HTTP Caching

1
HTTP Caching Cache-Bustingfor Content
Publishers
Michael J. Radwin http//public.yahoo.com/radwin/
ApacheCon 2004 November 17, 2004
2
Hi, Im Michael J. Radwin

• Engineering Manager, Yahoo! Inc.
• Internal FAMP dev support
• FreeBSD, Apache, MySQL, PHP
• Also, some C/C libs (networking, data storage)
• Web Services infrastructure
• Developer Tools
• CVS, Bugzilla, package mgmt, i18n workflow
• Slides online
• http//public.yahoo.com/radwin/

3
Why youre here today

• Publishers have a lot of web content
• HTML, images, Flash, movies
• Speed is important part of user experience
• Bandwidth is expensive
• Use what you need, but avoid unnecessary extra
• Personalization differentiates
• Show timely data (stock quotes, news stories)
• Get accurate advertising statistics
• Protect sensitive info (e-mail, account balances)

4
Not covered in this talk

• Proxy deployment
• Configuring proxy cache servers (i.e. Squid)
• Configuring browsers to use proxy caches
• Transparent/interception proxy caching
• Intercache protocols (ICP, HTCP)
• HTTP acceleration (a k a reverse proxies)
• Database query results caching

5
HTTP Review
(1) Client connects to www.example.com port 80
Server
Client
Internet
(2) Client sends HTTP GET request
Server
Client
Internet
6
HTTP Review (contd)
(3) Client reads HTTP response from server
Server
Client
Internet
(4) Client and Server close connection
Server
Client
Internet
7
HTTP Example

• mradwin_at_machshav telnet www.example.com 80
• Trying 192.168.37.203...
• Connected to w6.example.com.
• Escape character is ''.
• GET /foo/index.html HTTP/1.1
• Host www.example.com
• HTTP/1.1 200 OK
• Date Wed, 28 Jul 2004 233612 GMT
• Last-Modified Fri, 23 Jul 2004 015237 GMT
• Content-Length 3688
• Connection close
• Content-Type text/html
• lthtmlgtltheadgt
• lttitlegtHello Worldlt/titlegt
• ...

8
Browsers use private caches
GET /foo/index.html HTTP/1.1 Host www.example.com
Server
Client
Internet
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul 2004
015237 GMT Content-Length 3688 Content-Type
text/html
Client stores copy of http//www.example.com/foo/i
ndex.html on its hard disk with timestamp.
9
Revalidation (Conditional GET)
GET /foo/index.html HTTP/1.1 Host
www.example.com If-Modified-Since Fri, 23 Jul
2004 015237 GMT
Server
Client
Internet
HTTP/1.1 304 Not Modified
10
Non-Caching Proxy
GET /foo/index.html HTTP/1.1 Host www.example.com
GET /foo/index.html HTTP/1.1 Host www.example.com
Server
Client
Proxy
Internet
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
11
Proxy Cache Miss
GET /foo/index.html HTTP/1.1 Host www.example.com
GET /foo/index.html HTTP/1.1 Host www.example.com
Server
Client
Proxy
Internet
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
12
Proxy Cache Hit
GET /foo/index.html HTTP/1.1 Host www.example.com
Server
Client
Proxy
Internet
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
13
Proxy Cache Revalidation Hit
GET /foo/index.html HTTP/1.1 Host www.example.com
GET /foo/index.html HTTP/1.1 Host
www.example.com If-Modified-Since Fri, 23 Jul ...
Server
Client
Proxy
Internet
HTTP/1.1 304 Not Modified
HTTP/1.1 200 OK Last-Modified Fri, 23 Jul
... Content-Length 3688 Content-Type text/html
14
Assumptions about content types
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
15
Top 5 techniques for publishers

1. Use Cache-Control private for personalized
   content
2. Implement Images Never Expire policy
3. Use a cookie-free TLD for static content
4. Use Apache defaults for CSS JavaScript
5. Use random strings in URL for accurate hit
   metering or very sensitive content

16
1. Use Cache-Control privatefor personalized
content
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
17
Shared caching gone awry (1)
GET /msg3.html HTTP/1.1 Host webmail.example.com
Cookie userjane
GET /msg3.html HTTP/1.1 Host webmail.example.com
Cookie userjane
Webmail Server
Proxy
Client 1
Internet
Janes e-mail message
Janes e-mail message

18
Shared caching gone awry (2)
GET /msg3.html HTTP/1.1 Host webmail.example.com
Cookie userjane
Webmail Server
Proxy
Client 1
Internet
Janes e-mail message
msg3.html
19
Shared caching gone awry (3)
Webmail Server
Proxy
GET /msg3.html HTTP/1.1 Host webmail.example.com
Cookie usermary
Internet
Client 2
msg3.html
Janes e-mail message
20
Whats cacheable?

• HTTP/1.1 allows caching anything by default
• Unless explicit Cache-Control header
• In practice, most caches avoid anything with
• Cache-Control/Pragma header
• Cookie/Set-Cookie headers
• WWW-Authenticate/Authorization header
• POST/PUT method
• 302/307 status code

21
Cache-Control private

• Shared caches bad for shared content
• Mary shouldnt be able to read Janes mail
• Private caches perfectly OK
• Speed up web browsing experience
• Avoid personalization leakage with single line in
  httpd.conf or .htaccess
• Header set Cache-Control private

22
2. Images Never Expire policy
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
23
Images Never Expire Policy

• Encourage caching of icons logos
• Forever 10 years in Internet biz
• Must change URL when you change img
• http//us.yimg.com/i/new.gif
• http//us.yimg.com/i/new2.gif
• Tradeoff
• More difficult for designers
• Bandwidth savings, faster user experience

24
Imgs Never Expire mod_expires

• Works with both HTTP/1.0 and HTTP/1.1
• ExpiresActive On
• ExpiresByType image/gif A315360000
• ExpiresByType image/jpeg A315360000
• ExpiresByType image/png A315360000

25
Imgs Never Expire mod_headers

• Works with HTTP/1.1 only
• ltFilesMatch "\.(gifjpe?gpng)"gt
• Header set Cache-Control \ "max-age315360000"

• lt/FilesMatchgt
• Works with both HTTP/1.0 and HTTP/1.1
• ltFilesMatch "\.(gifjpe?gpng)"gt
• Header set Expires \ "Mon, 28 Jul 2014
  233000 GMT"
• lt/FilesMatchgt

26
mod_images_never_expire

• / Enforce policy with module that runs at URI
  translation hook /
• static int translate_imgexpire(request_rec r)
• const char ext
• if ((ext strrchr(r-gturi, '.')) ! NULL)
• if (strcasecmp(ext,".gif") 0
  strcasecmp(ext,".jpg") 0
• strcasecmp(ext,".png") 0
  strcasecmp(ext,".jpeg") 0)
• if (ap_table_get(r-gtheaders_in,"If-Modified-
  Since") ! NULL
• ap_table_get(r-gtheaders_in,"If-None-Matc
  h") ! NULL)
• / Don't bother checking filesystem, just
  hand back a 304 /
• return HTTP_NOT_MODIFIED
• return DECLINED

27
3. Cookie-free static content
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
28
Use a cookie-free Top Level Domain for static
content

• For maximum efficiency use two domains
• www.example.com for HTML
• img.example.net for images
• Some proxies wont cache Cookie reqs
• But multimedia is never personalized
• Cookies irrelevant for images

29
Typical GET request w/Cookies

• GET /i/foo/bar/quux.gif HTTP/1.1
• Host www.example.com
• User-Agent Mozilla/5.0 (Windows U Windows NT
  5.0 en-US rv1.7) Gecko/20040707 Firefox/0.8
• Accept application/x-shockwave-flash,text/xml,app
  lication/xml,application/xhtmlxml,text/htmlq0.9
  ,text/plainq0.8,video/x-mng,image/png,image/jpeg
  ,image/gifq0.2,/q0.1
• Cookie UmtvtC1tp2MhYv9RL5BlpxYRFN_P8DpMJoamllEc
  A--uxIIr.ABun42vnticvufc8v brandflash1
  Bamfco1503sgp8b2 FaNC184LcsvfX96G.JR27qSjCHu
  7bII3s. tXa44psMLliFtVoJB_m5wecWY_.7bK1It
  LYCl_v2l_lv7l_lh03m8d50c8bo
  l_s3yu2qxz5zvwquwwuzv22wrwr5t3w1zsrl_lid14rsb7
  6l_ra8l_um1_0_1_0_0 GTSessionID8359908990238
  3599089902340645635 Yv1n6eecgejj7012f
  lh03m8d50c8bo/opm012o33013000007jb1647ra
  8lgusintlusnp1 PROMOSOURCEfp5 YGCVd
  TziTu.ABiZD/AB6dPWoqXibIcTzc0BjY3TzI3NTY0MzQ-a
  YAEskDAAwRz5HlDUN2Tdc2wBT0RBekFURXdPRFV3TWpFek
  5ETS0BYQFZQUUBb2sBWlcwLQF0aXABWUhaTVBBAXp6AWlUdS5B
  QmdXQQ--afQUFBQ0FDQURCOUFIQUJBQ0FEQUtBTE
  FNSDAmdHM9MTA5MDE4NDQxOCZwcz1lOG83MUVYcTYxOVouT2Ft
  c1ZFZUhBLS0- LYSl_fh0l_vomyla
  PAp0dg13DX4Ndgk-p16L5qmg--exMv.AB
  YP.usv2maddrd1525SRobertsonBlvd01LosAng
  eles01CA0190035-42310144800134.05159001-118.3
  8434201901a0190035
• Referer http//www.example.com/foo/bar.php?abc12
  3def456
• Accept-Language en-us,enq0.7,heq0.3
• Accept-Encoding gzip,deflate
• Accept-Charset ISO-8859-1,utf-8q0.7,q0.7
• Keep-Alive 300
• Connection keep-alive

30
Same request, no Cookies

• GET /i/foo/bar/quux.gif HTTP/1.1
• Host img.example.net
• User-Agent Mozilla/5.0 (Windows U Windows NT
  5.0 en-US rv1.7) Gecko/20040707 Firefox/0.8
• Accept application/x-shockwave-flash,text/xml,app
  lication/xml,application/xhtmlxml,text/htmlq0.9
  ,text/plainq0.8,video/x-mng,image/png,image/jpeg
  ,image/gifq0.2,/q0.1
• Referer http//www.example.com/foo/bar.php?abc12
  3def456
• Accept-Language en-us,enq0.7,heq0.3
• Accept-Encoding gzip,deflate
• Accept-Charset ISO-8859-1,utf-8q0.7,q0.7
• Keep-Alive 300
• Connection keep-alive
• Added bonus much smaller GET request
• Dial-up MTU size 576 bytes, PPPoE 1492
• 1450 bytes reduced to 550

31
4. Apache defaults for static, occasionally-changi
ng content
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
32
Revalidation works pretty well

• Revalidation default behavior for static content
• Browser sends If-Modified-Since request
• Server replies with short 304 Not Modified
• No fancy Apache config needed
• Use if you cant predict when content will change
• Page designers can change immediately
• No renaming necessary
• Cost extra HTTP transaction for 304
• Small with Keep-Alive, but large sites disable

33
5. Random URL strings for hit metering, sensitive
content
Rate of change once published Frequently
Occasionally Rarely/Never
HTML CSS JavaScript Images Flash PDF
Dynamic Content Static
Content Personalized Same for everyone
34
Accurate advertising statistics

• If you trust proxies
• Send Cache-Control must-revalidate
• Count 304 Not Modified log entries as hits
• If you dont
• Ask client to fetch uncacheable image URL
• Return 302 to highly cacheable image file
• Count 302s as hits
• Dont bother to look at cacheable server log

35
Hit-metering for ads (1)

• ltscript type"text/javascript"gt
• var r Math.random()
• var t new Date()
• document.write("ltimg width'109' height'52'
  src'http//ads.example.com/ad/foo/bar.gif?t"
  t.getTime() "r" r "'gt")
• lt/scriptgt
• ltnoscriptgt
• ltimg width"109" height"52" src
  "http//ads.example.com/ad/foo/bar.gif?js0"gt
• lt/noscriptgt

36
Hit-metering for ads (2)

• GET /ad/foo/bar.gif?t1090538707r0.5107729172349
  83 HTTP/1.1
• Host ads.example.com
• User-Agent Mozilla/5.0 (Windows U Windows NT
  5.0 en-US rv1.7) Gecko/20040707 Firefox/0.8
• Referer http//www.example.com/foo/bar.php?abc12
  3def456
• Cookie uidC50DF33E-E202-4206-B1F3-946AEDF9308B
• HTTP/1.1 302 Moved Temporarily
• Date Wed, 28 Jul 2004 234506 GMT
• Cache-Control max-age0,no-cache,no-store
• Expires Tue, 11 Oct 1977, 012345 GMT
• Pragma no-cache
• Location http//img.example.net/i/foo/bar.gif
• Content-Type text/html
• lta href"http//img.example.net/i/foo/bar.gif"gtMov
  edlt/agt

37
Hit-metering for ads (3)

• GET /i/foo/bar.gif HTTP/1.1
• Host img.example.net
• User-Agent Mozilla/5.0 (Windows U Windows NT
  5.0 en-US rv1.7) Gecko/20040707 Firefox/0.8
• Referer http//www.example.com/foo/bar.php?abc12
  3def456
• HTTP/1.1 200 OK
• Date Wed, 28 Jul 2004 234507 GMT
• Last-Modified Mon, 05 Oct 1998 183251 GMT
• ETag "69079e-ad91-40212cc8"
• Cache-Control public,max-age315360000
• Expires Mon, 28 Jul 2014 234507 GMT
• Content-Length 6096
• Content-Type image/gif
• GIF89a...

38
Defeating proxies turning public caches into
private caches

• Use distinct tokens in URL
• No two users use same token
• Defeats shared proxy caches
• Works well with private caches
• Doesnt break the back button
• May break visited-link highlighting
• e.g. JavaScript timestamps/random numbers
• Every link is blue, no purple

39
Breaking the Back button

• When users click browser Back button
• Expect to go back one page instantly
• Private cache enables this behavior
• Aggressive cache-busting breaks Back button
• Server sends Pragma no-cache or Expires in past
• Browser must re-visit server to re-fetch page
• Hitting network much slower than hitting disk
• Use very sparingly
• Compromising user experience is A Bad Thing

40
Review Top 5 techniques

1. Use Cache-Control private for personalized
   content
2. Implement Images Never Expire policy
3. Use a cookie-free TLD for static content
4. Use Apache defaults for CSS JavaScript
5. Use random strings in URL for accurate hit
   metering or very sensitive content

41
Review encouraging caching

• Send explicit Cache-Control or Expires
• Generate static content headers
• Last-Modified, ETag
• Content-Length
• Avoid cgi-bin, .cgi or ? in URLs
• Some proxies (e.g. Squid) wont cache
• Workaround use PATH_INFO instead

42
Review discouraging caching

• Use POST instead of GET
• Use random strings and ? char in URL
• Omit Content-Length Last-Modified
• Send explicit headers on response
• Breaks the back button
• Only as a last resort
• Cache-Control max-age0,no-cache,no-store
• Expires Thu, 01 Jan 1970 123456 GMT
• Pragma no-cache

43
Recommended Reading

• Web Caching and Replication
• Michael Rabinovich Oliver Spatscheck
• Addison-Wesley, 2001
• Web Caching
• Duane Wessels
• O'Reilly, 2001

44
Wrapping Up

• Please fill out Session Eval Form
• Session WE16
• Title HTTP Caching Cache-busting
• Speaker Michael Radwin
• Slides online
• http//public.yahoo.com/radwin/

45
(No Transcript)
