UltraSparc IV

1
UltraSparc IV

• Tolga TOLGAY

2
OUTLINE

• Introduction
• History
• What is new?
• Chip Multitreading
• Pipeline
• Cache
• Branch Prediction
• Conclusion

3
INTRODUCTION

• Sparc Scalable Processor Architecture
• Open processor architecture
• SUN UltraSparc v9
• RISC Architecture
• 64 bit address and data
• Superscalar

4
HISTORY

• Begin developing Sparc 1984
• First Sparc Processor 1986
• SuperSparc 1992
• UltraSparc I 1995
• UltraSparc II 1997
• UltraSparc III 2001
• UltraSparc IV 2004
• UltraSparc IV 2005
• UltraSparc T1 2005

5
WHAT IS NEW?

• What UltraSparc IV offers new
• CMT (Chip Multithreading)
• New registers added due to CMT enhancement
• MCU registers, Sun Fireplan Interconnect
  registers are shared.
• Enhancements on Floating Point Unit
• 16 MB L2 cache with 128 byte line-size shared by
  two processors.
• L2 caches uses LRU replacement strategy
• New write-cache indexing-hashing feature

6
Chip Multitreading (CMT)

• Two UltraSparc III cores into one die.
• Two mirrored cores share
• System bus
• DRAM controller
• Off-die L2 cache
• Fireplan registers.
• Also called Chip Multiprocessing

7
Chip Multitreading
8
Chip Multitreading

• Aim is to increase performance without increasing
  clock speed.
• Mirroring the cores cause a hot spot of floating
  point units.
• How to avoid hot spot
• Heat towers in copper interconnect

9
Chip Multitreading
10
Core

• More core improvements
• Improved instruction fetch and store bandwidth.
• Improved data prefetching
• FPU can handle more unexpected and underflow
  cases so reducing exceptions.
• On-die cache enhanced with a hashed index to
  better handle multiple writes.

11
Pipeline

• Because UltraSparc IV contains two UltraSparc III
  cores, it uses the same pipeline.
• 4-way superscalar architecture.
• 14-stage pipeline.

12
Pipeline Stages
13
Pipeline Stages
Pipeline Stage Definition
A Address Generation
P Preliminary Fetch
F Fetch Intructions from I-Cache
B Branch Target Computation
I Instruction Group Formation
J Grouping
R Register Access
E Execute
C Cache
M Miss Detect
W Write
X Extend
T Trap
D Done
14
Pipeline Stages
15
Pipeline Stages

• Stage A Address Generation
• Generates and selects the fetch address
• Address can be selected from several sources
• Stage P Preliminary Fetch
• Starts fetching from I-Cache
• Accesses to Branch Predictor
• Stage F Fetch
• Second half of I-Cache access
• At the end of stage 4 instructions may be latched
• Stage B Branch Target Computation
• Analyzes the instructions
• Calculate branch target address

16
Pipeline Stages

• Stage I Instruction Group Formation
• Instructions are grouped into instruction queue.
• Stage J Instruction Group Staging
• A group of instructions are dequeued and sent to
  R-Stage
• Stage R Dispatch and Register Access
• Dependency calculation
• Dependency solution

17
Pipeline Stages

• Stage E Integer Instruction Execution
• First stage of execution pipelines
• Integer instructions -gt A0 and A1 pipelines
• Branch instructions -gt Branch pipeline
• Other instructions -gt MS pipeline
• Stage C Cache
• Integer pipelines write results back
• SIU results are produced
• First stage for Floating Point Instructions

18
Pipeline Stages

• Stage M Miss
• Data cache misses are determined
• Second step for FP instructions
• Stage W Write
• MS pipeline results are written
• Third step for FP instructions
• D-cache miss requests send to L2 cache
• Stage X Extend
• Final step for Floating Point instructions
• Results from FP instructions are ready for bypass

19
Pipeline Stages

• Stage T Trap
• Traps are signalled
• After trap, instructions invalidate results
• Stage D Done
• Integer results are written into architectural
  register file
• Floating point results are written to floating
  point register file.
• Results became visible to any traps generated
  from younger instructions.

20
Pipeline Rules

• Grouping rules
• Group collection of instructions that does not
  limit eachother to be executed in parallel
• Made before R-stage
• Needed for
• The execution order is maintained
• Each pipeline runs a subset of instructions
• Instructions may require helpers
• Execution order in order execution

21
Cache Organization

• Doubled cache size because of dual core.
• Data Cache 64 KB x 2
• Instruction Cache 32 KB x 2
• L2 Cache 16 MB, off-chip, shared
• No L3 Cache

22
Cache Organization
23
Cache Organization

• Data Cache
• 64 KB Level 1 cache per core
• Instruction Cache
• 32 KB Level 1 cache per core
• 4 way associative

24
Cache Organization

• Prefetch Cache
• One of L1 caches
• 2 Kbyte SRAM 32 x 64 bytes
• Uses LRU replacement algorithm
• Aim is to fetch data before needed
• Reduces main memory access latency
• 2 ports reads 8 bytes, 1 port writes 16 bytes per
  cycle.
• Hardware prefetch

25
Cache Organization

• Write Cache
• Reduces the bandwidth due to store traffic
• 2 Kbyte cache
• Handles multiprocessor and on-chip cache
  consistency
• Improves error recovery
• Optionally uses a hashed index

26
Cache Organization

• L2 Cache
• 16 MB SRAM shared by two processors
• Seperate L2 cache tags
• Two way set associative
• LRU replacement policy
• 128 bytes of line size
• UltraSparc IV has an on-die Level 2 cache with
  an off-die Level 3 cache

27
Branch Prediction

• Branch Predictor
• Small, single-cycle accessed
• SRAM
• Output is connected to P-stage
• Branch detemination is made in B-stage
• If miss, return to A-Stage.

28
Conclusion

• UltraSparc IV is a milestone as it is first dual
  core chip of UltraSparc family
• Sun continues to develop UltraSparc
• UltraSparc IV
• UltraSparc T1

29
References

• UltraSparc IV Users Manual, Sun Microsystems
• UltraSparc IV Whitepaper, Sun Microsystems
• UltraSparc IV Mirrors Predecessor, Kevin Krewell
• Implementation and Productization of a 4th
  Generation 1.8GHz Dual-Core SPARC V9
  Microprocessor, Anand Dixit, Jason Hart, ...
• UltraSparc III Users Manual, Sun Microsystems

30
References

• Web Sites
• http//web.cs.unlv.edu/cs219/group3/index.html
• http//bwrc.eecs.berkeley.edu/CIC/archive/cpu_hist
  ory.htmlSPARC
• http//www.arcade-eu.org/overview/2005/
  sparcIV.html
• http//www.top500.org/orsc/2006/sparcIV.htm
• http//www.sparc.org/history.html
