Control Center Over the NET

1

• Control Center Over the NET
• CC2000 v.
  2.0

2
IT Professionals Challenges
How to manage multiple mgmt devices?
?
Can you remember IP of multiple mgmt devices?
How to manage user authority among mgmt devices?
How to ensure secure access to IT devices?
How to manage all ports related to one IT device?
How to get event logs of multiple mgmt devices?
CC2000 software the solution to meet these
challenges!
3
How can CC2000 help?
- Single portal to access multiple devices
- Centralized access right control
- Integrated management of Servers, Serial
devices and Power
- Centralized event monitoring

• - Secured remote access

4
CC2000 in Brief

• CC- Control Center over the Net
• Integrated Server Room Management from

- Single IP
- Single Sign-on
- Single Tree-view
5
CC2000- Network Architecture
CC2000 Master
Mumbai
CC2000 Slave
Bangalore
CC2000 Slave
Delhi

Chennai
Client
5
2010.02.10
6
Compatible Operating Systems
CC2000 Software can be installed in .
- Windows 2000, XP, 2000 Server, 2008 Server or
Windows Vista with JRE 1. 6 Update 11 or higher.
- Linux ( JRE 1.6 Update 11 or higher)
- Red Hat Linux V.4 and 5.

• - Novel Suse Enterprise Server 9 and 10

7
CC2000 Packages
Node License Definition
Standard package 1 x Master, 16 x Nodes
(software only, USB key not needed)
Basic Order Packages Basic Order Packages
Model No. Description
CC2000-XL Extra Light Pack 1 Master, 64 Nodes
CC2000-LE Lite Pack 1 Master, 128 Nodes
CC2000-LS Lite Standard Pack 1 Master, 256 Nodes
CC2000-SD Standard Pack 1 Master, 1 Slave, 512 Nodes
CC2000-PS Plus Pack 1 Master, 5 Slaves, 2048 Nodes
CC2000-PM Premium Pack 1 Master, 9 Slaves, 5120 Nodes
CC2000-PL Platinum Pack 1 Master, 15 Slaves, unlimited nodes
CC2000-MX Maximum Pack 1 Master, 31 Slaves, unlimited nodes
8
CC2000 Packages
System Add-ons
Model No. Description
CCS1 Add-on 1 Slave Server license
CCN1 Add-on 1 Node license
CCN10 Add-on 10 Nodes license
CCN50 Add-on 50 Nodes license
CCN100 Add-on 100 Nodes license
CCN500 Add-on 500 Nodes license
CCN1000 Add-on 1000 Nodes license
CCN10000 Add-on 10000 Nodes license
CCNU Add-on unlimited Nodes license
9
CC2000 v. 2.0 New Features

• Blade Server
• VM Ware
• IPv6
• Node License Warning
• Pull and Push name

- Syslog Support - NTP - OOBC - Proxy - Mac filter
10
Features
Master/Slave Topology
CC Server Redundancy / Double Redundancy
OOBC (dial-in, dial-back, dial-out)
IPv6 Support
Third-party Authentication
Event Notification SMTP, SNMP Trap, Syslog / Log
Server
IP Filter / Mac Filter
11
Features

• Pull Name and Push Name

SN Port Session history logging (including key
strokes, command, messagesetc.)
Task Scheduling
Multi-language Support English, Japanese,
Korean, Chinese, Germany, Russian
12
Add Device

• 6. Blade Server Support
• Server Brands IBM, DELL, HP
• Blade Server Tree View
• How it works?

1. Device
2. Aggregate Device
3. Generic Device (hyperlink)

• 7. VM Ware Support
• What is VM Ware?
• Virtualization
• VM Ware vs. CC2000
• CC Tree View (VM Ware)

4. Group Device
5. Folder (Category)
13
CC2000 User Interface
14
(No Transcript)
15
Node License Definition
- Each PORT of ATEN/ALTUSEN devices to be added
to CC2000 tree-view list will take ONE node
license

• Aggregate Device takes ONE node license only
• (up to 2 x KVM ports, 8 x PN ports, 4 x Serial
  ports)

• Blade Server VM Ware takes N 1 node license
• (N number of Blades / Virtual Machines)

CC2000 Server
TCP/IP
KN
PN
SN
Complete
16
Master Slave Topology
CC2000-M
Synchronization
SN
KN
PN
CC2000-S
CC2000-S
SN
KN
PN
SN
KN
PN
Support up to 31 Slave CC Servers
Complete
17
CC Redundancy
CC2000-M
SN
KN
PN
Crash
CC2000-M
CC2000-S
CC2000-S
SN
KN
PN
SN
KN
PN
Complete
18
CC Double Redundancy
CC2000-M
CC2000-S
CC2000-M
Crash
SN
KN
PN
VPN or Proxy
CC2000-S
CC2000-S
CC2000-S
CC2000-S
Crash
Crash
SN
SN
KN
PN
KN
PN
Complete
19
OOBC Dail IN
Dial in to access CC2000 Server
Modem
PSTN
Modem
Complete
CC2000 Server
20
OOBC Dail Back
Dail back
Modem
PSTN
Hang up the phone
Modem
Dail back phone number can be set as a Fix number
or a Flexible assigned number.
CC2000 Server
Complete
21
OOBC Dail Out
ISP
Dial out to ISP
Modem
Complete
CC2000 Server
22
What is VM Ware?
VM Virtual Machine
1. A virtual machine is a tightly isolated
software container that can run its own operating
systems and applications as if it were a physical
computer.
2. A virtual machine behaves exactly like a
physical computer and contains it own virtual
(ie, software-based) CPU, RAM hard disk and
network interface card (NIC).
Complete
23
Virtualization

• Virtualization lets you run multiple virtual
  machines on a single physical machine, with each
  virtual machine sharing the resources of that one
  physical computer across multiple environments.

Virtual Machines

• Different virtual machines can run different
  operating systems and multiple applications on
  the same physical computer.

Server platform
Complete
24
VM Ware vs. CC2000
CC2000
Download plug-in files (viewer)
CC2000 supports ESX, ESXi, vCenter, VSphere
Complete
25
CC Tree View (VM Ware)
5 Node license
Complete
26
Blade Server
3 Nodes
Complete
27
Blade Server How it works?
TCP/IP
CC2000 Server
CC sends signals to KN for switching blades
CC2000 gets Blade Servers information through
TCP/IP
KN contains Blade Servers hotkey
Blade Server
Blade 2
Blade 1
Blade 3
Blade 4
Complete
28
Aggregate Device
Support up to KVM port x 2 PN port x 8 SN port x
4
Why Aggregate Device??
One Node license only
Complete
29
Third-party Authentication
TCP/IP
Username Password
RADIUS, LDAP(S) Active Directory TACACS, NT Domain
CC2000 Server
Complete
30
Log Server / SMTP / SNMP Trap
TCP/IP

1. SMTP email notification
2. SNMP Trap notification
3. Syslog / Log Server event history

SNMP Manager
Log Server AP Or Syslog
SMTP
Complete
31
IP Filter / MAC Filter
Complete
32
Pull Name / Push Name
KN
CC2000
PC1
PC1
PC2
PC2
PC3
PC3
PC4
PC4
CC2000 push names to devices
CC2000 pull names from devices
PN
PN1
PN1
PN2
PN2
PN3
PN3
PN4
PN4
SN
SN1
SN1
SN2
SN2
SN3
SN3
SN4
SN4
Complete
33
Task Scheduling
Complete
