Lessons Learned Monitoring

• Les Cottrell, SLAC
• ESnet RD Advisory Workshop April 23, 2007
• Arlington, Virginia

Partially funded by DOE and by Internet2
2
Uses of Measurements

• Automated problem identification trouble
  shooting
• Alerts for network administrators, e.g.
• Baselines, bandwidth changes in time-series,
  iperf, SNMP
• Alerts for systems people
• OS/Host metrics
• Forecasts for Grid Middleware, e.g. replica
  manager, data placement
• Engineering, planning, SLA (set verify),
  expectations
• Also (not addressed here)
• Security spot anomalies, intrusion detection
• Accounting

3
History

• PingER (1994), IEPM-BW (2001)
• E2E, active, regular, end user view,
• all hosts owned by individual sites,
• core mainly centrally designed developed
  (homogenous), contributions from FNAL, GATech,
  NIIT (close collaboration)
• Why are you monitoring
• network trouble management, planning,
  auditing/setting SLAs, Grid forecasting are very
  different though may use same measurements

4
PingER (1994)

• PingER project originally (1995) for measuring
  network performance for US, Europe and Japanese
  HEP community - now mainly RE sites
• Extended this century to measure Digital Divide
• Collaboration with ICTP Science Dissemination
  Unit http//sdu.ictp.it
• ICFA/SCIC http//icfa-scic.web.cern.ch/ICFA-SCIC/


• gt120 countries (99 worlds connected population)
• gt35 monitor sites in 14 countries
• Uses ubiquitous ping facility

• Monitor 44 sites in S. Asia
• Most extensive active E2E monitoring in world

5
PingER Design Details

• PingER Design (1994 no web services, RRD,
  security not a big thing, etc.)
• Simple, no remote software (ping everywhere), no
  probe development, monitor host install 0.5 day
  effort for sys-admin
• Data centrally gathered, archived, analyzed, so
  hard jobs (archiving, analysis, viz) do NOT
  require distribution, only one copy
• Database flat ASCII files, rawdata, analyzed
  data, file/pair/day. Compressed saves factor 6
  (90GB)
• Data available via web (lot of use, some uses
  unexpected, often analysis by Excel)

6
PingER Lessons

• Measurement code rewritten twice, once to add
  extra data, once to document (perldoc) /
  parameterize / simplify installation
• Gathering code (uses LYNX or FTP) pull from
  archive, no major mods in 10 years
• Most of development for download, analyze data,
  viz, manage
• New ways to use data jitter, out of order,
  duplicates, derive throughput, MOS all required
  study of data then implement and integrate
• Dirty data (pathologies not related to network)
  require filtering or filling before analysis
• Had to develop easy make/install download,
  instructions, FAQ, still new installs require
  communication
• pre-reqs, getting name registration, getting cron
  jobs running, getting web server running,
  unblock, clarify documentation (often non-native
  English speakers)
• Documentation (tutorials, help, FAQs), publicity
  (brochures, papers, maps, presentations/travel),
  get funding/proposals
• Monitor availability of (developed tools to
  simplify/automate)
• monitor sites (hosts stop working security
  blocks, hosts replaced, site forgets), nudge
  contacts
• critical remote sites (beacons), choose new one
  (automatically updates monitor sites)
• Validate/update meta data (name, address,
  institute, lat/long, contact ) in database (need
  easy update)

7
IEPM-BW (2001)

• 40 target hosts in 13 countries
• Bottlenecks vary from 0.5Mbits/s to 1Gbits/s
• Traverse 50 AS, 15 major Internet providers
• 5 targets at PoPs, rest at end sites

• Added Sunnyvale for UltraLight
• Covers all USATLAS tier 0, 1, 2 sites
• Recently Added FZK, QAU
• Main author (Connie Logg) retired

8
IEPM Design Details

• IEPM-BW (2001)
• More focused (than PingER), fewer sites (e.g.
  BaBar collaborators), more intense, more probe
  tools (iperf, thrulay, pathload, traceroute,
  owamp, bbftp ), more flexibility
• Complete code set (measurement, archive, analyze,
  viz) at each monitoring site. Data distributed.
• Needs dedicated host
• Remote sites need code installed
• Originally executed remote via ssh, still needed
  code installed
• Security, accounts (require training), recovery
  problems
• Major changes with time
• Use servers rather than ssh for remote hosts
• Use mysql for configuration data bases rather
  than require perl scripts
• Provide management tools for configuration data
  etc.
• Add/replace probes

9
IEPM Lessons (1)

• Problems recommendations
• Need right versions of mysql, gnuplot, perl (and
  modules) installed on hosts
• All possible failure modes for probe tools need
  to be understood and accomodated
• Timeout everything, clean up hung processes
• Keep logfiles for day or so for debugging
• Review how processes run with Netflow (mainly
  manual)
• Scheduling
• dont run file transfer, iperf, thrulay, pathload
  at same time on same path
• Limit duration and frequency of intensive probes
  so do not impact network
• Host loses disk, upgrades OS, loses DNS,
  applications upgraded (e.g. gnuplot), IEPM
  database zapped etc.
• Need backup
• Have a local host as target for sanity check
  (e.g. monitoring host based issues)
• Monitor monitoring host load (e.g. Ganglia,
  Nagios)

10
IEPM Lessons (2)

• Different paths need different probes
  (performance and interest related)
• Experiences with probes (lot of work to
  understand, analyze compare)
• Owamp vs ping owamp needs server and accurate
  time ping only round trip available everywhere,
  may be blocked
• Traceroute need to analyze significance of
  results
• Packet pair separation
• Abwe noisy, inaccurate especially on Gbps paths
• Pathchirp better, pathload best (most intense
  approaches iperf), problems at 10Gbps, look at
  pathneck
• TCP
• thrulay more information, more manageable than
  iperf,
• need to keep TCP buffers optimized/updated
• File transfer
• Disk to disk close to iperf/thrulay
• disk measures file/disk system not network, but
  end user important
• Adding new hosts still not easy

11
Other Lessons

• Traceroute no good for layers 2 1
• Packet pair surpasses time granularity at 10Gbps
• Forecasting hard if path is congested, need to
  account for diurnal etc. variations
• Net admin cannot review thousands of graphs each
  day
• need event detection, alert notification, and
  diagnosis assistance
• Comparing QoS vs best effort requires adding path
  reservation
• Keeping TCP buffer parameters optimized difficult
• Network configurations not static
• Passive/Netflow valuable, complementary

12
PerfSONAR

• Our future focus (for us 3rd Generation)
• Open source, open community
• Both end users (LHC, GATech, SLAC, Delaware) and
  network providers (ESnet, I2, GEANT, Eu NRENs,
  Brazil, )
• Many developers from multiple fields
• Requires from the get go shared code,
  documentation, collaboration
• Hopefully not as dependent on funding as a single
  team, so persistent?
• Transparent gathering and storage of measurement,
  both from NRENs and end users
• Sharing of information across autonomous domains
• Uses standard formats
• More comprehensive view
• AAA to provide protection for of sensitive data
• Reduces debugging time
• Access to multiple components of the path
• No need to play telephone tag
• Currently mainly middleware, needs
• Data mining and viz
• Topology also at layers 1 2
• Forecasting
• Event detection and event diagnosis

13
Active E2E Monitoring
14
E.g. Using Active IEPM-BW measurements

• Focus on high performance for a few hosts needing
  to send data to a small number of collaborator
  sites, e.g. HEP tiered model
• Makes regular measurements with probe tools
• ping (RTT, connectivity), owamp (1 way delay)
  traceroute (routes)
• pathchirp, pathload (available bandwidth)
• iperf (one multi-stream), thrulay, (achievable
  throughput)
• supports bbftp, bbcp (file transfer applications,
  not network)
• Looking at GridFTP but complex requiring renewing
  certificates
• Choice of probes depends on importance of path,
  e.g.
• For major paths (tier 0, 1 some 2) use full
  suite
• For tier 3 use just ping and traceroute
• Running at major HEP sites CERN, SLAC, FNAL,
  BNL, Caltech, Taiwan, SNV to about 40 remote
  sites
• http//www.slac.stanford.edu/comp/net/iepm-bw.slac
  .stanford.edu/slac_wan_bw_tests.html

15
IEPM-BW Measurement Topology

• 40 target hosts in 13 countries
• Bottlenecks vary from 0.5Mbits/s to 1Gbits/s
• Traverse 50 AS, 15 major Internet providers
• 5 targets at PoPs, rest at end sites

Taiwan

• Added Sunnyvale for UltraLight
• Adding FZK Karlsruhe

TWaren
16
Top page
17
Probes Ping/traceroute

• Ping still useful
• Is path connected/node reachable?
• RTT, jitter, loss
• Great for low performance links (e.g. Digital
  Divide), e.g. AMP (NLANR)/PingER (SLAC)
• Nothing to install, but blocking
• OWAMP/I2 similar but One Way
• But needs server installed at other end and good
  timers
• Now built into IEPM-BW
• Traceroute
• Needs good visualization (traceanal/SLAC)
• No use for dedicated ? layer 1 or 2
• However still want to know topology of paths

18
Probes Packet Pair Dispersion

• Used by pathload, pathchirp, ABwE available bw
• Send packets with known separation
• See how separation changes due to bottleneck
• Can be low network intrusive, e.g. ABwE only 20
  packets/direction, also fast lt 1 sec
• From PAM paper, pathchirp more accurate than
  ABwE, but
• Ten times as long (10s vs 1s)
• More network traffic (factor of 10)
• Pathload factor of 10 again more
• http//www.pam2005.org/PDF/34310310.pdf
• IEPM-BW now supports ABwE, Pathchirp, Pathload

19
BUT

• Packet pair dispersion relies on accurate timing
  of inter packet separation
• At gt 1Gbps this is getting beyond resolution of
  Unix clocks
• AND 10GE NICs are offloading function
• Coalescing interrupts, Large Send Receive
  Offload, TOE
• Need to work with TOE vendors
• Turn off offload (Neterion supports multiple
  channels, can eliminate offload to get more
  accurate timing in host)
• Do timing in NICs
• No standards for interfaces
• Possibly use packet trains, e.g. pathneck

20
Achievable Throughput

• Use TCP or UDP to send as much data as can memory
  to memory from source to destination
• Tools iperf (bwctl/I2), netperf, thrulay (from
  Stas Shalunov/I2), udpmon
• Pseudo file copy Bbcp also has memory to memory
  mode to avoid disk/file problems

21
BUT

• At 10Gbits/s on transatlantic path Slow start
  takes over 6 seconds
• To get 90 of measurement in congestion avoidance
  need to measure for 1 minute (5.25 GBytes at
  7Gbits/s (todays typical performance)
• Needs scheduling to scale, even then
• Its not disk-to-disk or application-to
  application
• So use bbcp, bbftp, or GridFTP

22
AND

• For testbeds such as UltraLight, UltraScienceNet
  etc. have to reserve the path
• So the measurement infrastructure needs to add
  capability to reserve the path (so need API to
  reservation application)
• OSCARS from ESnet developing a web services
  interface (http//www.es.net/oscars/)
• For lightweight have a persistent capability
• For more intrusive, must reserve just before make
  measurement

23
Visualization Forecasting in Real World
24
Examples of real data
Caltech thrulay

• Misconfigured windows
• New path
• Very noisy

800
Mbps
0
Mar06
Nov05
UToronto miperf

• Seasonal effects
• Daily weekly

250
Mbps
0
Jan06
Nov05
Pathchirp
UTDallas

• Some are seasonal
• Others are not
• Events may affect
• multiple-metrics

120
thrulay
Mbps
0
iperf
Mar-10-06
Mar-20-06

• Events can be caused by host or site congestion
• Few route changes result in bandwidth changes
  (20)
• Many significant events are not associated with
  route changes (50)

25
Scattter plots histograms
Scatter plots quickly identify correlations
between metrics
Thrulay
Pathchirp
Iperf
Thrulay (Mbps)
RTT (ms)
Pathchirp iperf (Mbps)
Throughput (Mbits/s)
Pathchirp
Thrulay
Histograms quickly identify variability or
multimodality
26
Changes in network topology (BGP) can result in
dramatic changes in performance
Hour
Samples of traceroute trees generated from the
table
Los-Nettos (100Mbps)
Remote host
Snapshot of traceroute summary table
Notes 1. Caltech misrouted via Los-Nettos
100Mbps commercial net 1400-1700 2. ESnet/GEANT
working on routes from 200 to 1400 3. A
previous occurrence went un-noticed for 2
months 4. Next step is to auto detect and notify
Drop in performance (From original path
SLAC-CENIC-Caltech to SLAC-Esnet-LosNettos
(100Mbps) -Caltech )
Back to original path
Dynamic BW capacity (DBC)
Changes detected by IEPM-Iperf and AbWE
Mbits/s
Available BW (DBC-XT)
Cross-traffic (XT)
Esnet-LosNettos segment in the path (100 Mbits/s)
ABwE measurement one/minute for 24 hours Thurs
Oct 9 900am to Fri Oct 10 901am
27
On the other hand

• Route changes may affect the RTT (in yellow)
• Yet have no noticeable effect on on available
  bandwidth or throughput

Available Bandwidth
Achievable Throughput
Route changes
28
However

• Elegant graphics are great to understand problems
  BUT
• Can be thousands of graphs to look at (many site
  pairs, many devices, many metrics)
• Need automated problem recognition AND diagnosis
• So developing tools to reliably detect
  significant, persistent changes in performance
• Initially using simple plateau algorithm to
  detect step changes

29
Seasonal Effects on events

• Change in bandwidth (drops) between 1900 2200
  Pacific Time (700-1000am PK time)
• Causes more anomalous events around this time

30
Forecasting

• Over-provisioned paths should have pretty flat
  time series
• Short/local term smoothing
• Long term linear trends
• Seasonal smoothing

• But seasonal trends (diurnal, weekly need to be
  accounted for) on about 10 of our paths
• Use Holt-Winters triple exponential weighted
  moving averages

31
Experimental Alerting

• Have false positives down to reasonable level
  (few per week), so sending alerts to developers
• Saved in database
• Links to traceroutes, event analysis, time-series

32
Passive

• Active monitoring
• Pro regularly spaced data on known paths, can
  make on-demand
• Con adds data to network, can interfere with
  real data and measurements
• What about Passive?

33
Netflow et. al.

• Switch identifies flow by sce/dst ports, protocol
• Cuts record for each flow
• src, dst, ports, protocol, TOS, start, end time
• Collect records and analyze
• Can be a lot of data to collect each day, needs
  lot cpu
• Hundreds of MBytes to GBytes
• No intrusive traffic, real traffic,
  collaborators, applications
• No accounts/pwds/certs/keys
• No reservations etc
• Characterize traffic top talkers, applications,
  flow lengths etc.
• LHC-OPN requires edge routers to provide Netflow
  data
• Internet 2 backbone
• http//netflow.internet2.edu/weekly/
• SLAC
• www.slac.stanford.edu/comp/net/slac-netflow/html/S
  LAC-netflow.html

34
Typical days flows

• Very much work in progress
• Look at SLAC border
• Typical day
• 28K flows/day
• 75 sites with gt 100KB bulk-data flows
• Few hundred flows gt GByte

• Collect records for several weeks
• Filter 40 major collaborator sites, big (gt
  100KBytes) flows, bulk transport apps/ports
  (bbcp, bbftp, iperf, thrulay, scp, ftp )
• Divide by remote site, aggregate parallel streams
• Look at throughput distribution

35
Netflow et. al.

• Peaks at known capacities and RTTs
• RTTs might suggest windows not optimized, peaks
  at default OS window size(BWWindow/RTT)

36
How many sites have enough flows?

• In May 05 found 15 sites at SLAC border with gt
  1440 (1/30 mins) flows
• Maybe Enough for time series forecasting for
  seasonal effects
• Three sites (Caltech, BNL, CERN) were actively
  monitored
• Rest were free

• Only 10 sites have big seasonal effects in
  active measurement
• Remainder need fewer flows
• So promising

37
Mining data for sites

• Real application use (bbftp) for 4 months
• Gives rough idea of throughput (and confidence)
  for 14 sites seen from SLAC

38
Multi months
Bbcp throughput from SLAC to Padova

• Bbcp SLAC to Padova

• Fairly stable with time, large variance
• Many non network related factors

39
Netflow limitations

• Use of dynamic ports makes harder to detect app.
• GridFTP, bbcp, bbftp can use fixed ports (but may
  not)
• P2P often uses dynamic ports
• Discriminate type of flow based on headers (not
  relying on ports)
• Types bulk data, interactive
• Discriminators inter-arrival time, length of
  flow, packet length, volume of flow
• Use machine learning/neural nets to cluster flows
• E.g. http//www.pam2004.org/papers/166.pdf
• Aggregation of parallel flows (needs care, but
  not difficult)
• Can use for giving performance forecast
• Unclear if can use for detecting steps in
  performance

40
Conclusions

• Some tools fail at higher speeds
• Throughputs often depend on non-network factors
• Host interface speeds (DSL, 10Mbps Enet,
  wireless), loads, resource congestion
• Configurations (window sizes, hosts, number of
  parallel streams)
• Applications (disk/file vs mem-to-mem)
• Looking at distributions by site, often
  multi-modal
• Predictions may have large standard deviations
• Need automated assist to diagnose events

41
In Progress

• Working on Netflow viz (currently at BNL SLAC)
  then work with other LHC sites to deploy
• Add support for pathneck
• Look at other forecasters e.g. ARMA/ARIMA, maybe
  Kalman filters, neural nets
• Working on diagnosis of events
• Multi-metrics, multi-paths
• Signed collaborative agreement with Internet2 to
  collaborate with PerfSONAR
• Provide web services access to IEPM data
• Provide analysis forecasting and event detection
  to PerfSONAR data
• Use PerfSONAR (e.g. router) data for diagnosis
• Provide viz of PerfSONAR route information
• Apply to LHCnet
• Look at layer 1 2 information

42
Questions, More information

• Comparisons of Active Infrastructures
• www.slac.stanford.edu/grp/scs/net/proposals/infra-
  mon.html
• Some active public measurement infrastructures
• www-iepm.slac.stanford.edu/
• www-iepm.slac.stanford.edu/pinger/
• e2epi.internet2.edu/owamp/
• amp.nlanr.net/
• Monitoring tools
• www.slac.stanford.edu/xorg/nmtf/nmtf-tools.html
• www.caida.org/tools/
• Google for iperf, thrulay, bwctl, pathload,
  pathchirp
• Event detection
• www.slac.stanford.edu/grp/scs/net/papers/noms/noms
  14224-122705-d.doc

43
Outline

• Deployment, keeping in sync, management,
  timeouts, killing hung processes, host OS/env
  different
• Implementation
• MySQL dbs for data and configuration (host,
  tools, plotting etc.) info
• Scheduler, prevents backup
• Log files, analyze for troubles
• Local target as a sanity check on monitor
