Title: JCL


1
JCL DAY 3
2
PROCEDURES
  • It is a prepacked JCL.
  • JCL needed by many different users
  • A JCL executed on a repetitive basis
  • JCL often repeated within the execution of a
    single job

3
TYPE OF PROCEDURES
  • In-stream procedures
  • Coded in the executing job
  • max of 15 per JOB
  • Catalogued Procedure
  • Member of a PDS (procedure library)
  • max 255 steps

4
Invoking a Procedure
  • // EXEC procname
  • // EXEC PROCprocname
  • eg
  • //name1 EXEC MYPROC
  • //name1 EXEC PROCMYPROC

5
JCLLIB
  • Specifies the names of the private libraries the
    system is to search for
  • Procedures named on any EXEC statement
  • JCL referenced by the INCLUDE statement (after
    release 4)
  • ex // INCLUDE MEMBERMYJCL
  • The JCLLIB statement must be placed before the
    first EXEC
  • statement in the job

// name JCLLIB ORDER(library,library....) /
/MYLIB JCLLIB ORDER(MYPROC.JCL.PROCLIB, // M
YPROC.JCL.PROCLIB1)
6
PROCEDURES must not contain
  • 1) JOB statement
  • X 2) EXEC statement invoking a procedure
  • 3) JOBLIB DD statement
  • 4) DD , DD DATA - In-stream data
  • 5) / delimiter statement
  • 6) // Null statement
  • 7) JES statements
  • 8) PEND statement (for cataloged procedures)

7
CATALOGED PROCEDURE
  • It must be a member of PDS
  • PEND statement is not permitted
  • It can have a maximum of 255 steps
  • The name of the library (PDS) should be specified
    if cataloged library is not in the system defined
    library (SYS1.PROCLIB) using JES JOBPARM
    statement or JCLLIB statement

8
In-stream procedure
  • It must begin with a PROC statement and end with
    a PEND statement
  • It should be coded before the first EXEC
    statement invoking the instream procedure

000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000210 //PROC1 PROC
000220
//STEP2 EXEC PGMIEFBR14
000300 //DD1 DD DSNTEMP,SPACE(TRK,
(1,1)), 000400 //
DCB(RECFMFB,BLKSIZE800,LRECL80),VOLSERINUSR3
, 000500 // DISP(NEW,KEEP),UNITSYSDA
000600 // PEND
000610
//STEP1 EXEC PROC1
000700 /

9
Cataloged procedure
  • It must begin with a PROC statement and must not
    contain a PEND statement
  • It must be cataloged in order to access it that
    is it must be a member of a PDS.
  • Cataloged procedure

000200 //MYPROC PROC
000210 //STEP2 EXEC
PGMIEFBR14
000220 //DD1 DD DSNTEMP,SPACE(TRK,(1,1)),
000230 //
DCB(RECFMFB,BLKSIZE800,LRECL80),VOLSERINUSR3
, 000240 // DISP(NEW,KEEP),UNITSYSDA
  • Cataloged procedure called through a JCL

000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000110 //LIB1 JCLLIB ORDER(INF6244.JCL.SOURC
E) 000260 //STEP1 EXEC MYPROC
10
Questions ??
If a JCL has two an instream procedure and a
cataloged procedure with the same name which one
will be executed ?
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLASS
A 000110 //LIB1 JCLLIB
ORDER(INF6244.JCL.SOURCE)
000120 //MYPROC PROC
000130 //STEP1 EXEC PGMIEFBR14
000140 //DD1
DD DSNINF6244.TEST.CAT,SPACE(TRK,(1,1)),
000150 // DCB(RECFMFB,BLKSIZE800,LRECL
80),VOLSERINUSR3, 000160 //
DISP(NEW,DELETE),UNITSYSDA
000170 // PEND
000180 //STEP1 EXEC MYPROC
000190 /


Answer Instream procedure will be executed
11
Questions ??
If a JCL has two an instream procedure and a
cataloged procedure with the same name which one
will be executed ?
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLASS
A 000110 //LIB1 JCLLIB
ORDER(INF6244.JCL.SOURCE)
000111 //STEP1 EXEC MYPROC
000120 //MYPROC PROC
000130
//STEP1 EXEC PGMIEFBR14
000140 //DD1 DD DSNINF6244.TEST.CAT,SP
ACE(TRK,(1,1)), 000150 //
DCB(RECFMFB,BLKSIZE800,LRECL80),VOLSERINUSR3
, 000160 // DISP(NEW,DELETE),UNITSYSDA
000170 // PEND
000190 /


Answer Cataloged procedure will be executed
12
Questions ??
Is the JCL given below correct? Yes/No , Justify
your answer ?
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000110 //LIB1 JCLLIB ORDER(INF6244.JCL.SOURC
E) 000111 //TEST PROC
000112 //STEP1 EXEC MYPROC
000113 // PEND
000114 //STEP1 EXEC TEST
000115 /

Restriction relieve Procedure can have a exec
statement calling another procedure
13
Nested Procedures
  • Cataloged and In-stream procedure can invoke
    other procedure ( up to 15 level)

  • An In-stream procedure cannot be defined within
  • another procedure

14
Nested Procedures (examples)
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000110 //LIB1 JCLLIB ORDER(INF6244.JCL.SOU
RCE) 000111 //FSTPROC PROC
000112 //STEP1 EXEC MYPROC
000113 // PEND
000114 //SNDPROC
PROC 000115
//STEP1 EXEC FSTPROC
000116 // PEND
000120 //STEP1 EXEC SNDPROC
000130 /

  • SNDPROC is called first which calls FSTPROC
    which initiates
  • cataloged procedure MYPROC

15
Nested Procedures (examples)
  • NSTPROC
  • 000200 //NSTPROC PROC
  • 000201 //STEP1 EXEC
    PGMIEFBR14

  • MYPROC
  • 000200 //MYPROC PROC
  • 000201 //STEP1 EXEC NESTPROC
  • 000210 //STEP2 EXEC
    PGMIEFBR14,COND(0,NE)
  • 000220 //DD1 DD
    DSNTEMP,SPACE(TRK,(1,1)),
  • 000230 //
    DCB(RECFMFB,BLKSIZE800,LRECL80),
  • 000231 //
    VOLSERINUSR3,
  • 000240 //
    DISP(NEW,KEEP),UNITSYSDA

  • CALLJCL
  • 000100 //INF62441 JOB
    (AMLAN),NOTIFYINF6244,CLASSA
  • 000110 //LIB1 JCLLIB
    ORDER(INF6244.JCL.SOURCE)
  • 000260 //STEP1 EXEC MYPROC

16
Identifying procedure statements injobs JCL
listing


Identifier Identifier
Meaning For In stream for
Catalogued Procedure procedure //
//
Statement from Input JCL
XX Statement from
procedure / X/
Procedure statement that you
modified XX
Procedure statements, other than
comment
statements that were
converted to comments
Comments and JES2/JES3
control statements


17
Modifying the Procedure
  • SYMBOLIC PARAMETERS
  • OVERRIDING EXEC DD PARAMETERS

18
Symbolic Parameters
  • Symbolic parameters are variables used in
    procedures
  • Syntax - Varname
  • Varname - 1-7 character

Value can be specified at 1) SET statement 2)
EXEC PROC statement 3) PROC statement
19
Symbolic Parameters examples ...
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLASS
A 000101 //SET1 SET
AINF6244.SYMB.TEST
000107 //STEP1 EXEC PGMIEFBR14
000109 //DD1 DD
DSNA,SPACE(TRK,(1,1)),
000110 // DCB(RECFMFB,BLKSIZE800,LRECL80
),VOLSERINUSR3, 000120 //
DISP(NEW,DELETE),UNITSYSDA

20
Symbolic Parameters examples ...
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000101 //MYPROC PROC
AINF6244.SYMB.TEST
000102 //STEP2 EXEC PGMIEFBR14
000103 //DD1 DD
DSNA,SPACE(TRK,(1,1)),
000104 // DCB(RECFMFB,BLKSIZE800,LRECL8
0),VOLSERINUSR3, 000105 //
DISP(NEW,DELETE),UNITSYSDA
000106 // PEND
000107 //STEP1 EXEC MYPROC

21
Question ??
  • What will happen if the same symbolic parameters
    having different
  • values are declared in the PROC, SET statement
    of the cataloged
  • procedure SET statement of the calling JCL ?
  • State the order of precedence ?

22
REFERING BACK AND MODIFYING (examples)
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLAS
SA 000102 //STEP1 EXEC
PGMIEFBR14
000103 //DD1 DD DSNINF6244.TEST.PS1,SPACE(TRK,(1
,1)), 000104 //
DCB(RECFMFB,BLKSIZE800,LRECL80),VOLSERINUSR3
, 000105 // DISP(NEW,DELETE),UNITSYSDA
000106 //DD2 DD
DSNINF6244.TEST.PS2,SPACE(TRK,(1,1)),
000107 // DCB.DD1,VOLSERINUSR3,
000108 //
DISP(NEW,DELETE),UNITSYSDA

23
REFERING BACK AND MODIFYING (examples)
000100 //INF62441 JOB (AMLAN),NOTIFYINF6244,CLASS
A 000101 //STEP1 EXEC PGMIEFBR14
000102 //DD1
DD DSNINF6244.TEST.PS1,SPACE(TRK,(1,1)),
000103 // DCB(RECFMFB,BLKSIZE800,LRE
CL80),VOLSERINUSR3, 000104 //
DISP(NEW,CATLG),UNITSYSDA
000105 //STEP2 EXEC PGMIEFBR14
000106 //DD1 DD
DSN.STEP1.DD1,SPACE(TRK,(1,1)),
000107 // DCB.STEP1.DD1,VOLSER
INUSR3, 000108

24
Questions ??
  • Can all the parameters of DD statement refer
    back. Discuss ?

25
IBM UTILITY PROGRAMS
  • MVS provides a number of pre-written utility
    programs that can be
  • used by analysts, system programmers, and
    application programmers
  • to assist them in maintaining and organizing
    data.
  • Provides a variety of useful function like
  • Copying a member/data set
  • Listing
  • Maintaining source libraries etc.

26
UTILITY PROGRAMS
  • SYSTEM UTILITY
  • IEHATLAS
  • IEHINITT
  • IEHMOVE
  • IEHPROGM
  • IFHSTATR
  • DATA SET UTILITY
  • IEBCOMPR
  • IEBCOPY
  • IEBDG
  • IEBEDIT
  • IEBGENER
  • IEBISAM

27
GENERAL FORMAT FOR IEBXXXX
  • //STEP EXEC PGMIEBxxxx
  • //SYSPRINT DD -message data set ,no DCB
  • //SYSIN DD -control information for utility
  • //SYSUT1 DD -input data set
  • //SYSUT2 DD -output dataset

28
IEBGENER utility
  • It is used to copy one sequential file to
    another.

000001 //INF6244B JOB CLASSA,NOTIFYINF6244
000002 //STEP1 EXEC PGMIEBGENER
000003 //SYSPRINT DD SYSOUT
000004 //SYSUT2 DD DSNINF6244.IEBGENE
R.NEWPS, 000005 // VOLSERINUSR2,SPACE(TR
K,(1,1)), 000006 // DCB(RECFMFB,LRECL
80,BLKSIZE800), 000007 //
DISP(NEW,CATLG)
000008 //SYSUT1 DD DSNINF6244.INPUT.JCLPS1,DISP
SHR 000009 //SYSIN DD DUMMY

29
IEBCOPY
  • To copy PDS on to DASD
  • To copy PDS on to Tapes by converting it to
    sequential dataset etc

000001 //INF6244A JOB NOTIFYINF6244
000002 //STEP1 EXEC PGMIEBCOPY
000003 //SYSPRINT DD SYSOUTA
000004 //SYSUT1 DD DSNINF6244.JCL.SOURC
E,DISPSHR 000005 //SYSUT2 DD
DSNINF6244.IEBCOPY.PDS, 000006 //
VOLSERINUSR2,SPACE(TRK,(5,5,8)), 000007
// DCB(RECFMFB,LRECL80,BLKSIZE800),
000008 // DISP(NEW,CATLG)
000009 //SYSIN DD
000010 COPY INDDSYSUT1,OUTDDSYSUT2
000011 /

30
IEHPROGM PROGRAM
  • SCRATCHES
  • RENAMES
  • CATALOGS
  • UNCATALOGS
  • UTILITY CONTROL STATEMENTS
  • SCRATCH DSNAMEdsname,VOLdeviceserial
  • UNCATLG DSNAMEdsname

31
IEHLIST PROGRAM
  • LIST CATALOG
  • LIST PDS
  • LIST VTOC
  • UTILITY CONTROL STATEMENT
  • LISTPDS DSNAMEdsname,
    x VOLdeviceserial,format
  • LISTVTOC DSNAMEdsname,
    x VOLdeviceserial,format

32
Thats all for DAY 3
