HWR

1
IV Milky Way / Local Group Tomography
The stellar distribution in the Milky Way is not
smooth. What can it tell us bout its formation
history?

• Hans-Walter Rix
• MPI for Astronomy
• Heidelberg

2
Substructure Signposts of Hierarchical
Formation

• The motions of stars (or groups) still reflect
  their formation history after many dynamical
  periods.
• In collissionless systems, the phase-space
  density/distribution is preserved.
• Phase mixing may lead to a smooth appearance in r
  or v space.

3
(No Transcript)
4
2. Seeing Galaxies 2D, 6D or (the right) 3D
5
(No Transcript)
6
..but all is well in phase space(e.g. Helmi, de
Zeeuw 2000)
Also holds true if the overall potential changes
adiabatically (Penarrubbia et al 2005) Scattering
off sub-structure to be checked!
7
Questions

• Is there direct evidence for such sub-structure?
• In all galaxies? In the Milky Way?
• What is the mass spectrum of pieces?
• Is hierarchical accretion still going on?
• Can we use the streams to measure the
  gravitational potential?
• How tightly is chemical enrichment coupled to
  kinematics (i.e. to formation episode)?

8

• Is (sub-)structure of the phase-space
  distribution observable in galaxies with
  unresolved stellar populations?

9
Tomography of Unresolved Galaxies?NGC 4473
data-modelCappellari, de Zeeuw et al SAURON
2D-binned data
V s h3 h4
Symmetrized data
Axisymmetric model
Are the V-shaped velocity and high major-axis
dispersion produced by a counter rotating stellar
component?
10
Schwarzschild's approach
Observed galaxy image
images of model orbits

• Compute all orbits possible in a given galaxy
• The goal is to find the combination of orbits
  that actually appear in the galaxy ? dynamical
  model
• But images alone don't contain enough information

11
NGC 4473 orbital structureCappellari, de Zeeuw
in prep.
Counter-rotating stars
Main galaxy rotation
12
Are spiral galaxies smooth?Lets step back and
look at M31
13
Probing the Halo of M31 with SDSSZucker et al
2004
Advantage large volume-filling factor
easy Disadvatage 3D information limited
14
M 31 Status QuoLewis et al 2004
15
4. Substructure in the Milky Way Halo

• How to find it?
• Status quo
• How to interpret what has been found?

16
A clear case the Sagittarius stream
17
The density of turn-off colored stars in the
SDSS equatorial stripe
Galactic Plane
18
Hess diagrams as diagnostic tools
19
The Wilky Ways Low-Latitude Ring(Monoceros,
Tri/And, CMa, etc)
Kicked out (of the plane) or Dragged in
(disrupting satellite)?
20
THE FIRST SCENARIO TIDALLY DISRUPTING DWARF
GALAXY
21
THE SECOND SCENARIO THE MILKY WAY WARP
(Momany et al 2004)
22
Low-Latitude Stellar Overdensities in the MW

• Is it a tidal stream? -- external
• Can all pieces be fit as originating from one
  disrupted entity?
• Is there a parent?
• Is a warp (or more complex response to a
  perturbation)? internal
• Discriminants
• Kinematics disk/warp-like
• Spatial distribution
• Chemical composition diff. star-formation
  history

23
Modelling the Low-Latitude Ring(Penarrubbia,
Rix, et al. 2005)

• Question can all overdensities be attributed to
  one stream?
• Approach
• semi-analytic point orbit (incl. dynamical
  friction)
• full N-body realization

Best prograde semi-analytic orbit
24
The Wilky Ways Low-Latitude Ring(Monoceros,
Tri/And, CMa, etc)
25
Spatial Distribution wide z-range little R
range
? ? Not a warp
26
Results of the stream modeling

• The location of all known over-densities at low
  latitude (trailing tidal tails of a disrupted satellite
• Geometry excludes warp
• Satellite orbit prograde, very low ellipticity
  (0.1-0.05) at low inclination (20o-5o)
• Parent location not well determined
• metallicity gradient of debris suggest l250
• Orbit model suggests distance dsun12 kpc
• Parent satellite mass 2x108-109Msun

27
Does the stream have a parent galaxy?
Selecting stars with red giant colors and taking
apparent magnitude as a distance proxy
28
Geometry/Kinematic of Low-Latitude Overdensities

• Orbit near-circular
• Orbit prograde
• Several wraps needed to explain observations
• Extends -10 kpc out of the plane
• At nearly the same R!
• Parent satellite towards CMa plausible

29
(No Transcript)
30
Martinez-Delgado, Rix, et al 2004 (see also
Bellazzini et al 2004)
saturation
mV,0 24 (l,b)(240,-8)
31
Density of MS stars towards CMa as a function of
distance (app. magnitude)
Depth of CMa r1/20.85kpc _at_ RGC13kpc
32
What is the density profile of CMa?
galactic plane
Butler, Martinez-Delgado, Rix 05 (in prep.)
33

• Narrow MS (15 depth)
• High-contrast (3)
• Two distinct (age?) populations
• Distance 8kpc

34

• Buit lifes never easy!
• CMa may not be the point of maximal density

35
Proper Motions of Canis Majoris
WCMa-49-15 km/s
36
What would the Milky Ways response be to such a
disrupting satellite?
below
37
SDSSSEGUE Sky Coverage
38
NearTerm Future Astrometry

• PRIMA differential astrometry with VLTI
• 2008
• 10mas _at_ 17 mag across 30

39
6. GAIA 2012---
40
Summary

• Sub-structure exists (may even be pervasive)
• The observed parts were created recently (z
• We still have to learn how to best find it
• Quantitatively
• Objectively
• Milky Way seems to be surrounded by at least two
  large streams
• parent of the low-latitude stream is probably
  near Canis Majoris
• Impact of those streams on the Milky Way is
  considerable
• Milky Way subject to quite intense gravitational
  noise
• SEGUE (SDSS-II) and GAIA can revolutionize the
  field.
• The existing analysis tools for these data are
  still rudimentary
