shared SYSVOL folder
• Provides Group Policy settings
• Supports both ADM and ADMX templates

• Contains Group Policy settings
• Stores content in two locations

9
What Are ADM and ADMX Files?
ADM files are

• Copied into every GPO in SYSVOL
• Difficult to customize

ADMX files are

• Language neutral
• Not stored in the GPO
• Extensible through XML

10
What Is the Central Store?
The Central Store

• Is a central repository for ADMX and ADML files
• Is stored in SYSVOL
• Must be created manually
• Is detected automatically by Windows Vista or
  Server 2008

ADMX files
Windows Vista or Windows Server 2008workstation
Domain controller with SYSVOL
Domain controller with SYSVOL
11
Demonstration Configuring Group Policy Objects

• In this demonstration, you will see how to
• Create a GPO
• Configure settings

12
Lesson 2 Configuring the Scope of Group Policy
Objects

• Group Policy Processing Order
• What Are Multiple Local Group Policies?
• Options for Modifying Group Policy Processing
• Demonstration Configuring Group Policy Object
  Links
• Demonstration Configuring Group Policy
  Inheritance
• Demonstration Filtering Group Policy Objects
  Using Security Groups
• Demonstration Filtering Group Policy Objects
  Using WMI Filters
• How Does Loopback Processing Work?
• Discussion Configuring the Scope of Group Policy
  Processing

13
Group Policy Processing Order
GPO1
Local group
GPO5
OU
OU
14
What Are Multiple Local Group Policies?

• One layer of computer configurations that
  applies to all users

• Layers apply only to individual users, not to
  groups

• There are three layers of user configurations
• Administrator
• Non-Administrator
• User-specific

15
Options for Modifying Group Policy Processing

• Five methods to modify GPO default processing

• Block inheritance

• Enforcement

• Filtering using security groups or WMI filters

• Disabling GPOs

• Loopback processing

16
Demonstration Configuring Group Policy Object
Links

• In this demonstration, you will see how to
• Create and link GPOs to different locations
  within AD DS
• Disable a GPO link

17
Demonstration Configuring Group Policy
Inheritance

• In this demonstration, you will see how to
• Block GPO inheritance
• Enforce GPO inheritance

18
Demonstration Filtering Group Policy Objects By
Using Security Groups

• In this demonstration, you will see how to filter
  the application of GPOs using security groups

19
Demonstration Filtering Group Policy Objects
Using WMI Filters

• In this demonstration, you will see how to create
  and assign a WMI filter

20
How Does Loopback Processing Work?
21
Discussion Configuring the Scope of Group Policy
Processing
Woodgrove Bank Domain Tree
Woodgrove Bank
Head Office site
Head Office
Slow link
Branches
High-speed link
Toronto
Winnipeg
Servers
SQL Server
Exchange Server
22
Lesson 3 Evaluating the Application of Group
Policy Objects

• What Is Group Policy Reporting?
• What Is Group Policy Modeling?
• Demonstration How to Evaluate the Application of
  Group Policies

23
What Is Group Policy Reporting?
Group policy reporting is a method of planning
and troubleshooting group policy

• Group Policy results are provided by the GPMC

• GPResult is a command line utility

24
What Is Group Policy Modeling?
The Group Policy Modeling Wizard calculates the
simulated net effect  of GPOs

• The Group Policy Modeling Wizard simulates

• Site membership
• Security group membership
• WMI filters
• Slow links
• Loopback processing
• The effects of moving user or computer objects to
  a different Active Directory container

25
Demonstration How to Evaluate the Application of
Group Policies

• In this demonstration, you will see how to run
  each of the tools for reviewing the application
  of group policies

26
Lesson 4 Managing Group Policy Objects

• GPO Management Tasks
• What Is a Starter GPO?
• Demonstration How to Copy a GPO
• Demonstration Backing up and Restoring GPOs
• Demonstration Importing a GPO
• Migrating Group Policy Objects

27
GPO Management Tasks

• GPO management tasks

• Back up GPOs
• Restore GPOs
• Copy GPOs
• Import GPOs

28
What Is a Starter GPO?

• Stores administrative template settings on which
  the new GPOs will be based
• Can be exported to .cab files
• Can be imported into other areas of the enterprise

Exported to cab file
Imported to GPMC
starterGPO
Cab file
Load cabinet file
29
Demonstration How to Copy a GPO

• In this demonstration, you will see how to copy a
  GPO

30
Demonstration Backing up and Restoring GPOs

• In this demonstration, you will see how to back
  up and restore a GPO

31
Demonstration Importing a GPO

• In this demonstration, you will see how to
• Import a GPO
• Use a migration table

32
Migrating Group Policy Objects
33
Lesson 5 Delegating Administrative Control of
Group Policies

• Options for Delegating Control of GPOs
• Demonstration How to Delegate Administrative
  Control of GPOs

34
Options for Delegating Control of GPOs
Methods to delegate control of GPOs Create GPOs in the domain Edit or delete GPOs Link GPOs to containers Use reporting tools
Membership in Group Policy Creator Owners group or explicit permission to create GPOs
Assign Edit rights to individual policies
Delegate the right to link GPOs to containers
Delegate the right to use group policy reporting tools
35
Demonstration How to Delegate Administrative
Control of GPOs

• In this demonstration, you will see how to
  delegate the right to create, edit, link, and use
  the reporting tools for group policies

36
Lab Creating and Configuring GPOs

• Exercise 1 Creating Group Policy Objects
• Exercise 2 Managing the Scope of GPO Application
• Exercise 3 Verifying GPO Application
• Exercise 4 Managing GPOs
• Exercise 5 Delegating Administrative Control of
  GPOs

Logon information
Virtual machine NYC-DC1, NYC-CL1
User name Administrator
Password Paw0rd
Estimated time 75 minutes
37
Lab Review

• What other method could be used to grant a user
  the right to create GPOs in the domain?
• If you need to apply a GPO to computers that have
  certain services installed, what is the best
  approach?

38
Module Review and Takeaways

• Considerations
• Review questions
