Introduction to the Properties of Gases

1
Introduction to the Properties of Gases

• Chapter 14

2
What do you know about gases?

• particle diagrams
• Ar(g), H2(g), CO2(g)
• gases take shape volume of their container
• gases flow
• gases have low densities

3
Properties of Gases

• gases have mass
• gases take shape volume of container
• gases are compressible
• gases easily move through each other (perfume,
  skunks!)
• diffusion
• gases exert pressure

4
gases take shape of container

Why dont the balloons on
the right keep expanding

until they pop?
5
What is pressure?

• pressure force per unit area
• P force

area
force mass x acceleration
Would you rather have your foot stepped on by
someone wearing sneakers or stilleto heels? Why?
6
What is air pressure?

• pressure exerted on us by weight of gases above
  our heads ( all around our body)
• 0
• at sea level
• air pressure 1 atmosphere
• this is standard pressure

7

• http//www.youtube.com/watch?vJsoE4F2Pb20

8
Torricelli

• discovered air pressure
  invented mercury
  barometer in 1643
• 1st person to propose correct
  explanation for wind

9
(No Transcript)
10
reporting air pressure - take short-cut
report height of Hg column at 1 atm column
height is 29.92 in Hg (? 30) or 76 cm Hg or 760
mm Hg
11
How does downward
pressure of Hg in column
compare to pressure
of atmosphere?
12
Can we use H2O in a barometer?

• sure, but consider the densities of the 2
  liquids
• DHg 13.6 g/ml and Dwater 1.0 g/ml
• therefore
• a barometer made with water has to be
• 13.6 times taller than a Hg barometer!

13
How does air pressure at top of Mt. Whitney
(14,494 ft) compare to air pressure at John
Jay?What about Death Valley (86 m below sea
level)?
its LOWER than standard atmospheric pressure

its HIGHER than standard atmospheric pressure
14
When you drink through straw, you reduce pressure
in straw so

• Why does liquid in cup go up the straw?
• Could you drink a soda
  this way on the moon?
  Explain why or why not?

15
Units of pressure

• 14.70 lb/in2 U.S. pressure gauges
• 29.9 in Hg U.S. weather
• 101.325 kPa SI Units (Regents)
• (kPa kilopascal)
• 1.013 Bars Physics Astronomy
• CHEMISTRY also use
• 760 Torr, 760 mm Hg, 1 atm

16
What causes the pressure of a gas in a closed
container?
impacts of gas molecules with walls of
container anything that increases of impacts
per second or force of each impact increases
pressure
Microscopic View
17
light molecules move faster and hit walls more
often heavy molecules hit walls with greater
force these 2 effects essentially balance out
gas pressure doesnt depend on the identity of
the gas
18
Pressure Depends on

• concentration
• ( gas molecules per unit volume)
• and
• 2) temperature

19
How fast do the molecules in the air move?

• depends on mass
• light molecules faster than heavy molecules at
  same temperature
• temperature measure of average KE of particles
  in system

20
Molecular Speeds at 298 K

• H2 1.93 X 105 cm/sec
• He 1.36 X 105 cm/sec
• O2 4.82 X 104 cm/sec
• Ar 4.31 X 104 cm/sec
• Xe 2.38 X 104 cm/sec

48200 cm x 1 in x 1 ft x 1 mile x
3600 sec
sec
2.54 cm
5280 ft
1 hour
1080 miles per hour
21
speeds of various gasses according to mass
22
Molecular Speed vs. Temperature
23
Pressure Microscopic View

• gas molecules hit walls of their container
• pressure depends on
• impacts per unit time
• Force each impact

24
Pressure Macroscopic View

• pressure depends on
• how many ( moles) gas molecules per unit
  volume
• temperature
• same amount of gas exerts different pressure at
  different temperatures (tires)

25
Describing Gas Phase System

• need 4 variables to completely
• describe gas-phase system from
• macroscopic (lab) view
• 1. pressure
• 2. volume
• 3. temperature
• 4. amount gas ( moles)

26
Exit Ticket

• name 5 common properties of all gases
• draw particle diagram of oxygen in gas phase
• use your particle diagram to explain at least 2
  properties of gases (state the prop indicate
  how your diagram illustrates it)
• Bonus
• At 0oC, a He atom is moving at 1200 m/s. How
  fast is this in miles per hour? Show all work!
