Laser Induced Nuclear Excitations,

1

• Laser Induced Nuclear Excitations,
• past, present and future of isomer research using
  Compton backscattering (LICB) facilities
• K Spohr
• Scottish University Physics Alliance (SUPA)
• University of the West of Scotland
• University of Strathclyde

2
Nuclear excitation research with lasers

• Pumping of isomeric state with laser generated
  bremsstrahlung
• Direct population with plasma
• Isomer production via nuclear reaction e.g. (?,n)
• Joint Laser/ELINAC systems
• Laser induced inverse Compton backscattering
  (LICB)
• Elevation of incident laser photon energy into
  keV regime
• Resonant pumping of isomeric states?
• Photon intensity higher than almost all
  synchrotron systems
• Photo nuclear reactions with LICB created
  quasi-monoenergetic ?-beams
• Recently discovered forms of nuclear excitations
• Coherent ensembles of excitations in nuclei
  (excitons)
• Quantum beats, Nuclear Lighthouse effect
• Enhancement of decay width, hence resonant
  absorption probability?
• Nuclear lasing?

3
Laser Driven Isomer research of SUPA group

• Unsuccessful attempt of resonant photon
  population of isomer with laser induced
  bremsstrahlung at the Astra (RAL)
• 181Ta, low-lying, long-lived, state (t1/2 6?s),
  E? 6.23keV (E1 9/2-?7/2)
• Spohr KM et al., J Mod Opt 53 (16), 2633 (2006)
• Before 2006 a series of unsuccessful attempts
  and doubtful claims
• Resume Dont use lasers to produce just
  ordinary bremsstrahlung
• Creation of nuclear isomers with lasers plasma
  triggered reaction
• Photo induced reaction 70Zn(?,n)69mZn,
• K Spohr et al., New J Phys 10, 043037 (2008), K
  Spohr et al. Physics Best of 2008, IoP
  Collection
• Experiment was dedicated to the study of laser
  induced photo-proton reactions

4
Setup of ASTRA Experiment (2005)

• Laser Plasma parameters
• YAG laser with ? 800nm
• I1017 Wcm-2 tpulse200fs
• kT 10 keV
• tplasma lt 10ps ltlt t1/2181Ta)

5
Detector response after shot
?
6
Laser induced production of nuclear isomers

• Aim to produce laser induced photo-proton
  reactions and measure ?int(?, p)
• Established by Stoyer et al., Rev Sci Inst 72,
  767 (2001)
• nuclear activation technique
• ?-rays allow determination of reaction channels
  and yield
• Table-top Laser systems as tool for nuclear
  research
• high intensity and hot bremstrahlung spectra
• Quasi-Maxwellian distribution T?Te, McCall, J
  Phys D15, 823 (1982)
• ?-radiation for achievable temperatures covers
  GDR
• kT 3 MeV
• Result Photo induced reaction 70Zn(?,n)69mZn

7
Experimental Set-up
Activation
Liesfeld et al., J Phys D 79,1047
(2004) Schwoerer et al., Phys Rev Lett 86, 2317
(2001)
8
IOQ Laser Facility (Jena) Target Chamber
9
Relativistic electrons from 10TW Laser-Gas
Interaction
Simulated e- density
Simulated e- momentum distribution for different
depths
PIC simulations, Pukov A and Meyer-ter-Veen, PRL
76 (21) 3975 (1996)
Energy of e- (measured)
Spatial confinement of e- (measured, E18 MeV)
2106
1106
250 mrad
0
from Guiletti A et al., PRL 101 105002 (2008)
10
Simulated ?-distribution after Ta-radiator and
Mo-probe (GEANT4)
11
kT measurement via Ta-activation
fitted kT2.73(22)MeV
12
Laser induced population of 69mZn

• only 8 min of laser activation
• total of 5000 pulses _at_ 10Hz
• I 3-5x1019 Wcm-2,

438.6 keV
13.76h
9/2
Conclusively proven that nuclear isomers can be
produced and measured using university-style
table-top Laser systems
56.40m
1/2-
69Zn
ß-
t1/2exp15.2(19)h
13
sint-value of 70Zn(?,n)69mZn
TRK sum-rule
aligned acc. to branching
No errors given in Literature values
64Zn (g, 2n)62Cu
70Zn (g, n)69mZn
67Zn (g, p)66Cu
Ivanchenko V et al., P.ZHETF 11, 452 (1966)
Carlos P et al., NP A258, 365 (1976)
Goryachev A et al., Yad.Fiz. 8, 121 (1982)
14

• LICB systems will become game-changers in nuclear
  excitation research
• SUPA Cobald/Alice team at Daresbury (Priebe,
  Seddon) SUPA beamline at the ELBE/150TW laser
  system _at_FZ-Rossendorf

15
Motivation Nuclear Physics with LICB

• LICB systems (high powered laser combined with an
  electron accelerator) will provide unique quality
  features for new research with ?-radiation
• Finest g-source available
• High photon intensities predicted1021photons/s/mm
  2/mrad2/0.1?E/E
• shortest steerable pulse duration 350 fs
• A game-changing tool for investigations of
  isomeric states
• Observations of coherent ensembles of ?
  excitations in nuclei? (excitons)
• Newly discovered quantum phenomena (quantum
  beats), coherent nuclear physics, Nuclear
  Lighthouse effect
• Enhancement of decay width, hence resonant
  absorption probability

NEW UNIQUE
16
The principle of Laser Induced Compton
Backscattering
Superconducting Elinac
energy recovery of e-beam
Cobald/ERLP _at_ Daresbury ELBE/150TW system has
similarities
17
Laser/e-beam collision geometry
For given ? , the energy E? is a defined function
of the scattering angle ? ? 1800 (head on) ?
900 (transverse)
Thompson Scattering

• normalised vector potential of the laser field
• electromagnetic energy gained across laser
  wavelength compared to electron rest-mass
• 0 (classical Compton scattering), gt 1 non-linear

from Schoenlein RW et al., Science 274, 236
(1996)
18
Cobald _at_ Daresbury
19
Studying selected isomers with LICB

• Laser inverse Compton Backscattering present an
  unique opportunity for studies into the laser
  induced pumping of nuclear states
• Ideal cases short lived Mößbauer isomers 161Dy,
  149Sm, 57Fe,181Ta,
• Questions feasibility, efficiency (yields), ..
  ,population inversion?

2gt
LICB
E1
1gt
Baldwin G and Solem J, Rev Mod Phys 69 (4), 1085
(1995)
161Dy
Einstein A, Phys Zeit 18, 121 (1917)
20
Spatial distribution of photon-energy
from Priebe G et al., Laser and Particle Beams 26
(4), 201 (2008)
21
Photon-energy vs scattered angle
57Fe (14.4keV,98ns)
? p
161Dy (25.7keV,29ns)
181Ta (6.2keV,6.0µs)
149Sm (22.5keV,7.3ns)
22
Photon brightness vs photon energy
Simulation
161Dy (25.7keV,29ns)
149Sm (22.5keV,7.3ns)
23
Spatial distribution of photons
very thin hollow cylinder target to absorb
monoenergetic photons
Backscattering angular distribution each colour
is a 1 keV energy band with 20-21 keV on outside
and 30-31 keV at centre
24
Selected ELINAC features of LICB systems

• Challenges
• XHV conditions plt10-13 bar ? quality of e-beam
  pulse
• Synchronisation of e-beam and laser pulse
• Focussing and shot-to-shot reproducibility

25
Selected Laser features of COBALD
26
LICB experiment on resonant photoabsorption of
Mößbauer nuclei

• Nuclear Lighthouse Effect (NLE)
• Röhlsberger R et al., Phys Rev Lett 87 (4),
  047601 (2001)
• Resonant scattering of 149Sm achieved with
  synchrotron radiation
• Photon flux 2 x 1010 photons/s
• Massively enhanced transition rate (exciton
  state)
• Target spins within ultra-fast rotating spindle
  35kHz
• mapping of time into spatial domain possible, as
  population of state is short compared to life
  time and target rotates ultra fast 0.1mrad/ns
• Beam-line 3m after interaction area
• APD diode used

27
Nuclear Lighthouse Effect
Rotors up to 70kHz air-driven MAS spindle
e.g.149Sm
fast rotor
Avalanche Photo Diode
28
Nuclear Lighthouse Effect using LICB

• Is a direct laser induced population of nuclear
  isomers achievable and can the NLE be observed
  using LICB?
• Not just a mere repeat of Röhlsbergers
  experiment on 149Sm
• Do we observe changes for higher flux values per
  pulse using LICB systems?
• Presumably an ensemble of coupled nucleons in the
  same state of excitation (excitons) could be
  created
• Ideal field to study collective coherent
  ?-phenomena
• Excited states migrate through the probe with
  slow speeds (polaritons)
• Influence of Nuclear Lighthouse effect using
  LICB?
• Pronounced quantum beating as different hyperfine
  components interfere?
• Decay rate is increases, hence the absorption
  line-width
• Even more so, if an ensemble of interacting
  polaritons is created
• Theory of excitons is related with general
  phenomena of open quantum systems (coupling to
  the continuum)
• Shell-Model in complex plane Michel N,
  Nazarewicz W, J Phys G36 (1), 013101 (2009)

29
Resonant photoabsorption of Mößbauer nuclei

• Proposal probing resonant excitation of 161Dy
  via LICB
• Measurements for cooled and un-cooled probe
• Corresponds to resonant and fully-non resonant
• Probe of thickness 2mm, ?res(25.6keV)
  10-8-10-7
• Exciton/Polariton creation can massively enhance
  resonant absorption, hence resonant yield
• Good, detectable yield for 3-5 days investigation
• 5 x 105 ?-rays in 5 days
• Efficiency for APD is high
• Low Energy Germanium Detectors have high
  efficiency at estimated rates ?total(25.6keV)0.8
  -0.9
• Good generic time resolution for low energy ? of
  ? ns
• ?Extraction of isomeric decay can be done with
  software gate
• ?Minimisation of prompt non-resonant background

30
Resonant photoabsorption of Mößbauer nuclei

• At first probing resonant absorption
• Resonant excitation of 161Dy (E?25.6keV, t1/2
  29ns)
• Promising high yield (dtarget2mm) 5 x 105
  ?-rays in 5 days
• Cooling required (TDebye 210K)

Complex Shvydko et al., Eur Phys Lett 56 (2),
305 (2001)
Simpler APD and/or LEPs
6m
cryo
LEP
LEP
APD
LICB
Al2O3
APDs
31
Resonant photoabsorption of Mößbauer nuclei

• Alternative target probes
• Much lower yields than 161Dy
• Photon flux, self-absorption and conversion
  coefficients
• 181Ta (E?6.2keV, t1/2 6.0µs), 57Fe
  (14.4keV,98ns)
• 181Ta
• ASTRA experiment (2005), with 1010 higher flux!

• No cooling required for 57Fe (TDebye 490K)

LEP
LEP
APD?
LICB
32
Resonant photoabsorption of Mößbauer nuclei

• High-power laser driven resonant population of
  nuclear isomers could be demonstrated
• Direct, ?-induced population of states
• Big step towards the control of nuclear states
  (switch on)
• LICB as tool for high precision measurements
  involving isomers?
• Evaluation of related cross-section
• Creation of ensembles of interacting coherent
  polariton states?
• Radiative width increases dramatically, hence the
  probability of resonant absorption,
  Npolaritons(10-1000)
• Avalanche like growth of linewidth?
• gt more and more photons of the wider ?-beam
  may join condensate
• New, theoretical challenging field of coherent
  phenomena
• Collective properties of polariton condensates
• Coherent gamma-ray spectroscopy

33
A final thought on controlled amplification
?
34
Final thoughts induced nuclear emission (lasing)

• Induced emission at resonance
• Purely radiative decay into stable g.s.
• Problem population inversion, many nuclei in
  g.s. level
• Never feasible for 1gt within bulk target,
  without delicate preparation
• Decay from unstable state 2gt into unstable state
  1gt
• Becomes feasible if higher energetic 2gt is more
  populated than 1gt
• achievable by appropriate reaction for T2 gt T1
• favourable pumping reaction to enhance
  population of 2gt
• favourable branching for population of the two
  states
• And decay times are somewhat similar, as for T2
  gtgt T1, ?s is small
• Resembles Four-level pumping scheme of optical
  lasers

35
Final thought induced nuclear emission (lasing)
Pumping nuclear reaction e.g. photonuclear type
High energetic levels
2gt
LICB g
1gt
g.s.
36
Final thought induced nuclear emission (lasing)

• Stedile generated population inversion via NRF in
  stable 103Rh
• 2gt 357 keV, (5/2-) t107 ps and 1gt 295
  keV, (3/2-) t9.8 ps
• Generating an inversion on a nuclear transition
  - Photopumping of 103Rh, Stedile F, Hyper
  Inter. 143 (1-4), 133 (2002)
• Idea Use bremsstrahlung radiation to create
  population inversion via NRF with high yields
  (high rep rate) and then impinge
  quasi-monochromatic matching ?-energy from LICB
  on target!
• For the moment yields by far to small (however
  one may not need so much, if a potential lasing
  effect would be strong!)
• 103Rh not ideal, E?62 keV too high , better
  isotopes need to be identified and measured,
• New Idea investigate the possible increase of
  radiative width due to production of polaritons
  with high photon-fluxes

37
Summary

• Laser driven studies on nuclear isomers are
  starting to deliver
• Efficient production of isomers via photonuclear
  reactions e.g. (?,n)
• Exploitation of laser produced electron
  bremsstrahlung is not that suited for an
  efficient direct pumping of isomers!
• Laser Induced Compton Backscattering systems
  promise to become the real game-changer
• trigger research into coherent nuclear phenomena
  with isomers
• LICB systems have the potential to add a new
  unique quality to nuclear research
• Cobald can become a leading facility for such
  investigations

38
Collaborators

• K. Spohr
• J.J. Melone
• R. Chapman
• A. Andreiev
• S. Pain
• M. Shaw
• R Samir
• M. Hassan
• KWD. Ledingham
• P. McKenna
• W. Galster (in memoriam)
• G. Priebe
• E. Seddon
• R. Sauerbrey
• U. Schramm
• ..

Thanks for your attention
