Projective 3D geometry class 4

1
Projective 3D geometryclass 4

• Multiple View Geometry
• Slides modified from Marc Pollefeys Comp 290-089

2
Last week
line at infinity (affinities)
circular points (similarities)
(orthogonality)
3
Last week
cross-ratio
pole-polar relation
conjugate points lines
Chasles theorem
projective conic classification
affine conic classification
4
Fixed points and lines
(eigenvectors H fixed points)
(?1?2 ? pointwise fixed line)
5
Singular Value Decomposition
6
Singular Value Decomposition

• Homogeneous least-squares
• Span and null-space
• Closest rank r approximation
• Pseudo inverse

7
Projective 3D Geometry

• Points, lines, planes and quadrics
• Transformations
• ?8, ?8 and O 8

8
3D points
3D point
in R3
in P3
projective transformation
(4x4-115 dof)
9
Planes
3D plane
Dual points ? planes, lines ? lines
10
Planes from points
Or implicitly from coplanarity condition
11
Points from planes
Parameterizing points on a plan by representing a
plane by its span
12
Lines
(4dof)
Example X-axis
13
Points, lines and planes
14
Plücker matrices
Plücker matrix (4x4 skew-symmetric homogeneous
matrix)

1. L has rank 2
2. 4dof
3. generalization of
4. L independent of choice A and B
5. Transformation

Example x-axis
15
Plücker matrices
Dual Plücker matrix L
Correspondence
Join and incidence
(plane through point and line)
(point on line)
(intersection point of plane and line)
(line in plane)
(coplanar lines)
16
Plücker line coordinates
17
Plücker line coordinates
(Plücker internal constraint)
(two lines intersect)
(two lines intersect)
(two lines intersect)
18
Quadrics and dual quadrics
(Q 4x4 symmetric matrix)

1. 9 d.o.f.
2. in general 9 points define quadric
3. det Q0 ? degenerate quadric
4. pole polar
5. (plane n quadric)conic
6. transformation

19
Quadric classification
Rank Sign. Diagonal Equation Realization
4 4 (1,1,1,1) X2 Y2 Z210 No real points
2 (1,1,1,-1) X2 Y2 Z21 Sphere
0 (1,1,-1,-1) X2 Y2 Z21 Hyperboloid (1S)
3 3 (1,1,1,0) X2 Y2 Z20 Single point
1 (1,1,-1,0) X2 Y2 Z2 Cone
2 2 (1,1,0,0) X2 Y2 0 Single line
0 (1,-1,0,0) X2 Y2 Two planes
1 1 (1,0,0,0) X20 Single plane
20
Quadric classification
Projectively equivalent to sphere
sphere
ellipsoid
paraboloid
hyperboloid of two sheets
21
Twisted cubic

1. 3 intersection with plane (in general)
2. 12 dof (15 for A 3 for reparametrisation (1 ?
   ?2?3)
3. 2 constraints per point on cubic, defined by 6
   points
4. projectively equivalent to (1 ? ?2?3)
5. Horopter degenerate case for reconstruction

22
Hierarchy of transformations
Projective 15dof
Intersection and tangency
Parallellism of planes, Volume ratios,
centroids, The plane at infinity p8
Affine 12dof
Similarity 7dof
The absolute conic O8
Euclidean 6dof
Volume
23
Screw decomposition
Any particular translation and rotation is
equivalent to a rotation about a screw axis and a
translation along the screw axis.
24
The plane at infinity
The plane at infinity p? is a fixed plane under
a projective transformation H iff H is an
affinity

1. canical position
2. contains directions
3. two planes are parallel ? line of intersection in
   p8
4. line // line (or plane) ? point of intersection
   in p8

25
The absolute conic
The absolute conic O8 is a (point) conic on p?.
In a metric frame
or conic for directions (with no real points)
The absolute conic O8 is a fixed conic under the
projective transformation H iff H is a similarity

1. O8 is only fixed as a set
2. Circle intersect O8 in two points
3. Spheres intersect p8 in O8

26
The absolute conic
Euclidean
Projective
(orthogonalityconjugacy)
normal
plane
27
The absolute dual quadric
The absolute conic O8 is a fixed conic under
the projective transformation H iff H is a
similarity

1. 8 dof
2. plane at infinity p8 is the nullvector of O8
3. Angles

28
Next classesParameter estimation
Direct Linear Transform Iterative
Estimation Maximum Likelihood Est. Robust
Estimation
