RAMP Gold: Architecture and Timing Model

1
RAMP Gold Architecture and Timing Model

• Andrew Waterman, Zhangxi Tan, Rimas Avizienis,
  Yunsup Lee, David Patterson, Krste Asanovic

Parallel Computing Laboratory University of
California, Berkeley
2
RAMP Gold Overview
Par Lab InfiniCore

• Tiled CMP simulator
• ISA SPARC V8
• (ARM/Thumb-2 later?)
• Split timing and function (both on FPGA)
• Host-multithreaded
• Runs on V5LX110T (XUP)

3
RAMP Gold Target Machine
64 cores
SPARC V8 CORE
SPARC V8 CORE
SPARC V8 CORE
SPARC V8 CORE

I
D
I
D
I
D
I
D
Shared L2 / Interconnect
DRAM
4
RAMP Gold v1 Target Features

• 64 single issue in-order SPARCv8 processors
• Simple, 5-stage pipeline
• FPU
• Cache Timing model
• Configurable size, line size, associativity, miss
  penalty, shared/private
• Change parameters without resynthesis

5
RAMP Gold Architecture

• Mapping the target machine directly to an FPGA is
  inefficient
• Solution split timing and functionality
  Multithreading
• The timing logic decides how many target cycles
  an instruction sequence should take
• Simulating the functionality of an instruction
  might take multiple host cycles

6
Function/Timing Split Advantages

• Flexibility
• Can configure target at runtime
• Synthesize design once, change target model
  parameters at will
• Efficient FPGA resource usage
• Example 1 model a 2-cycle FPU in 10 host cycles
• Example 2 model a 16MB L2 using only 256KB host
  BRAM to store tags/metadata
• Enables multithreading

7
Split Timing and Function
Target Machine
Functional Model
Timing Model
CPU TM
CPU
CPU FM


L1 D
L1 D TM
L1 D FM
MEM
MEM FM
MEM TM

• Functional model executes ISA correctly
• Timing model determines how long a program takes
  to run

8

Split Timing and Function
Target Machine
Functional Model
Timing Model
CPU TM
CPU
CPU FM


L1 D
L1 D TM
MEM FM
MEM
MEM TM

• Functional model executes ISA correctly
• Timing model determines how long a program takes
  to run

9
TM FM from 30,000 ft
Memory Timing Model
ld/st address
stall
CPU Timing Model
L1 D Timing Model
stall
ld/st address store data
ld/st address store data
instruction complete
CPU Functional Model
Memory Functional Model
load data
instruction
10
TM FM from 3,000 ft
Memory Timing Model
ld/st address
stall
CPU TM
L1 D TM
stall
IF
CTRL
TM1
TM2
ld/st address, store data
ld/st address, store data
instruction complete
CPU FM
Memory Functional Model
WB
DEC
EX
MEM
instruction
load data
11
Example Target Load Miss
Memory Timing Model
6
4
ld/st address
stall
CPU TM
L1 D TM
7
4
stall
IF
CTRL
TM1
TM2
3
1
ld/st address, store data
ld/st address, store data
instruction complete
4
CPU FM
Memory Functional Model
WB
DEC
EX
MEM
instruction
2
load data
5
12
Timing-Driven Host Pipeline
T0
T1
T2
TARGET MEMORY TM/FM
ADD
LD
ST
CPU/D Timing Model
L1 D TM
TS
TM1
TM2
TM3
IF
Store Buffer
TID,INST
TID,ADDR
CPU Functional Model
Load Result Buffer
DE
EX
WB
MEM2
MEM1
13
Cache Modeling

• The cache model maintains tag, state, protocol
  bits internally
• Whenever the functional model issues a memory
  operation, the cache model determines how many
  target cycles to stall

tag
index
offset
associativity

tag, state
tag, state
tag, state



hit/miss
14
Multithreaded, Pipelined Cache TM
hit?


Address

tag, state
tag, state
tag, state
Index
15
Quick Dirty Validation

• 32KB, 2-way L1 D, 64B lines
• 256KB, 4-way L2, 64B lines

16
Status

• Functional simple timing model work in HW
• Running real programs (e.g. SPLASH2)
• Near term future work
• Move from current functional-first stall
  configuration to timing-driven described here
• More interesting memory system timing model
• Functional potpourri (FDIV, MMU, )

17
DEMO

• Run OCEAN with different L1 D parameters

18
Questions?

• Thank you!
