Polynuclear Hydrocarbons

1
Polynuclear Hydrocarbons
2
Classification of Polynuclear Hydrocarbons
Polynuclear Hydrocarbons may be divided into two
groups,
3

• Polynuclear Hydrocarbons
• Benzenoid Non- Benzenoid

Isolated Fused rings
Linear Angular
4
Isolated Ring Polynuclear HydrocarbonsBiphenyl
(diphenyl)
5
a) Fittig reaction b) From benzene
diazonium sulphate c) From benzidine

Preparation of Biphenyl
6

d) Ulmann diaryl synthesis
e) By using Arylmagnesium halide
7
Reactions of biphenylBiphenyl undergoes
substitution reactions,
8
In biphenyl one ring act as electron donating
group and the other act as electron withdrawing
group
9
Resonance shows that O- and P- are the most
reactive positions towards electrophilic
substitution.The electrophilic substitution
occurs in 4- position (major) and 2- position
(minor) due to steric effect of other benzene
ring.The 2nd substitution occurs in the empty
ring in 2 or 4- position.e.g.
10
Problem Explain the
products formed when biphenyl is
mononitrated and when it is dinitrated.
11
Biphenyl derivatives
(1) Benzidine (4, 4-diaminobiphenyl)
(2) Diphenic acid
(3) Diphenyl methane
12
Benzidine (4, 4' diaminobiphenyl)
Methods of preparation
13
From dihydrazo benzene
14
Q. Show how could you prepare benzidine from
benzene?

• Answer

15
Uses of Benzidine

• preparation of Congo red

16
(2) Diphenic acid
Methods of preparation
17
From anthranilic acid
18
Ulmann diaryl synthesis
19
oxidation of Phenanthrene or phenanthraquinone
20
Chemical Reactions
21
1. with acetic anhydride
22
2. Conversion of diphenic acid to dflourenone
23
3. with conc. H2SO4
24
4. Oxidation of KMnO4
25
5. with sodalime
26
Atropisomers of biphenyl

• Optical isomers produced due to restricted
  rotation is called atropisomers
• Restricted rotation produce when 0- position
  contains two different bulky groups and hence
  molecule is optically active.. for example

27
(No Transcript)
28

• When o- position contains two similar groups, the
  molecule is optically inactive due to presence of
  plane of symmetry .. for example

29
(3) Diphenyl methane
Methods of preparation
30
1. Friedel- Crafte
31
2. From benzophenone
32
Chemical Reactions
33
1. Nitration
34
2. Halogenation
35
3. Oxidation
36
II. Fused System
37
a) Naphthalene
38
Structure elucidation of naphthalene
1- Molecular Formula C6H8
2-
So naphthalene contain the skeleton
39
3-
So nitro group is present in benzene ring
40
4-
The benzene ring in phthalic acid produced by
oxidation of aminonaphthalene is not the same
ring is that obtained by oxidation of
nitronaphthalene.
41
i.e. Naphthalene contains two benzene rings and
we can explain this by this equation
42
The structure of naphthalene is confirmed by
method of its analysis
1- Howarth method
43
Other way of cyclization
44

• The reaction occurs if R is o- or p- directing
  group such as NH2, NHR, OH, OR, R, halogen.
• If R is m- directing group (e.g. NO2, CN, COOH,
  COCH3, SO3H) no reaction occur.
• The above reaction gives ? -substituted
  naphthalene.

45
Synthesis of 1-alkyl naphthalene
46
2- From ?-benzylidene propenoic acid
47
Chemical Reactions of naphthalene
48
1. Reduction
49
2. Oxidation
50
3. Addition of Cl2
51
4. Electrophilic substitution reaction
Q Naphthalene udergoes electrophilic
substitution at position 1 not 2. Explain
At position 1 carbocation intermediate stabilize
by two resonance
So carbocation is more stable position 1 than 2
52
Examples of electrophilic substitution
53
(No Transcript)
54
Substituted naphthalene

• Activating groups direct the electrophile to the
  same ring, while deactivating groups direct it to
  the other ring.

Elctrodonating group (EDG) NH2, OH, OR, alkyl
Electrowithdrawing group (EWG) NO2, CO, COOH,
CN, SO3H
55
Homonuclear attack
56
Heteronuclear attack
57
Examples
58
Naphthalene derivatives
59
1. Nitronaphthalene

• 1. naphthalene is prepared by direct nitration

• 2. naphthalene is prepared by indirect method

60
2. Naphthols

• Preparation

61

• Properties

1- Reaction of ? and ?- naphthols with aryl
diazonium salt
62
2- Reaction of ? and ?- naphthols with nitrous
acid
63
3- Conversion of ? and ?- naphthols to naphthyl
ether
64
3. Naphthylamine

• Preparation
• 1- Naphthylamine

65

• Preparation
• 2- Naphthylamine

Bucherer reaction
66
Mechanism
67
4. Halogenated naphthalene

• A) Preparation of 1- halogented naphthalene

68

• B) Preparation of 2- halogenated naphthalene via
  Sandemeyer

69
Questions

• Convert 2- naphthol to
• A) 2- bromonaphthol
• b) Naphthalene -2- carboxylic acid
• C) 1,2- naphthaquinone-1- oxime
• D) Ethyl ?naphthyl ether

70
5. Alkyl naphthalene

• Synthesis of 1- alkyl naphthalene

71

• Synthesis of 2- alkyl naphthalene

72
6. Naphthaquinones

• There are six possible naphthaquinones, but only
  common are 1,2 1,4 2,6- naphthaquinones

73
Preparation of naphthaquinones
74
1,4- Naphthaquinone
75
1,2- Naphthaquinone
76
2,6- Naphthaquinone
77
7. Naphthoic acid
78
Preparation of 1-naphthoic acid
79
From bromonaphthalene
80
From 1- naphthylamine
81
From 1- acetylacetophenone
2- Naphthoic acid can be prepared by the same
above methods
82
Anthracene
83

• Anthracene has 4 isomers

Resonance I, II are more stable, contain 2
benzene rings.
84
Synthesis of anthracene

• 1. Friedl Crafts

85

• 2. Elbe reaction

86

• 3. From 1,4- Naphthoquinone

The above method shows presence of naphthalene in
anthracene
87

• 4. From benzene and phthalic anhydride

88
Chemical reactions
89

• 1) Diels Alder

90

• 2) Addition of one molecule of O2

91

• 3) Halogenation of anthracene

92

• 4) Oxidation of anthracene

In using dil. HNO3 only to obtain 9,10-
anthraquinone
93

• 4) Reduction of anthracene

94
Anthraquinone
95
Preparation
96
(No Transcript)
97
Chemical Reactions
98
(No Transcript)
99

• Nitration

100

• Sulphonation

Anthraquinone does not undergo Friedl Craft
reaction

• Preparation of 2-amino-anthraquinone

101
Alizarin
102
Preparation
103
Preparation of Alizarine Blue
Alizarine blue is used for dyeing wool by blue
color
104
Phenanthrene
105
Position of double bond
106
Preparation of phenanthrene

• 1) Howrth method

107

• Preparation of 1- alkyl phenanthrene

• Preparation of 2- alkyl phenanthrene

108

• 2) Posher synthesis

109
Chemical Reactions
110
(No Transcript)
111
Benzil-Benzilic rearrangement
Mechanism
112
Mechanism
113
Phenanthraquinone

• Preparation

114
Condition necessary for aromaticity

• Any compound to be aromatic, it must be
• 1. Cyclic
• 2. Planner
• 3. All atoms must be SP2
• 4. All double bonds must be conjugated
• 5. Obey Huckle rule which state that any aromatic
  compound must contain 4n2 pi electrons where n
  0,1,2,3,

115
Examples
116
Examples of non- benzenoid aromatic cmpound
All are aromatic( cyclic, planner,1, and agree
with Huckle rule 4n2 6 (n1)
117
Examples of non- aromatic
Not aromatic both contain Sp3
118
Not aromatic Does not obey Huckel rule 4n28
n1.5
Not aromatic Does not obey Huckel rule 4n24
n0.5
Aromatic cyclic, planner, obey Huckel
rule 4n22 n0
Aromatic 4n210 n2
Not Aromatic 8 pi electrons
Aromatic 4n214 n3
Aromatic 4n210 n2
Aromatic 4n210 n2
