Title: Layout


1
Layout
  • How multiple components are composed to build
    interfaces

2
Placement of widgets
  • We need to be able to control the placement of
    widgets on the screen
  • Need to be able to handle movement and
    repositioning and keep these consistent
  • Keeping objects geometrically consistent is a
    fundamental problem.
  • When the objects are widgets it is called the
    layout problem.
  • When the objects are other things it is called
    constraints.

3
(No Transcript)
4
Layout
  • We need to programme interfaces to ensure all
    widgets move appropriately.
  • Three basic algorithms underpin layout
  • Fixed position
  • Edge anchored
  • Variable intrinsic size
  • For each approach we need to consider
  • what information must be stored with the widgets
    from which the layout can be computed
  • what is the algorithm for computing the layout,
  • how will the interface designer specify the
    layout either interactively or programmatically.

5
Fixed Position Layout
  • Simplest layout approach assign every widget a
    fixed rectangle
  • Coordinates relative to the parent
  • Good for fixed interface that you do not want to
    resize or whose components do not change.

6
(No Transcript)
7
  • Simple rectangle for each widget
  • Container widget sets the childs bounds location
    to its own plus the childs

public class Widget other fields and methods
public Rectangle desiredBounds public void
doLayout(Rectangle newBounds)
setBounds(newBounds) foreach child widget C
Rectangle newChildBounds new
Rectangle(newBounds.leftC.desiredBounds.left,
newBounds.TopC.desiredBounds.
top, C.desiredBounds.width,
C.desiredBounds.height) C.doLayout(newChildBo
unds)
8
Fixed Layout
  • Advantages
  • a simple algorithm
  • minimal data
  • very simple model to specify.
  • Designing Programmatically
  • construct a rectangle with the desired location
    and size
  • set desiredBounds
  • add the widget to its container.
  • Disadvantage
  • Resizing not handled at all well
  • To small parts of components clipped or not shown
    at all
  • To big all in the top corner

9
Edge anchored layout
  • Modifying widgets so that their edges can be
    anchored to the edges of their containers
    rectangle.
  • widget has coordinates for left, right, top and
    bottom.
  • interpretation depends upon the boolean values
    anchorLeft, anchorRight, anchorTop, anchorBottom.
  • widget has a desiredWidth and desiredHeight.
  • Edges are either anchored or not
  • If anchored then it is a fixed distance away from
    the corresponding container edge.
  • The algorithms for the X and Y axes are
    independent and identical.
  • If only one edge is anchored, then the desired
    width is used to determine the location of the
    other edge.
  • If neither edge is anchored, then the left value
    is used to compute a proportional distance
    between the container edges and the desired width
    is used for the other edge.
  • Both edges are anchored, they follow their
    respective edges.

10
Public class Widget . . . . other fields and
methods . . . public Rectangle bounds public
int left, right, top, bottom public boolean
anchorLeft, anchorRight, anchorTop, anchorBottom
public int width, height public const int
MAXSIZE4096 public void doLayout( Rectangle
newBounds) boundsnewBounds foreach
child widget C Rectangle childBoundsnew
Rectangle() if (C.anchorLeft)
childBounds.leftnewBounds.leftC.left if
(C.anchorRight) childBounds.rightnewBounds
.right-C.right else
childBounds.rightchildBounds.leftC.width
else if (C.anchorRight) // right is
anchored left is not childBounds.rightnewB
ounds.right-C.right childBounds.leftchildBo
unds.right-C.width else // neither
edge is anchored childBounds.left
newBounds.widthC.left/MAXSIZE
childBounds.rightchildBounds.leftC.width
. . . . perform similar computation for
Y . . . . C.doLayout(childBounds)

11
Key concepts
  • Container does the layout work on the widgets
    children
  • To lay out a widget, a programmer sets the
    various member fields and adds the widget to its
    container.
  • The container then will make certain that the
    widgets bounds are placed in the correct
    position.
  • Programming this interactively requires a special
    interface to highlight the edge relationships
    and specify how they are bound

12
(No Transcript)
13
Variable intrinsic size layout
  • On many occasions he designer does not want to
    manually position the widgets
  • Create group and have them position themselves
  • Menus
  • Changes in language/font for labels
  • Want to automatically adapt the layout to changes
    in interface content
  • Each widget knows how much screen space it can
    reasonably use (intrinsic size)
  • Each container has a plan for how to allocate
    screen space based on the needs of its children.
  • Recursively arranging containers with various
    layout plans
  • This is main approach used in Java

14
Layout algorithm
  • Based on two recursive passes
  • first pass requests each widget to report its
    desired size.
  • second pass sets the widget bounds

public void doLayout(Rectangle newBounds)
foreach child widget C ask for desired
size of C //based on desired sizes and
newBounds, decide where //each child should go
foreach child widget C C.doLayout( new
bounds for C)
15
  • Intrinsic size layouts ask a widget for
  • minimum size (the smallest dimensions that it
    can effectively use),
  • desired size (the dimensions that would work
    best for this widget)
  • maximum size (the largest dimensions that it can
    effectively use).
  • Determined by nature of each widget
  • Containers calculate this based on the size of
    its children

16
  • Widget class extended to handle sizes for layout
  • Each component implements in own way

public class Dimension public int width
public int height public class Widget
. . . other methods and fields . . . public
Dimension getMinSize() . . . public
Dimension getDesiredSize() . . . public
Dimension getMaxSize() . . .
17
Sizes of Simple Widgets
18
  • Desire sizes includes the margin
  • Minimum size looses the margin
  • Font details used to calculate size based on text
    in label

public class Button . . . other methods and
fields . . . public Dimension getMinSize()
int minWidth bevelWidth2font.getLength(labelT
ext) int minHeight bevelWidth2font.getHeig
ht() return new Dimension(minWidth,minHeight)
public Dimension getDesiredSize() int
desWidth bevelWidth2marginWidth2font.getLeng
th(labelText) int minHeightbevelWidth2margi
nHeight2font.getHeight() return new
Dimension(desWidth,desHeight) public
Dimension getMaxSize() return
getDesiredSize()
19
Simple container layouts
  • The simplest containers are the vertical and
    horizontal stack. Box widgets in Java

Horizontal Stack
A
B
C
D
Vertical Stack
20
public class HorizontalStack public
Dimension getMinSize() int minWidth0
int minHeight0 foreach child widget C
Dimension childSize C.getMinSize()
minWidth childSize.width if
(minHeightltchildSize.height)
minHeightchildSize.height return new
Dimension(minWidth,minHeight) public
Dimension getDesiredSize() similar to
getMinSize using C.getDesiredSize() public
Dimension getMaxSize() similar to getMinSize
using C.getMaxSize()
21
doLayout() for horizontal stack
  • when a new window is opened
  • request the desired size of the root widget and
    allocate that as the window size.
  • BUT, there may not be enough screen space for a
    window that big.
  • Space is allocated among the children depends
    upon
  • whether the width is less than min
  • greater than min but less than desired
  • greater than desired but less than max
  • greater than max.
  • The idea of the algorithm is to give each child
    as much as possible and then divide up the
    remainder proportionally among the children
    according to their requests.

22
public class HorizontalStack . . . the other
methods and fields . . . public void
doLayout(Rectangle newBounds) Dimension min
getMinSize() Dimension desired
getDesiredSize() Dimension max
getMaxSize() If (min.widthgtnewBounds.width)
// give all children their minimum and let
them be clipped int childLeftnewBounds.left
foreach child widget C Rectangle
childBounds new Rectangle() childBounds.to
pnewBounds.top childBounds.heightnewBounds
.height childBounds.leftchildLeft
childBounds.width C.getMinSize().width
childLeftchildBounds.width
C.doLayout(childBounds)
23
else if (desired.widthgtnewBounds.width) //
give min to all and proportional on what is
available for desired int desiredMargin
desired.width-min.width float fraction
(float)(newBounds.width-min.width)/desiredMargin
int childLeftnewBounds.left foreach child
widget C Rectangle childBoundsnew
Rectangle() childBounds.topnewBounds.top
childBounds.heightnewBounds.height
childBounds.leftchildLeft int
minWidthC.getMinSize().width int
desWidthC.getDesiredSize().width
childBounds.widthminWidth(desWidth-minWidth)
fraction childLeftchildBounds.width
C.doLayout(childBounds)
24
else // allocate what remains based on
maximum widths int maxMargin
max.width-desired.width float fraction
(float)(newBounds.width-desired.width)/maxMargin
int childLeftnewBounds.left foreach
child widget C . . . Similar code to
previous case . . .
25
Combining layouts
  • Use multiple horizontal and vertical stacks to
    produce layouts

26
Efficiency of layout
  • Problem 1 Recursion The window will call the
    root widget to ask for its desired size. The root
    widget will recursively call all of its children
    to compute that size.
  • When the root widget starts to do its layout it
    will call the Palette groups desired sizes
    again.
  • When the Palette group starts its own layout it
    will call the Colors groups desired sizes yet
    again
  • finally when the Colors group does its layout it
    will call desired sizes on the text box.
  • The desired size methods on the Colors text box
    was called at least 4 times.
  • Problem 2 Changes. The size of a window may be
    changed many times but the desires sizes of the
    various widgets do not change often.Most systems
    cache but what happens when things do change
  • an invalidate() method is provided that informs
    the parent widget that the desired sizes are no
    longer correct.
  • invalidate() method not only sets its own sizes
    to be invalid, but also sends the invalidate()
    message to its container.
  • Java/Swing does not propagate invalidate() up the
    tree causing interfaces not to change when they
    might be expected to.

27
public class HorizontalStack private
Dimension minSize private Dimension
desiredSize private Dimension maxSize
private boolean sizesAreValid public
Dimension getMinSize() if (sizesAreValid)
return minSize int minWidth0 int
minHeight0 foreach child widget C
Dimension childSize C.getMinSize()
minWidth childSize.width if
(minHeightltchildSize.height)
minHeightchildSize.height
sizesAreValidtrue return new
Dimension(minWidth,minHeight) public
Dimension getDesiredSize() similar to
getMinSize using C.getDesiredSize() public
Dimension getMaxSize() similar to getMinSize
using C.getMaxSize() public void
invalidate() sizesAreValidfalse if
(myContainer!null) myContainer.invalidate()

28
public class HorizontalStack private
Dimension minSize private Dimension
desiredSize private Dimension maxSize
private boolean sizesAreValid public
Dimension getMinSize() if (sizesAreValid)
return minSize int minWidth0 int
minHeight0 foreach child widget C
Dimension childSize C.getMinSize()
minWidth childSize.width if
(minHeightltchildSize.height)
minHeightchildSize.height
sizesAreValidtrue return new
Dimension(minWidth,minHeight) public
Dimension getDesiredSize() similar to
getMinSize using C.getDesiredSize() public
Dimension getMaxSize() similar to getMinSize
using C.getMaxSize() public void
invalidate() sizesAreValidfalse if
(myContainer!null) myContainer.invalidate()

29
Spatial arrangements
  • Simple Stacks not enough to provide layouts
  • Need some more control over spacing between
    components
  • We use spreaders and spacers to do this
  • In java this is the role of the Box.Filler class
  • Special widgets that are not drawn
  • Invisible
  • Have min, desired and max sizes
  • Spacer
  • min, desired and max sizes set to same value
    ensuring fixed space between widgets
  • Spreader
  • Small min and desired but large max making
    spacing widgets apart
  • Use of spreaders and spacer is effective but not
    that intuitive for new designers.

30
Layout Managers
  • Separate objects that handle a particular style
    of layout
  • Desired layout for containers is a property of
    the container

31
public interface LayoutManager public
Dimension getMinSize(Widget containerWidget)
public Dimension getDesiredSize(Widget
containerWidget) public Dimension
getMaxSize(Widget containerWidget) public void
doLayout(Rectangle newBounds, Widget
containerWidget) public class Widget .
. . other methods and fields . . . private
Dimension minSize private Dimension
desiredSize private Dimension maxSize
private boolean sizesAreValid private
LayoutManager myLayout public LayoutManager
getLayoutManager() return myLayout public
void setLayoutManager(LayoutManager newLayout )
myLayoutnewLayout invalidate()
public Dimension getMinSize() if
(sizesAreValid) return minSize
minSizemyLayout.getMinSize(this)
sizesAreValidtrue public Dimension
getDesiredSize() . . . similar to getMinSize()
. . . public Dimension getMaxSize() . . .
similar to getMinSize() . . . public void
doLayout(Rectangle newBounds)
myLayout.doLayout(newBounds,this)
32
Summary
  • Introduced the importance of layout and placement
  • Discussed a series of techniques for layout
  • Outlined the broad approach of layout managers.
  • Next Examples of the use of Swing Layouts in
    practice
  • Read through the swing tutorials.
Write a Comment
User Comments (0)
About PowerShow.com
