Chapter 19: Acids And Bases

1
Chapter 19 Acids And Bases
2
Class question

• Where can acids be found?
• Sodas
• Stomach
• Vinegar
• Citrus fruits

• Where can bases be found?
• Soap
• Drano
• Antacid tablets
• Windex
• detergent

3
Properties of Acids

• Taste sour
• React with bases
• Litmus paper test turn blue litmus paper red
• Electrolytic conduct electricity

4
Properties of Bases

• Taste bitter
• Feels slippery
• React with acids
• Litmus paper test turn red litmus paper blue
• electrolytic

5
Nomenclature of Acids

• Acids are composed of a(n)
• ________________ followed by
• a(n) _______

Hydrogen ion (H)
anion
H Cl1-
HCl
Ex
H SO42-
H2SO4
6
H anion

• H anion with ide ending ?
• acid name is __________________
• HCl anion? _______
• acid name ________________

Hydro _____ic acid
chloride
Hydrochloric acid
7
H anion

• H anion with ide ending ?
• acid name is __________________
• HF anion? _______
• acid name ________________

Hydro _____ic acid
fluoride
Hydrofluoric acid
8
H anion

• H anion with ate ending ?
• acid name is __________________
• HNO3 anion? _______
• acid name ________________

_____ic acid
nitrate
nitric acid
9
H anion

• H anion with ate ending ?
• acid name is __________________
• H2SO4 anion? _______
• acid name ________________

_____ic acid
sulfate
sulfuric acid
10
H anion

• H anion with ite ending ?
• acid name is __________________
• HNO2 anion? _______
• acid name ________________

_____ous acid
nitrite
nitrous acid
11
H anion

• H anion with ite ending ?
• acid name is __________________
• HClO2 anion? _______
• acid name ________________

_____ous acid
chlorite
chlorous acid
12
Writing acid formulas

• Hydrobromic acid
• anion? ___________ formula ______
• Acetic acid
• anion? ___________ formula ______
• Nitrous acid
• anion? ___________ formula ______

HBr
Bromide (Br1-)
HC2H3O2
acetate(C2H3O21-)
HNO2
nitrite (NO21-)
13
Nomenclature of Bases

• Bases are composed of a(n)
• _______ followed by
• a(n) ________________

cation
hydroxide (OH1-)
14
Writing Base Names

• Rule name the cation and add hydroxide
• NaOH
• Mg(OH)2
• Fe(OH)3

sodium hydroxide
magnesium hydroxide
Iron (III) hydroxide
Memorize NH3 ammonia
15
Writing base formulas

• potassium hydroxide
• cation? ______ formula ______
• Calcium hydroxide
• cation? ______ formula ______
• Aluminum hydroxide
• cation? ______ formula ______

KOH
K
Ca(OH)2
Ca2
Al(OH)3
Al3
16
Ions In Solution

• Why are some solutions acidic, basic, or neutral?
• depends on number of H and OH- ions present

17
Ions In Solution

• Acidic solution contain more H ions than OH-
  ions
• 4000 H and 0 OH- is acidic
• 1000 H and 500 OH- is acidic
• 5 H and 3 OH- is acidic

18
Ions In Solution

• Basic Solution contain more OH- ions than H
  ions
• 4000 OH- and 0 H is basic
• 1000 OH- and 500 H is basic
• 5 OH- and 3 H is basic

19
Ions In Solution

• Neutral Solution equal amounts of H and OH-
  ions
• 4000 OH- and 4000 H is neutral
• 1000 OH- and 1000 H is neutral
• 5 OH- and 5 H is neutral

20
Self Ionization of Water

• Proper ionization
• H2O H2O ?

H3O OH-
hydronium ion
H
O

?
O

H
O
H
H
H
H
O
H
H
21
Self Ionization of Water

• simplified version
• H2O ?

H OH-
22
Types of Acids/Bases

• Arrhenius Model
• Bronsted-Lowry Model

23
Arrhenius Model of Acids and Bases

• Arrhenius Acids
• Defn contain H and ionizes to form H
• Examples
• HCl ?
• HNO3 ?

makes solution ACIDIC
H Cl-
H NO3-
24
Arrhenius Model of Acids and Bases

• Arrhenius Bases
• Defn
• contain OH- and ionizes to produce OH- ions
• Examples
• NaOH ?
• Ca(OH)2 ?

makes solution BASIC
Na OH-
Ca2 2 OH-
25
Flaw with Arrhenius model

• Not all bases contain hydroxide
• Ex ammonia (NH3) is basic
• Therefore a new type of acid/base must be
  determined

26
Bronsted-Lowry Model

• Bronsted-Lowry Acid
• Defn proton/H donor
• can give H to another species
• Bronsted-Lowry Base
• Defn proton/H acceptor
• can take H from another species

27
Bronsted-Lowry Model

• REMEMBER!!!! REMEMBER!!!!
• acids donate, bases accept protons
• Ashley does boys always

28
Bronsted-Lowry Model

• Examples
• HCl H2O ? Cl- H3O

What is happening here?
Acid (donates proton)
Base (accepts proton)
Which is the acid? base?
29
Bronsted-Lowry Model

• Examples
• NH3 H2O ? NH4 OH-

What is happening here?
Acid (donates proton)
Base (accepts proton)
Which is the acid? base?
30
Conjugate Acid/Base Pairs

• Conjugate acid new species produced when base
  gains H ion
• Conjugate base new species produced when acid
  donates H ion

31
Conjugate Acid/Base Pairs

• general Bronsted-Lowry reaction
• acid base ? conj. acid conj. base

conj. acid/base pair
conj. acid/base pair
Every acid has a conjugate base. Every base has a
conjugate acid.
32
Conjugate Acid/Base Pairs

• Examples
• HNO3 H2O ? H3O NO3-

What is the acid? base?
conj. acid/base pair
C.A.
C.B.
acid
base
What is the conjugate acid/base?
conj. acid/base pair
33
Conjugate Acid/Base Pairs

• Examples
• NH3 H2O ? NH4 OH-

What is the acid? base?
conj. acid/base pair
acid
base
C.B.
C.A.
What is the conjugate acid/base?
conj. acid/base pair
34
Conjugate acid-base pairs

• What is the conjugate base of
• H2SO4 _________ H3O ________
• What is the conjugate acid of
• HPO42- _________ OH1- ________

HSO41-
H2O
H2PO41-
H2O
How can H2O be both acid and base?
35
What is the conjugate base?

• Acid Conjugate Base
• H2SO4
• HPO42-
• NH41
• H3O1
• H2O

HSO41-
PO43-
NH3
H2O
OH-
How can H2O be both acid and base?
36
Amphoteric

• Defn substance that can act as both acids and
  bases
• HNO3 H2O ? H3O NO3-
• NH3 H2O ? NH4 OH-

Is H2O a base or acid?
base
Is H2O a base or acid?
acid
Water is amphoteric b/c it is acts as a base in
one reaction and acts as an acid in the second
37
Mono-, Di-, Triprotic Acids

• Defns
• monoprotic (HA) one ionizable proton
• ex HF, HCl, HBr
• diprotic (H2A) two ionizable protons
• ex H2SO4, H2CO3
• triprotic (H3A) three ionizable protons ex
  H3PO4, H3BO3

38
Polyprotic Acid Ionization

• Always forms ONE H
• H3PO4 ?
• H2PO41- ?
• HPO42- ?

H2PO41- H
HPO42- H
PO43- H
39
Strong Acid/Base

• Defn acid or base that completely ionizes
• HA H A-
• XOH X OH-

100
ionization
100
ionization
?every single HA molecule ionizes into H and A-
40
Strong Acid

• Illustration

-

H
H
A
A

-

H
H
A
A

-

H
H
A
A
All break into ions
41
Strength of Acids and Bases

• Acid/base strength is based on ? the degree to
  which they ionize
• 1) strong (?)
• 2) weak (?)

42
6 Strong Acids

• HCl hydrochloric acid
• HBr hydrobromic acid
• HI hydroiodic acid
• HClO4 perchloric acid
• H2SO4 sulfuric acid
• HNO3 nitric acid

43
Strong Bases

• Group I and II metal hydroxides

LiOH NaOH KOH RbOH
Mg(OH)2 Ca(OH)2 Sr(OH)2 Ba(OH)2
No need to memorize exact ones
44
Weak Acid/Base

• Defn acid or base that partially ionizes
• HA H A-
• XOH X OH-

partial
ionization

• not all will ionize the weaker it is
• the less it ionizes

45
Weak Acid

• Illustration

-

H
H
A
A
H
H
A
A
H
H
A
A
Only some break into ions
46
What are the weak acids and bases?

• The ones that are NOT strong

47
Strong or weak, concentrated or diluted

• For acids and bases, it is important to
  distinguish between concentrated and dilute from
  strong and weak. The words _________ and
  __________
• have different meanings. Similarly, ___________
  and ___________ are not the same either.

strong
concentrated
weak
dilute
48
Strong or weak, concentrated or diluted

• Strong and weak refer to
• ____________________________
• Concentrated and dilute refer to
• ____________________________

how much substance ionizes
how much solute is present
49
Example

• 1 M HCl
• 12 M HCl
• 1 M H2CO3
• 12 M H2CO3

Strong and dilute
Strong and concentrated
weak and dilute
weak and concentrated
50
Ion Product Constant for Water (Kw)

• Defn equilibrium value for self ionization of
  water (H2O ? H OH-)
• Formula
• Kw HOH- 1 x 10-14

ALWAYS ALWAYS ALWAYS
51
Ion Product Constant for Water (Kw)

• in pure water ?
• H OH- 1 x 10-7
• in non pure water ?
• (acidic/basic conditions), value of H and
  OH- differ

Remember pure water is neutral
But still HOH- 1 x 10-14
52
Is solution acidic, basic, or neutral?

• Acidic
• Basic
• neutral

H gt OH-
H lt OH-
H OH-
53
pH and pOH

• pH
• Defn pH -log H
• Scale range from 0 to 14

ACIDIC
BASIC
0
7
14
pH
(neutral)
54
pH

• c) change one pH unit ?
• represents a ten fold change in strength
• - ex pH 3 vs pH 4
• pH 3 is 101 or 10 times more acidic
• - ex pH 7 vs pH 10
• pH 7 is 103 or 1000 times more acidic

55
pOH

• Formula -log OH-

56
Relation of pH and pOH

• pH pOH 14

If given one variable, subtract to find the other
57
Overall Relationship
pH
pOH
H
OH-
58
Sample problem (a)

• Calculate the pH of a solution with H 3.0 x
  10-6 M.
• pH -log H
• - log 3.0 x 10-6
• 5.52

59
Sample problem (b)

• Calculate the pH of a solution with OH- 8.2 x
  10-6.
• pOH -logOH-
• -log 8.2 x 10-6
• 5.09

60
Sample problem (b)

• pH pOH 14
• pH 5.09 14
• pH 8.91

61
Sample problem (b)

• Calculate the pH of a solution with OH- 8.2 x
  10-6.
• HOH- 1 x 10-14
• H8.2 x 10-6 1 x 10-14
• H 1.22 x 10-9
• pH -log1.22 x 10-9 8.91

62
Sample problem (c)

• What is the H of a solution with pH 2?
• pH -logH
• H 10-pH
• 10-2
• 0.01 M

63
Sample problem (d)

• (i) What is the OH- of a solution with pOH
  3.7?
• OH- 10-pOH
• OH- 10-3.7
• 2 x 10-4 M

64
Sample problem (d)

• (ii) What is the pH?

• pH pOH 14
• pH 3.7 14
• pH 10.3

65
Sample problem (d)

• (iii) What is the H ?
• H 10-pH
• 10-10.3
• 5 x 10-11 M

66
Reaction between acids and bases

• Neutralization (defn) reaction of acid and base
  to form a salt and water
• The reaction is a double replacement
• Salt (defn) ionic compound made of cation from
  base and anion from acid

67
Reaction between acids and bases

• Ex reaction
• Mg(OH)2 HCl ?

MgCl2 H2O
base
acid
salt
water
Mg2 OH-
H Cl-
Mg2 - cation from base Cl- - anion from acid
68
Ex problems

• i) What is the salt formed from sulfuric acid
  (H2SO4) and potassium hydroxide (KOH)?
• base cation?
• acid anion?

K
SO42-
What is salt?
K2SO4
69
Ex problems

• ii) What is the salt formed when Al(OH)3 and HBr
  react?
• base cation?
• acid anion?

Al3
Br-
What is salt?
AlBr3
70
Salt Hydrolysis

• Basically says what is the acid and base that
  formed the salt solution?
• What is the parent acid?
• What is the parent base?

H and salt anion
Salt cation and OH-
71
Ex problems

• What is parent acid and base of these salts?
• a) NaCl

What ions make up NaCl?
? Na Cl-
Acid?
H Cl- ?
HCl
Base?
NaOH
Na OH- ?
72
Ex problems

• What is parent acid and base of these salts?
• b) K3PO4

What ions make up K3PO4?
? K PO43-
Acid?
H PO43- ?
H3PO4
Base?
KOH
K OH- ?
73
Is salt solution acidic, basic, or neutral?

• a) strong acid strong base ?
• b) strong acid weak base ?
• c) weak acid strong base ?

Neutral salt
acidic salt
basic salt
74
Ex problem

• Determine if salt solution is acidic, basic, or
  neutral.
• LiBr
• acid?
• base?

? Li Br-
HBr
(strong acid)
(strong base)
LiOH
NEUTRAL
Salt is ____________
75
Ex problem

• Determine if salt solution is acidic, basic, or
  neutral.
• b) Fe(NO3)3
• acid?
• base?

? Fe3 NO3-
HNO3
(strong acid)
(weak base)
Fe(OH)3
ACIDIC
Salt is ____________
