JavaScript: Control Structures

1
JavaScript Control Structures

• September 27, 2005
• Slides modified fromInternet World Wide Web
  How to Program. 2004 (3rd) edition. By Deitel,
  Deitel, and Goldberg. Published by Prentice Hall.
  ISBN 0-13-145091-3

2
Chapter 7 - JavaScript Introduction to Scripting
Outline 7.1 Introduction 7.2 Simple Program
Printing a Line of Text in a Web Page 7.3
Obtaining User Input with prompt
Dialogs 7.3.1 Dynamic Welcome Page 7.3.2 Adding
Integers 7.4 Memory Concepts 7.5 Arithmetic 7.6
Decision Making Equality and Relational
Operators 7.7 Web Resources
3
Objectives

• In this lesson, you will learn
• To be able to write simple JavaScript programs.
• To be able to use input and output statements.
• To understand basic memory concepts.
• To be able to use arithmetic operators.
• To understand the precedence of arithmetic
  operators.
• To be able to write decision-making statements.
• To be able to use relational and equality
  operators.

4
Introduction to JavaScripting
5
7.1 Introduction

• JavaScript scripting language
• Enhances functionality and appearance
• Client-side scripting
• Makes pages more dynamic and interactive
• Foundation for complex server-side scripting
• Program development
• Program control

6
What can JavaScript programs do?From
http//www.javascripter.net/faq/javascri.htm

• Giving the user more control over the browser
• Detecting the user's browser, OS, screen size,
  etc.
• Performing simple computations on the client side
• Validating the user's input
• Handling dates and time
• Generating HTML pages on-the-fly without
  accessing the Web server.

7
What cant JavaScript programs do?From
http//www.javascripter.net/faq/javascr2.htm

• Use printers or other devices on the user's
  system or the client-side LAN
• Directly access files on the user's system or the
  client-side LAN the only exception is the
  access to the browser's cookie files.
• Directly access files on the Web server.
• Implement multiprocessing or multithreading.

8
Programming context

• Interpreted language
• Web browser as the interpreter
• Client-side only
• Compatibility depends on browser version
• But virtually every browser supports JavaScript
• Follow ECMAScript standard!
• Security issues
• You cannot access the clients system beyond
  their web browser
• Thus, no file access or direct printing

9
Notes on compatibility

• Browser versions
• 80-90 of people user Internet Explorer
• Of which 99 use IE 6 or IE 5
• 10-15 use Gecko-based browsers
• Firefox, Netscape, Mozilla
• JavaScript and cookies
• Only 85-90 have JavaScript enabled
• Cookies usually enabled by defaultI dont have
  statistics for how many leave this on
• Screen resolutions
• 25 use 800x600
• 70 use 1024x768 or higher
• Recommendations
• Test all pages with IE 5/6 and Firefox
• Dont assume that users have JavaScript or
  cookies enabled
• Your site should still be functional without
  client-side scripting or cookies
• Design to be comfortably viewable with 800x600
  resolution
• Sources
• http//www.upsdell.com/BrowserNews/stat_trends.htm

• http//www.w3schools.com/browsers/browsers_stats.a
  sp

10
Object orientation in JavaScript

• JavaScript is an object-oriented programming
  language
• Based on objects with properties and methods
• JavaScript uses prototyping to replicate
  behaviour, rather than classification (classes)
• There are two types of variables
• Simple variables (also called primitives)
• Objects

11
Objects in JavaScript

• An object is a complex type of variable that
  contains its own variables (properties), and has
  its own functions (methods)
• Properties
• The variables of an object
• Can also be other objects
• Methods
• The functions that belong to an object
• e.g. document.bgColor, window.location
• JavaScript has a rich set of built-in objects
• http//www.devguru.com/Technologies/ecmascript/qui
  ckref/js_objects.html
• You can also define your own objects

12
How to specify JavaScript code

• Inline Code
• Add dynamic functionality to an individual
  element
• ltimg onMouseOverdoThisFunction(this)gt
• Write JavaScript code directly in appropriate
  event attributes
• Embedded scripts
• Embed JavaScript code in an XHTML documenteither
  in the head or in the body
• ltscript typetext/javascriptgt x3 y9
  document.writeln( x y ) lt/scriptgt
• Inserting external scripts
• Insert a file with .js extension that contains
  JavaScript code
• ltscript typetext/javascript srcexternal.js
  /gt
• JavaScript libraries can be shared by multiple
  XHTML documents
• A note on CDATA
• lt!CDATA gt
• Necessary for legal XML to ignore and lt symbols
  (which are common in scripts)
• However, most browsers work fine without them
• http//www.w3schools.com/xml/xml_cdata.asp
• The textbook says to use lt!-- comments to hide
  your code --gt
• But CDATA is proper XML syntax
• Comments should validate, but not guaranteed

13
First scripts
14
7.2 Simple Program Printing a Line of Text in a
Web Page

• Inline scripting
• Written in the ltbodygt of a document
• ltscriptgt tag
• Indicate that the text is part of a script
• type attribute
• Specifies the type of file and the scripting
  language use
• writeln method
• Write a line in the document
• Escape character ( \ )
• Indicates special character is used in the
  string
• alert method
• Dialog box

15
welcome.html(1 of 1)
16
welcome2.html(1 of 1)
17
welcome3.html1 of 1
18
welcome4.html1 of 1
19
Illegal characters inXHTML vs. JavaScript

• XHTML
• HTML entities
• amp lt gt
• Others http//www.w3schools.com/tags/ref_entities
  .asp
• JavaScript
• Escape sequences
• \ \ \n \t \\
• Others http//www.devguru.com/Technologies/ecmasc
  ript/quickref/escaped_characters.html
• To convert between the two,use an XHTML ?
  JavaScript converter
• Google HTML JavaScript converter
• Best that Ive found
• http//javascript.about.com/library/blscr02.htm

20
7.2 Common escape sequences
For full list, see http//www.devguru.com/Technolo
gies/ecmascript/quickref/escaped_characters.html
21
7.3.1 Dynamic Welcome Page

• A script can adapt the content based on input
  from the user or other variables

22
welcome5.html(1 of 2)
23
7.3.1 Dynamic Welcome Page
This is the text field in which the user types
the value.
Fig. 7.7 Prompt dialog displayed by the window
objects prompt method.
24
JavaScript data types

• In JavaScript, you can use the var statement to
  create a variable, but it is not required
• You do not declare any data type (loosely typed)
• For scripting languages, data types are
  automatically determined
• Automatically converts between values of
  different types
• JavaScript data types
• Numbers
• Numbers are numbers, whether integer or floating
  point
• Boolean values
• true or false
• Strings
• Anything within quotes
• Anything within quotes
• Null
• "special key word denoting a null value"
• Means no value
• From http//www.ryerson.ca/JavaScript/lectures/bas
  icDataTypes/basicTypes.html

25
7.3.2 Adding Integers

• Prompt user for two integers and calculate the
  sum (Fig. 7.8)
• NaN (not a number)
• parseInt
• Converts its string argument to an integer

26
Addition.html(1 of 2)
27
JavaScript native functions

• See http//www.devguru.com/Technologies/ecmascript
  /quickref/js_functions.html
• parseInt()
• Converts a string into an integer, if possible
• parseFloat ()
• Converts a string into a floating-point number,
  if possible
• string ()
• Converts any object into a string
• number ()
• Converts any object into a number, if possible
• isNAN ()
• true if the object is Not A Number
• escape() and unescape()
• Converts and deconverts strings to safe
  characters

28
Operators in JavaScript

• http//www.devguru.com/Technologies/ecmascript/qui
  ckref/js_operators.html

29
7.5 Arithmetic operators
30
7.6 Decision Making Equality and Relational
Operators
?

31
welcome6.html(1 of 3)
32
welcome6.html(2 of 3)
33
7.6 Decision Making Equality and Relational
Operators
34
Chapter 8 - JavaScript Control Statements I
Outline 8.1 Introduction 8.2 Algorithms 8.3
Pseudocode 8.4 Control Structures 8.5 if
Selection Statement 8.6 ifelse Selection
Statement 8.7 while Repetition Statement 8.8
Formulating Algorithms Case Study 1
(Counter-Controlled Repetition) 8.9 Formulating
Algorithms with Top-Down, Stepwise Refinement
Case Study 2 (Sentinel-Controlled
Repetition) 8.10 Formulating Algorithms with
Top-Down, Stepwise Refinement Case Study 3
(Nested Control Structures) 8.11 Assignment
Operators 8.12 Increment and Decrement
Operators 8.13 Note on Data Types 8.14 Web
Resources
35
Objectives

• In this lesson, you will learn
• To understand basic problem-solving techniques.
• To be able to develop algorithms through the
  process of top-down, stepwise refinement.
• To be able to use the if and ifelse selection
  statements to choose among alternative actions.
• To be able to use the while repetition statement
  to execute statements in a script repeatedly.
• To understand counter-controlled repetition and
  sentinel-controlled repetition.
• To be able to use the increment, decrement and
  assignment operators.

36
8.1 Introduction

• Writing a script
• Thorough understanding of problem
• Carefully planned approach
• Understand the types of building blocks that are
  available
• Employ proven program-construction principles

37
8.4 Control Structures

• Sequential execution
• Statements execute in the order they are written
• Transfer of control
• Next statement to execute may not be the next one
  in sequence
• Three control structures
• Sequence structure
• Selection structure
• if
• ifelse
• switch
• Repetition structure
• while
• dowhile
• for
• forin

38
8.4 JavaScript keywords
39
8.5 if Selection Statement

• Single-entry/single-exit structure
• Indicate action only when the condition evaluates
  to true
• Indicate different actions to be perform when
  condition is true or false
• Conditional operator (?)
• JavaScripts only ternary operator
• Three operands
• Forms a conditional expression

40
8.7 while Repetition Statement

• Repetition structure (loop)
• Repeat action while some condition remains true

41
8.10 Formulating Algorithms with Top-Down,
Stepwise Refinement Case Study 3 (Nested Control
Structures)

• Consider problem
• Make observations
• Top-down, stepwise refinement

42
analysis.html(1 of 2)
43
(No Transcript)
44
More on JavaScript operators
45
8.11 Compound Assignment Operators
46
8.12 Increment and Decrement Operators

• Preincrement or predecrement operator
• Increment of decrement operator placed before a
  variable
• Postincrement or postdecrement operator
• Increment of decrement operator placed after a
  variable

47
8.12 Increment and Decrement Operators
48
increment.html(1 of 2)
49
8.12 Increment and Decrement Operators
50
Chapter 9 - JavaScript Control Statements II
Outline 9.1 Introduction 9.2 Essentials of
Counter-Controlled Repetition 9.3 for Repetition
Statement 9.4 Examples Using the for
Statement 9.5 switch Multiple-Selection
Statement 9.6 dowhile Repetition Statement 9.7
break and continue Statements 9.8 Labeled break
and continue Statements 9.9 Logical
Operators 9.10 Summary of Structured
Programming 9.11 Web Resources
51
Objectives

• In this lesson, you will learn
• To be able to use the for and dowhile repetition
  statements to execute statements in a program
  repeatedly.
• To understand multiple selection using the switch
  selection statement.
• To be able to use the break and continue
  program-control statements.
• To be able to use the logical operators.

52
9.2 Essentials of Counter-Controlled Repetition

• Counter-controlled repetition
• Name of a control
• Initial value
• Increment or decrement
• Final value

53
WhileCounter.html(1 of 2)
54
9.3 for Repetition Statement

• for repetition statement
• Handles all the details of counter-controlled
  repetition
• for structure header
• The first line

55
ForCounter.html(1 of 1)
56
9.3 for Repetition Statement
name
Control variable
Final value
of control variable
for
keyword
for which the condition is true
for
(
var
counter
1
counter lt
7
counter )
Initial value
of control variable
of control variable
Increment
Loop-continuation condition
Fig. 9.3 for statement header components.
57
9.4 Examples Using the for Statement

• Summation with for
• Compound interest calculation with for loop
• Math object
• Method pow
• Method round

58
Sum.html(1 of 1)
59
Interest.html(1 of 2)
60
9.5 switch Multiple-Selection Statement

• Controlling expression
• Case labels
• Default case

61
SwitchTest.html(1 of 3)
62
SwitchTest.html(2 of 3)
63
9.6 dowhile Repetition Statement

• Similar to the while statement
• Tests the loop continuation condition after the
  loop body executes
• Loop body always executes at least once

64
DoWhileTest.html(1 of 2)
65
9.7 break and continue Statements

• break
• Immediate exit from the structure
• Used to escape early from a loop
• Skip the remainder of a switch statement
• continue
• Skips the remaining statements in the body of the
  structure
• Proceeds with the next iteration of the loop

66
BreakTest.html(1 of 2)
67
ContinueTest.html(1 of 2)
68
9.8 Labeled break and continue Statements

• Labeled break statement
• Break out of a nested set of structures
• Immediate exit from that structure and enclosing
  repetition structures
• Execution resumes with first statement after
  enclosing labeled statement
• Labeled continue statement
• Skips the remaining statements in structures
  body and enclosing repetition structures
• Proceeds with next iteration of enclosing labeled
  repetition structure
• Loop-continuation test evaluates immediately
  after the continue statement executes

69
BreakLabelTest.html(1 of 2)
70
ContinueLabelTest.html(1 of 2)
71
Logical operators
72
9.9 Logical Operators

• More logical operators
• Logical AND ( )
• Logical OR ( )
• Logical NOT ( ! )

73
9.9 Logical Operators
74
9.9 Logical Operators
75
LogicalOperators.html(1 of 2)
76
9.9 Logical Operators
77
Conclusion to JavaScript introduction
78
9.10 Summary of Structured Programming

• Flowcharts
• Reveal the structured nature of programs
• Single-entry/single-exit control structures
• Only one way to enter and one way to exit each
  control structure
• Control structure stacking
• The exit point of one control structure is
  connected to the entry point of the next control
  structure

79
When things go wrongDebugging JavaScript

• Taken from http//www.ryerson.ca/JavaScript/lectur
  es/scriptTags/debugging.html
• JavaScript is case sensitive
• Document.write() will not work. Neither will
  document.Write(). Almost every object, property,
  and method name like document and write() begin
  with a lower case letter. In cases like
  document.bgColor the second word in an object,
  property, or method name is almost always
  capitalized. I.e. the C in bgColor but nothing
  else.
• Use the American spelling of color
• There is no colour property.
• Don't forget the closing bracket, and dont
  forget both quotes
• Make sure your pairs of (parentheses) and double
  quotes or single quotes all match
• Spelling counts
• Drop the e in document and watch what happens.
• The order you do things in matters
• If you set the background colour in the head of
  the document the document background colour may
  not change. If you set it in the body it will.
• Watch out for quotes inside quotes
• Whenever you write out an HTML tag with an
  attribute that requires quotes you must escape
  the quote inside the tag by placing a backslash
  just before it.
• For example document.write("ltA HREF"myURL.html"gtA
  LINKlt/Agt") will produce an error.
• Escaping the quotes will fix this
  document.write("ltA HREF\"myURL.html\"gtA
  LINKlt/Agt").
• Make sure you escape both of them.

80
8.14 Web Resources

• http//www.javascripter.net/faq/index.htm
• http//www.ecma-international.org/publications/sta
  ndards/Ecma-262.htm
• http//www.devguru.com/Technologies/ecmascript/qui
  ckref/javascript_index.html
• http//javascript.about.com/library/blscr02.htm
• http//www.ryerson.ca/JavaScript/lectures/
• www.javascriptmall.com
• developer.netscape.com/tech/javascript
• www.mozilla.org/js/language
