Respiration

1
Respiration

• The hows and whys of a breath

2
(No Transcript)
3
The Tidal movement of air
4
Tidal movement of air

• Nasal cavities
• nasopharynx
• pharynx
• larynx
• vocal cords
• trachea

5
More airways

• Bronchioles
• respiratory bronchioles
• aveoli
• can you name all the structure air passes?

6
Human Respiratory System. Putting it all together
Figure 10.1
7
The lungs

• Located in thoracic cavity above dome shaped
  diaphragm.
• Surrounded by a sac like membrane with fluid in
  it called the pleural sac.
• Alveoli (blind sacs) are surrounded by a dense
  capillary network and is site of gas exchange.

8
(No Transcript)
9
(No Transcript)
10
Respiratory Cycle
Figure 10.9
11
Factors that effect gas exchange

• Air is 21 oxygen. (partial pressure)
• The pressure of air affects the amount of oxygen
  available.
• O2 CO2 move from high to low pressure.
• Gas exchange occurs at the surface which must be
  moist. (800sq feet of surface)

12
Lung capacity

• Male 4800ml Female 3800(vital capacity)
• 150ml is dead space.
• 500ml is moved in and out during rest. (tidal
  volume)
• 350ml actull reach alveoli
• 1200ml of residual air is always in the lungs and
  cannot be forced out. (residual volume)

13
Measurement of Lung Capacity
Figure 10.10a
14
(No Transcript)
15
The two sites of gas exchange

• In the lungs
• Oxygen has a high pressure in the lungs and flows
  into the blood
• Carbon dioxide has a high pressure in the blood
  and flows out

• In the tissues
• oxygen moves towards the tissues
• carbon dioxide moves to the blood

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Question

• What is pulmonary surfactant?

20
Movement of gases

• Oxygen
• Binds to hemoglobin in RBC.
• Hemoglobin gives up oxygen under warm low pH
  conditions.

• Carbon dioxide
• 23 to hemoglobin 70 bicarbonate in blood
• red blood cells convert carbon dioxide to
  bicarbonate

21
(No Transcript)
22
(No Transcript)
23
Blood Transports Gases between the Lungs and the
Cells

• Most carbon dioxide is transported as bicarbonate
  ions
• Bicarbonate is made in the red blood cells
• Carbon dioxide and water are converted to
  bicarbonate ions and hydrogen.
• The hydrogen is carried by hemoglobin (no ph
  change)
• Bicarbonate circulates in the blood stream and
  removes excess acids.

24
Relative gas concentrations, be able to figure
out where the gas will go
25
Control of respiration

• The body tries to equilibrate blood and air flow.
• Airflow can be increased by dilating bronchiole
  tubes.
• Increased oxygen causes blood vessels to dilate.

26
Regulation of Breathing
Figure 10.13
27
Regulation of Breathing Nervous System
Involvement

• Respiratory center in the medulla oblongata
  establishes basic breathing pattern
• Chemical receptors monitor carbon dioxide,
  hydrogen ions, and oxygen levels
• Medulla sensitive to hydrogen ions in
  cerebrospinal fluid resulting from carbon dioxide
  in blood

28
Regulation of Breathing Nervous System
Involvement

• Carotid and aortic bodies sensitive to carbon
  dioxide, pH, and oxygen levels
• Conscious control resides in higher brain
  centers ability to modify breath

29
Unusual places to breath

• When moving from high to low pressures, gases can
  escape into the blood, decompression sickness.
• Hypoxia is due to low oxygen pressure at high
  elevations.
• Carbon monoxide binds to hemoglobin better than
  oxygen.

30
Disorders of Respiratory System

• Reduced air flow asthma, emphysema, bronchitis
• Infections pneumonia, tuberculosis, botulism
• Lung cancer
• Congestive heart failure
• Cystic fibrosis
