Chapter 2 A Loop in the Pattern

Description:

Chapter 2 A Loop in the Pattern Designing the Main Loop and Timing – PowerPoint PPT presentation

Number of Views:40
Avg rating:3.0/5.0
Slides: 19
Provided by: LucioD4
Category:

less

Transcript and Presenter's Notes

Title: Chapter 2 A Loop in the Pattern


1
Chapter 2 A Loop in the Pattern
  • Designing the Main Loop and Timing

2
Checklist
  • The following tools will be used throughout the
    course
  • MPLAB X, Integrated Development Environment (v1.8
    or later, free)
  • MPLAB XC16, C compiler (v1.11 or later, free)
  • The following pieces of documentation will be
    used during this lesson
  • PIC24FJ128GA010 Datasheet DS39747 (latest rev.)
  • PIC24 Family Reference Manual - Section 14.
    Timers
  • Make sure they are available and/or installed and
    ready to use on your computer.
  • You can download them from Microchip web site at
    http//www.microchip.com/mplabx
  • And http//www.microchip.com/xc16

3
A New Project
  • Use the New Project wizard to create a new
    project
  • Call it 2-ALoopInThePattern
  • Use the New File wizard to create a new source
    file
  • Call it Loop.c
  • / File Loop.c Author your name here
    Created current date here /
  • include ltxc.hgt
  • int main( void)
  • return 0

But you can also use the form void main(
void) // no return required Or
simply main()
4
while Loops
  • In C there are several ways to design a loop. The
    first we are going to explore is the while
    loop
  • while ( x)
  • // your code here
  • Where ( X) is a logical expression
  • false is represented as the integer zero
  • true is represented by any integer except zero

5
Logical Operators
  • the logic OR operator,
  • the logic AND operator,
  • ! the logic NOT operator
  • These operators consider their operands as
    logical (Boolean) values using the rule mentioned
    above, and they return a logical value.
  • Here are some trivial examples, assuming
  • a 17
  • b 1
  • ( a b) is true,
  • ( a b) is true
  • ( !a) is false

In other words, they are both true
6
Comparison Operators
  • There are, then, a number of operators that
    compare numbers (integers of any kind and
    floating point values, too) and return logic
    values.
  • They are
  • the equal-to operator,
  • ! the NOT-equal to operator.
  • gt the greater-than operator.
  • gt the greater-or-equal to operator.
  • lt the less-than operator.
  • lt the less-or-equal to operator.
  • Here are some examples, assuming
  • a 10
  • ( a gt 1) is true
  • (-a gt 0) is false
  • ( a 17) is false
  • ( a ! 3) is true

Composed of two equal signs to distinguish it
from the assignment operator we used in the
previous lesson.
7
Curious Cases
  • while ( 0)
  • // your code here
  • while ( 1)
  • // your code here

Will never execute this code!
Will execute this code for ever!
8
Writing a Main Loop
  • It is time to add a few new lines of code to the
    loop.c source file and put the while loop to
    good use.
  • main()
  • // init control registers
  • TRISA 0xff00 // all PORTA as output
  • // main application loop
  • while( 1)
  • PORTA 0xff
  • PORTA 0
  • // main loop
  • // main

9
Animation
  • NOTE The Animation feature has been removed from
    MPLAB X!

10
Not so fast, please!
  • Run gt Run Program from the main menu.
  • MPLAB X will now recompile the program for
    immediate execution. It will be downloaded into
    the PIC24 flash memory and execution will start
    immediately
  • NOTE When in run mode, there is no animated icon
    and MPLAB X seems inactive, but the target PIC24
    is alive and executing continuously the
    application at full speed
  • Warning You will not be able to see any flashing
    of the LED bar!
  • This is due to a limitation of our human eyes.
  • The PIC24 is actually turning the LEDs on and off
    but, assuming our default configuration of the
    main oscillator (32MHz), this is happening at the
    rate of several million times per second!

11
Using a Timer
  • Timer1 Block Diagram

12
Configuring Timer1 T1CON
  • Use the following basic configuration
  • Activate Timer1 TON 1
  • Use the MCU clock as the source (Fosc/2) TCS 0
  • Set the prescaler to the maximum value (1256)
    TCKPS 11
  • The input gating and synchronization functions
    are not required, since we use the MCU internal
    clock directly as the timer clock TGATE 0,
    TSYNC 0
  • Do not worry about the behavior in IDLE mode, for
    now TSIDL 0 (default)
  • Once we assemble all the bits into a single
    16-bit binary value, we get
  • T1CON 0b1000000000110000
  • Or in a more compact hexadecimal notation
  • T1CON 0x8030

13
A Timed Loop
  • include ltconfig.hgt
  • define DELAY 16000
  •
  • main()
  • // init control registers
  • TRISA 0xff00 // all PORTA as output
  • T1CON 0x8030 // TMR1 on, prescale 1256
    Tclk/2
  • // main application loop
  • while( 1)
  • //1. turn pin 0-7 on and wait for 1/4 of
    a second
  • PORTA 0xff
  • TMR1 0
  • while ( TMR1 lt DELAY)
  •

14
Notes for Assembly Experts
  • Logic vs. Binary operators in C
  • Binary logic operators take pairs of bits from
    each operand and compute the result according to
    the defined table of truth.
  • Logic operators, look at each operand
    (independently of the number of bits used) as a
    single Boolean value.
  • Example on byte sized operands
  • 11110101 11110101
    (true)
  • binary OR 00001000 logical OR 00001000
    (true)
  • -------- --------
  • gives 11111101 gives 00000001
    (true)

15
Notes for PICmicro Experts
  • Difference between 8-bit PICmicros and the PIC24
  • There is no Timer0
  • All timers are 16-bit wide.
  • Each timer has a 16-bit period registers (PR).
  • A new 32-bit mode timer-pairing mechanism is
    available for Timer2/3 and Timer4/5.
  • A new external clock gating feature has been
    added on Timer1.

16
Tips and Tricks
  • When designing applications that have to operate
    reliably on large time scales (months, years ),
    consider providing a periodic refresh of the most
    important control registers of the essential
    peripherals used by the application.
  • Group the sequence of initialization instructions
    in one or more functions.
  • Call the functions once at power up, before
    entering the main loop, but also make sure that
    inside the main loop the initialization functions
    are called when no other critical task is pending
    and every control register is re-initialized
    periodically.

17
Suggested Excercises
  • Output a counter on the PortA pins instead of the
    alternating on and off patterns.
  • Use a rotating pattern instead of alternating on
    and off

18
Recommended Readings
  • Ullman, L. Liyanage, M. (2005), C Programming,
    Peachpit Press, Berkeley, CA.
  • Adams, N. (2003), The flyers, in search of Wilbur
    and Orville Wright, Three Rivers Press, New York,
    NY

19
Online Resources
  • http//en.wikipedia.org/wiki/Control_flowLoops
  • A wide perspective on programming languages and
    the problems related to coding and taming loops.
