Designing Static CMOS Logic Circuits

1
Designing Static CMOSLogic Circuits
2
Static CMOS Circuits
3
Static Complementary CMOS
VDD
In1
PMOS only
In2
PUN

InN
F(In1,In2,InN)
In1
In2
PDN

NMOS only
InN
PUN and PDN are logically dual logic networks
4
NMOS Transistors in Series/Parallel Connection
Transistors can be thought as a switch controlled
by its gate signal NMOS switch closes when switch
control input is high
5
PMOS Transistors in Series/Parallel Connection
6
Threshold Drops
VDD
VDD
PUN
S
D
VDD
D
S
0 ? VDD
0 ? VDD - VTn
VGS
VDD ? 0
PDN
VDD ? VTp
VGS
S
D
VDD
S
D
7
Complementary CMOS Logic Style
8
Example Gate NAND
9
Example Gate NOR
10
Complex CMOS Gate
OUT D A (B C)
A
D
B
C
11
Constructing a Complex Gate

• Logic Dual need not be Series/Parallel Dual
• In general, many logical dual exist, need to
  choose one with best characteristics
• Use Karnaugh-Map to find good duals
• Goal find 0-cover and 1-cover with best
  parasitic or layout properties
• Maximize connections to power/ground
• Place critical transistors closest to output node

C
(a) pull-down network
SN1
SN4
SN2
SN3
D
F
F
A
D
B
C
D
F
A
B
C
(b) Deriving the pull-up network
hierarchically by identifying
sub-nets
D
A
A
B
C
V
V
B
(c) complete gate
DD
DD
12
Example Carry Gate
C C
AB 0 0
AB 0 1
AB 1 1
AB 0 1

• F (abbcac)
• Carry c is critical
• Factor c out
• F(abc(ab))
• 0-cover is n-pd
• 1-cover is p-pu

13
Example Carry Gate (2)

• Pull Down is easy
• Order by maximizing connections to ground and
  critical transistors
• For pull up Might guess series dual would
  guess wrong

14
Example Carry Gate (3)

• Series/Parallel Dual
• 3-series transistors
• 2 connections to Vdd
• 7 floating capacitors

15
Example Carry Gate (4)

• Pull Up from 1 cover of Kmap
• Get abacbc
• Factor c out
• 3 connections to Vdd
• 2 series transistors
• Co-Euler path layout
• Moral Use Kmap!

16
Cell Design

• Standard Cells
• General purpose logic
• Can be synthesized
• Same height, varying width
• Datapath Cells
• For regular, structured designs (arithmetic)
• Includes some wiring in the cell
• Fixed height and width

17
Standard Cell Layout Methodology 1980s
Routing channel
VDD
signals
GND
18
Standard Cell Layout Methodology 1990s
Mirrored Cell
No Routing channels
VDD
VDD
M2
M3
GND
GND
Mirrored Cell
19
Standard Cells
N Well
Cell height 12 metal tracks Metal track is
approx. 3? 3? Pitch repetitive distance
between objects Cell height is 12 pitch
Out
In
2?
Rails 10?
GND
Cell boundary
20
Standard Cells
With silicided diffusion
With minimaldiffusionrouting
Out
In
Out
In
GND
GND
21
Standard Cells
2-input NAND gate
A
B
Out
GND
22
Stick Diagrams
Contains no dimensions Represents relative
positions of transistors
Inverter
NAND2
Out
Out
In
A
B
GND
GND
23
Stick Diagrams
Logic Graph
A
C
j
B
X C (A B)
C
i
A
B
A
B
C
24
Two Versions of C (A B)
C
A
B
A
B
C
VDD
VDD
X
X
GND
GND
25
Consistent Euler Path
X
C
VDD
i
X
A
B
j
A
B
C
GND
26
OAI22 Logic Graph
X
PUN
A
C
C
D
B
D
VDD
X
X (AB)(CD)
C
D
A
B
A
B
PDN
A
GND
B
C
D
27
Example x abcd
28
Properties of Complementary CMOS Gates Snapshot
High noise margins

V
and
V
are at
V
and
GND
, respectively.
OH
OL
DD
No static power consumption

There never exists a direct path between
V
and
DD
V
(
GND
) in steady-state mode
.
SS
Comparable rise and fall times
(under appropriate sizing conditions)
29
CMOS Properties

• Full rail-to-rail swing high noise margins
• Logic levels not dependent upon the relative
  device sizes ratioless
• Always a path to Vdd or Gnd in steady state low
  output impedance
• Extremely high input resistance nearly zero
  steady-state input current
• No direct path steady state between power and
  ground no static power dissipation
• Propagation delay function of load capacitance
  and resistance of transistors

30
Switch Delay Model
Req
A
A
NOR2
INV
NAND2
31
Input Pattern Effects on Delay

• Delay is dependent on the pattern of inputs
• Low to high transition
• both inputs go low
• delay is 0.69 Rp/2 CL
• one input goes low
• delay is 0.69 Rp CL
• High to low transition
• both inputs go high
• delay is 0.69 2Rn CL

Rn
B
32
Delay Dependence on Input Patterns
Input Data Pattern Delay (psec)
AB0?1 67
A1, B0?1 64
A 0?1, B1 61
AB1?0 45
A1, B1?0 80
A 1?0, B1 81
AB1?0
A1 ?0, B1
A1, B1?0
Voltage V
time ps
NMOS 0.5?m/0.25 ?m PMOS 0.75?m/0.25 ?m CL
100 fF
33
Transistor Sizing

4 4
2 2
34
Multi-Fingered Transistors
One finger
Two fingers (folded)
Less diffusion capacitance
35
Transistor Sizing a Complex CMOS Gate
B
8
6
4
3
C
8
6
4
6
OUT D A (B C)
A
2
D
1
B
C
2
2
36
Fan-In Considerations
A
Distributed RC model
(Elmore delay) tpHL 0.69 Reqn(C12C23C34CL)
Propagation delay deteriorates rapidly as a
function of fan-in quadratically in the worst
case.
B
C
D
37
tp as a Function of Fan-In
Gates with a fan-in greater than 4 should be
avoided.
tp (psec)
tpLH
fan-in
38
tp as a Function of Fan-Out
All gates have the same drive current.
tpNOR2
tpNAND2
tpINV
tp (psec)
Slope is a function of driving strength
eff. fan-out
39
tp as a Function of Fan-In and Fan-Out

• Fan-in quadratic due to increasing resistance
  and capacitance
• Fan-out each additional fan-out gate adds two
  gate capacitances to CL
• tp a1FI a2FI2 a3FO

40
Practical Optimization

• The previous arguments regarding tp raise the
  question why build nor at all?
• Criticality is not a path but a transition so it
  is usually only on rising or falling (but not
  both)
• NOR forms have bad pull-up but good pull down
• NAND forms have bad pull-down but good pull up
• Determine the critical transition(s) and design
  for them using Elmore or Simulation on the
  appropriate edge only!
• Logical Effort presupposes uniform rise and fall
  times, so good in general, but can be beat
• Static Timing Analyzers nearly always get this
  wrong!

41
Fast Complex GatesDesign Technique 1

• Transistor sizing
• as long as fan-out capacitance dominates
• Progressive sizing

Distributed RC line M1 gt M2 gt M3 gt gt MN (the
fet closest to the output is the smallest)
InN
MN
In3
M3
In2
M2
Can reduce delay by more than 20 decreasing
gains as technology shrinks
In1
M1
42
Fast Complex GatesDesign Technique 2

• Transistor ordering

critical path
critical path
0?1
charged
charged
In1
1
In3
M3
M3
1
In2
1
In2
M2
discharged
M2
charged
1
In3
discharged
In1
M1
charged
M1
0?1
delay determined by time to discharge CL, C1 and
C2
delay determined by time to discharge CL
43
Fast Complex GatesDesign Technique 3

• Alternative logic structures

F ABCDEFGH
44
Fast Complex GatesDesign Technique 4

• Isolating fan-in from fan-out using buffer
  insertion

45
Fast Complex GatesDesign Technique 5

• Reducing the voltage swing
• linear reduction in delay
• also reduces power consumption
• But the following gate may be much slower!
• Large fan-in/fan-out requires use of sense
  amplifiers to restore the signal (memory)

tpHL 0.69 (3/4 (CL VDD)/ IDSATn )
0.69 (3/4 (CL Vswing)/ IDSATn )
46
Sizing Logic Paths for Speed

• Frequently, input capacitance of a logic path is
  constrained
• Logic also has to drive some capacitance
• Example ALU load in an Intels microprocessor is
  0.5pF
• How do we size the ALU datapath to achieve
  maximum speed?
• We have already solved this for the inverter
  chain can we generalize it for any type of
  logic?

47
Buffer Example
In
Out
CL
1
2
N
(in units of tinv)
For given N Ci1/Ci Ci/Ci-1 To find N Ci1/Ci
4 How to generalize this to any logic path?
48
Logical Effort
p intrinsic delay (3kRunitCunitg) - gate
parameter ? f(W) g logical effort (kRunitCunit)
gate parameter ? f(W) f effective
fanout Normalize everything to an inverter ginv
1, pinv 1 Divide everything by
tinv (everything is measured in unit delays
tinv) Assume g 1.
49
Delay in a Logic Gate
Gate delay
d h p
effort delay
intrinsic delay
Effort delay
h g f
logical effort
effective fanout Cout/Cin
Logical effort is a function of topology,
independent of sizing Effective fanout
(electrical effort) is a function of load/gate
size
50
Logical Effort

• Inverter has the smallest logical effort and
  intrinsic delay of all static CMOS gates
• Logical effort of a gate presents the ratio of
  its input capacitance to the inverter capacitance
  when sized to deliver the same current
• Logical effort increases with the gate complexity

51
Logical Effort
Logical effort is the ratio of input capacitance
of a gate to the input capacitance of an inverter
with the same output current
g 5/3
g 4/3
g 1
52
Logical Effort of Gates
t
pNAND
g p d
t
pINV
Normalized delay (d)
g p d

F(Fan-in)
1
2
3
4
5
6
7
Fan-out (h)
53
Logical Effort of Gates
t
pNAND
g 4/3 p 2 d (4/3)h2
t
pINV
Normalized delay (d)
g 1 p 1 d h1

F(Fan-in)
1
2
3
4
5
6
7
Fan-out (h)
54
Add Branching Effort
Branching effort
55
Multistage Networks
Stage effort hi gifi Path electrical effort F
Cout/Cin Path logical effort G
g1g2gN Branching effort B b1b2bN Path
effort H GFB Path delay D Sdi Spi Shi
56
Optimum Effort per Stage
When each stage bears the same effort
Stage efforts g1f1 g2f2 gNfN
Effective fanout of each stage
Minimum path delay
57
Optimal Number of Stages
For a given load, and given input capacitance of
the first gate Find optimal number of stages and
optimal sizing
Substitute best stage effort
58
Logical Effort
From Sutherland, Sproull
59
Method of Logical Effort

• Compute the path effort F GBH
• Find the best number of stages N log4F
• Compute the stage effort f F1/N
• Sketch the path with this number of stages
• Work either from either end, find sizes Cin
  Coutg/f
• Reference Sutherland, Sproull, Harris, Logical
  Effort, Morgan-Kaufmann 1999.

60
Example Optimize Path
g 1f a
g 1f 5/c
g 5/3f b/a
g 5/3f c/b
Effective fanout, F G H h a b
61
Example Optimize Path
g 1f a
g 1f 5/c
g 5/3f b/a
g 5/3f c/b
Effective fanout, F 5 G 25/9 H 125/9
13.9 h 1.93 a 1.93 b ha/g2 2.23 c hb/g3
5g4/f 2.59
62
Example Optimize Path
g4 1
g1 1
g2 5/3
g3 5/3
Effective fanout, H 5 G 25/9 F 125/9
13.9 f 1.93 a 1.93 b fa/g2 2.23 c fb/g3
5g4/f 2.59
63
Example 8-input AND
64
Summary
Sutherland, Sproull Harris
65
Homework 5

• Using the Carry cell design from earlier
  homework, optimally size the carry propagate
  chain for a 16-bit adder to minimize worst case
  delay where Cin is driven by a 1u/0.6u inverter
  and Cout drives a fanout of 4 such loads. (use
  logic effort, show your work!)
• For the problems below, use parameters from class
  for 0.5um and use 2x voltages as applicable. Chap
  5 problems 4, 7, 8, 15
• Chap 6, problems 2, 4, 5, 7
• Design the parity tree c a xor b xor c xor d
  in Complementary Pass Transistor Logic, insert
  inverters to restore the output swing Given
  input drive from an inverter stage, and an
  inverter every 2 stages of logic, and inverter
  output restore, estimate the propagation time for
  devices using the AMI 0.5um model.
• New (digital) AMI model (for minimum length
  only!)
• n-channel VT0.77, l0.03, Vsat1.56V,
  k32mA/V2
• p-channel VT-0.95, l0.03 Vsat2.8V, k-16mA/V2
